APEX
USER MANUAL
ELEC TRIC S C O O TER
Congratulations
on your purchase!
This user manual will help you assemble and
operate your new Electric Scooter. Be sure to read
ALL OF THE INFORMATION in this manual
before riding.
NOTE TO ALL RIDERS UNDER 18 YEARS OF
AGE:
permission before riding your electric scooter.
ALWAYS wear a helmet when riding your Electric Scooter.
Make sure your scooter has a full battery before taking it out to
ride.
Always be aware of local road laws, and follow them.
Do not
Always respect pedestrians.
Do not ride under wet conditions. The scooter may slide from under
your feet causing injury. Wet conditions may damage the electronics
Don’t ride until you read this
1. Avoid water - The scooter is not waterproof. The electronics may
in injury.
2. Abuse
extreme riding.
3. Whenever you ride the GOTRAX electric scooter , you risk
caution and ride at your own risk.
4. Do not
5. Keep
operating the scooter.
6. Before riding
scooter is operating correctly before each use.
7. Before riding - be sure to check that the braking system is functioning
properly; also be sure to check that all safety labels are in place and
you understand the safety warnings.
Warning Message
8. Before riding - be sure that any and all axle guards, chain guards, or
9. Before riding - be sure to check that the tires are in good condition,
10. Never exceed the 220 lb (100 kg) maximum load rating.
11. The electric scooter should never be used by children under the age of 13.
12. Maximum Speed - Your electric scooter goes the maximum speed of 15.5 mph.
Unpack
1. Electric Scooter
2. Console & Handlebars
4. 4mm Allen Wrench
6. Screws (x2)
1
2
3
4
6
5
Get to know your scooter
The electric scooter comes partially assembled.
Top Speed:
Distance per Charge:
Weight Range Up To:
Battery Type:
Battery Charger:
Charge Time:
Motor Power:
Power Requirements:
15.5mph
~15 Miles
220lbs
36V 6.0AH
DC 42V 1.5A
about 4 hours
250W
AC 100-240V ~ 50/60HZ
Handle bar
Accelerator
Handle Brake
Headlight
Bell
Charger port
Folding mechanism
Pedal
Motor
Fender buckle
Tiller
Hook
Safety latch
Ba�ery
Kickstand
Rear light/Brake light
Console
folding hook and fender buckle, then lift the tiller
trying to fold.
TOOLS YOU’LL NEED: 4 mm Allen Key Wrench (included).
Take the cord that is attached to the hook and
towards you and insert the round metal piece into
the solid piece of the handbrake. Make sure the
metal piece on the red cord is pushed fully into
the handbrake.
from the top of the tiller.
Assemble Your Scooter
4
Grab the red cord and hook and bring it back
behind the tiller and reattach the hook to the back
of the tiller using the screws and an Allen wrench.
( The red cord should go around the tiller.)
Charge Your Scooter
Before using the scooter, you must fully charge the battery.
2. Insert the charging plug into the port.
fully charged and a red light when charging.
charging port to keep it clear of dust and debris.
Charging Requirement: Make sure to charge your scooter in conditions
that do not exceed 104 degrees Fahrenheit or below 32 degrees
Fahrenheit.
Charging Time: about 4 hours
• To power the scooter on, press and hold the red button for 1
second.
• press and hold the red button for 5
seconds.
• press the red button for 1 second
while the scooter is powered on.
• The console on the Scooter displays speed in MPH, Battery life, and
headlight&tail light status.
Scooter Console Functions
* Error message
·E1: Communication failure
·E2: Error with the brake
·E3: Error with the transfer handles
·E5: Error with the control
1. You will want to start riding your electric scooter with one foot on the
platform and one foot on the ground. Use your foot on the ground
to push off and at the same time, press the throttle button to begin
movement.
2. Press the handbrake to slow down or stop.
3. The scooters perform best when on a smooth surface e.g. carparks,
smooth roads, footpaths, & bike lanes.
4. Always clean your scooter (wheels, platform..etc.), it’s a machine and it
needs to be maintained.
5. Do not press the throttle while walking with the scooter beside you.
6. Be aware of the terrain you are riding on, watch out for curbs and
obstacles!
7. Cruise Control: To activate the cruise control press the right-hand throttle
down for 10 seconds. To deactivate the cruise control press either the
right-hand throttle or brake button to deactivate the cruise control.
Riding Tips
8. Brake Light Status: The taillight is also the brake light. When you turn on the
headlight, the brake light will steady on. When you hold the handlebrake,
the taillight will quickly flash, reminding the vehicles and pedestrians behind.
Before folding the scooter, make sure that the scooter is powered off.
Folding: Ensure the electric scooter is powered off, hold the tiller and
pull out the spring pin on the right folding panel then rotate the spring
pin clockwise. Insert the hook on the tiller into the loop on the
rear fender buckle. You may hear a click which indicates that you were
successful in folding and locking the scooter.
Unfolding:
lock the folding mechanism.
Putting Your Scooter
Away/Folding
1 2
If you regularly clean and maintain your electric scooter, it will
extend its life.
Cleaning and storage: If the scooter is dirty, wipe it clean with a soft
damp cloth.
Brake Adjustments & Service: If you notice you need brake
team and we will adjust and repair your scooter. Do not repair your
scooter.
Tires:
Recommended PSI: 50
DO NOT
cause damage to the electronics.
Storage:
tires.
Maintenance & Repair
Tightening the Tiller: If you notice that the tiller is loose or wiggles while
Adjusting the Disc Brake: If the disc brake is too tight, use the 4MM
to extend the brake wire and retighten the screws. If the disc brake is too
loose, loosen the screws and pull the brake wire to extend the brake wire
and retighten the screws.
GOTRAX power adapter to charge your scooter,
Make sure to store your scooter and power adapter in conditions that do
not exceed 122 degrees Fahrenheit or below -4 degrees Fahrenheit.
Warning -
materials, store indoors when not in use.
Battery Information
GOTRAX.com
rights to update and change manuals online.
Please contact our customer service team if you are
experiencing problems or need more detailed information.
They can be reached at GOTRAX.com
Warranty
GOTRAX.com .
Troubleshooting
W W W .GO TRAX. C O M
#RideGOTRAX
GOLABS, INC
GOTRAX.com
2201 Luna Rd.
Carrollton, TX 75006
