Owner’s Manual
Digital Retro Coin Counter
Royal Sovereign International, Inc.
Please read and retain these instructions.
RC-20BL
CONTENTS
Read & Fully Understand This Owner’s Manual Before Using This Machine.
Thank you for purchasing the Royal Sovereign Digital Retro Coin Counter, RC-20BL. This
manual will provide you with safetyinformation, instructions for optimal use, and proper
care and maintenance for your product. Please read this manual carefully before
operating.
SAFETY INSTRUCTIONS
................................................................................ 3
PRODUCT VIEW
.......................................................................................... 4
PRODUCT OPERATION
................................................................................. 5
MACHINE MAINTENANCE
............................................................................. 8
TROUBLESHOOTING
................................................................
.................... 1
0
SPECIFICATIONS
........................................................................................ 11
WARRANTY
.............................................................................................. 1
2
2
SAFETY INSTRUCTIONS
When using this appliance follow these safety precautions to reduce the risk of fire, electric shock, or injury.
WARNING
1. Do not operate the machine for any purpose other than its intended use.
2. When using the machine, place it on a sturdy and level work place.
3. Do not allow any other materials to enter except coins.
4. Do not alter the construction or design.
5. Do not operate the machine if the electrical plug or power cord is damaged.
6. Do not alter the electric plug in anyway.
7. The machine should be placed near the electrical outlet so that the outlet is easily accessible.
8. Do not immerse the machine in water or permit liquid to get inside the machine.
9. Turn off the power when unattended or not in use. Unplug the machine before moving it or when it is not
in use for an extended period of time.
3
SAFETY INSTRUCTIONS
PRODUCT VIEW
4
Hopper
Coin Tubes
Control Panel
$/#
CLEAR
MODE
RUN/STOP
LCD DISPLAY
Q
1. Plug the pronged end of the adapter cord into the adapter plug on the side of the unit.
Plug the adapter into a standard wall unit.
2. Insert preformed coin wrappers (sold separately) into the corresponding tubes (A).
3. Press the “RUN/STOP” button to start coin counting (B)
4. Place loose change into the hopper (C).
*IF MACHINE SLOWS DOWN CONSIDERABLY, DO NOT ADD MORE COINS UNTIL MACHINE
RECOVERS IN SPEED!*
QUICK START GUIDE
5
For More Detailed Instructions, Go To Page 6
A B
Q
1. Place the machine on a level work surface.
2. Plug the pronged end of the adapter cord into the adapter plug on the side of the unit. Plug
the adapter into a standard wall unit.
3. Insert preformed coin wrappers
(sold separately) into the corresponding coin tubes.
4. Press the “RUN/STOP” button to start the machine.
5. Gradually insert coins into the coin hopper. Coins will begin to sort into the corresponding
coin tubes.
6. Press the “$/#” button to switch between total dollar amount or individual coin count view.
Press the “MODE” button at any time to switch between Quarters, Pennies, Nickels, and
Dimes.
7. When a coin tube is full, the machine will stop temporarily. To remove filled wrappers, pull
up on the exposed edge of the plastic tube and remove. Then, push the coin wrapper up
from the bottom of the tube and fold the edges of the wrapper.
8. Place a new wrapper into the coin tube and return the tube back in place.
9. Press the “RUN/STOP” button to reset the data for the tube that was full. Press the
“RUN/STOP” button again to restart the machine.
10. After sorting is finished, press the “RUN/STOP” button to stop the machine. Press the
“CLEAR” button to reset the display.
PRODUCT OPERATION
6
COIN QUANTITY DOLLAR AMOUNT
Pennies 50 $0.50
Nickels 40 $2.00
Dimes 50 $5.00
Quarters 40 $10.00
MODEL RC-20BL
Dimensions 5.9” x 6.2” x 8.1”
Speed 120 coins per minute
Motor Type DC Motor
Power Consumption 3W
Power Supply 100-240V 50/60HZ Adapter
Weight 1.3 lbs.
SPECIFICATIONS
11
COIN WRAPPER AVAILABILITY
Royal Sovereign offers a wide variety of coin wrappers to suit your coin sorting needs. Royal
Sovereign coin wrappers come in sizes of 112, 504, and 1,008. Within each size, Royal
Sovereign offers packs that are assorted and by denomination (Quarter, Penny, Nickel, and
Dime). Royal Sovereign coin wrappers come preformed and crimped on one end to provide
easy and hassle free coin wrapping.
Royal Sovereign International, Inc. warranties this product to be free from defects in material and workmanship
for a period of one (1) year. This warranty is extended to the original purchaser only.
This warranty only covers products that are properly installed, properly maintained, and properly operated in accordance
with the instructions provided. This limited warranty does not cover any failures or operating difficulties due to normal wear
and tear, accident, abuse, misuse, alteration, misapplication, improper installation, or improper maintenance and service by
you or any third party.
Returned product will not be accepted without a Return Authorization number. To request a Return Authorization number,
please visit us at www.royalsovereign.com. All transportation costs for the return of damaged product or parts will be the
responsibility of the purchaser. Return defective product, in original packaging, to the address below.
Royal Sovereign International, Inc. requires reasonable proof of your date of purchase from an authorized retailer or
distributor. Therefore, you should keep your receipt, invoice, or canceled check from the original purchase. The limited
warranty shall be limited to the repair or replacement of parts which prove defective under normal use and service within
the warranty period.
Royal Sovereign International, Inc. (and its affiliated companies) SHALL HAVE NO LIABILITY WHATSOEVER TO
PURCHASER OR ANY THIRD PARTY FOR ANY SPECIAL, INDIRECT, PUNITIVE, INCIDENTAL, OR CONSEQUENTIAL DAMAGES.
Some states do not allow the exclusion or limitation of incidental or consequential damages so the above exclusion and
limitations may not apply to you.
For product support and warranty questions, please visit us at
www.royalsovereign.com
ROYAL SOVEREIGN INTERNATIONAL, INC.
2 Volvo Dr., Rockleigh, NJ 07647 USA
TEL: 1-800-397-1025
Email: info@royalsovereign.com
12
ONE YEAR LIMITED WARRANTY
