Mi
dd
l
e
1. Comb hair and remove tangles.
Add the largest attachment guard to
the clipper.
2. Start at hairline on side of head
and cut up to middle of head. Note:
If cut hair is too long, repeat
with next smaller guard.
3. Continue around head repeating step 2. 4. You are now ready to cut
the middle portion of the hair.
5. Use the attachment guard with the
next highest number than in step 3.
Example: If you used a #6 guard in
step 3, select guard #7.
6. Continue cutting around middle
portion of head as in steps 2 and 3.
7. For cutting top of head, use the
attachment guard with the next highest
number than in step 6. Start at front bang
area.
8. Cut across top of head. Comb hair
on entire head to assess if further
cutting is necessary.
Attach the “R” RIGHT attachment guard to the
clipper as directed.
Starting BEHIND the right ear (so shorter
portion of guard fingers are closest to the
ear), move the clipper upward and around
towards the front side of the ear repeating as
necessary. (Fig A)
Keep the “R” attachment guard on clipper.
Starting on the FRONT of the left ear (so
shorter portion of guard fingers are closest to
the ear), move the clipper upward and around
towards the back side of the ear repeating as
necessary. (Fig B)
The cutting length of the
ear taper guards range
from 3/16” (#1-1/2”) to
1/4” (#4).
Remove the “R” RIGHT attachment guard and
attach the “L” LEFT attachment guard.
Starting BEHIND the left ear (so shorter
portion of guard fingers are closest to the
ear), move the clipper upward and around
towards the front side of the ear repeating as
necessary. (Fig C)
Keep the “L” attachment guard on clipper.
Starting on the FRONT of the right ear (so
shorter portion of guard fingers are closest to
the ear), move the clipper upward and around
towards the back side of the ear repeating as
necessary. (Fig D)
STEP-BY-STEP GUIDE FOR CUTTING HAIRTIPS & TECHNIQUES
CLIPPER MAINTENANCE
When you cut your hair, you should visualize the head as if it were divided
into four sections. Image below shows the different sections. Using proper
techniques when moving from one section to the next will help you blend the
sections together for professional looking results.
• The first time you cut hair, cut only a small amount of hair until you become
accustomed to the length of hair each attachment guard provides.
• For best results, hair should be dry before using clipper.
• For best results, when cutting hair, go through hair at a slow, even speed.
Don’t force the clipper through the hair.
• For best results, go through the hair against the direction of your hair’s growth,
so you can catch more hair with the guard.
• The blades on your new clipper should be oiled every few haircuts.
Model
PVCM
For Household Use Only
Model
MC3
Model
79050
Model
79610
Models
MC, MC2,
CNT2-M
SC, SC2
(No taper lever)
Model number can be
found on the underside
of the clipper.
EASY-TO-USE ATTACHMENT GUARDS
WARRANTY
Section 2:
Under the rim
of the head
Section 4:
Top of the head
Section 1:
The neckline
Section 3:
The rim or side
5-YEAR LIMITED WARRANTY
Valid in U.S.A. Only. If your Wahl product fails to operate satisfactorily within five (5) years
from the date of original purchase or receipt as a gift, Wahl will, at our option, repair or
replace the product and return it to you FREE OF CHARGE.
ELITE PRO / PRO SERIES / LIFEPROOF PRO CLIPPERS ONLY
LIMITED LIFETIME WARRANTY (EXCLUDES BLADES)
Valid in U.S.A. Only. If your Wahl product fails to operate satisfactorily, Wahl will, at our
option, repair or replace the product and return it to you FREE OF CHARGE.
REFURBISHED CLIPPERS
Valid in U.S.A. Only. If your Wahl product fails to operate satisfactorily within 90 days from
the date of original purchase or receipt as a gift, Wahl will, at our option, repair or replace the
product and return it to you FREE OF CHARGE.
HOW TO GET WARRANTY SERVICE
Do not return this product to store where purchased. Products needing repair under this
warranty should be returned with postage prepaid to:
Wahl Clipper Corp.
Attn: Repair Department
3001 Locust Street
Sterling, Illinois 61081
Or, call 1-800-767-9245 for assistance.
When mailing, please include a note describing the defect and the date of original purchase or
receipt as a gift. Product out of warranty will be repaired at our standard repair charges.
WHAT THIS WARRANTY DOES NOT COVER
This warranty does not cover products damaged by: (1) Modification or repair by anyone
other than Wahl Clipper Corporation or a Wahl authorized service center; (2) Commercial
(non-consumer) use or unreasonable use.
This warranty gives you specific legal rights, and you may also have other rights which
vary from state to state. No other written express warranty is given. No responsibility is
assumed for incidental or consequential damages of any type or for the use of unauthorized
attachments. Some states may not allow the exclusion or limitation of incidental or
consequential damages, so the limitation may not apply to you. Warranty valid in U.S.A. only.
Outside U.S.A., check with store for Wahl authorized distributor’s warranty.
© 2 022 WAHL CLIP PER COR POR ATION
P.O. Box 5 78 , St erli ng, Illino is 6108 1 USA
Artwork #91585-1101
v20 22.03
ADDING:
While holding at a slight angle, place the
attachment guard onto the clipper so the tips
of the blade rests into the slots of the guard
fingers. (fig A)
Using your thumb, push down on the guard,
where the guard size number is located, until
you hear a “SNAP”. (fig B)
REMOVING:
While holding the top of attachment guard,
place your thumb on the underside of the
attachment guard tab. Push up on tab to
remove guard from clipper. (fig C)
1. No attachments needed.
Start with the sideburns.
2. Continue around ear as
shown.
3. Trim neckline as shown.
When you want to blend from one section to the next, you will need to practice moving the
clipper in an upward rocking motion. This motion will leave the hair slightly longer where the
clipper pulls away from the scalp, enabling you to blend between the sections and achieve
a smooth transition from one length of hair to the next. This technique will enhance the
appearance of your haircuts.
1. Blend out any cut lines.
Lines may form where you
change guard sizes. Use the
same guard used in step 3
3. Using the guard used in
step 8 repeat blending the
top outline as needed.
2. Using a rocking motion,
blend out the middle cut
line.
BUILT-IN TRIMMER
CUSTOMER SUPPORT
ATTACHMENT GUARDS:
Not all kits include the guards shown below
Attachment guards help you cut hair to a desired length by keeping the blades at a set distance
from the skin, helping ensure an even hair length after cutting hair with a guard attached to the
clipper. For easy reference, each guard is numbered and lists what length the hair will be after
being cut using the noted size guard. Always start with a longer length guard (you can always
use a shorter length guard if the length is not short enough). The first time you cut hair, cut
only a small amount of hair until you become accustomed to the length of hair each attachment
guard provides. To achieve an even “tapered” cut around the ears, use the LEFT and RIGHT
tapered attachment guards. To trim eyebrow hair, use the BROW trim attachment guard.
Before adding or removing guards from clipper, make sure the on/off switch is turned off
(or in “0” position). Not all kits include all the different size and style of guards listed in this
instruction sheet.
Your kit will include a set
of either ‘Standard’ or ‘Elite’
attachment guards.
Use clipper or battery trimmer (not all kits include a trimmer).
CONVERT TO A TRIMMER:
CNT2-M Clipper Only
• Open your detail trimmer by unsnapping the detail trimmer lid (Fig 1).
• Guide the detail trimmer lid over the clipper blade (like adding an attachment guard). The
clipper blade must be positioned between the trimmer lid and detail trimmer guide fingers
(Fig 2).
• Press down on the top center of detail trimmer lid to snap onto the clipper blade (Fig 3).
Do not push on the detail trimmer blade.
CONVERT BACK TO A CLIPPER:
• Unsnap the detail trimmer lid from the clipper blade by lifting the back of the trimmer
lid (like removing an attachment guard) Fig (4). Lift the detail trimmer lid around the
detail clipper blade.
• Close your detail trimmer by tucking the detail trimmer blade down starting on top side
(Fig 5).
• Snap into place by pressing down on the top center of detail trimmer lid (Fig 6).
• When exposed to excessive force such as
dropping, the detail trimmer is designed to
pop off rather than break. To re-attach your detail
trimmer, simply snap the detail trimmer arm
back into place (Fig 7).
CORD / PLUG:
The cord should not be used to pull the clipper. Since freedom of movement needs to be
maintained, care should be used to keep the cord untwisted and unobstructed. YOUR
CLIPPER HAS A POLARIZED PLUG: To reduce the risk of electric shock, this appliance
has a polarized plug (one plug blade is wider than the other). This plug fits in a polarized
outlet only one way. In the event the plug doesn’t fit fully in the outlet, reverse the plug. DO
NOT CHANGE THE PLUG IN ANY WAY.
MAXIMUM POWER SETTING:
MC, SC, SC2, MC2, CNT2-M, MC3 Clippers Only
ADJUSTING POWER SCREW FOR MAXIMUM POWER SETTING:
1) Turn your clipper “ON”
2) Use the end of your detail cleaning brush or a screwdriver to turn power screw in a
CLOCKWISE direction until you start to hear a clattering noise.
3) Then turn the power screw in the opposite (counterclockwise) direction at least ¼ turn
(clattering sound should have stopped).
IF YOUR CLIPPER IS TOO NOISY:
MC, SC, SC2, MC2, CNT2-M, MC3 Clippers Only
(A) Oil blades as directed in previous portion of instruction booklet
(B) You can reduce the “clatter sound” by adjusting the power screw. The power screw was
adjusted for peak efficiency before leaving the factory. However, if voltage in your home is
too high or low, the clipper power screw may need adjustment.
ADJUSTING POWER SCREW TO REDUCE CLIPPER NOISE (excessive clattering):
1) Turn your clipper “ON”
2) Use the end of your detail cleaning brush or a screwdriver to turn power screw in a
COUNTER CLOCKWISE direction until clatter goes away.
TAPER LEVER:
MC, MC2, CNT2-M, MC3, PVCM, 79050 Clippers Only
The taper lever adds versatility to your clipper by allowing
you to gradually change the closeness of your cut, ideal for
blending and fading. Lever in “Up” Position = Closest Cut;
Lever in “Down” Position = Longest Cut. Should the blades
become jammed with hair, move the taper lever up and down
several times to help free up the blades.
REMOVING BLADES: 79610 Clippers Only
Before removing blades, make sure the on/off switch is
turned to the “0” or “OFF” position.
• Hold the clipper in both hands. Using both thumbs,
push the blades away from the front of the clipper.
• The blade set with the top and bottom blades
will come off in one piece.
ATTACHING BLADES: 79610 Clippers Only
Before reattaching blades, make sure the on/off switch is turned to
the “0” or “OFF” position.
• Place the blade at an angle (with the bottom portion of blade
fitting into the clipper) so the outer white clips of the blade set sit
just below the metal clips inside the clipper. Make sure blade is
center aligned with clipper.
•
While holding the bottom of the blade, push the blade onto the
clipper with your thumb until blade “snaps” into place. Don’t
use excessive force to push blade into place.
OIL BLADES:
The blades on your new clipper
should be oiled every few haircuts.
When oiling your clipper, turn the clipper “ON - I,”
hold the unit with the blades facing DOWN and squeeze
three drops across the front of the blade and one drop
on each side on the heel of the blade. Wipe off excess
oil with soft cloth.
NOTICE—DO NOT OVER OIL!
Excessive oiling or application of liquids will cause
damage if allowed to seep back into motor.
DO NOT USE HAIR OIL, GREASE, OR ANY OIL
MIXED WITH KEROSENE OR ANY SOLVENT.
Corded
Home
Haircutting
BLENDING
DETAILING / OUTLINING
Find us on social media:
@WAHLGROOMING
wahlUSA.com
1.800.767.9245help@wahlclipper.com
DETACHABLE BLADES:
79610 Clippers Only
CLEANING BLADES:
Use the cleaning brush(es) provided to remove hair from between the blades. DO NOT USE
WATER TO CLEAN THE BLADES. For best results, after brushing the blades, add Wahl
clipper oil to the blades.
(fig 1) (fig 2) (fig 3)
(fig 6)(fig 5)
(fig 7)
(fig 4)
Standard Elite
SPECIALTY ATTACHMENT GUARDS:
Not all kits include the guards shown below
EAR TAPER GUARDS:
Standard
Elite
fig. C
fig. A
fig. D
fig. B
Standard
Elite
(fig B) (fig C)(fig A)
BROW TRIM
GUARDS
Attach the BROW attachment guard to
the clipper as directed above.
For longer cut length, start from just
above your nose and slowly guide the
clipper to the outside of your face.
For shorter cut length, start from
outside of face and slowly guide
clipper to the inside of your face.
Blades (1) Detachable Blades (2) Taper Lever (3)
Cord (4) On/Off Switch (5) Power Screw (6)
1
1
1
1
4
4
4
4
4
6
6
5
5
5
5
5
2
3
3
3
3
Clipper How-To
Info
Clipper Replacement
Parts & Accessories
Digital Copy of
Instruction Book
ALIGNING CLIPPER BLADES:
MC, SC, SC2, MC2, CNT2-M, MC3, PVCM, 79050 Clippers Only
Your Wahl clipper blades were oiled and aligned before leaving our factory. Blades may
need to be realigned if they have been bumped or removed for cleaning. To determine if
realignment is necessary, compare your clipper blades with this sketch.
1) If your clipper has a taper lever, position the lever in the closest cut (up) position.
2) End of top (small) blade teeth should be approximately 1/32-inch (.64 mm) back from bottom
(large) blade.
3) Extreme left-hand tooth of top blade must be covering or to the left of the first small tooth
of bottom blade.
4) Extreme right-hand tooth of top blade must be touching the big tooth on the bottom blade.
If blade alignment is incorrect, add a few drops of Wahl Clipper Oil to the blades, turn
clipper “ON” for a few moments, turn “OFF” and unplug. Loosen screws slightly and
adjust. Tighten screws after blades are aligned. Other than blades, this clipper has no user-
serviceable parts.
Loading ...
Loading ...
Loading ...
