OVERVIEW
The Built-in Coee Maker features a stylish stainless steel
finish and can be installed in multiple configurations to suit
kitchen design and preference. With 13 beverage options,
our Coee Maker is designed to consistently pour delicious
coee – from Flat White to Latte or Americano. Favourite
coee can be memorised and set to start at the same time
each day, while the conical burr grinder delivers a
consistent grind for the perfect coee.
MODELS
Built-in Coee Maker, 60cm,
Stainless steel, Touchscreen, Dial
EB60DSX1
SERIES & STYLE
Series 9
Contemporary
FEATURES
1 Designed to pair perfectly with 60cm ovens and
companion products
2 Stylish stainless steel finish
3 Install in multiple configurations to suit your kitchen
design
4 Intuitive touch display
5 13 functions to suit any taste and selection – from
Espresso to Latte
6 Personalised coffee and smart self-learning menu
preferences
7 Stainless steel conical burr grinder with 13 coarseness
positions
8 15 bar pump pressure
9 Self-cleaning function and easy to empty coffee grounds
container and drip tray
"0 2.5L water tank capacity
ACCESSORIES
1 Thermal milk jug (0.5L)
2 Water filter
3 Coffee spoon
4 Extractable steam outlet
5 Descaling agent bottle
6 Optional 76cm trim kit (part 82760)
90002405 Date: 7 April 2022 The models shown in this Preliminary Specification Guide (PSG) may not be available in all markets and are subject to change at any time. Product specifications may vary
from those shown. This PSG is superseded and will become obsolete upon launch of the product. This PSG should not be used as installation guidance for any product. Further information is required to
safely and correctly install the products featured here. Specific installation guidance will be available with the product on delivery and on our website fisherpaykel.com
PRELIMINARY SPECIFICATION GUIDE BUILT-IN COFFEE MAKER, 60CM
90002405 Date: 7 April 2022 The models shown in this Preliminary Specification Guide (PSG) may not be available in all markets and are subject to change at any time. Product specifications may vary
from those shown. This PSG is superseded and will become obsolete upon launch of the product. This PSG should not be used as installation guidance for any product. Further information is required to
safely and correctly install the products featured here. Specific installation guidance will be available with the product on delivery and on our website fisherpaykel.com
PRELIMINARY SPECIFICATION GUIDE BUILT-IN COFFEE MAKER, 60CM
ISO VIEW
ISO VIEW
SPECIFICATIONS
Model No.
EB60DSX1
Dimensions H 458mm W 596mm D 480mm
Total water tank capacity 2.4L
Weight 29kg (unpackaged)
9kg (packaged)
Electrical
Supply 220-240VAC, 50Hz
Service 10A circuit
PRODUCT DIMENSIONS
mm
A Overall height 458
B Overall width 596
C Depth of chassis 460
D Depth front frame 20
CAVITY DIMENSIONS
mm
A Minimum inside height 450
B Minimum inside width 560
C Minimum inside depth 545
C
B
A
A
C
B
D
