Write the model and serial
numbers here:
Model # _________________
Serial # _________________
You can find them on a label
behind the door or drawer.
ESPAÑOL
Para consultar una version en
español de este manual de
instrucciones, visite nuestro sitio de
internet GEAppliances.com.
OWNER’S MANUAL
RANGES
Electric Free-Standing
49-2001000 Rev. 2 12-21 GEA
SAFETY INFORMATION .......... 3
USING THE RANGE
Surface Units ........................... 7
Cookware for Radiant Glass Cooktop. . . . . .10
Oven Controls ..........................11
Special Features ........................12
Oven Racks ............................13
Aluminum Foil and Oven Liners ...........13
Cookware ..............................13
Cooking Modes .........................14
Cooking Guide .........................15
Air Fry Cooking Guide ...................16
CARE AND CLEANING
Cleaning the Range – Exterior ............17
Cleaning the Range – Interior ............19
Cleaning the Glass Cooktop ..............21
Oven Light ............................ 23
Oven Door ............................24
Storage Drawer. . . . . . . . . . . . . . . . . . . . . . . . 24
TROUBLESHOOTING TIPS ....... 25
LIMITED WARRANTY ............ 27
ACCESSORIES .................... 28
CONSUMER SUPPORT ........... 32
JB655 - 30" Free-Standing Range
GE is a trademark of the General Electric Company. Manufactured under trademark license.
2 49-2001000 Rev. 2
THANK YOU FOR MAKING GE APPLIANCES A PART OF YOUR HOME.
Whether you grew up with GE Appliances, or this is your first, we’re happy to have you in the family.
We take pride in the craftsmanship, innovation and design that goes into every GE Appliances
product, and we think you will too. Among other things, registration of your appliance ensures that we
can deliver important product information and warranty details when you need them.
Register your GE appliance now online. Helpful websites and phone numbers are available in the
Consumer Support section of this Owner’s Manual. You may also mail in the pre-printed registration
card included in the packing material.
49-2001000 Rev. 2 3
READ AND SAVE THESE INSTRUCTIONS
IMPORTANT SAFETY INFORMATION
READ ALL INSTRUCTIONS BEFORE USING THE APPLIANCE
SAFETY INFORMATION
ANTI-TIP DEVICE
To reduce the risk of tipping the range,
the range must be secured by a properly
installed anti-tip bracket. See installation
instructions shipped with the bracket for
complete details before attempting to install.
For Free-Standing and Slide-In Ranges
To check if the bracket is installed and
engaged properly, look underneath the
range to see that the rear leveling leg is
engaged in the bracket. On some models, the storage drawer or kick panel
can be removed for easy inspection. If visual inspection is not possible,
slide the range forward, confirm the anti-tip bracket is securely attached to
the floor or wall, and slide the range back so the rear leveling leg is under
the anti-tip bracket.
If the range is pulled from the wall for any reason, always repeat this
procedure to verify the range is properly secured by the anti-tip bracket.
Never completely remove the leveling legs or the range will not be secured
to the anti-tip device properly.
WARNING
Read all safety instructions before using the product. Failure to follow these instructions may result
in fire, electrical shock, serious injury or death.
• A child or adult can tip the range and be killed.
• Install the anti-tip bracket to the wall or floor.
•
Engage the range to the anti-tip bracket by sliding th
e
range back such that the foot is engaged.
• Re-engage the anti-tip bracket if the range is moved.
• Failure to do so can result in death or serious burns
to children or adults.
Tip-Over Hazard
WARNING
Anti-Tip
Bracket
Leveling Leg
Free-Standing and Slide-In Ranges
WARNING
GENERAL SAFETY INSTRUCTIONS
Ŷ 8VHWKLVDSSOLDQFHRQO\IRULWVLQWHQGHGSXUSRVHDV
described in this Owner’s Manual.
Ŷ +DYH\RXUUDQJHLQVWDOOHGDQGSURSHUO\JURXQGHGE\
a qualified installer in accordance with the provided
installation instructions.
Ŷ $Q\DGMXVWPHQWDQGVHUYLFHVKRXOGEHSHUIRUPHG
only by a qualified installer or service technician.
Do not attempt to repair or replace any part of your
range unless it is specifically recommended in this
manual.
Ŷ %HIRUHSHUIRUPLQJDQ\VHUYLFHXQSOXJWKHUDQJH
or disconnect the power supply at the household
distribution panel by removing the fuse or switching
off the circuit breaker.
Ŷ 'RQRWOHDYHFKLOGUHQDORQH²FKLOGUHQVKRXOGQRW
be left alone or unattended in an area where an
appliance is in use. They should never be allowed
to climb, sit or stand on any part of the appliance.
Ŷ
CAUTION
Do not store items of interest to
children above a range or on the backguard of a
UDQJH²FKLOGUHQFOLPELQJRQWKHUDQJHWRUHDFK
items could be seriously injured.
Ŷ 8VHRQO\GU\SRWKROGHUV²PRLVWRUGDPSSRW
holders on hot surfaces may result in burns from
steam. Do not let pot holders touch hot surface
units or heating elements. Do not use a towel or
other bulky cloth in place of pot holders.
Ŷ 1HYHUXVH\RXUDSSOLDQFHIRUZDUPLQJRUKHDWLQJ
the room.
Ŷ %HVXUHDOOSDFNLQJPDWHULDOVDUHUHPRYHGIURPWKH
range before operating to prevent ignition of these
materials.
Ŷ 'RQRWXVHDQ\W\SHRIIRLORUOLQHUWRFRYHUWKH
oven bottom or anywhere in the oven, except as
described in this manual. Oven liners can trap heat
or melt, resulting in damage to the product and risk
of shock, smoke or fire.
Ŷ ,IDKHDWLQJHOHPHQWHLWKHURQDVXUIDFHXQLWRULQ
the oven, develops a glowing spot or shows other
signs of damage, do not use that area of the range.
A glowing spot indicates the surface unit may fail
and present a potential burn, fire, or shock hazard.
Turn the heating element off immediately and have
it replaced by a qualified service technician.
4 49-2001000 Rev. 2
WARNING
KEEP FLAMMABLE MATERIALS AWAY FROM THE RANGE
Failure to do so may result in fire or personal injury.
Ŷ 'RQRWVWRUHRUXVHIODPPDEOHPDWHULDOVLQDQRYHQ
or near the cooktop, including paper, plastic, pot
holders, linens, wall coverings, curtains, drapes and
gasoline or other flammable vapors and liquids.
Ŷ 1HYHUZHDUORRVHILWWLQJRUKDQJLQJJDUPHQWVZKLOH
using the appliance. These garments may ignite if
they contact hot surfaces causing severe burns.
Ŷ 'RQRWOHWFRRNLQJJUHDVHRURWKHUIODPPDEOH
materials accumulate in or near the range. Grease
in the oven or on the cooktop may ignite.
Ŷ &OHDQYHQWLODWLQJKRRGVIUHTXHQWO\*UHDVHVKRXOG
not be allowed to accumulate on the hood or filter.
SAFETY INFORMATION
READ AND SAVE THESE INSTRUCTIONS
WARNING
IN THE EVENT OF A FIRE, TAKE THE FOLLOWING
STEPS TO PREVENT INJURY AND FIRE SPREADING
Ŷ 'RQRWXVHZDWHURQJUHDVHILUHV1HYHUSLFNXS
a flaming pan. Turn the controls off. Smother a
flaming pan on a surface unit by covering the pan
completely with a well-fitting lid, cookie sheet or flat
WUD\8VHDPXOWLSXUSRVHGU\FKHPLFDORUIRDPW\SH
fire extinguisher.
Ŷ ,IWKHUHLVDILUHLQWKHRYHQGXULQJEDNLQJVPRWKHU
the fire by closing the oven door and turning the
oven off or by using a multi-purpose dry chemical or
foam-type fire extinguisher.
Ŷ ,IWKHUHLVDILUHLQWKHRYHQGXULQJVHOIFOHDQWXUQ
the oven off and wait for the fire to go out. Do not
force the door open. Introduction of fresh air at self-
clean temperatures may lead to a burst of flame
from the oven. Failure to follow this instruction may
result in severe burns.
IMPORTANT SAFETY INFORMATION
READ ALL INSTRUCTIONS BEFORE USING THE APPLIANCE
WARNING
GENERAL SAFETY INSTRUCTIONS (Cont.)
Ŷ 'RQRWWRXFKWKHVXUIDFHXQLWVWKHKHDWLQJHOHPHQWV
or the interior surface of the oven. These surfaces
may be hot enough to burn even though they are
dark in color. During and after use, do not touch,
or let clothing or other flammable materials contact
the surface units, areas nearby the surface units or
any interior area of the oven; allow sufficient time
for cooling first. Other surfaces of the appliance
may become hot enough to cause burns. Potentially
hot surfaces include the cooktop, areas facing the
cooktop, oven vent opening, surfaces near the
opening and crevices around the oven door.
Ŷ 'RQRWKHDWXQRSHQHGIRRGFRQWDLQHUV3UHVVXUH
could build up and the container could burst,
causing an injury.
Ŷ $YRLGVFUDWFKLQJRULPSDFWLQJJODVVGRRUVFRRN
tops or control panels. Doing so may lead to glass
breakage. Do not cook on a product with broken
glass. Shock, fire or cuts may occur. Contact a
qualified technician immediately.
Ŷ &RRNIRRGWKRURXJKO\WRKHOSSURWHFWDJDLQVW
foodborne illness. Minimum safe food temperature
recommendations can be found at IsItDoneYet.gov
and fsis.usda.gov8VHDIRRGWKHUPRPHWHUWRWDNH
food temperatures and check several locations.
Ŷ
Do not allow anyone to climb, stand, or hang on the
oven door, drawer, or cooktop. They could damage
the range or tip it over, causing severe injury or death.
WARNING
COOKTOP SAFETY INSTRUCTIONS
Ŷ Never leave the surface units unattended. Boilovers
cause smoking and greasy spillovers that may
ignite.
Ŷ 1HYHUOHDYHRLOXQDWWHQGHGZKLOHIU\LQJ,IDOORZHG
to heat beyond its smoking point, oil may ignite
resulting in fire that may spread to surrounding
FDELQHWV8VHDGHHSIDWWKHUPRPHWHUZKHQHYHU
possible to monitor oil temperature.
Ŷ 7RDYRLGRLOVSLOORYHUDQGILUHXVHDPLQLPXP
amount of oil when shallow pan-frying and avoid
cooking frozen foods with excessive amounts of ice.
Ŷ 8VHSURSHUSDQVL]H²VHOHFWFRRNZDUHKDYLQJ
flat bottoms large enough to cover the surface
heating element. The use of undersized cookware
will expose a portion of the surface unit to direct
contact and may result in ignition of clothing. Proper
relationship of cookware to surface unit will also
improve efficiency.
49-2001000 Rev. 2 5
SAFETY INFORMATION
READ AND SAVE THESE INSTRUCTIONS
IMPORTANT SAFETY INFORMATION
READ ALL INSTRUCTIONS BEFORE USING THE APPLIANCE
WARNING
OVEN SAFETY INSTRUCTIONS
Ŷ 6WDQGDZD\IURPWKHUDQJHZKHQRSHQLQJWKHRYHQ
door. Hot air or steam which escapes can cause
burns to hands, face and/or eyes.
Ŷ 'RQRWXVHWKHRYHQLIDKHDWLQJHOHPHQWGHYHORSV
a glowing spot during use or shows other signs
of damage. A glowing spot indicates the heating
element may fail and present a potential burn, fire,
or shock hazard. Turn the oven off immediately and
have the heating element replaced by a qualified
service technician.
Ŷ .HHSWKHRYHQYHQWXQREVWUXFWHG
Ŷ .HHSWKHRYHQIUHHIURPJUHDVHEXLOGXS*UHDVHLQ
the oven may ignite.
Ŷ 3ODFHRYHQUDFNVLQGHVLUHGORFDWLRQZKLOHRYHQLV
cool. If rack must be moved while oven is hot, do not
let pot holder contact hot heating element in oven.
Ŷ :KHQXVLQJFRRNLQJRUURDVWLQJEDJVLQWKHRYHQ
follow the manufacturer’s directions.
Ŷ 3XOOWKHRYHQUDFNWRWKHVWRSORFNSRVLWLRQZKHQ
loading and unloading food from the oven. This
helps prevent burns from touching hot surfaces of
the door and oven walls.
Ŷ 'RQRWOHDYHLWHPVVXFKDVSDSHUFRRNLQJXWHQVLOV
or food in the oven when not in use. Items stored in
an oven can ignite.
Ŷ 1HYHUSODFHFRRNLQJXWHQVLOVSL]]DRUEDNLQJVWRQHV
or any type of foil or liner on the oven floor. These
items can trap heat or melt, resulting in damage to
the product and risk of shock, smoke or fire.
WARNING
COOKTOP SAFETY INSTRUCTIONS
Ŷ :KHQXVLQJJODVVFHUDPLFFRRNZDUHPDNHVXUHLW
is suitable for cooktop service; others may break
because of sudden change in temperature.
Ŷ 7RPLQLPL]HWKHSRVVLELOLW\RIEXUQVLJQLWLRQRI
flammable materials and spillage, the handle of a
container should be turned toward the center of the
range without extending over nearby surface units.
Ŷ :KHQSUHSDULQJIODPLQJIRRGVXQGHUDKRRGWXUQ
the fan on.
Ŷ ,ISRZHULVORVWWRDQHOHFWULFFRRNWRSZKLOHD
surface unit is ON, the surface unit will turn back on
as soon as power is restored.
Ŷ ,QWKHHYHQWRISRZHUORVVIDLOXUHWRWXUQDOOVXUIDFH
unit knobs to the OFF position may result in ignition
of items on or near the cooktop, leading to serious
injury or death.
Ŷ 'RQRWFRRNRQDEURNHQFRRNWRS,IJODVVFRRNWRS
should break, cleaning solutions and spillovers
may penetrate the broken cooktop and create a
risk of electric shock. Contact a qualified technician
immediately.
Ŷ $YRLGVFUDWFKLQJWKHJODVVFRRNWRS7KHFRRNWRS
can be scratched with items such as knives, sharp
instruments, rings or other jewelry, and rivets on
clothing.
Ŷ 'RQRWSODFHRUVWRUHLWHPVWKDWFDQPHOWRUFDWFK
fire on the glass cooktop, even when it is not being
used. If the cooktop is inadvertently turned on, they
may ignite. Heat from the cooktop or oven vent after
it is turned off may cause them to ignite also.
Ŷ 8VHFHUDPLFFRRNWRSFOHDQHUDQGQRQVFUDWFK
cleaning pad to clean the cooktop. Wait until the
cooktop cools and the indicator light goes out
before cleaning. A wet sponge or cloth on a hot
surface can cause steam burns. Some cleaners can
produce noxious fumes if applied to a hot surface.
NOTE: Sugar spills are an exception. They should
be scraped off while still hot using an oven mitt
and a scraper. See the Cleaning the glass cooktop
section for detailed instructions.
WARNING
RADIANT COOKTOP SAFETY INSTRUCTIONS
8VHFDUHZKHQWRXFKLQJWKHFRRNWRS7KHJODVVVXUIDFHRIWKHFRRNWRSZLOOUHWDLQKHDWDIWHUWKHFRQWUROVKDYH
been turned off. Clean cooktop With Caution – If a wet sponge or cloth is used to wipe spills on a hot cooking
area, be careful to avoid steam burn. Some cleaners can produce noxious fumes if applied to a hot surface.
6 49-2001000 Rev. 2
How to Remove Protective Shipping Film and Packaging Tape
Carefully grasp a corner of the protective shipping film
with your fingers and slowly peel it from the appliance
surface. Do not use any sharp items to remove the film.
Remove all of the film before using the appliance for the
first time.
To assure no damage is done to the finish of the
product, the safest way to remove the adhesive from
packaging tape on new appliances is an application of
a household liquid dishwashing detergent. Apply with a
soft cloth and allow to soak.
NOTE: The adhesive must be removed from all parts. It
cannot be removed if it is baked on.
Consider recycling options for your appliance packaging
material.
SAFETY INFORMATION
READ AND SAVE THESE INSTRUCTIONS
IMPORTANT SAFETY INFORMATION
READ ALL INSTRUCTIONS BEFORE USING THE APPLIANCE
WARNING
SELF-CLEANING OVEN SAFETY INSTRUCTIONS
The self-cleaning feature operates the oven at temperatures high enough to burn away food soils in the oven.
Follow these instructions for safe operation.
Ŷ 'RQRWWRXFKRYHQVXUIDFHVGXULQJVHOIFOHDQ
RSHUDWLRQ.HHSFKLOGUHQDZD\IURPWKHRYHQGXULQJ
self-cleaning. Failure to follow these instructions
may cause burns.
Ŷ %HIRUHRSHUDWLQJWKHVHOIFOHDQF\FOHUHPRYHSDQV
shiny metal oven racks and other utensils from the
oven. Only gray porcelain-coated oven racks may
be left in the oven. Do not use self-clean to clean
other parts, such as drip pans or bowls.
Ŷ %HIRUHRSHUDWLQJWKHVHOIFOHDQF\FOHZLSHJUHDVH
and food soils from the oven. Excessive amount
of grease may ignite leading to smoke damage to
your home.
Ŷ ,IWKHVHOIFOHDQLQJPRGHPDOIXQFWLRQVWXUQWKH
oven off and disconnect the power supply. Have it
serviced by a qualified technician.
Ŷ 'RQRWFOHDQWKHGRRUJDVNHW7KHGRRUJDVNHWLV
essential for a good seal. Care should be taken not
to rub, damage or move the gasket.
Ŷ 'RQRWXVHDSURWHFWLYHFRDWLQJWROLQHWKHRYHQDQG
do not use commercial oven cleaner unless certified
for use in a self-cleaning oven.
PROPER DISPOSAL OF YOUR APPLIANCE
Dispose of or recycle your appliance in accordance with Federal and Local Regulations. Contact your local
authorities for the environmentally safe disposal or recycling of your appliance.
49-2001000 Rev. 2 7
Throughout this manual, features and appearance may vary from your model.
How to Set
Push the knob in and turn in either direction to the
setting you want.
A surface ON indicator light will glow when any surface
unit is on
For glass cooktop surfaces:
A HOT COOKTOP indicator light will:
Ŷ FRPHRQZKHQWKHXQLWLVKRWWRWKHWRXFK
Ŷ VWD\RQHYHQDIWHUWKHXQLWLVWXUQHGRII
Ŷ VWD\RQXQWLOWKHXQLWLVFRROHGWR
approximately 150°F.
USING THE RANGE:6XUIDFH8QLWV
Surface Units
WARNING
FIRE HAZARD: Never leave the range unattended with the cooktop on medium or high settings.
.HHSIODPPDEOHLWHPVDZD\IURPWKHFRRNWRS7XUQRIIDOOFRQWUROVZKHQGRQHFRRNLQJ)DLOXUHWR
follow these instructions can result in fire, serious injury or death.
Dual Surface Units and Control Knobs (on some models)
The surface unit has 2 cooking sizes to select from so
you can match the size of the unit to the size of the
cookware you are using.
At both OFF and HI the control clicks
into position. You may hear slight
clicking sounds during cooking,
indicating the control is maintaining
your desired setting.
Be sure you turn the control knob to
OFF when you finish cooking.
Models with a Dual-Ring
surface element only
Melt setting (on some models)
will melt chocolate or butter.
8 49-2001000 Rev. 2
Surface Units (Cont.)
USING THE RANGE:6XUIDFH8QLWV
Using the Warming Zone
WARNING
FOOD POISON HAZARD: Bacteria may grow in food at
temperatures below 140°F.
Ŷ Always start with hot food. Do not use warm setting to
heat cold food.
Ŷ Do not use warm setting for more than 2 hours.
The WARMING ZONE, located in the back center of
the glass surface, will keep hot, cooked food at serving
temperature. Always start with hot food. Do not use to
heat cold food. Placing uncooked or cold food on the
WARMING ZONE could result in foodborne illness.
Turn the control knob to the ON position.
For best results, all foods on the WARMING ZONE
should be covered with a lid or aluminum foil. When
warming pastries or breads, the cover should be vented
to allow moisture to escape.
The initial temperature, type and amount of food, type of
pan, and the time held will affect the quality of the food.
Always use pot holders or oven mitts when removing
food from the WARMING ZONE, since cookware and
plates will be hot.
NOTE: The surface warmer will not glow red like the
cooking elements.
49-2001000 Rev. 2 9
Home Canning Tips
Be sure the canner is centered over the surface unit.
Make sure the canner is flat on the bottom.
To prevent burns from steam or heat, use caution when
canning.
8VHUHFLSHVDQGSURFHGXUHVIURPUHSXWDEOHVRXUFHV
These are available from manufacturers such as Ball
®
DQG.HUU
®
and the Department of Agriculture Extension
Service.
)ODWERWWRPHGFDQQHUVDUHUHFRPPHQGHG8VHRIZDWHU
bath canners with rippled bottoms may extend the time
required to bring the water to a boil.
Temperature Limiter on Radiant Glass Cooktops
Every radiant surface unit has a temperature limiter.
The temperature limiter protects the glass cooktop from
getting too hot.
The temperature limiter may cycle the surface units off
for a time if:
Ŷ WKHSDQERLOVGU\
Ŷ WKHSDQERWWRPLVQRWIODW
Ŷ WKHSDQLVRIIFHQWHU
Ŷ WKHUHLVQRSDQRQWKHXQLW
Radiant Glass Cooktop
The radiant cooktop features heating units beneath a
smooth glass surface.
NOTE: A slight odor is normal when a new cooktop is
used for the first time. It is caused by the heating of new
parts and insulating materials and will disappear in a
short time.
NOTE: On models with light-colored glass cooktops, it is
normal for the cooking zones to change color when hot
or cooling down. This is temporary and will disappear as
the glass cools to room temperature.
The surface unit will cycle on and off to maintain your
selected control setting.
It is safe to place hot cookware on the glass surface
even when the cooktop is cool.
Even after the surface units are turned off, the glass
cooktop retains enough heat to continue cooking. To
avoid overcooking, remove pans from the surface units
when the food is cooked. Avoid placing anything on the
surface unit until it has cooled completely.
Ŷ :DWHUVWDLQVPLQHUDOGHSRVLWVDUHUHPRYDEOHXVLQJ
the cleaning cream or full-strength white vinegar.
Ŷ 8VHRIZLQGRZFOHDQHUPD\OHDYHDQLULGHVFHQWILOPRQ
the cooktop. The cleaning cream will remove this film.
Ŷ 'RQ¶WVWRUHKHDY\LWHPVDERYHWKHFRRNWRS,IWKH\
drop onto the cooktop, they can cause damage.
Ŷ 'RQRWXVHWKHVXUIDFHDVDFXWWLQJERDUG
USING THE RANGE:6XUIDFH8QLWV
Surface Units (Cont.)
Never cook directly on the glass. Always
use cookware.
Always place the pan in the center of the
surface unit you are cooking on.
Do not slide cookware across the cooktop because
LWFDQVFUDWFKWKHJODVV²WKHJODVVLVVFUDWFK
resistant, not scratch proof.
10 49-2001000 Rev. 2
Cookware for Radiant Glass Cooktop
USING THE RANGE: Cookware for Radiant Glass Cooktop
The following information will help you choose cookware which will give good performance on glass cooktops.
NOTE: Follow all cookware manufacturer’s recommendations when using any type of cookware on the ceramic cooktop.
Recommended
Stainless Steel
Aluminum:
heavy weight recommended
Good conductivity. Aluminum residues
sometimes appear as scratches on the
cooktop but can be removed if cleaned
immediately. Because of its low melting
point, thin weight aluminum should not
be used.
Copper Bottom:
Copper may leave residues which can
appear as scratches. The residues can
be removed, as long as the cooktop
is cleaned immediately. However, do
not let these pots boil dry. Overheated
metal can bond to glass cooktops. An
overheated copper bottom pot will leave
a residue that will permanently stain the
cooktop if not removed immediately.
Enamel (painted) on Cast Iron:
recommended if bottom of pan is coated
Avoid/Not Recommended
Enamel (painted) on Steel:
Heating empty pans can cause
permanent damage to cooktop glass.
The enamel can melt and bond to the
ceramic cooktop.
Glass-ceramic:
Poor performance. Will scratch the
surface.
Stoneware:
Poor performance. May scratch the
surface.
Cast Iron:
QRWUHFRPPHQGHG²XQOHVVGHVLJQHG
specifically for glass cooktops
Poor conductivity and slow to absorb
heat. Will scratch the cooktop surface.
Check pans for flat bottoms by
using a straight edge.
Pans with rounded, curved,
ridged or warped bottoms are
not recommended.
For Best Results
Ŷ 3ODFHRQO\GU\SDQVRQWKHVXUIDFHHOHPHQWV'RQRW
place lids on the surface elements, particularly wet lids.
Wet pans and lids may stick to the surface when cool.
Ŷ 'RQRWXVHZRNVWKDWKDYHVXSSRUWULQJV7KLVW\SHRI
wok will not heat on glass surface elements.
Ŷ :HUHFRPPHQGWKDW\RXXVHRQO\DIODWERWWRPHG
wok. They are available at your local retail store. The
bottom of the wok should have the same diameter as
the surface element to ensure proper contact.
Ŷ 6RPHVSHFLDOFRRNLQJSURFHGXUHVUHTXLUHVSHFLILF
cookware such as pressure cookers or deep-fat
fryers. All cookware must have flat bottoms and be
the correct size.
Do not place wet pans on the glass cooktop.
Do not use woks with support rings on the glass cooktop.
8VHIODWERWWRPHGZRNVRQWKHJODVVFRRNWRS
49-2001000 Rev. 2 11
USING THE RANGE: Oven Controls
Oven Controls
Oven Light
12
23845
1
9
13
11
6
14
7
10
1. Convection Cooking: Convection cooking
modes use increased air circulation to improve
performance. See the Cooking Modes section for more
information.
2. Traditional Cooking Modes: Your oven has
the following traditional cooking modes: Bake and
Broil Hi/Lo. See the Cooking Modes section for more
information.
3. Self Clean: See the Cleaning the Oven section for
important information about using these modes.
4. Start: Must be pressed to start any cooking,
cleaning, or timed function.
5. Cancel/Off: Cancels ALL oven operations except
the clock and timer.
6. + Pad: Short taps to this pad will increase the time
or temperature by small amounts. Touch and hold
the pad to increase the time or temperature by larger
amounts.
7. - Pad: Short taps to this pad will decrease the time
or temperature by small amounts. Touch and hold
the pad to decrease the time or temperature by larger
amounts.
8. Cook Time: Counts down cooking time and turns
off the oven when the cooking time is complete. Press
the Cook Time pad, use the +/- pads to program a
cooking time in hours and minutes, then press Start.
This can only be used with Bake and Convection Bake
(where available).
9. Set Clock: Press +/- keys at the same time once to
turn off the clock display, twice to set time using the +/-
keys individually, and a third time to accept the change
or allow time to be displayed.
10. Timer: Works as a countdown timer. Press the
Timer pad and the +/- pads to program the time in
hours and minutes. Press the Start pad. The timer
countdown is complete. To turn the timer off press the
Timer pad.
11. Delay Time: Delays when the oven will turn on.
8VHWKLVWRVHWDWLPHZKHQ\RXZDQWWKHRYHQWRVWDUW
Press the Delay Time pad and use the +/- pads to
program the time of day for the oven to turn on then
press Start. Press the desired cooking mode and
temperature then press Start. A Cook Time may also
be programmed if desired. Follow the directions under
Cook Time for setting this feature. This can only be
used with Bake, Convection Bake and Self-Clean.
NOTE: When using the Delay Time feature, foods that
VSRLOHDVLO\²VXFKDVPLONHJJVILVKVWXIILQJVSRXOWU\
DQGSRUN²VKRXOGQRWEHDOORZHGWRVLWIRUPRUHWKDQ
1 hour before or after cooking. Room temperature
promotes the growth of harmful bacteria. Be sure that
the oven light is off because heat from the bulb will
speed harmful bacteria growth.
12. Oven Light: Turns the oven light on or off.
13. Lock Controls: Locks out the control so that
pressing the pads does not activate the controls. Press
and hold the +/- pads or the Lock Controls pad, for
three seconds to lock or unlock the control. Cancel/Off
is always active, even when the control is locked.
14. Air Fry: Air Fry is a special, no-preheat, cooking
mode that is designed to produce foods with a crispier
exterior than traditional oven cooking. The Air Fry
mode is intended for single rack cooking only
12 49-2001000 Rev. 2
Special Features
USING THE RANGE: Special Features
There are several different special features on your range. To change the settings of these special features:
Ŷ 3UHVVWKHBake and Broil pads at the same time and hold for three seconds.
Ŷ ³6)´ZLOODSSHDULQWKHGLVSOD\
Ŷ 6HOHFWWKHIHDWXUH\RXZDQWWRFKDQJH
Ŷ :KHQWKHFKDQJHKDVEHHQPDGHSUHVVWKHStart key to save the change and return to the time of day.
Adjust the Oven Temperature
This feature allows the oven baking and convection
baking temperature to be adjusted up to 35ºF hotter
RUGRZQWR)FRROHU8VHWKLVIHDWXUHLI\RXEHOLHYH
your oven temperature is too hot or too cold and wish to
change it. This adjustment affects Bake and Convection
Bake modes. No other cooking modes are affected.
Press the Bake pad to enter the temperature adjustment
PRGH$QXPEHUEHWZHHQDQGZLOOGLVSOD\8VH
the +/- pads to set the desired temperature adjustment
and use the Bake pad to change between negative and
positive. Press the Start pad to save the temperature
adjustment.
Clock Display
This feature can turn off the time of day display. Press
the Timer On/Off pad to display the time of day (on) or
turn off the time of day display (oFF).
NOTE: For models with a Set Clock pad, the time of
day display cannot be turned off in special features. Exit
special features. To turn the time of day display off on
these models, press the Set Clock pad once and then
the Start pad. To have the display turned back on, press
the Set Clock pad again and then the Start pad.
12-hour auto shut-off and Sabbath
2SWLRQVIRUWKLVIHDWXUHDUH³6$E´KRXUDXWRVKXWRII
³2Q´DQG³2II´
12-hour auto shut-off turns off the oven after 12 hours of
continuous operations.
Sabbath mode disables all sounds (the control will not
beep when a button is pressed), Convection, Broil, Cook
Time, Timer, Clock, and Delay Time functions. Sabbath
mode can only be used with Bake.
NOTE: The oven light comes on automatically (on some
models) when the door is opened and goes off when the
door is closed. The bulb may be removed. See the Oven
Light Replacement section. On models with a light switch
on the control panel, the oven light may be turned on
and left on.
Press the Set Clock pad to view the current setting and
then to change the setting.
For models that use the +/- keys to set the clock, press
the Cook Time pad to view the current setting and then
to change the setting.
7RXVH6DEEDWKPRGHVHOHFW³6$E´DQGSUHVVStart. A ]
will appear in the display and the clock will not display.
Once in Sabbath mode, at any time you can press Bake
to start the oven. Note that when programming a bake
in Sabbath mode, the preset starting temperature will
automatically be set to 350°F. Press the + or - pads to
increase or decrease the temperature in 25°F increments
for temperatures between 170°F and 550°F and then
press Start.
No sound will be given when the keys are pressed. At a
random time between 30 seconds and 1 minute, ][, will
appear in the display indicating the oven is running.
If you need to adjust the temperature while baking,
press Bake again. Press the + or - pads to increase
or decrease the temperature in 25°F from the previous
temperature you set to the new baking temperature and
then press Start.
To exit Sabbath mode, make sure that the cooking mode
is turned off. To turn it off, press Cancel/Off. The oven
will immediately turn off. At a random time between
30 seconds and 1 minute, ][ will change to ] indicating
that the cooking mode has turned off. Press and hold
the Bake and Broil pads for 3 seconds to enter special
features, then press Delay Time or Cook Time until
HLWKHUKRXU³2Q´RU³2II´LVLQWKHGLVSOD\DQGSUHVV
Start.
NOTE: If power outage occurs, the Sabbath mode will
not resume when power is restored.
49-2001000 Rev. 2 13
Recommended rack positions for various types of
foods are provided in the Cooking Guide. Adjusting
rack position is one way to impact cooking results. For
example, if you would prefer darker tops on cakes,
muffins, or cookies, try moving food one rack position
higher. If you find foods are too brown on top try moving
them down next time.
When baking with multiple pans and on multiple racks,
ensure there is at least 1½" between pans to allow
sufficient space for air to flow.
To avoid possible burns, place the racks in the desired
position before you turn the oven on.
USING THE RANGE: Oven Racks / Aluminum Foil and Oven Liners / Cookware
Oven Racks
Cookware
Cookware Guidelines
The material, finish, and size of cookware affect baking
performance.
Dark, coated and dull pans absorb heat more readily
than light, shiny pans. Pans that absorb heat more
readily can result in a browner, crisper, and thicker crust.
If using dark and coated cookware check food earlier
than minimum cook time. If undesirable results are
obtained with this type of cookware consider reducing
oven temperature by 25º F next time.
Shiny pans can produce more evenly cooked baked
goods such as cakes and cookies.
Glass and ceramic pans heat slowly but retain heat well.
These types of pans work well for dishes such as pies
and custards.
Air insulated pans heat slowly and can reduce bottom
browning.
.HHSFRRNZDUHFOHDQWRSURPRWHHYHQKHDWLQJ
CAUTION
Do not use any type of foil or oven liner to cover the oven bottom. These items can trap heat
or melt, resulting in damage to the product and risk of shock, smoke or fire. Damage from improper use of
these items is not covered by the product warranty.
Foil may be used to catch spills by placing a sheet on a lower rack, several inches below the food. Do not use more
IRLOWKDQQHFHVVDU\DQGQHYHUHQWLUHO\FRYHUDQRYHQUDFNZLWKDOXPLQXPIRLO.HHSIRLODWOHDVW´IURPRYHQZDOOV
to prevent poor heat circulation.
Aluminum Foil and Oven Liners
The number of rack positions may vary by model.
14 49-2001000 Rev. 2
Your new oven has a variety of cooking modes to help you get the best results. These modes are described below.
Refer to the Cooking Guide section for recommendations for specific foods. Remember, your new oven may perform
differently than the oven it is replacing.
Baking Modes
Select a mode for baking based on the type and quantity
of food you are preparing. When preparing baked goods
such as cakes, cookies, and pastries always preheat
the oven first. Follow recipe recommendations for food
placement. If no guidelines are provided, center food in
the oven.
Bake
The bake mode is intended for single rack cooking. This
mode uses heat primarily from the lower element but
also from the upper element to cook food. To use this
mode press the Bake pad, use the +/- pads to set the
desired temperature, and then press Start. Preheating is
generally recommended when using this mode.
Convection Bake
The Convection Bake mode is intended for baking on
multiple racks at the same time. This mode uses heat
from the upper and lower elements, along with air
movement from the convection fan to enhance cooking
evenness. Baking time might be slightly longer for
multiple racks than what would be expected for a single
rack. To use this mode press the Convection Bake
pad, enter a temperature, and then press Start. Always
preheat when using this mode. When baking more
delicate foods like cookies and cakes, it is recommended
to reduce the input temperature by 25°F for improved
cooking performance.
Broiling Modes
0RQLWRUIRRGFORVHO\ZKLOHEURLOLQJ8VHFDXWLRQZKHQ
broiling on upper rack positions as placing food closer to
the broil element increases smoking, spattering, and the
possibility of fats igniting. For best performance center
food below the broil heating element.
Try broiling foods that you would normally grill. Adjust
rack positions to adjust the intensity of the heat to the
food. Place foods closer to the broil element when a
seared surface and rare interior is desired. Thicker foods
and foods that need to be cooked through should be
broiled on a rack position farther from the broiler or by
using Broil Lo.
Broil Hi
The Broil Hi mode uses intense heat from the upper
element to sear foods. It is recommended that Broil Hi be
GRQHZLWKWKHGRRURSHQIRULPSURYHGVHDULQJ8VH%URLO
Hi for thinner cuts of meat and/ or foods you prefer less
done on the interior. To use this mode press the Broil
pad once and then press Start. It is not necessary to
preheat when using this mode.
Broil Lo
The Broil Lo mode uses less intense heat from the upper
element to cook food thoroughly while also producing
surface browning. The door may be closed or open when
XVLQJ%URLO/R8VH%URLO/RIRUWKLFNHUFXWVRIPHDWDQG
or foods that you would like cooked all the way through.
To use this mode press the Broil pad twice and then
press Start. It is not necessary to preheat when using
this mode.
Pre-Heat
Proper preheating ensures that the oven is hot enough
to begin baking. Improper preheating (that is, cooking
in the oven that has not come up to set temperature)
can negatively affect cooking. Depending on the recipe
recommendations, the temperature of your foods when
they go into the oven may determine your final baking
time and baking results; if you put your food, such as
biscuits or breads, in during Pre-heat, they may over
brown on top or burn.
IMPORTANT: The more items to be heated in the oven
during preheat (this includes multiple racks, baking
stones, etc.) will affect the length of your pre-heat time.
Always begin baking after the pre-heat signal. The signal
will be a beep, indicaotr light or chime. This lets you
know your oven is at your needed baking temperature.
For best results, turn the oven On before you begin your
prep work.
Air Fry:
Air Fry is a special, no-preheat, cooking mode that is
designed to produce foods with a crispier exterior than
traditional oven cooking. The Air Fry mode is intended
for single rack cooking only. Select Air Fry, then input
the desired set temperature and press Start. The
temperature can be set between 300°F and 500°F.
Preheating is not recommended for this mode. Follow
traditional oven recipe or package guidelines for set
temperatures and cook times; adjust cook time to
achieve your desired crispness. Additional guidelines
for using this mode can be found in the Air Fry Cooking
Guide.
Cooking Modes
USING THE RANGE: Cooking Modes
49-2001000 Rev. 2 15
USING THE RANGE: Cooking Guide
Cooking Guide
FOOD TYPE
RECOMMENDED
MODE(S)
RECOMMENDED
RACK POSITION(S) ADDITIONAL SUGGESTIONS
Baked Goods
Layer Cakes, sheet cakes, bundt
cakes, muffins, quick breads on a
Single Rack
Bake 4 8VHVKLQ\FRRNZDUH
Layer cakes* on Multiple Racks Bake 3 and 5
Ensure adequate airflow
(see illustration below).
Chiffon cakes (angel food) Bake 1 8VHVKLQ\FRRNZDUH
Cookies, biscuits, scones on a
Single Rack
Bake 4 8VHVKLQ\FRRNZDUH
Cookies, biscuits, scones on
Multiple Racks
Bake
Convection Bake (if available)
3 and 5
Ensure adequate airflow. Reduce input temperature
by 25°F when using Convection Bake only.
Beef & Pork
Hamburgers Broil Hi 6
8VHDEURLOSDQPRYHIRRGGRZQIRUPRUH
doneness/less searing. Watch food closely when
broiling. For best performance center food below the
broil heating element
Steaks & Chops Broil Hi 6
8VHDEURLOSDQPRYHIRRGGRZQIRUPRUH
doneness/less searing. Watch food closely when
broiling. For best performance center food below the
broil heating element
Roasts Bake 3 or 4
8VHDORZVLGHGSDQVXFKDVDEURLOSDQ3UHKHDWLQJ
is not necessary
Poultry
Whole chicken Bake 3 or 4 8VHDORZVLGHGSDQVXFKDVDEURLOSDQ
Bone-in chicken breasts, legs,
thighs
Broil Hi 3 If breaded or coated in sauce avoid Broil Hi modes.
Broil skin side down first. Watch food closely when
broiling. For best performance when broiling, center
food below the broil heating element.
Broil Lo
Bake
3 or 4
Boneless chicken breasts
Broil Lo
Bake
3 or 4
If breaded or coated in sauce avoid Broil Hi modes.
Broil skin side down first. Watch food closely when
broiling. For best performance when broiling, center
food below the broil heating element
Whole turkey Bake 2 or 3 8VHDORZVLGHGSDQVXFKDVDEURLOSDQ
Turkey Breast Bake 2 or 3 8VHDORZVLGHGSDQVXFKDVDEURLOSDQ
Fish Broil Lo
6 (1/2 thick or less)
5 (>1/2 inch)
Watch food closely when broiling. For best
performance center food below the broil heating
element.
Casseroles Bake 4
Frozen Convenience Foods
Pizza, french fries, tator tots,
chicken nuggets, appetizers on a
Single Rack
Bake 4 8VHVKLQ\FRRNZDUH
Pizza, french fries, tator tots,
chicken nuggets, appetizers on
Multiple Racks
Bake
Convection Bake (if available)
3 and 5
8VHVKLQ\FRRNZDUH5HGXFLQJLQSXWWHPSHUDWXUHLV
not recommended when using Convection Bake.
*When baking four cake layers at a time, use racks 3
and 5. Place the pans as shown so that one pan is not
directly above another.
Cook food thoroughly to help protect against food
borne illness. Minimum safe food temperature
recommendations for food safety can be found at
IsItDoneYet.gov. Make sure to use a food thermometer
to take food temperatures.
Rack position for baking 4 layer cakes.
16 49-2001000 Rev. 2
Air Fry is a special, no-preheat, cooking mode that
is designed to produce foods with a crispier exterior
than traditional oven cooking. Select Air Fry, then
input the desired set temperature and press Start. The
temperature can be set between 300°F and 500°F.
Air Fry Cookware Guidelines
• Only use broil safe cookware when using Air Fry mode.
• A dark sheet pan is recommended. A dark pan
promotes better browning and crisping.
• Oven baking baskets and baking grids can also be
used. A sheet pan should be placed on the rack below
the foods to catch any drippings when using a baking
basket.
General Tips for Air Fry Mode
• The Air Fry mode is designed for cooking on a single
rack.
• The Air Fry mode is designed to be used without
preheating.
• Rack position 3 is recommended for most foods.
• Foods may cook faster than expected if the oven is
already hot when food is placed in the oven.
• When air frying foods with sauce, it is recommended to
apply the sauce at the end of cooking.
• If foods are browning too quickly, try a lower rack
position or lower oven set temperature.
• For packaged foods, use traditional oven cooking
instructions for set temperature and expected cook
time.
• It is not necessary to flip or stir food during cooking
• Arrange food in a single layer on the pan, do not
overload the pan.
• Always check internal food temperature to confirm
minimum safe temperatures have been reached.
Minimum safe food temperatures can be found on
packages and at IsItDoneYet.gov.
FOOD TYPE
RECOMMENDED
RACK POSITION(S)
RECOMMENDED
SET TEMPERATURES (F°)
RECOMMENDED
COOK TIME (MIN) NOTES
Fresh boneless fish or
poultry pieces, breaded such
as nuggets, tenders, fillets
3 375-400 15-30
8VHU ORZHU VHW WHPSHUDWXUHV IRU ODUJHU SLHFHV
8VH VKLQ\ FRRNZDUH
Fresh bone in
chicken wings
3 375-400 25-40
Salt wings or coat in a dry rub, if using sauce
apply after cooking or toward the end of cooking
Fresh bone in chicken
drumsticks or thighs
3 375-400 30-55 8VHU ORZHU VHW WHPSHUDWXUHV IRU ODUJHU SLHFHV
Fresh French fries,
thin (< ½ inch)
3 400-425 15-30
Parchment paper is recommended when
preparing fresh French fries. For crispier fries,
toss fries in corn starch or rice flour before
cooking.
Fresh French fries,
thick (> ½ inch)
3 375-400 20-35
Parchment paper is recommended when
preparing fresh French fries. For crispier fries,
toss fries in corn starch or rice flour before
cooking.
Frozen packaged
foods
3
8VH WUDGLWLRQDO RYHQQRW $LU )U\ FRRNLQJ LQVWUXFWLRQV DV D JXLGHOLQH IRU VHW WHPSHUDWXUH DQG FRRN WLPH$GGLWLRQDO
cook time beyond recommended package time may be required for some foods. If oven is hot when starting, food
may cook faster than the minimum package time.
Primary recommended cookware
Alternate cookware options
Air Fry Cooking Guide
USING THE RANGE: Air Fry Cooking Guide
49-2001000 Rev. 2 17
Cleaning the Range – Exterior
WARNING
If your range is removed for cleaning, servicing or any reason, be sure the
anti-tip device is reengaged properly when the range is replaced. Failure to
take this precaution could result in tipping of the range and can result in death
or serious burns to children or adults.
Be sure all controls are off and all surfaces are cool before cleaning any part of the range.
Control Knobs
The control knobs may be removed for easier cleaning.
Make sure the knobs are in the OFF positions and pull
them straight off the stems for cleaning.
The knobs can be cleaned in a dishwasher or they may
also be washed with soap and water. Make sure the
inside of the knobs are dry before replacing.
Replace the knobs, in the OFF position to ensure proper
placement.
Control Lockout
If desired, the touch pads may be deactivated before
cleaning.
See Lock Controls in the Oven Controls section in this
manual.
Clean up splatters with a damp cloth.
You may also use a glass cleaner.
Remove heavier soil with warm, soapy water. Do not use
abrasives of any kind.
Reactivate the touch pads after cleaning.
Control Panel
It’s a good idea to wipe the control panel after each use.
Clean with mild soap and water or vinegar and water,
rinse with clean water and polish dry with a soft cloth.
Do not use abrasive cleansers, strong liquid cleansers,
plastic scouring pads or oven cleaners on the control
SDQHO²WKH\ZLOOGDPDJHWKHILQLVK
Oven Exterior
Do not use oven cleaners, abrasive cleansers, strong
liquid cleansers, steel wool, plastic scouring pads, or
cleaning powders on the exterior of the oven. Clean with
a mild soap and water or vinegar and water solution.
Rinse with clean water and dry with a soft cloth. When
cleaning surfaces, make sure that they are at room
temperature and not in direct sunlight.
If stain on the door vent trim is persistent, use a mild
abrasive cleaner and a sponge-scrubber for best results.
Spillage of marinades, fruit juices, tomato sauces and
basting liquids containing acids may cause discoloration
and should be wiped up immediately. Let hot surfaces
cool, then clean and rinse.
Painted Surfaces
Painted surfaces include the sides of the range and the
door, top of control panel and the drawer front. Clean
these with soap and water or a vinegar and water solution.
Do not use commercial oven cleaners, cleaning powders,
steel wool or harsh abrasives on any painted surface.
Porcelain Enamel Cooktop
The porcelain enamel finish is sturdy but breakable if
misused. This finish is acid-resistant. However, any
acidic foods spilled (such as fruit juices, tomato or
vinegar) should not be permitted to remain on the finish.
If acids spill on the cooktop while it is hot, use a dry paper
towel or cloth to wipe it up right away. When the surface
has cooled, wash with soap and water. Rinse well.
For other spills such as fat spatterings, wash with soap
and water or cleansing powders after the surface has
cooled. Rinse well. Polish with a dry cloth.
CARE AND CLEANING: Cleaning the Range – Exterior
18 49-2001000 Rev. 2
Cleaning the Range – Exterior
Fingerprint Resistant Stainless Steel* (Black Stainless, Slate, Dark Slate, and Painted)
DO NOT use Stainless Steel cleaners on outside surfaces.
IMPORTANT: The use of incorrect products may
damage the outer finish of Fingerprint Resistant
Stainless and Black Stainless models. Please follow
these instructions and use only the appropriate items
below to clean your appliance surfaces.
Ŷ Clean interior/exterior surfaces with warm water, mild
soap or detergent, and a soft or microfiber cloth to
avoid damage.
Ŷ Wipe the appliance surface dry with a soft clean cloth
or microfiber towel to avoid streaking or water spotting.
Stainless Steel Surfaces (on some models)
Do not use a steel wool pad; it will scratch the surface.
To clean the stainless steel surface, use warm sudsy
water or a stainless steel cleaner or polish. Always wipe
the surface in the direction of the grain. Follow the cleaner
instructions for cleaning the stainless steel surface.
To inquire about purchasing cleaning products including
stainless steel appliance cleaner or polish, see the
Accessories and Consumer Support sections at the end
of this manual.
NOTE: DO NOT allow stainless steel cleaner to come
in contact with any plastic parts such as control knobs.
If unintentional contact of cleaners with plastic parts
does occur, clean plastic part with a sponge and mild
detergent mixed with warm water.
DO USE DO NOT USE
Ŷ6RIWFOHDQFORWKRUVSRQJH0LFURILEHUFORWK Ŷ$EUDVLYHFORWKVSDSHUWRZHOVVFUXEELQJVSRQJHV
(with or without soap), scouring or steel wool pads
Ŷ
Mild detergent mixed with warm water
Ŷ$EUDVLYHSRZGHUVOLTXLGVRUVSUD\V
Ŷ:LQGRZVSUD\VDPPRQLDRUEOHDFK
Ŷ&LWUXVRUSODQWRLOEDVHGFOHDQHUV
Ŷ$FLGLFRUYLQHJDUEDVHGFOHDQHUV
Ŷ2YHQFOHDQHUV
Ŷ$ONDOLQHFOHDQHUV
Ŷ6WDLQOHVVVWHHOFOHDQHUV
DO USE DO NOT USE
Ŷ6RIWFOHDQFORWKRUVSRQJH Ŷ$EUDVLYHFORWKVVFUXEELQJVSRQJHVZLWKRUZLWKRXWVRDS
scouring or steel wool pads
Ŷ0LOGGHWHUJHQWPL[HGZLWKZDUPZDWHU
Ŷ$SSURYHGVWDLQOHVVVWHHOFOHDQHUV
Visit the GE Appliances parts store
for approved stainless steel cleaners:
GEApplianceparts.com or call 877.959.8688
Ŷ&OHDQHUVZLWKR[DOLFDFLGVXFKDV%DU
.HHSHUV)ULHQG6RIW&OHDQVHUFDQEHXVHG
to remove surface rust, tarnish and small
blemishes on stainless steel surfaces only.
Ŷ$EUDVLYHSRZGHUVRUVSUD\V
Ŷ:LQGRZ6SUD\VRU$PPRQLD
Ŷ&LWUXVRUSODQWRLOEDVHGFOHDQHUV
Ŷ$FLGLFRUYLQHJDUEDVHGFOHDQHUV
Ŷ2YHQFOHDQHUV
Ŷ&OHDQHUVFRQWDLQLQJDFHWRQHSURSDQRQH
Ŷ$Q\FOHDQHUZLWK:$51,1*DERXWSODVWLFFRQWDFW
*Easily wipe away smudges and fingerprints.
CARE AND CLEANING: Cleaning the Range – Exterior
49-2001000 Rev. 2 19
CARE AND CLEANING: Cleaning the Range – Interior
The interior of your new oven can be cleaned manually or by using Self Clean mode.
Spillage of marinades, fruit juices, tomato sauces and basting liquids containing acids may cause discoloration and
should be wiped up immediately. Let hot surfaces cool, then clean and rinse.
Manual Cleaning
Do not use oven cleaners (unless certified for self-
cleaning oven), abrasive cleaners, strong liquid
cleansers, steel wool, scouring pads, or cleaning
powders on the interior of the oven. Clean with a mild
soap and water or vinegar and water solution. Rinse with
clean water and dry with a soft cloth. When cleaning
surfaces, make sure that they are at room temperature.
Cleaning the Range – Interior
Porcelain Oven Interior (on models that do not have a self-clean feature)
With proper care, the porcelain enamel finish on the
LQVLGHRIWKHRYHQ²WRSERWWRPVLGHVEDFNDQGLQVLGH
RIWKHGRRU²ZLOOVWD\QHZORRNLQJIRU\HDUV
Let the oven cool before cleaning. We recommend that
you wear rubber gloves when cleaning the oven.
Soap and water will normally do the job. Heavy spattering
or spillovers may require cleaning with a mild abrasive
cleaner. Soap-filled scouring pads may also be used.
Do not allow food spills with a high sugar or acid content
(such as tomatoes, sauerkraut, fruit juices or pie filling)
to remain on the surface. They may cause a dull spot
even after cleaning.
Household ammonia may make the cleaning job easier.
Place 1/2 cup in a shallow glass or pottery container
in a cold oven overnight. The ammonia fumes will help
loosen the burned-on grease and food.
If necessary, you may use an oven cleaner. Follow the
package directions.
Ŷ 'RQRWVSUD\RYHQFOHDQHURQWKHHOHFWULFDOFRQWUROV
and switches because it could cause a short circuit
and result in sparking or fire.
Ŷ 'RQRWDOORZDILOPIURPWKHFOHDQHUWREXLOGXSRQWKH
WHPSHUDWXUHVHQVRU²LWFRXOGFDXVHWKHRYHQWRKHDW
improperly. (The sensor is located at the top of the
oven.) Carefully wipe the sensor clean after each oven
cleaning, being careful not to move the sensor as a
change in its position could affect how the oven bakes.
Ŷ 'RQRWVSUD\DQ\RYHQFOHDQHURQWKHRYHQGRRU
handles or any exterior surface of the oven, cabinets
or painted surfaces. The cleaner can damage these
surfaces.
20 49-2001000 Rev. 2
Cleaning the Range – Interior (Cont.)
Self Clean Mode
Read Self-Cleaning Oven Safety Instructions at the
beginning of this manual before using Self Clean Mode.
Self clean uses very high temperatures to clean the oven
interior. You will need to lock the oven door when using
this feature. Before operating the self-clean cycle, wipe
up grease and soils from the oven. Remove all items
from the oven other than enameled (dark color) racks.
Shiny or silver racks and any cookware or other items
should all be removed from the oven before initiating a
self-clean cycle. Close the door. Latch the door.
NOTE: Never force the latch. If the oven is too hot, you
will not be able to slide the latch. Allow the oven to cool.
Press the Self Clean pad and a default self-clean time
is displayed. The clean time can be changed to any
time between 3:00 and 5:00 hours by using the +/-
pads to enter a different time and pressing Start. For
heavily soiled ovens, the maximum 5 hour clean time is
recommended. If you wish to use the default time, press
the Start pad immediately after pressing the Self Clean
pad. The oven will turn off automatically when the self-
clean cycle is complete. After the oven has cooled down
wipe any ash out of the oven.
We recommend venting your kitchen with an open
window or using a ventilation fan or hood during the first
self-clean cycle.
Soil on the front frame of the range and outside the
gasket on the door will need to be cleaned by hand.
Clean these areas with hot water, soap-filled steel-wool
pads or cleansers such as Soft Scrub
®
. Rinse well with
clean water and dry.
Do not clean the gasket. The fiberglass material of
the oven door gasket cannot withstand abrasion. It is
essential for the gasket to remain intact. If you notice it
becoming worn or frayed, replace it.
Make sure the oven light bulb cover is in place and the
oven light is off.
IMPORTANT: The health of some birds is extremely
sensitive to the fumes given off during the self-cleaning
cycle of any range. Move birds to another well-
ventilated room.
To Stop a Self-Clean Cycle
Press the Cancel/Off pad. Wait until the oven has cooled
below the locking temperature to unlatch the door. You
will not be able to open the door right away unless the
oven has cooled below the locking temperature.
Racks
All racks can be washed with warm, soapy water.
Enameled (not shiny) racks can be left in the cavity
during self clean.
Racks may be more difficult to slide, especially after
a self-clean. Put some vegetable oil on a soft cloth or
paper towel and rub onto the left and right edges.
NOTE:8VLQJRWKHUFRRNLQJRLOVZLOOFDXVHDGLVFRORULQJ
or a rust like color residue on the racks and cavity sides.
To clean this residue, use a soap and water or a vinegar
and water solution. Rinse with clean water and dry with a
soft cloth.
Oven Heating Elements
Do not clean the bake element or the broil element. Any
soil will burn off when the elements are heated.
To clean the oven floor, gently lift the bake element.
Clean the oven floor with warm, soapy water.
Gently lift the bake element
CARE AND CLEANING: Cleaning the Range – Interior
49-2001000 Rev. 2 21
CARE AND CLEANING: Cleaning the Glass Cooktop
Cleaning the Glass Cooktop
To maintain and protect the surface of your glass cooktop,
follow these steps:
1. Before using the cooktop for the first time, clean it
with a ceramic cooktop cleaner. This helps protect the
top and makes cleanup easier.
2. Regular use of ceramic cooktop cleaner will help keep
the cooktop looking new.
3. Shake the cleaning cream well. Apply a few drops of
ceramic cooktop cleaner directly to the cooktop.
8VHDSDSHUWRZHORUQRQVFUDWFKFOHDQLQJSDGIRU
ceramic cooktops to clean the entire cooktop surface.
8VHDGU\FORWKRUSDSHUWRZHOWRUHPRYHDOOFOHDQLQJ
residue. No need to rinse..
NOTE: It is very important that you DO NOT heat the
cooktop until it has been cleaned thoroughly.
Burned-On Residue
NOTE: DAMAGE to your glass surface may occur if you
use scrub pads other than those recommended.
1. Allow the cooktop to cool.
2. Spread a few drops of ceramic cooktop cleaner on
the entire burned residue area.
8VLQJDQRQVFUDWFKFOHDQLQJSDGIRUFHUDPLF
cooktops, rub the residue area, applying pressure as
needed.
4. If any residue remains, repeat the steps listed above
as needed.
5. For additional protection, after all residue has been
removed, polish the entire surface with ceramic
cooktop cleaner and a paper towel.
Heavy, Burned-On Residue
1. Allow the cooktop to cool.
8VHDVLQJOHHGJHUD]RUEODGHVFUDSHUDWDSSUR[LPDWHO\
a 45° angle against the glass surface and scrape the
soil. It will be necessary to apply pressure to the razor
scraper in order to remove the residue.
3. After scraping with the razor scraper, spread a few drops
of ceramic cooktop cleaner on the entire burned residue
DUHD8VHDQRQVFUDWFKFOHDQLQJSDGWRUHPRYHDQ\
remaining residue.
4. For additional protection, after all residue has been
removed, polish the entire surface with ceramic
cooktop cleaner and a paper towel.
8VHDQRQVFUDWFKFOHDQLQJSDGIRU
ceramic cooktops.
Clean your cooktop after each
VSLOO8VHDFHUDPLFFRRNWRS
cleaner.
For cleaning videos and
instructions, scan the QR code
with your device.
Ceramic
Cooktop
Cleaner
The ceramic cooktop scraper and all recommended supplies
are available through our Parts Center. See the Accessories
and Consumer Support sections at the end of this manual.
NOTE: Do not use a dull or nicked blade.
22 49-2001000 Rev. 2
Metal Marks and Scratches
1. Be careful not to slide pots and pans across your
cooktop. It will leave metal markings on the cooktop
surface.
These marks are removable using the ceramic
cooktop cleaner with a non-scratch cleaning pad for
ceramic cooktops.
2. If pots with a thin overlay of aluminum or copper
are allowed to boil dry, the overlay may leave black
discoloration on the cooktop.
This should be removed immediately before heating
again or the discoloration may be permanent.
NOTE: Carefully check the bottom of pans for roughness
that would scratch the cooktop.
3. Be careful not to place aluminum baking sheets or
aluminum frozen entrée containers on a hot cooktop
surface. It will leave shinny dots or markings on the
cooktop surface. These markings are permanent and
cannot be cleaned off.
Damage from Sugary Spills and Melted Plastic
Special care should be taken when removing hot substances to avoid permanent damage of the glass surface.
Sugary spillovers (such as jellies, fudge, candy, syrups) or melted plastics can cause pitting of the surface of your
cooktop (not covered by the warranty) unless the spill is removed while still hot. Special care should be taken when
removing hot substances.
Be sure to use a new, sharp razor scraper.
Do not use a dull or nicked blade.
1. Turn off all surface units. Remove hot pans.
2. Wearing an oven mitt:
D 8VHDVLQJOHHGJHUD]RUEODGHVFUDSHUWRPRYH
the spill to a cool area on the cooktop.
b. Remove the spill with paper towels.
3. Any remaining spillover should be left until the surface
of the cooktop has cooled.
4. Don’t use the surface units again until all of the
residue has been completely removed.
NOTE: If pitting or indentation in the glass surface has
already occurred, the cooktop glass will have to be
replaced. In this case, service will be necessary.
Cooktop Seal
To clean the cooktop seal around the edges of the glass,
lay a wet cloth on it for a few minutes, then wipe clean
with nonabrasive cleaners.
Cleaning the Glass Cooktop (Cont.)
CARE AND CLEANING: Cleaning the Glass Cooktop
49-2001000 Rev. 2 23
WARNING
SHOCK OR BURN HAZARD: Before replacing oven light bulb, disconnect the electrical power to the
range at the main fuse or circuit breaker panel. Failure to do so may result in electric shock or burn.
CAUTION
BURN HAZARD: The glass cover and bulb should be removed when cool. Touching hot glass with
bare hands or a damp cloth can cause burns.
Oven Light
Oven Light Replacement (on some models)
To remove:
1. Turn the glass cover counterclockwise until the glass
is removed. Wearing latex gloves may offer a better
grip.
2. Remove the bulb by pulling it straight out.
To replace:
8VHDQHZYROWKDORJHQEXOEQRWWRH[FHHG
50 watts. Replace the bulb with the same type of bulb
that was removed. Be sure the replacement bulb is
rated 120 volts or 130 volts (NOT 12 volts) and has a
G9 base.
8VLQJJORYHVRUDGU\FORWKUHPRYHWKHEXOEIURPLWV
packaging. Do not touch the bulb with bare fingers. Oil
from skin will damage the bulb and shorten its life.
3. Push the bulb straight into the receptacle all the way.
4. Replace the glass cover. For improved lighting inside
the oven, clean the glass cover frequently using a
wet cloth. This should be done when the oven is
completely cool and the light is off.
5. Reconnect electrical power to the oven.
Oven Light Replacement (on some models)
To remove:
1. Turn the glass cover
counterclockwise 1/4 turn until the
tabs of the glass cover clear the
grooves of the socket. Wearing latex
gloves may offer a better grip.
2. Remove the bulb by turning it
counter-clockwise.
To replace:
1. Replace bulb with a new 40-watt appliance bulb.
Insert the bulb and turn it clockwise until it is tight.
2. Place the tabs of the glass cover into the grooves of
the socket. Turn the glass cover clockwise 1/4 turn.
For improved lighting inside the oven, clean the glass
cover frequently using a wet cloth. This should be
done when the oven is completely cool.
3. Reconnect electrical power to the oven.
G9 Bulb
Socket
Tab
Glass cover
Receptacle
G9 Bulb
Socket
Glass cover
Receptacle
8VHJORYHV
or cloth
Receptacle
Oven Light Replacement (on some models)
The oven light bulb is covered with a removable glass cover that is held in place with a bail-shaped wire. Remove
the oven door, if desired, to reach the cover easily. See the Lift-Off Oven Door section for detailed oven door
removal instructions.
Replacing the Light Bulb:
1. Disconnect electrical power to the range.
2. Hold the glass cover stable, so it doesn’t fall when
released.
3. Slide near the indent of the cover holder until the
cover is released. Do not remove any screws to
release the glass cover.
4. Replace bulb with a 40-watt household appliance
bulb. Do not touch hot bulb with hand or wet
cloth. Only remove bulb when it is cool.
5. Hold glass cover stable over new bulb.
6. Pull the wire cover holder near the indent until the
indent in the
wire cover
holder is located
in the indent of
the glass cover.
7. Connect
electrical power
to range.
Wire cover holder
Indent
Glass cover
(on self clean
model only)
CARE AND CLEANING: Oven Light
24 49-2001000 Rev. 2
The door is very heavy. Be careful when removing and lifting the door.
Do not lift the door by the handle.
To remove the door:
1. Fully open the door.
2. Pull the hinge locks down toward the door frame, to
the unlocked position. A tool, such as a small flat-
blade screwdriver, may be required.
3. Firmly grasp both sides of the door at the top.
4. Close door to the door removal position. The door
should be open approximately 3" with no obstruction
above the door.
5. Lift door up and out until both hinge arms are clear of
the slots.
To replace the door:
1. Firmly grasp both sides of the door at the top.
2. Starting on the left side, with the door at the same
angle as the removal position, seat the indentation of
the hinge arm into the bottom edge of the hinge slot.
The notch in the hinge arm must be fully seated into
the bottom of the slot. Repeat for right side.
3. Fully open the door. If the door will not fully open, the
indentation is not seated correctly in the bottom edge
of the slot.
4. Push the hinge locks up against the front frame of the
oven cavity, to the locked position.
5. Close the oven door.
To remove the drawer:
1. Pull the drawer out until it stops.
2. Lift the front of the drawer until the stops clear the
guides.
3. Remove the drawer.
To replace the drawer:
1. Place the drawer rails on the guides.
2. Push the drawer back until it stops.
3. Lift the front of the drawer and push back until the
stops clear the guides.
4. Lower the front of the drawer and push back until it
closes.
Removal position
Oven Door
Storage Drawer
Hinge lock
Slot
Pull hinge locks down to unlock
Push hinge locks up to lock
Hinge
lock
Hinge
arm
Indentation
Bottom
edge of
slot
Hinge arm
Stop guide
Rail
CARE AND CLEANING: Oven Door / Storage Drawer
49-2001000 Rev. 2 25
Troubleshooting Tips ... Before you call for service
Save time and money! Review the charts on the following pages first and you may not need to call for service.
Check out self-help videos and FAQ at GEAppliances.com/support.
Problem Possible Cause What To Do
Surface units will not maintain
a rolling boil or cooking is not
fast enough
Improper cookware being used. 8VHSDQVZKLFKDUHIODWDQGPDWFKWKHGLDPHWHURIWKHVXUIDFHXQLWVHOHFWHG
In some areas, the power (voltage)
may be low.
Cover pan with a lid until desired heat is obtained.
Surface units do not work
properly
A fuse in your home may be blown or
the circuit breaker tripped.
Replace the fuse or reset the circuit breaker.
Cooktop controls improperly set. Check to see the correct control is set for the surface unit you are using.
Surface unit stops glowing
when turned to a lower setting
The unit is still on and hot. This is normal.
Scratches (may appear as
cracks) on cooktop glass
surface
Incorrect cleaning methods being
used.
Scratches are not removable. Tiny scratches will become less visible in time
as a result of cleaning.
Cookware with rough bottoms being
used or coarse particles (salt or sand)
were between the cookware and the
surface of the cooktop. Cookware has
been slid across the cooktop surface.
To avoid scratches, use the recommended cleaning procedures. Make sure
bottoms of cookware are clean before use, and use cookware with smooth
bottoms.
Areas of discoloration on the
cooktop
Food spillovers not cleaned before
next use.
See the Cleaning the glass cooktop section.
Hot surface on a model with a light-
colored cooktop.
This is normal. The surface may appear discolored when it is hot. This is
temporary and will disappear as the glass cools.
Plastic melted to the surface Hot cooktop came into contact with
plastic placed on the hot cooktop.
6HHWKH*ODVVVXUIDFH²SRWHQWLDOIRUSHUPDQHQWGDPDJHVHFWLRQLQWKH
Cleaning the glass cooktop section.
Pitting (or indentation) of the
cooktop
Hot sugar mixture spilled on the
cooktop.
Call a qualified technician for replacement.
Frequent cycling off and on of
surface units
Improper cookware being used. 8VHRQO\IODWFRRNZDUHWRPLQLPL]HF\FOLQJ
My new oven doesn't cook
like my old one. Is something
wrong with the temperature
settings?
Your new oven has a different
cooking system from your old oven
and therefore may cook differently
than your old oven.
For the first few uses, follow your recipe times and temperatures carefully.
If you still think your new oven is too hot or too cold, you can adjust the
temperature yourself to meet your specific cooking preference. NOTE: This
adjustment affects Bake, and Convection Bake temperatures; it will not affect
Convection Roast, Broil or Clean.
Food does not bake properly Oven controls improperly set. See the Cooking Modes section.
Rack position is incorrect or rack is
not level.
See the Cooking Modes section and Cooking Guide.
Incorrect cookware or cookware of
improper size being used.
See the Cookware section.
Oven temperature needs adjustment. See the Special Features section.
Ingredient substitution Substituting ingredients can change the recipe outcome.
Food does not broil properly Oven controls improperly set. Make sure you select the appropriate broil mode.
Improper rack position being used. See Cooking Guide for rack location suggestions.
Food being cooked in a hot pan. Make sure cookware is cool.
Cookware not suited for broiling. 8VHDSDQVSHFLILFDOO\GHVLJQHGIRUEURLOLQJ
Aluminum foil used on the broiling
pan and grid has not been fitted
properly and slit as recommended.
If using aluminum foil conform to pan slits.
In some areas the power (voltage)
may be low.
Preheat the broil element for 10 minutes.
Oven temperature too hot or
too cold
Oven temperature needs adjustment. See the Special Features section.
Oven does not work or
appears not to work
A fuse in your home may be blown or
the circuit breaker tripped.
Replace the fuse or reset the circuit breaker.
Oven controls improperly set. 6HHWKH8VLQJWKH2YHQVHFWLRQ
Oven is in Sabbath Mode.
Verify, that the oven is not in Sabbath Mode. See the Special Features section.
“Crackling” or “popping”
sound
This is the sound of the metal heating
and cooling during both the cooking
and cleaning functions.
This is normal.
TROUBLESHOOTING TIPS
26 49-2001000 Rev. 2
Troubleshooting Tips ... Before you call for service
Problem Possible Cause What To Do
Why is my range making a
"clicking" noise when using
my oven?
Your range cycles the heating
elements by turning relays on and off
to maintain the oven temperature.
This is normal.
Clock and timer do not work A fuse in your home may be blown or
the circuit breaker tripped.
Replace the fuse or reset the circuit breaker.
Plug on range is not completely
inserted in the electrical outlet.
Make sure electrical plug is plugged into a live, properly grounded outlet.
Oven controls improperly set. 6HHWKH8VLQJWKHNLWFKHQWLPHUVHFWLRQ
Storage drawer won’t close Power cord may be obstructing
drawer in the lower back of the range.
Reposition the drawer and power cord. See the Storage Drawer Removal
instructions in the Care and cleaning of the range section.
Rear drawer support is on top of the
guide rail.
Reposition the drawer. See the Storage Drawer Removal instructions in the
Care and cleaning of the range section.
Oven door is crooked The door is out of position. Because the oven door is removable, it sometimes gets out of position
during installation. To straighten the door, re-install the door. See the "Lift-
Off Oven Door" instructions in the "Care and Cleaning" section.
Oven light does not work Light bulb is loose or defective. Tighten or replace bulb.
Pad operating light is broken. Call for service.
Oven will not self-clean The temperature is too high to set a
self-clean operation.
Allow the oven to cool and reset the controls.
Oven controls improperly set. See the Cleaning the Oven section.
Excessive smoking during
clean cycle
Excessive soil or grease. Press the Cancel/Off pad. Open the windows to rid the room of smoke. Wait
until the LOCKED light goes off. Wipe up the excess soil and reset the clean
cycle.
Excessive smoking during
broiling
Food too close to burner element. Lower the rack position of the food.
Oven door will not open after
a clean cycle
Oven too hot. Allow the oven to cool below locking temperature.
Oven not clean after a clean
cycle
Oven controls improperly set. See the Cleaning the Oven section.
Oven was heavily soiled. Clean up heavy spillovers before starting the clean cycle. Heavily soiled
ovens may need to self-clean again or for a longer period of time.
"LOCK DOOR" flashes in the
display
The self-clean cycle has been
selected but the door is not closed.
Close the oven door. Latch the door.
DOOR LOCK light is on when
you want to cook
The oven door is locked because
the temperature inside the oven
has not dropped below the locking
temperature.
Press the Cancel/Off pad. Allow the oven to cool.
“F— and a number or letter”
flash in the display
You have a function error code. Press the Cancel/Off pad. Allow the oven to cool for one hour. Put the oven
back into operation.
If the function code repeats. Disconnect all power to the oven for at least 30 seconds and then reconnect
power. If the function error code repeats, call for service.
Display goes blank A fuse in your home may be blown or
the circuit breaker tripped.
Replace the fuse or reset the circuit breaker.
The clock is turned off. See the Special features section.
Oven is in Sabbath Mode.
Verify that the oven is not in Sabbath Mode. See the Special Features section.
Power outage, clock flashes Power outage or surge Reset the clock. If the oven was in use, you must reset it by pressing the
Cancel/Off pad, setting the clock and resetting any cooking function.
“Burning” or “oily” odor
emitting from the vent
This is normal in a new oven and will
disappear in time.
To speed the process, set a self-clean cycle for a minimum of 3 hours. See
the Cleaning the Oven section.
Strong odor An odor from the insulation around
the inside of the oven is normal for the
first few times the oven is used.
This is temporary and will go away after several uses or a self-clean cycle.
Fan noise
(on some models)
A convection fan may automatically
turn on and off.
This is normal. The fan is designed to operate intermittently to maximize
cooking evenness. The convection fan will operate during preheat of
the bake cycle. The fan will turn off after the oven is heated to the set
temperature. This is normal.
My oven door glass appears
to be "tinted" or have a
"rainbow" color. Is this
defective?
No. The inner oven glass is coated
with a heat barrier to reflect the heat
back into the oven to prevent heat
loss and keep the outer door cool
while baking.
7KLVLVQRUPDO8QGHUFHUWDLQOLJKWRUDQJOHV\RXPD\VHHWKLVWLQWRU
rainbow color.
TROUBLESHOOTING TIPS
49-2001000 Rev. 2 27
Notes
28 49-2001000 Rev. 2
GEAppliances.com
All warranty service is provided by our Factory Service Centers, or an authorized Customer Care
®
technician. To schedule
service online, visit us at GEAppliances.com/service, or call GE Appliances at 800.GE.CARES (800.432.2737). Please
have your serial number and your model number available when calling for service.
Servicing your appliance may require the use of the onboard data port for diagnostics. This gives a GE Appliances factory
service technician the ability to quickly diagnose any issues with your appliance and helps GE Appliances improve its
products by providing GE Appliances with information on your appliance. If you do not want your appliance data to be
sent to GE Appliances, please advise your technician not to submit the data to GE Appliances at the time of service.
What GE Appliances will not cover:
Ŷ Service trips to your home to teach you how to use
the product.
Ŷ ,PSURSHULQVWDOODWLRQGHOLYHU\RUPDLQWHQDQFH
Ŷ )DLOXUHRIWKHSURGXFWLILWLVDEXVHGPLVXVHG
modified or used for other than the intended purpose
or used commercially.
Ŷ 'DPDJHWRWKHJODVVFRRNWRSFDXVHGE\XVHRI
cleaners other than the recommended cleaning
creams and pads.
Ŷ 'DPDJHWRWKHJODVVFRRNWRSFDXVHGE\KDUGHQHG
spills of sugary materials or melted plastic that
are not cleaned according to the directions in the
Owner's Manual.
Ŷ 5HSODFHPHQWRIKRXVHIXVHVRUUHVHWWLQJRIFLUFXLW
breakers.
Ŷ 'DPDJHWRWKHSURGXFWFDXVHGE\DFFLGHQWILUH
floods or acts of God.
Ŷ 'DPDJHWRILQLVKVXFKDVVXUIDFHUXVWWDUQLVKRUVPDOO
blemishes not reported within 48 hours of delivery.
Ŷ ,QFLGHQWDORUFRQVHTXHQWLDOGDPDJHFDXVHGE\
possible defects with this appliance.
Ŷ 'DPDJHFDXVHGDIWHUGHOLYHU\
Ŷ 3URGXFWQRWDFFHVVLEOHWRSURYLGHUHTXLUHGVHUYLFH
Ŷ 6HUYLFHWRUHSDLURUUHSODFHOLJKWEXOEVH[FHSWIRU
LED lamps.
Ŷ (IIHFWLYH-DQXDU\FRVPHWLFGDPDJHWRWKH
glass cooktop such as, but not limited to, chips,
scratches, or baked on residue not reported within 90
days of installation.
Ŷ (IIHFWLYH-DQXDU\
damage to the glass cooktop
due to impact or misuse. See
example.
EXCLUSION OF IMPLIED WARRANTIES
Your sole and exclusive remedy is product repair as provided in this Limited Warranty. Any implied warranties,
including the implied warranties of merchantability or fitness for a particular purpose, are limited to one year or
the shortest period allowed by law.
This limited warranty is extended to the original purchaser and any succeeding owner for products purchased for
KRPHXVHZLWKLQWKH86$,IWKHSURGXFWLVORFDWHGLQDQDUHDZKHUHVHUYLFHE\D*($SSOLDQFHV$XWKRUL]HG6HUYLFHU
is not available, you may be responsible for a trip charge or you may be required to bring the product to an Authorized
GE Appliances Service location for service. In Alaska, the limited warranty excludes the cost of shipping or service
calls to your home.
Some states do not allow the exclusion or limitation of incidental or consequential damages. This limited warranty
gives you specific legal rights, and you may also have other rights which vary from state to state. To know what your
legal rights are, consult your local or state consumer affairs office or your state’s Attorney General.
Warrantor: GE Appliances, a Haier company
/RXLVYLOOH.<
Extended Warranties: Purchase a GE Appliances extended warranty and learn about special discounts that are
available while your warranty is still in effect. You can purchase it online anytime at
GEAppliances.com/extended-warranty
or call 800.626.2224 during normal business hours. GE Appliances Service will still be there after your warranty expires.
For the period of GE Appliances will replace
One year
From the date
of the original
purchase
Any part of the range which fails due to a defect in materials or workmanship. During this
limited one-year warranty, GE Appliances will provide, free of charge, all labor and in-home
service to replace the defective part.
Staple your receipt here. Proof of the original purchase
date is needed to obtain service under the warranty.
LIMITED WARRANTY
GE Appliances Electric Range Limited Warranty
49-2001000 Rev. 2 29
ACCESSORIES
Looking For Something More?
GE Appliances offers a variety of accessories to
improve your cooking and maintenance experiences!
Refer to the Consumer Support page for phone numbers
and website information.
The following products and more are available:
Accessories
Accessories
6PDOO%URLOHU3DQô´[ó´[ò³
/DUJH%URLOHU3DQô´[ó´[ò³
;/%URLOHU3DQ´[ó´[³
Parts
Oven racks
Oven elements
Light bulbs
Cleaning Supplies
&LWUX6KLQH6WDLQOHVV6WHHO:LSHV
Stainless Steel Appliance Cleaner
Non-scratch Cleaning Pads for Ceramic Cooktops
Ceramic Cooktop Cleaner
Ceramic Cooktop Scraper
.LW.LWLQFOXGHVFUHDPDQGFRRNWRSVFUDSHU
7KHODUJHEURLOHUSDQGRHVQRWILWLQ´´UDQJHV
7KH;/EURLOHUSDQGRHVQRWILWLQ´ZDOORYHQV´GURSLQVRU´´UDQJH
NOTE: Go to GE Appliances website to view recommended cleaners.
30 49-2001000 Rev. 2
Notes
49-2001000 Rev. 2 31
Notes
32 49-2001000 Rev. 2
3ULQWHGLQWKH8QLWHG6WDWHV
Consumer Support
CONSUMER SUPPORT
GE Appliances Website
Have a question or need assistance with your appliance? Try the GE Appliances Website 24 hours a day, any day
of the year! You can also shop for more great GE Appliances products and take advantage of all our on-line support
VHUYLFHVGHVLJQHGIRU\RXUFRQYHQLHQFH,QWKH86GEAppliances.com
Register Your Appliance
Register your new appliance on-line at your convenience! Timely product registration will allow for enhanced
communication and prompt service under the terms of your warranty, should the need arise. You may also mail in
WKHSUHSULQWHGUHJLVWUDWLRQFDUGLQFOXGHGLQWKHSDFNLQJPDWHULDO,QWKH86GEAppliances.com/register
Schedule Service
Expert GE Appliances repair service is only one step away from your door. Get on-line and schedule your service at
\RXUFRQYHQLHQFHDQ\GD\RIWKH\HDU,QWKH86GEAppliances.com/service
or call 800.432.2737 during normal business hours.
Extended Warranties
Purchase a GE Appliances extended warranty and learn about special discounts that are available while your
warranty is still in effect. You can purchase it on-line anytime. GE Appliances Services will still be there after your
ZDUUDQW\H[SLUHV,QWKH86GEAppliances.com/extended-warranty
or call 800.626.2224 during normal business hours.
Remote Connectivity
For assistance with wireless network connectivity (for models with remote enable),
visit our website at GEAppliances.com/connect RUFDOOLQWKH86
Parts and Accessories
Individuals qualified to service their own appliances can have parts or accessories sent directly to their homes
(VISA, MasterCard and Discover cards are accepted). Order on-line today 24 hours every day.
,QWKH86GEApplianceparts.com or by phone at 877.959.8688 during normal business hours.
Instructions contained in this manual cover procedures to be performed by any user. Other servicing
generally should be referred to qualified service personnel. Caution must be exercised, since improper
servicing may cause unsafe operation.
Contact Us
If you are not satisfied with the service you receive from GE Appliances, contact us on our Website with all the
details including your phone number, or write to:
,QWKH86*HQHUDO0DQDJHU&XVWRPHU5HODWLRQV_*($SSOLDQFHV$SSOLDQFH3DUN_/RXLVYLOOH.<
GEAppliances.com/contact
