NEC Direct View LED-Q078e
(7.8mm Q-Series Outdoor)
NEC Direct View LED – Intelligent display solutions for a brighter world
TThe S[quadrat] Q-Series by NEC provide crystal clear images for the ultimate visual
experience. With pixel spacing options of 2.8mm, 3.9mm & 4.8mm, the optimum display
resolution can be achieved regardless of viewing distance; plus, the front serviceable design
allows easy access and quick maintenance when needed. Designed for vibrant and colorful
content visualization, the S[quadrat] Q-series dvLED is the ideal solution for auditoriums,
reception areas, retail stores, control and meeting rooms, museums, broadcast studios and
airports or train stations. NEC offers full design & planning services plus post installation
service plans, ensuring you get a custom tailored solution allowing you to focus on what’s
most important – your business
BENEFITS
Easy front access for installation and maintenance
Application in corporate, transport, retail, cinema, entertainment, museum and arenas
Low power consumption and less heat dissipation make “Ocean Series” an environment-
friendly product
High efficient LED chip plus black mask for higher contrast ratio
Unique strong, light weight modules with quick lock devices to easily enable rental LED
system
All rights reserved in favor of their respective owners. All hardware and software names are brand names and/or registered trademarks of the respective manufacturers. All specifi cations are
subject to change without notice.
©2018 NEC Display Solutions of America, Inc. and the NEC logo are registered trademarks of NEC.
www.necdisplay.com
Cat.No. 25.NEC.80.GL.UN.305 | 8.15.2018
DISPLAY
Panel Technology Direct View LED
Pixel Con guration 3-1 SMD (Black)
Panel Resolution 65 x 64
Pixel Pitch 7.8mm
Brightness (maximum) 5000cd/m2
Display 80,000 hours
Contrast Ratio(typical) 6000:1
Viewing Angle 70/70 horizontal / 70/70 vertical
Dimming Capability 256 levels
Color Processing 16 bit
Displayable Colors 281 Trillion
Refresh Rate(Hz) 1920
Orientation Landscape
Connectivity
Input Terminals
Digital: DVI-D Dual Link in/out or HDMI
External Control: RS232 / USB
External Control USB
PowerConsumption(typical)
On 245Watts/sqm
Max 700Watts/Sqm
Physical Speci cations
Dimensions (W x H x D) [mm] 500 x 500 x 78mm
Weight [kg] 19.8lbs (9kg)
Environmental Conditions
Operating Temperature -4° to 122°f / -20° to 50°c
Environmental Conditions 10% to 90%
Storage Temperature -4° to 122°f / -20° to 50°c
Servicability
Rear Service
IP Level
IP65
Accessories
Controller
Mounting Frame
Ambient Light Sensor
Power Box with remote On/Off Control
Onsite Installation
NEC Direct View LED-Q078e (7.8mm Q Series Outdoor) - Technical Specifi cation
