Razor Speakers are a low-prole, outdoor
architectural speaker series that sets new
standards in style and acoustical performance.
The Coastal Source Razor Speaker is the rst line
of outdoor wall and hardscape speakers built with
true HiFi performance in mind, with options for
bi-amped sub/sat congurations along with tri-
amped solutions that utilize external subs. Coastal
Source speakers have already set the standard
for landscape and deck applications creating a
demand for Coastal quality high-performance
audio on hardscapes such as walls, decks, and
horizontal & vertical corners.
The Razor Speaker series offers striking
sound from a slim prole speaker system
that elegantly disappears into the background
meeting homeowners’ current hidden technology
expectations. The Razor minimizes the visual
impact on the home’s outdoor aesthetic while
maximizing superior sound performance.
Fully modular — architecturally pleasing. The razor speaker
line offers the exceptional performance we’re known for, in an
exquisitely slim and modern profile.
Patent Pending
scan for video
Coastal Source 2022 New Product Guide | coastalsource.com 8
The Razor Speaker line boasts custom-designed, engineered, and
optimized ultra-shallow drivers to provide impressive performance
from a slim enclosure. The Acoustic Fractal Waveguide™ tweeter bridge
dramatically improves clarity and efficiency.
RZ220
9 Coastal Source 2022 New Product Guide | coastalsource.com9 Coastal Source 2022 New Product Guide | coastalsource.com
10.50
36.00
3.38
4.00
0.63
45°
45°
10.50
21.63
3.38
4.00
45°
0.63
45°
10.63
10.50
0.63
45°
4.00
45°
RZ110
SHEET 1 OF 1
8-25-22
SEAN
UNLESS OTHERWISE SPECIFIED:
SCALE: 1:4
WEIGHT:
REV
DWG. NO.
A
SIZE
TITLE:
RAZOR RZ110
BASIC DIMENSIONS
COASTAL SOURCE
NAME
DATE
COMMENTS:
Q.A.
MFG APPR.
ENG APPR.
CHECKED
DRAWN
BLACK/WHITE
ALUMINUM
FINISH
MATERIAL
INTERPRET GEOMETRIC
TOLERANCING PER:
DIMENSIONS ARE IN INCHES
TOLERANCES:
FRACTIONAL
ANGULAR: MACH
BEND
TWO PLACE DECIMAL
THREE PLACE DECIMAL
REVISIONS
5
4
3
2
1
PROPRIETARY AND CONFIDENTIAL
THE INFORMATION CONTAINED IN THIS
DRAWING IS THE SOLE PROPERTY OF
COASTAL SOURCE.
ANY REPRODUCTION IN PART OR AS A
WHOLE WITHOUT THE WRITTEN PERMISSION
OF COASTAL SOURCE IS PROHIBITED.
REV. DESCRIPTION DATE APPROVED
Coastal Source 2022 New Product Guide | coastalsource.com 10
RAZOR SPECIFICATIONS
Preliminary specications subject to change
Construction: Aluminum extrusion,
Aluminum wall bracket,
Kydex composite grille
Finish: White & Black Powder Coat
Impedance: 6-8 ohms
Mounting: Corner, Surface
Speaker Connector: Male CMC Pigtail(s)
Warranty: 5-Year Limited Warranty
ALL MODELS IN WHITE POWDER COAT FINISH
AVAILABLE Q2 2023
RZ200 SERIES
Size (H x W x D): 21.63in x 10.5in x 4in
MODELS
RZ210 2.5-WAY SPEAKER
RZ220 HIGH POWER 3-WAY SPEAKER
RZ300 SERIES
Size (H x W x D): 36in x 10.5in x 4in
MODELS
RZ310 HIGH POWER 3-WAY SPEAKER
RZ320 HIGH POWER SOUND BAR
RZ330 HIGH POWER LCR SPEAKER
RZ340 LINE SOURCE SPEAKER
RZ350 SUBWOOFER
RZ100 SERIES
Size (H x W x D): 10.63in x 10.5in x 4in
MODELS
RZ110 2-WAY SPEAKER
