En-1
PART No. 9387081046
AIR CONDITIONER
Wall Mounted Type
OPERATING MANUAL
Before using this product, read these instructions thoroughly. Also, keep this manual for future reference,
together with the installation manuals for the indoor and outdoor units.
Safety Precautions
To prevent personal injury, or property damage, read this section carefully before you use this product, and be sure to comply with the following
safety precautions.
Incorrect operation due to failure to follow the instructions may cause harm or damage, the seriousness of which is classifi ed as follows:
WARNING CAUTION
This mark warns of death or serious injury. This mark warns of injury or damage to property.
Contents
Safety Precautions ..........................................................En-1
Indoor Unit Overview and Operations .............................En-2
Remote Controller Overview and Operations ..................En-3
Timer Operation...............................................................En-6
Human Sensor (Energy Saving) ......................................En-8
General Informations on Operation .................................En-9
Operating Tips .................................................................En-9
Cleaning and Care.........................................................En-10
Troubleshooting .............................................................En-12
WARNING
• This product contains no user-serviceable parts. Always consult
authorized service personnel for repairing, installation, and
relocation of this product.
Improper installation or handling will cause leakage, electric shock,
or fi re.
• In the event of a malfunction such as burning smell, immediately
stop operation of the air conditioner, and disconnect all the power
supply by turning off the electrical breaker or disconnecting the
power plug. Then consult authorized service personnel.
• Take care not to damage the power supply cable.
If it is damaged, it should only be replaced by authorized service
personnel.
• In the event of refrigerant leakage, be sure to keep away from fi re or
any fl ammables, and consult authorized service personnel.
• In the event of a thunder storm or any prior sign of a lightning strike,
turn off the air conditioner via the remote controller, and refrain from
touching the product or the power source to prevent any electrical
hazards.
• This appliance is not intended for use by persons (including
children) with reduced physical, sensory or mental capabilities, or
lack of experience and knowledge, unless they have been given
supervision or instruction concerning use of the appliance by a
person responsible for their safety. Children should be supervised to
ensure that they do not play with the appliance.
• Do not start or stop the operation of this product by inserting or
pulling out the power plug, or by turning on or off the circuit breaker.
• Do not use fl ammable gases near this product.
• Do not expose yourself directly to the cooling airfl ow for many hours.
• Do not insert your fi ngers or any other objects into outlet port, open
panel, or intake grille.
• Do not operate with wet hands.
CAUTION
• Provide occasional ventilation during use.
• Always operate this product with air fi lters installed.
• Ensure that any electronic equipment is at least 1 m (40 in) away
from either the indoor unit or outdoor unit.
• Disconnect all the power supply when you are not using this product
for extended periods.
• After a long period of use, ensure to get the mounting of the indoor
unit checked to prevent this product from falling down.
• The airfl ow direction and the room temperature should be carefully
considered when you use this product in a room with infants,
children, elderly or sick persons.
• Connection valves become hot during Heating; handle with care.
• Do not place any other electrical products or household belongings
under this product.
Dripping condensation from this product might get them wet, and
may cause damage or malfunction of your property.
• Do not expose this product directly to water.
• Do not use this product for preservation of food, plants, animals,
precision equipment, art work, or other objects. This may cause
quality deterioration of those items.
• Do not expose animals or plants to the direct airfl ow.
• Do not drink the drainage from the air conditioner.
• Do not pull the power supply cable.
• Do not touch the aluminum fi ns of heat exchanger built-in this
product to avoid personal injury when you maintain the unit.
• Do not direct the airfl ow at fi replaces or heating apparatus.
• Do not block or cover the intake grille and the outlet port.
• Do not apply any heavy pressure to radiator fi ns.
• Do not climb on, place objects on, or hang objects from this product.
EnglishFrançaisEspañol
9387081046_OM.indb 19387081046_OM.indb 13/4/2016 10:53:30 AM3/4/2016 10:53:30 AM
