Tripp Lite SUTX40K SmartOnline SUTX Series 3-Phase 220/380V, 230/400V, 240/415V 40kVA 40kW On-Line Double-Conversion UPS, Tower, Extended Run, SNMP Option

Owner's Manual

For SUTX40K. Series: SUTX Series
Also, The document are for others Tripp Lite models: SUTX20K

PDF File Manual, 208 pages, Read Online | Download pdf file

Owner’s Manual

SmartOnline

SUTX

3-Phase UPS System

20/40kVA

Models: SUTX20K, SUTX40K

Input: 220/230/240V (Ph-N)

380/400/415V (Ph-Ph), 3ph 4-Wire + PE

1111 W. 35th Street, Chicago, IL 60609 USA • www.tripplite.com/support

Loading ...

File type: PDF

File name: 82974822_sutx40k.pdf

File size: 1.08 MB

File Language: English, French, Spanish, Russian

Pages: 208

Author: Tripp Lite

File created: 2021-02-02

Published: 2023-11-27

Updated: 2023-12-13

Verified by Eldridge Fisher on 2023-12-13

Download File

Specifications

Brand: Tripp Lite

Model: SUTX40K

Category: Tools - Home Improvement

Nominal Input Voltage Description: 3-Phase Wye, 4 wire (L1, L2, L3, N, G)

Power Factor: 1

Nominal Voltage Details: Factory default output voltage is 230/400V

Frequency Compatibility: 50 / 60 Hz

Frequency Compatibility Details: Automatic frequency selection

Output Voltage Regulation (Line Mode): +/-1%

Output Voltage Regulation (Economy Line Mode): +/- 10% of nominal voltage

Output Voltage Regulation (Battery Mode): +/-1%

Output AC Waveform (Battery Mode): Pure Sine wave

External Battery Pack Compatibility: BP480V09

DC System Voltage (VDC): +/- 240VDC

Battery Recharge Rate (Included Batteries): 8.1 hours from 10 to 90%

Battery Replacement Description: Hot-swappable, replaceable batteries

Voltage Regulation Description: Online, double-conversion power conditioning

UPS Power Module Dimensions (hwd, in.): 55.1 x 19.3 x 33.1

UPS Power Module Weight (kg): 382.83

UPS Power Module Weight (lbs.): 844

Battery Mode Heat Dissipation (BTU/Hr) @ Full Load: 1379

UPS Input Connection Type: Hardwire

Product Compliance: RoHS; CE (Europe)

Output Capacity (VA): 40000

Output Capacity (kVA): 40

Output Capacity (Watts): 40000

Output Capacity (kW): 40

Primary UPS Depth (mm): 841

Primary UPS Height (mm): 1,400

Primary UPS Width (mm): 490

Shipping Dimensions (hwd / in.): 64.60 x 28.50 x 39.80

Shipping Weight (lbs.): 925.90

Unit Dimensions (hwd / in.): 55.100 x 19.300 x 33.100

Unit Weight (lbs.): 844.4

Runtime Full Load (min.): 5.9 min. (40kW)

Runtime Half Load (min.): 15.5 min. (20kW)

Expandable Runtime: Yes

EMI / RFI AC Noise Suppression: Yes

AC Suppression Response Time: Instantaneous

Operating Temperature Range: 32° to 104°F (0° to 40°C)

Storage Temperature Range: 4° to 104°F (-20° to 40°C)

Relative Humidity: Up to 95%, non-condensing

AC Mode Efficiency Rating (100% Load): 95%

AC Economy Mode Efficiency Rating (100% Load): 99%

Audible Noise: Less than 60dBA at 1m front side

Operating Elevation (m): 0 to 1000m, but derates 1% per 100 m above 1000 m

UPS Housing Material: Steel

View in the file: Full Specifications

See other models: SUTX20K SUT60KMBP SUT40KMBP SUT30KMBP SUT20KMBPX
