VOLTAGE
120 VAC, 60 Hz
AMPS 12.5 Amps
WATTS 1500 Watts
PRODUCT SPECIFICATIONS
OPERATING INSTRUCTIONS
PACKAGE CONTENTS
ASSEMBLY INSTRUCTIONS
For Customer Service:
tsicustomerservice.com
(+1) 888-674-7517
8:30 a.m.-5:30 p.m., EST, Monday-Friday
Manufactured and distributed by Twin-Star
International, Inc., under license from Duraflame,
Inc. duraflame, the flame symbol and logo are
registered trademarks of Duraflame, Inc.
Twin-Star International, Inc.
Delray Beach, FL 33445
Note: When rst running the heater there may
be an odor. This is normal as the heater has a
surface coating on the internal parts. For the
rst several hours of operation, the coating
reacts with the internal parts to permanently
protect them. The odor is safe; if you are
sensitive to the odor, it is recommended
to run the heater in a well-ventilated area until
the odor dissipates.
Warning: This is an unvented, electric appliance.
DO NOT attempt to burn wood or manufactured
relogs in or on this appliance or grate.
Go to tsicustomerservice.com for product warranty registration
Remote Control
Control Panel
Location
Remote Receiver
-- POWER
-- FLAME
-- HEATER
-- TIMER
1.The power button supplies power to all of the stove functions. The power button will
put the stove in a standby mode. This will turn off all functions at once, but will hold
the settings in the memory. By pressing the Power button again, the unit will turn on
with the retained settings.
2.With the power on, press and hold the Power button on the control panel for 10
seconds to disable or re-enable the heater function. Once disabled or re-enabled, the
ember bed lights will ash multiple times.
3. Before the stove powers off, the fan will continue to run for a period of time to cool
down the internal parts.
OPERATING INSTRUCTIONS
1. There are 5 brightness levels that can be selected and OFF (00) setting.
2. Settings F5 - F1 decrease in brightness. Defaut is F5.
MOUNTING THE LEGS
1) Align the mounting tab into
the bracket and lower the
leg into place.
2) Fasten the leg to the bracket
using the included screws,
1 per leg.
Control Panel
1. The stove contains a fan forced infrared element heater.
2. The default temperature is 72°F(22°C ).
3. The thermostat setting range is 62°F - 82°F (17°C - 27°C) or continously ON or
OFF(00).
4. The thermostat is adjustable by 2°F or 1°C increments by pressing the HEATER button
on the control panel.
5. To change between °F and °C press and hold the HEATER button on the control panel
for 3 seconds.
1. Pressing the timer button will cycle through the timer settings: 30 minutes, 1 Hour,
2H, 3H, 4H, 5H, 6H, 7H, 8H, 9H and off (00).
The manufacturer warrants that your new Electric Stove is free from manufacturing and material defects for a period of one year from date of puchase, subject to
the following conditions and limitations.
1. Install and operate this Electric Stove in accordance with the installation and operating instructions furnished with the product at all times. Any unauthorized
repair, alteration, willful abuse, accident, or misuse of the product shall nullify this warranty.
2. This warranty is non-transferable, and is made to the original owner, provided that the purchase was made through an authorized supplier of the product.
3. The warranty is limited to the repair or replacement of part(s) found to be defective in material or workmanship, provided that such part(s) have been subjected
to normal conditions of use and service, after said defect is conrmed by the manufacturer’s inspection.
4. The manufacturer may, at its discretion, fully discharge all obligations with respect to this warranty by refunding the wholesale price of the defective part(s).
5. Any installation, labor, construction, transportation, or other related costs/expenses arising from defective part(s), repair, replacement, or otherwise of same, will
not be covered by this warranty, nor shall the manufacturer assume responsibility for same.
6. The owner/user assumes all other risks, if any, including the risk of any direct, indirect or consequential loss or damage arising out of the use, or inability to use
the product, except as provided by law.
7. All other warranties – expressed or implied –with respect to the product, its components and accessories, or any obligations/liabilities on the part of the manu-
facturer are hereby expressly excluded.
8. The manufacturer neither assumes, nor authorizes any third party to assume on its behalf, any other liabilities with respect to the sale of the product.
9. The warranties as outlined within this document do not apply to non accessories used in conjunction with the installation of this product.
10.This warranty gives you specic legal rights, and you may also have other rights which vary from state to state.
This warranty is void if:
a. The replace is subjected to prolonged periods of dampness or condensation.
b. Any unauthorized alteration, willful abuse, accident, or misuse of the product.
c. You do not have the original receipt of purchase.
IF WARRANTY SERVICE IS NEEDED
Contact the manufacturer by calling customer service department at 1-888-674-7517. Our Consumer Service
department is available Monday – Friday 8:30 am – 5:30 pm EST.
Make sure you have your warranty, your sales receipt, location of purchase and the model/serial number of
your product.
IMPORTANT INSTRUCTIONS
SAVE THESE
INSTRUCTIONS
Battery Replacement
When using electrical appliances, basic precautions should always be followed to reduce the risk of fire, electrical shock, and injury to persons including the following:
1-YEAR LIMITED WARRANTY
C2291
© 2021, Twin-Star International, Inc.
Delray Beach, FL 33445
MODEL: DFI-7122-01, DFI-7122-02, DFI-7122-03, DFI-7122-04,DFI-7122-05, DFI-7122-07
AAAA
PART DESCRIPTION QUANTITY
A Stove Main Body 1
B
Remote Control
1
C Legs 4
AA Assembly Screws TM4 x 12mm 4
AA
B
AA
BB
AAAA
A
A
C
AA
NOTE: Battery disposal
Please always dispose of batteries
at a suitable recycling point.
CAUTION:
• Do not ingest battery.
• Non-rechargeable battery are not to be recharged.
• Battery are to be inserted with the correct polarity.
• Exhausted battery are to be removed from the product.
• Always purchase the correct size and grade of battery most suitable for the
intended use.
• Clean the battery contacts and also those of the device prior to battery installation.
• Remove used battery promptly.
WARNING: Chemical Burn Hazard. Keep batteries away from children.
This product contains a lithium button/coin cell battery. If a new or
used lithium button/coin cell battery is swallowed or enters the body, it
can cause severe internal burns and can lead to death in as little as 2
hours. Always completely secure the battery compartment. If the battery
compartment does not close securely, stop using the product, remove the
batteries, and keep it away from children. If you think batteries might have
been swallowed or placed inside any part of the body, seek immediate
medical attention.
a)The cells shall be disposed of properly, including keeping them away
from children; and
b) Even used cells may cause injury.
1. Read all instructions before using this appliance.
2. This appliance is hot when in use. To avoid burns, do not let bare skin touch hot
surfaces. If provided, use handles when moving this appliance. Keep combustible
materials, such as furniture, pillows, bedding, papers, clothes and curtains at
least 3 feet (0.9 m) from the front of this appliance and keep away from the sides
and the rear.
3. CAUTION: Never leave the heater operating unattended. Extreme caution is
necessary if unsupervised children or people of reduced physical or mental
capabilities are nearby.
4. The appliance is not to be used by children or persons with reduced physical,
sensory or mental capabilities, or lack of experience and knowledge, unless they
have been given supervision or instruction.
5. Always unplug this appliance when not in use.
6. Do not operate any heater with a damaged cord or plug or after the heater
malfunctions, has been dropped or damaged in any manner. Discard heater,or
returnto authorized service facility for examination and/or repair.
7. Do not use outdoors.
8. This heater is not intended for use in bathrooms, laundry areas and similar indoor
locations. Never locate this appliance where it may fall into a bathtub or other
water container.
9. Do not run cord under carpeting. Do not cover cord with throw rugs, runners, or
similar coverings. Do not route cord under furniture or appliances. Arrange cord
away from trafc area and where it will not be tripped over.
10.To disconnect this appliance, turn controls to the off position, then remove plug
from outlet.
11.Do not insert or allow foreign objects to enter any ventilation or exhaust
opening as this may cause an electric shock or fire, or damage the
appliance.
12.To prevent a possible fire, do not block air intakes or exhaust in any
manner. Do not use on soft surfaces, like a bed, where opening may
become blocked.
13. This appliance has hot and arcing or sparking parts inside. Do not use it
in areas where gasoline, paint or flammable liquids are used or stored.
This stove should not be used as a drying rack for clothing. Christmas
stockings or decorations should not be hung in the area of it.
14.Use this appliance only as described in the manual. Any other use not
recommended by the manufacturer may cause fire, electric shock or injury
to persons.
15.This product is equipped with a polarized plug (one blade is wider than
the other blade). To reduce the risk of electrical shock, this plug will fit into
a polarized outlet only one way. This is a safety feature. If you are unable
to insert the plug into the electrical outlet, try reversing the plug. If the
plug still does not fit, contact a qualified electrician. Always plug heaters
directly into a wall outlet/ receptacle.Never use with an extension cord or
relocatable power tap( oulet/power strip).
