• • Extract speed of 710 RPM spins clothes out drier
• • Integrated meter case
• • Advanced suspension system
• • Easy-to-read digital display
• • Cycle programming exibility
• • Multi-level vend pricing
• • Individual cycle modier keys
• • Durable stainless steel tub standard
• • 3.19 cu. ft. (90.3 liters) wash capacity
• • Large capacity meter case standard
• • Wash Alert™ capability
Quantum
®
Gold Pro Control
The Quantum
®
Gold Pro control delivers a truly premium
experience to residents. From intuitive soft touch buttons
that walk them through cycle options to multiple actuations
(coin, card, mobile) for payment exibility, this control gives
residents the wash and dry options they want, and the
revenue potential managers desire.
SPEED QUEEN
®
MULTI-HOUSING LAUNDRY SOLUTIONS
Top Load Washer
Built for Reliable Performance
Speed Queen’s two-speed top load washer, defined by its simplicity
and its performance, provides everything you need to get the job done
– and nothing you don’t. Speed Queen’s top load washer combines
heavy-duty construction with reliable operation proven to stand
the test of time. Speed Queen
®
washers provide maximum energy
efficiency and long-lasting performance.
• • Touch pad control with sound annunciator
• • 27 cycle selections
Quantum
®
Gold Pro
Prep for Card | Coin Drop Installed
Top Load Washer
Quantum
®
Gold Pro
AM21-0044
speedqueencommercial.com
Speed Queen by Alliance Laundry Systems
©2021 Alliance Laundry Systems LLC
* Average usage based on multiple load sizes and current DOE test protocol. Real usage will vary depending on load size, composition and cycle selectivity.
For the most accurate information, the installation guide should be used for all design and construction purposes. Due to continuous product improvements, design and specifications
subject to change without notice. The quality management systems of Alliance Laundry Systems are registered to ISO 9001.
A
B
C
A. Overall Width - in (mm)
25.625 (651)
B. Overall Depth - in (mm)
28 ( 711)
C. Overall Height - in (mm)
43 (1092)
Models Actuation
SWNNC2SP116TW01
Coin
Drop
Installed
SWNNY2SP116TW01
Prep for
Card
Specifications
Control Option
Quantum Gold Pro
Color
White
Capacity - lb (kg)
16 ( 7.3)
Overall Width - in (mm)
25.63 (651)
Overall Depth - in (mm)
28 (711)
Overall Height - in (mm)
43 (1092)
Cylinder Volume - cu. ft. (liters)
3.19 (90.3)
Spin Speed G-Force (RPM)
150 (710)
Motor Size - HP (kw)
0.5 (0.37)
Water Consumption Per Cycle - g (liter)*
28.07 (106)
IWF (Water Factor) - gal/ft³ (liters/liter/
cycle)*
8.8 (1.18)
MEF
J2
(Modied Energy Factor)
ft³/kWh/cycle (Liters/kWh/cycle)*
1.35 (38.2)
Available Water Temperatures
Cold, Warm, Hot
Available Cycles
Normal, Synthetic,
Delicate
Electrical Requirements (v/Hz/Ph-Amp)
120/60/1 - 15 Amp
Water Pressure - p.s.i. (bar)
20-120 (1.4/8.3)
Drain
Pump
Cylinder Finish
Stainless Steel
Net Weight - lb (kg)
206 (93.4)
Shipping Weight - lb (kg)
218 (98.8)
Shipping Dimensions
Approx. - in (mm)
Width
28 ( 711)
Depth
30 (762)
Height
45 (1143)
Agency Approvals
cULus
