Dual HDMI 1.4 Input Module
Key Features
● Fully modular architecture
● Support HDMI(with HDCP) inputs
● Input resolution up to 3840×2160@30Hz
● EDID management,support ultra width and height input
● Support hot swap
Specification
Connectors Input
2×HDMI-A
Performance Input Resolutions
SMPTE 720p@50/60 | 1080p@30/50/60 | 2160p@30
VESA 800×600@60 | 1024×768@60 | 1280×720@60 | 1280×800@60 | 1280×1024@60 |
1360×768@60 | 1366×768@60 | 1440×900@60 | 1400×1050@60 | 1600×1200@60 |
1680×1050@60 | 1920×1080@60 | 1920×1200@60 | 3840×2160@30
Supported Standard
HDMI 1.4
Physical Weight
0.3kg
Dimension
199.5mm×160mm×20mm
Order Codes
Dimensions
Product Code Item
791-0020-02-0 Dual HDMI 1.4 Input Module
Compatibility
This module can be used in the following products.
Product Code Item
711-0020-02-0-16 Q16pro-2U
711-0020-01-0-16 Q16pro-4U
711-0020-04-0-16 Q16pro-8U
711-0020-05-0-16 Q16pro-14U
711-0020-06-0-16 Q16pro-18U
711-0020-07-0-16 Q16pro-26U
Tel: +86-592-5771197 | Fax: +86-592-5788216 | E-mail: [email protected]
Headquarter: Room 601A, No. 37-3 Banshang community, Building 3, Xinke Plaza, Torch Hi-Tech Industrial Development Zone, Xiamen, China
Specifications are correct at time of printing and subject to change or alteration without notice.
