User’s Guide
KL-HD1
EN
RJA532737-001V02
Supported Tape Widths
6
mm
9
mm
12
mm
18
mm
Important!
Be sure to keep all user documentation handy for future reference.
1
EN
Read This First!
x
CASIO COMPUTER CO., LTD. shall not be held liable for any loss or
claims by you or any other person or entity that may arise through the use
of this printer.
x
Reproduction of this manual in any form, either in part or its entirety, is
forbidden without the express permission of CASIO COMPUTER CO.,
LTD.
x
The contents of the manual are subject to change without notice.
x
The software is continually being revised and updated. Because of this,
the software supplied to you and the contents of the displays it produces
may be different from those described in this manual, or some items
described in this manual may no longer be available.
x
Screen shots and examples shown in this manual assume that “English”
was selected as the display language. Screens produced when another
display language is selected may be different from the screen shots
shown here.
x
Be sure to read this manual carefully before attempting to use the product
for the fi rst time.
English
Contents
Safety Precautions ....................................................................... 2
Operating Precautions ................................................................. 4
Part 1 Getting Ready ................................................................. 5
Part 2 Inputting Characters and Symbols ............................... 8
Part 3 Deleting and Inserting Characters .............................. 10
Part 4 Fonts, Character Sizes and Character Styles ............ 10
Part 5 Printing .......................................................................... 12
Part 6 Confi guring Form Settings .......................................... 14
Part 7 Using Frames ............................................................... 15
Part 8 Creating and Printing a Label with a Logo ................ 15
Part 9 Memory ......................................................................... 16
Part 10 Confi guring the Printer Setup ..................................... 17
Part 11 Reference ...................................................................... 17
Appendix ...............................................................................APP-1
2
EN
Warning
Smoke, abnormal odor, overheating, and other
abnormalities
Do not continue to use this product while it is emitting smoke
or strange odor, or generating heat. Continued use creates the
risk of fi re and electric shock. Immediately perform the following
steps whenever any of the above symptoms are present.
1. Turn off power.
2. Contact your original retailer.
Batteries
Continued use of the printer without removing the batteries
after they have leaked creates the risk of fi re and electric
shock. Should batteries leak, immediately stop using the printer
and contact your original retailer.
Misuse of batteries can cause them to leak, resulting in
damage to nearby objects, or to explode, creating the risk of
fi re and personal injury. Always make sure you observe the
following precautions.
x
Never try to take batteries apart or allow them to become
shorted.
x
Never expose batteries to heat or dispose of them by
incineration.
x
Never mix old batteries with new ones.
x
Never mix batteries of different types.
x
Do not charge the batteries.
x
Make sure the positive (+) and negative (–) ends of the
batteries are facing correctly.
Dropping and rough treatment
Continued use of the product after it has been damaged due to
dropping or other rough treatment creates the risk of fi re and
electric shock. Immediately perform the following steps if the
product should ever become damaged.
1. Turn off power.
2. Contact your original retailer.
Safety Precautions
Thank you for purchasing this quality CASIO product.
Before using it, be sure to read the following Safety Precautions. Keep the
manual in a convenient location for future reference when necessary.
Danger
This symbol indicates information that, if ignored or applied
incorrectly, creates the danger of death or serious personal injury.
Warning
This symbol indicates information that, if ignored or applied
incorrectly, creates the possibility of death or serious personal injury.
Caution
This symbol indicates information that, if ignored or applied
incorrectly, creates the possibility of personal injury or material
damage.
Examples of graphic markings
indicates something you should not do. The symbol shown here
indicates you should not try to take the unit apart.
indicates something you should do.
Danger
Batteries
Perform the following steps immediately if fl uid leaking from
batteries ever gets into your eyes.
1. Do not rub your eyes! Rinse them with water.
2. Contact your physician immediately.
Leaving alkaline battery fl uid in your eyes can lead to loss of sight.
3
EN
Warning
Disassembly and Modifi cation
Never try to take this product apart or modify it in any way.
Doing so creates the risk of electric shock, burn injury, and
other personal injury.
Leave all internal inspection, maintenance, and repair up to
your original retailer.
Liquids and Foreign Matter
Water, sports drinks, seawater, animal or pet urine, or foreign
objects (pieces of metal, etc.) getting into this product creates
the risk of fi re and electric shock.
Immediately perform the steps below whenever any of the
above symptoms are present.
1. Turn off power.
2. Contact your original retailer.
Keep Away From Fire
Never throw this product into fi re to dispose of it.
Doing so creates the risk of explosion, which can cause fi re or
personal injury.
Packaging Plastic Bag
Take care never to allow the plastic bag this product comes in to
be ingested or placed over anyone’s head.
Doing so creates the risk of suffocation. Particular care is required
in households where small children are present.
Do not affi x labels to a container to be used in
a microwave oven.
Do not affi x labels to any container you plan to use in a
microwave oven. The label material contains metal, which
creates the risk of fi re and burn injury when heated in a
microwave oven. It can also cause deformation of the container
to which the label is affi xed.
Caution
Batteries
Misuse of batteries can cause them to leak, resulting in
damage to nearby objects, or to explode, creating the risk of
fi re and personal injury. Always make sure you observe the
following precautions.
x
Use only batteries that are specifi ed for use with this
product.
x
Remove batteries from the product if you do not plan to use
it for a long time.
Keep backup copies of all important data.
Be sure to keep separate copies of important data in a
notebook or some other location. Malfunction of the product,
repairs, and dead batteries can cause data stored memory to
be lost.
Heavy Objects
Do not place heavy objects on this product. Doing so can
cause this product to tip over or fall, creating the risk of
personal injury.
Unstable Locations
Never place the product on an unstable surface, on a high
shelf, etc. Doing so can cause the product to fall, creating the
risk of personal injury.
Locations to be Avoided
Never leave this product in any of the types of locations
described below.
Doing so creates the risk of fi re and electric shock.
x
Areas subject to large amounts of humidity or dust.
x
Food preparation areas or other locations where oil smoke
is present.
x
Near heaters, on a heated carpet, in areas exposed to
direct sunlight, in a closed vehicle parked in the sun, or
other areas subject to very high temperatures.
4
EN
Caution
Loading and replacing batteries
The springs inside of the battery compartment have sharp
edges. Take care that you do not touch the springs with your
fi ngers when loading or replacing batteries. Doing so creates
the risk of personal injury.
Display Screen
x
Never push on the display screen’s LCD panel or subject it
to strong impact. Doing so can cause the LCD panel’s glass
to crack, creating the risk of personal injury.
x
Should the LCD panel ever crack or break, never touch the
liquid inside of the panel. LCD panel liquid can cause skin
irritation.
x
Should LCD panel liquid ever get inside your mouth,
immediately wash out your mouth with water and contact
your physician.
x
Should LCD panel liquid ever get into your eyes or onto
your skin, rinse with clear water for at least 15 minutes, and
then contact a physician.
High temperature precaution
The print head and the metal parts around it can become very
hot. Do not touch them. Doing so creates the risk of burn injury.
Cutter Precautions
Do not insert your fi ngers into the print head or the cutter at
the tape outlet. Doing so creates the risk of fi nger cuts and
personal injury.
Important!
x
Contact a nearby dealer whenever you require servicing.
x
Note that the manufacturer shall not be held liable for any loss
or claims by third parties, which may arise out of the use of this
product.
x
Note that the manufacturer shall not be held liable for any damages
incurred as a result of data loss caused by malfunctions, repairs, or
interruption of power supply.
x
It is up to the user to keep backup records of important data.
Operating Precautions
Observe the following precautions to ensure that the printer provides you with
the years of trouble-free operation for which it is designed.
x
Avoid using the printer in areas exposed to direct sunlight, and in areas
subjected to high humidity, electrostatic charge, sudden temperature
changes, and temperature extremes. Operating Temperature Range: 10°C
to 35°C (50°F to 95°F)
x
Battery capacity becomes lower at temperatures of 10°C (50°F) and colder.
This can cause the message "
LOW BATTERY!
" to appear sooner than
normal. If this happens, move the printer to a location that is within the
operating temperature range (10°C to 35°C (50°F to 95°F)).
x
Never subject the printer to strong impact or shock.
x
Never allow paper clips, pins, or other similar objects to get inside the
printer mechanism.
x
Never pull on the tape with excessive force or try to push it into the cassette.
x
Place the printer on a level surface when printing. A tilted surface can make
normal printing impossible.
x
Unclear printing can indicate a dirty print head. If printing becomes unclear,
use the procedures on page 17 to clean the print head and rubber roller.
5
EN
Part 1 Getting Ready
Important!
x
Be sure to read this section before attempting to use the printer.
Power Supply
The printer can run on six AA-size alkaline batteries. Be sure to use
alkaline batteries only.
Replacing Batteries
A handy low battery power indicator lets you know when battery power is
getting too low for proper operation. The message “
LOW BATTERY!
” appears
on the display if battery power is low when you perform any of the following
operations.
x
Turn power on
x
Execute a print operation
Whenever the “
LOW BATTERY! OK/CANCEL
” message appears, press
OK
to clear it from the display. You should still be able to perform some printer
operations, but some power intensive operations (like printing) may become
impossible if battery power is too low. In any case, you should replace batteries
as soon as possible after the “
LOW BATTERY!
” message appears.
To load batteries
Caution
x
The springs inside of the battery compartment
have sharp edges. Take care that you do not
touch the springs with your fi ngers when
loading or replacing batteries. Doing so
creates the risk of personal injury.
General Guide
Display (LCD)
Function key
Power Key
Turns printer on or off.
Letter keys
Tape cutter button
Tape outlet
Tape window
Printer cover
6
EN
1. Turn off the printer.
2. While pressing the location of the up arrow ( ), lift up the printer cover to
open and remove it.
3. Load batteries into the battery
compartment.
x
Be sure to use alkaline batteries.
x
Make sure the positive (+) and
negative (–) ends of the batteries
are facing correctly when you load
them.
4. Replace the printer cover.
Turning the Printer On or Off
Press to turn the printer on or off.
x
When you turn on the printer, the tape width selection screen will appear.
Use and to select the tape width you will use, and then press
OK
.
Resetting the Memory
You should reset the memory of the printer before using it for the fi rst time.
Important!
x
Resetting the printer memory clears its memory of all input data.
To reset the memory
1. Make sure that printer power is off.
2. While holding down
and the space key, press to turn power on.
x
This prompt confi rms whether or not you want to initialize the printer.
3. Release , the space key, and .
4. Press
OK
to initialize the printer or
to abort the reset operation
without initializing anything.
Display Language Setting
You can select English, German, French, Italian, Spanish, Swedish,
Portuguese, or Indonesian as the language to be used for display messages.
For information about how to change the language setting, see page 17.
7
EN
Auto Power Off Function
If you do not perform any key operation for about six minutes, the printer will
turn off automatically. To restore power, press .
x
The printer will remember any text you input before power turned off.
Retrieving a Sentence from Memory
If power is turned off or if Auto Power Off is triggered while you are creating a
sentence, the sentence that was being created is saved temporarily in printer
memory. The next time you turn on power, the message “
[OK] TO RECALL
”
will appear. Pressing
OK
will display the sentence currently stored in memory.
Tape Cartridges
Use the procedures described below to load a tape cartridge into the printer.
Important!
x
Never try to push the tape back into the cassette. Once tape is out of the
cassette, there is no way to wind it back in. Trying to do so can cause op-
erational problems with the printer.
x
The following are the tape widths that can be used with this printer:
6mm (
1
/
4
"), 9mm (
3
/
8
"), 12mm (
1
/
2
"), 18mm (
3
/
4
").
To load a tape cartridge
1. Make sure that the printer is turned off.
2. While pressing the location of the up arrow ( ), lift up the printer cover to
open and remove it.
x
Never touch the print head or other metal objects near the head. These
items become very hot, and touching them creates the risk of burn
injury.
3. Remove the stopper from a new tape cartridge
and check to see that the tape is ready to use.
x
Make sure that the tape is under the tape guide and that it is not bent or
twisted.
OK! NO!
Tape guide
4. Pull the tape out about 3cm (1
3
/
16
").
Important!
x
Once tape is pulled out, there is no way to get it back into the cartridge.
x
Never use excessive force when pulling on the tape. Doing so can cause
the ink ribbon to break, creating the risk of malfunction.
5. Use a pencil or some other thin object to take
up slack in the ink ribbon as shown in the
illustration. Note that the tape does not move
at this time.
x
If the ink ribbon is slack when you load it into
the printer, it can break or cause some other
problem.
x
Be sure to turn the ink ribbon take up spool
only in the direction indicated by the arrow (a).
x
Turn the spool until the other spool (b) starts
turning in the direction noted by the arrow.
This indicates there is no slack in the ribbon.
Stopper
Tape
Ink ribbon
(under the tape)
(b)
(a)
8
EN
Part 2 Inputting Characters and Symbols
Important!
x
You can input up to 80 characters per label. Further input becomes
impossible after you input the 80th character.
Key Name
OK
Function
Cancel
Accent
Number lock
Caps
Space
Return
Backspace
Symbol
Memory (Delete all)
Setup (Feed)
Print (Print preview)
Tape length (Logo)
Character style (Frame)
Character size (Font)
6. Load the tape cartridge into the printer, making sure that the tape and ink
ribbon pass between the head and roller.
Roller
Head
7. Close the printer cover.
8. Turn on printer power and press
FUNC
and then (FEED) two or three
times to make sure that the tape comes out without any problem.
x
If the tape does not come out normally, turn off power and start again
from step 1 above.
9
EN
Display Symbols and Indicators
Before getting into actual input, you should fi rst become acquainted with the
symbols and indicators used on the printer display.
Function indicator
Accent indicator (page 9)
Number lock Indicator
(page 9)
Tape width indicators (page 17)
Cursor
Character position marks
Mirror print indicator (page 14)
Vertical text indicator (page 14)
Style indicators (page 12)
Font Indicator (page 11)
Imager (page 9)
Tape length (page 14)
Character size indicators
(page 11)
Caps indicator (page 9)
Basic Alpha-Numeric Input
Note
x
If you hold down any key, it will repeat its operation or input at high speed
until you release it.
To input alpha-numeric characters
1. Turn on the printer (page 6).
2. Specify the tape width.
3. Input the fi rst line of characters.
x
To toggle between upper case and lower case input, press
.
x
To input numbers, press
. Pressing also enables input of
symbols (, . - ! ?) with the symbol key in the lower right corner of the
keyboard.
x
If you input a wrong character, press
to delete it and input again.
See page 10 for other details on editing text.
4. When you reach the end of a line of text, press
to input a newline
mark.
x
A newline operation is indicated on the display by the symbol. This
shows where you changed lines. The Imager shows the number of lines
that have been input in the label. Each label line is shown as a horizontal
line in the Imager area. The label line currently being edited is indicated
by a fl ashing Imager line.
Examples
Two lines of label text, line 2 being edited
Three lines of label text, line 2 being edited
x
The maximum number of lines that can be input is one line when the
tape width is 6mm (
1
/
4
") and 9mm (
3
/
8
"), two lines when the width is
12mm (
1
/
2
"), and three lines when the width is 18mm (
3
/
4
").
5. Input the characters in the second line.
6. To print the text that you input, press
. For details on printing, see page 12.
To input accented characters
1. Press .
2. Press the key that corresponds to the accented character you want to
input.
x
This will display a menu of accented characters.
3. Use
and to select the accented character you want and then press
OK
.
Symbols and Illustrations
Pressing enables input of symbols and illustrations.
To input symbols and illustrations
1. Press .
2. Use
and to select the
SYMBOL
or
ILLUST
group, and then press
OK
.
x
This displays a selection screen for the group (
SYMBOL
or
ILLUST
)
you selected.
3. Use the cursor keys to select the symbol or illustration you want to input
and then press
OK
.
10
EN
Part 3 Deleting and Inserting Characters
Moving the Cursor
To make the cursor do this: Do this:
Move left Press
.
Move right Press
.
Jump to the fi rst (leftmost) text
character
Press
FUNC
then
.
Jump to the last (rightmost)
text character
Press
FUNC
then
.
Move at high speed Hold down
or .
To delete characters
1. Use and to move the cursor to the right of the character you want to
delete.
2. Press
to delete the character to the left of the cursor position.
x
If the cursor is located at the fi rst (leftmost) character, pressing will
delete the fi rst character.
To clear the display
Press
FUNC
and then (Delete all).
At this time the message “
CLEAR? OK/CANCEL
” appears on the display to
confi rm that you want to clear the display. Press
OK
to clear or
to abort
the operation without clearing anything.
To insert characters
1. Use and to move the cursor to the location where you want to insert
the characters.
2. Input the new characters.
x
This inserts the characters at the current cursor position.
Part 4
Fonts, Character Sizes and Character Styles
Selecting a Font
Your printer gives you a choice of eight fonts (examples shown below). The
currently selected font is indicated by an icon (which shows a letter and
number) in the upper right corner of the display.
Font Indicator Sample
SANS-SERIF
SANS-SERIF RND
(Sans-serif Rounded)
ROMAN
COURIER
POP
SLAB SERIF
BORDEAUX HEAVY
CURSIVE
11
EN
You can specify a font for the text you have just input or you can specify a
default font that is used automatically whenever you create a new label.
Important!
x
The font setting is applied to all of the characters. You cannot make multiple
specifi cations for specifi c characters.
To change the default font setting
1. Press to display the
SET UP
menu.
2. Use and to select
DEFAULT FONT
and then press
OK
.
3. Use and to select the font you want to use as the default, and then
press
OK
.
x
The default font you specifi ed will be used initially for all new labels.
When inputting text, you can use the procedure above to change the
font to another style, if you want.
To change the font of text you have just input
1. After inputting the text you want, press
FUNC
and then (Font).
2. Use and
to select the font you want to change to and then press
OK
.
x
This will apply the setting and return to the text input screen.
Character Size
You can select from among four different character sizes: Extra large, Large,
Medium, and Small.
Examples of each are shown below.
Extra large
Large
Medium
Small
Character size changes are applied to printed text only. The size of displayed
text does not change.
Important!
x
The maximum printable character size depends on the width of the tape
loaded in the printer and the number of lines of text to be printed.
x
The selected character size is applied to all of the characters. You cannot
make multiple specifi cations for specifi c characters.
To select a character size
1. Input the text.
2. Press
to display the size setting menu.
3. Use
and to move the pointer to the character size you want to use,
and then press
OK
.
12
EN
Character Styles
There are six character styles that you can assign: normal, bold, outline
shading, underline, and box. Examples of each are shown below.
Style Indicator Sample
Normal None
Bold
Outline
Shading
Underline
Box
Character style changes are applied to printed text only. The appearance
of the displayed text does not change, but the character style indicators will
show you when a character style is being used.
To specify a character style
1. Press to display the character style setting screen.
2. Use
and to move the pointer to the style you want to use, and then
press
OK
.
Part 5 Printing
Printing Precautions
x
Never turn power off while printing is being performed.
x
Make sure that the tape outlet is not blocked before you start printing.
x
Never operate the tape cutter while printer is being performed (indicated by
the message “NOW PRINTING” on the display).
Important!
x
Never touch the tape cutter while a tape cut operation is being performed.
Doing so can result in cuts and other personal injury.
Printing a Tape
Printing a tape is as easy as pressing the key.
To display the print preview
1. Press
FUNC
and then (PREVIEW).
x
The print image that appears scrolls on the display for easy viewing.
2. To stop the scrolling, press
OK
. Press
OK
again to restart scrolling.
3. Exiting preview will return you automatically to the screen that was
displayed prior to starting preview.
x
To cancel preview part way through, press
.
To print a tape
1. While the text input screen is displayed, press .
x
This will display a screen for specifying the number of copies.
2. Use
and , to specify the number of copies.
x
You can also input a value for the number of copies.
3. Press
OK
to start printing.
x
To stop a print operation that is in progress, press
.
4. After the print operation is complete, press down on the tape cutter button
to cut the tape.
13
EN
Important!
Check to make sure that printing is completely stopped before cutting the
tape. Cutting the tape while printing is in progress can cause tape jams and
damage to the printer.
To affi x a tape to a surface
1. Use scissors or some other implement to trim the tape to the required size,
if necessary.
2. Remove the backing from the tape and
affi x it to the desired surface.
x
Bending a corner of the label makes
the backing easier to peel off.
x
Removing a label from a surface
where it was affi xed may cause
adhesive residue to remain on the
surface.
Important!
Do not try to affi x a label to the objects or in the locations described below.
x
On a surface exposed to direct sunlight or rain
x
On the body of a person or animal
x
On a utility pole, on a fence or structure not owned by you, etc.
x
On a container used for heating in a microwave oven
Unsuitable Surfaces (Label may not stick.)
x
Rough surfaces
x
Surfaces that are wet, oily, dusty, or covered with other matter
x
Special plastic materials (silicon, polypropylene, etc.)
Tape
Backing
HAPPY!
PPY!
To feed the Tape
1. Press
FUNC
and then (FEED).
x
This will feed the tape approximately 19mm (
12
/
16
").
14
EN
Part 6 Confi guring Form Settings
You can use the procedure in this section to confi gure direction, mirror,
alignment, pitch, and tape length settings.
Confi guring Direction, Mirror, Align, and Pitch Settings
1. Input the text you want.
2. Press .
3. Use and to select the item you want to change and then press
OK
.
4. Use
and to change the setting.
5. Press
OK
to return to the text input screen.
When this setting
is selected:
Use and to select the option you want:
DIRECTION • HORIZONTAL: Positions text from left to right.
• VERTICAL: Positions text from top to bottom.
MIRROR • NORMAL: Prints the tape normally.
• MIRROR: Prints the tape in mirror image onto
special optionally available iron transfer tape.
ALIGN • LEFT: Aligns text fl ush left.
• CENTER: Centers text.
• RIGHT: Aligns text fl ush right.
• EQUAL: Equally spaces text to fi ll the entire
space available.
PITCH
• Specify one of the following settings for the pitch
(space between characters): “NONE” (0 mm),
“NARROW” (1 mm), or “WIDE” (2 mm). Changing
this setting also causes the tape length to change
accordingly.
• This setting cannot be changed when EQUAL is
selected for the ALIGN setting, and when FIX is
selected for the TAPE LENGTH setting.
Tape Length Setting
You can use either of the methods below to specify the tape length.
x
AUTO:
Automatically adjusts tape length in accordance with the number of
characters.
x
FIX:
Maintains a fi xed tape length in the range of 0cm (0”) to 99.9cm
(39
5
/
16
”).
To have tape length set automatically (AUTO)
1. Press .
2. Use
and to select
AUTO
, and then press
OK
.
To specify a fi xed tape length (FIX)
1. Press .
2. Use
and to select
FIX
.
3. Use
and
to specify the tape length and then press
OK
.
x
Each press of (–) or (+) changes the current length setting by 0.1.
x
You can also input a value for the tape length.
Note
x
Brackets to the left and right of the display tape length value provide the
information described below.
[xx.x cm]: Print will be the specifi ed length.
(xx.x cm]: Print will be the specifi ed length, but text will be compressed
horizontally.
xx.x cm]: Print will be longer than that specifi ed length.
15
EN
Part 7 Using Frames
The printer comes with a selection of built-in frames that you can use in your
tape labels. See page APP-4 for a list of frames that are available.
To create a framed label
1. Input the text you want.
x
Including a frame in a label affects the allowable number of lines for
each tape wide as shown below.
18mm (
3
/
4
") tape: Up to two lines
12, 9, 6mm (
1
/
2
,
3
/
8
,
1
/
4
") tape: One line
2. Press
FUNC
and then
(Frame).
3. Use the cursor keys to select the frame you want, and then press
OK
.
4. Use
and to select
PRINT
, and then press
OK
.
5. Specify the number of copies and then press
OK
to start printing.
• The SHADING, UNDERLINE, and BOX character style settings cannot
be applied when printing with a frame.
Part 8
Creating and Printing a Label with a Logo
Your printer comes with 60 built-in logos that you can incorporate into your
tape labels quickly and easily.
To create a label with a logo
Important!
x
You can incorporate built-in logos into tape labels that are printed using
12mm (
1
/
2
") or 18mm (
3
/
4
") tape only.
1. Press
FUNC
and then
(LOGO).
2. Use and to select the group you want to use, and then press
OK
.
x
For details, see “Built-in Logos” on page 21.
3. Use and
to select the logo you want to use, and then press
OK
.
4. Use
and
to select the language you want to use, and then press
OK
.
5. Use
and
to select
PRINT
and then press
OK
.
6. Specify the number of copies and then press
OK
to start printing.
16
EN
Part 9 Memory
You can store two blocks of text in memory, containing up of 80 characters.
Important!
x
Be sure to keep written backup copies of all important data.
To store text
1. Input the text you want to store.
2. Press .
3. Use
and to select
STORE
.
4. Press
OK
.
5. Use and
to select the location where you want to store the text and
then press
OK
.
6. Press
OK
to store the text or
to abort the store procedure without
storing anything.
x
If there is nothing stored at the memory location you selected yet,
pressing
OK
will store your text.
• If there is already text stored at the location, the message “
OVERWRITE?
OK/CANCEL
” will appear when you press
OK
. Press
OK
again to
replace the existing text with the new text, or to cancel the store
operation.
To recall text
1. While the input screen is on the display, press .
x
Note that recalled text will replace any input text currently on the display.
2. Use
and to select
RECALL
.
3. Press
OK
.
4. Use and to select the text you want to recall and then press
OK
.
5. Press
OK
to recall the text or
to cancel the recall operation.
x
This recalls the text.
x
If all of the recalled text does not fi t on the display, you can use
and
to scroll it to the left and right.
x
Note that recalling text replaces anything that is currently on the input
display. Recalled text cannot be appended to existing text.
To delete stored text
1. While the input screen is on the display, press .
2. Press and to select
DELETE
.
3. Press
OK
.
4. Use and
to select the text you want to delete and then press
OK
.
x
This will display the message “
DELETE? OK/CANCEL
” to confi rm.
5. Press
OK
to delete the text.
17
EN
Part 10 Confi guring the Printer Setup
The printer has a
SET UP
screen that you can use to confi gure a variety of
basic settings.
To confi gure the printer setup
1. Press .
2. Use and to select the
SET UP
item whose setting you want to change,
and then press
OK
.
3. Use the cursor keys to change the currently selected setting.
When this setting
is selected:
Change its setting like this:
TAPE WIDTH
• Use
and to select the tape width setting you
want to use.
DEFAULT FONT
• Use
and to select the font you want to use.
CONTRAST
• Use
and to adjust the display contrast.
DENSITY
• Use
and to adjust the print density setting.
LANGUAGE
• Use
and to select the display language you
want to use.
cm/inch
• Use
and to select centimeters (cm) or inches
as the unit of measurement.
4. Press
OK
to apply the setting.
Part 11 Reference
Cleaning the Printer Head and Roller
A dirty printer head and roller can result in poor print quality. If you have
problems with print quality, use the following procedure to clean the printer
head and roller.
To clean the printer head and roller
1. Make sure the printer is turned off.
2. Open the printer cover.
x
If a tape cartridge is loaded in the printer, remove it.
3. Use a cotton swab dipped in alcohol to clean the printer head and roller as
shown in the illustration.
Printer head
Roller
x
Never touch the print head or other metal objects near the head. These
items become very hot, and touching them creates the risk of burn
injury.
4. Replace the tape cartridge and close the printer cover.
Cleaning the Printer Exterior
Wipe the exterior of the printer with a cloth moistened with plain water.
Wring all excess liquid from the cloth before wiping the printer.
Never use benzene, alcohol, thinner, or other volatile agents to clean the
printer exterior. Doing so can damage the case.
18
EN
Troubleshooting
• Power Supply
Nothing appears on the display.
Possible Causes Action Page
Battery power is low or the
wrong type of batteries
are loaded in the printer.
Load a fresh set of AA-size alkaline
batteries (supplied by you).
5
Improper display contrast
setting
Adjust display contrast.
17
Batteries loaded
incorrectly
Remove batteries and reload them
correctly.
5
• Text Input
Cannot input text.
Possible Causes Action Page
FUNC
key has been
pressed.
Press
to clear
FUNC
key
operation.
8
• Printing
Tape does not come out when is pressed.
Possible Causes Action Page
Tape cartridge
compartment cover is not
closed completely.
Securely close the printer cover.
7
No more tape left in the
cartridge.
Replace the tape cartridge with a
new one.
7
Tape jam Remove the tape cartridge and pull
out the jammed tape by hand. Cut
off excess tape with scissors, and
carefully replace the cartridge into
the label printer.
Important!
Never allow the tape outlet to
become blocked and never touch
tape as it is being fed during printing.
7
Printing is blurred, blotched, broken, etc.
Possible Causes Action Page
Improper print density
setting
Adjust the print density setting.
17
Improper loading of the
cartridge
Remove the tape cartridge and
reload it correctly.
7
Dirty printer head or
rubber roller
Clean the printer head and roller.
17
Printer powers down while printing is in progress.
Possible Causes Action Page
Battery power is low or the
wrong type of batteries
are loaded in the printer.
Load a fresh set of AA-size alkaline
batteries (supplied by you). 5
19
EN
Ink ribbon is being fed from the tape outlet along with the tape.
Possible Causes Action Page
Tape cartridge loaded
while the ink ribbon is
slack.
Remove the tape cartridge and
check to make sure the ink ribbon is
not broken. Next, take up any slack
in the ink ribbon and then reload the
tape cartridge.
Important!
• Before loading a tape cartridge
into the label printer, always make
sure you take up any slack in the
ink ribbon fi rst.
• If the ink ribbon is broken, you
must change to another tape
cartridge.
7
• Tape Cutting
Cannot cut tape.
Possible Causes Action Page
Tape cutter blade is dull. Take the label printer to the dealer
from whom you purchased it to have
the tape cutter blade replaced.
—
Printed text is cut off by tape cut operation.
Possible Causes Action Page
Out of tape Replace the tape cartridge with a
new one.
7
• Using Labels
Label will not adhere to a surface.
Possible Causes Action Page
The backing paper is still
on the back of the tape.
Peel the backing paper from the
back of the tape to expose the
adhesive.
13
Surface is unsuitable for
affi xing a tape.
Labels do not adhere well to
surfaces that are rough, wet, oily, or
dirty.
13
20
EN
Error Messages/Display Messages
Message Possible Causes Action
LABEL LONGER
THAN SETTING!
OK/CANCEL
•
This message appears
when the length of the
tape that will actually
be printed is longer
than the specifi ed
tape length.
• To print, press OK.
• To cancel printing, press
.
You can then decrease the
number of characters, change
to a longer tape setting, or
select auto tape length.
LOAD A TAPE
CARTRIDGE
12mm OR 18mm
• You are trying to use
the Logo function
while a 6mm (
1
/
4
")
or 9mm (
3
/
8
") tape
cartridge is loaded in
the printer.
•
Turn off the printer and replace
the tape cartridge with a
12mm (
1
/
2
") or 18mm (
3
/
4
")
cartridge, and specify the tape
width setting on the printer.
LOW BATTERY!
• Battery power is low. • Replace the batteries.
NO DATA!
• You are attempting
to recall text from
memory when there
is none stored.
• Store the text in memory and
then try again.
NO INPUT
TEXT!
• You are attempting
a print or preview
operation when no
text is input.
• Input the text and then try
again.
PRINT ERROR!
• The tape became
jammed during
printing.
• Turn off the printer and
remove the tape cartridge.
Next, remove the jammed
tape.
• If the steps described above
do not clear the error message,
contact your retailer or your
nearest CASIO service center.
Message Possible Causes Action
PRINTER NOT
SHUT DOWN
PROPERLY
LAST TIME
• You removed the
batteries the last time
power was turned on
or while the message
“PLEASE WAIT”
was displayed, so the
printer did not power
down normally.
• Press any key to initialize the
data that was partially deleted
the last time the printer
powered down.
TOO MANY
CHARACTERS!
• You are attempting
to input more than
80 characters of
text.
• Reduce the number of input
characters.
TOO MANY
LINES!
• The number of line
breaks you input
caused the label to
exceed the maximum
number of lines for
the tape you are
using.
• You are attempting
to print more than
three lines while an
18mm (
3
/
4
") tape
cartridge is loaded.
•
You are attempting to
print more than two
lines while a 12mm
(
1
/
2
") tape cartridge is
loaded.
• You are attempting
to print more than
one line while a 6mm
(
1
/
4
") or 9mm (
3
/
8
")
tape cartridge is
loaded.
• Use wider tape or reduce
the number of lines. The
maximum number of lines
for each tape width is shown
below.
6mm (
1
/
4
") tape...1 line
9mm (
3
/
8
") tape...1 line
12mm (
1
/
2
") tape...Up to 2
lines
18mm (
3
/
4
") tape...Up to 3
lines
• Use wider tape or reduce the
number of lines with frame.
The maximum number of lines
for each tape width when
printing with a frame is shown
below.
6mm (
1
/
4
") tape...1 line
9mm (
3
/
8
") tape...1 line
12mm (
1
/
2
") tape...1 line
18mm (
3
/
4
") tape...Up to 2
lines
21
EN
Built-in Logos
● PRICE Labels
● SIGN Labels
22
EN
● WORK Labels
● ATTENTION
23
EN
Specifi cations
Model: KL-HD1
Input
Keyboard Layout: Alphabetic (ABCD)
Number of characters: 80
Character Types
Alpha (English and other languages): 231
Numbers: 10
Symbols: 426
Display
Type: Liquid crystal display
Character matrix: 96
u
32 dots, 12 columns
u
1 line
Printing
Resolution: 96 dots/200dpi
Type: Thermal transfer
Speed: Up to approximately 10mm (
3
/
8
")/second (normal conditions)
Width: 4mm (
3
/
16
") (6mm (
1
/
4
") tape), 7mm (
1
/
4
") (9mm (
3
/
8
") tape), 10mm (
3
/
8
")
(12mm (
1
/
2
") tape), 12mm (
1
/
2
") (18mm (
3
/
4
") tape)
Character Matrix: 48 × 48-dot
Character fonts: SANS-SERIF, SANS-SERIF RND, ROMAN, COURIER,
POP, SLAB SERIF, BORDEAUX HEAVY, CURSIVE
Character Styles: Normal, bold, outline, shading, underline, box
Character sizes: Small, Medium, Large, Ex.Large
Number of lines: 1 (6mm (
1
/
4
") and 9mm (
3
/
8
") tapes); 1 or 2 (12mm (
1
/
2
")
tape); 1 or 2 or 3 (18mm (
3
/
4
") tape)
Number of lines with frame: 1 (6mm (
1
/
4
"), 9mm (
3
/
8
") and 12mm (
1
/
2
") tapes);
1 or 2 (18mm (
3
/
4
") tape)
Memory
Text: Up to 80 characters
General
Power supply: Six AA-size alkaline batteries
Rated voltage: 9V DC
Power consumption: 1A (9W)
Auto Power Off: Approximately six minutes after last key operation.
Dimensions: 202(H)
u
112(W)
u
60(D) mm (7
15
/
16
"H
u
4
7
/
16
"W
u
2
3
/
8
"D)
Weight: Approximately 340 g (12 oz) excluding batteries
Ambient Temperature: 10°C to 35°C (50°F to 95°F)
Battery Life
• Printing of approximately four 18mm (
3
/
4
") tape cartridges under
standard printing conditions*
* Printing text or graphics that contain large areas of black, and
printing under cold temperatures can shorten battery life.
B
APP-1
Accented Characters
A
C
D
E
G
H
I
J
K
L
N
O
R
Appendix
S
T
U
Y
Z
APP-2
a
c
d
e
g
h
i
j
k
l
n
o
r
s
t
u
y
z
KL-HD1_Appendix_EU.indd 2KL-HD1_Appendix_EU.indd 2 2014-12-9 16:44:10 PM2014-12-9 16:44:10 PM
APP-3
Symbols
● SYMBOL
● DINGBAT
● NUMBER
● GREEK
Illustrations
● ILLUST 1
KL-HD1_Appendix_EU.indd 3KL-HD1_Appendix_EU.indd 3 2014-12-9 16:44:11 PM2014-12-9 16:44:11 PM
APP-4
● ILLUST 2
Frames
KL-HD1_Appendix_EU.indd 4KL-HD1_Appendix_EU.indd 4 2014-12-9 16:44:15 PM2014-12-9 16:44:15 PM
APP-5
KL-HD1_Appendix_EU.indd 5KL-HD1_Appendix_EU.indd 5 2014-12-9 16:44:19 PM2014-12-9 16:44:19 PM
Manufacturer:
CASIO COMPUTER CO., LTD.
6-2, Hon-machi 1-chome, Shibuya-ku, Tokyo 151-8543, Japan
Responsible within the European Union:
CASIO EUROPE GmbH
Casio-Platz 1, 22848 Norderstedt, Germany
www.casio-europe.com
CASIO COMPUTER CO., LTD.
6-2, Hon-machi 1-chome
Shibuya-ku, Tokyo 151-8543, Japan
MO1502-B Printed in China/Imprimé en Chine
© 2015 CASIO COMPUTER CO., LTD.
