OIL:
The blades on your new clipper should be oiled every few haircuts. Place a few drops of Wahl
Clipper Oil on the teeth (front) as well as at the back side of the blade. Use only Wahl Clipper
oil (a small bottle is included in this kit, additional oil can be purchased separately, see www.
grooming.Wahl.com for details). DO NOT USE HAIR OIL, GREASE, OR ANY OIL
MIXED WITH KEROSENE OR ANY SOLVENT.
IF YOUR CLIPPER IS TOO NOISY:
(A) Oil blades as directed in previous section of this
instruction booklet.
(B) You can reduce the “clatter sound” by adjusting the
power screw. The power screw was adjusted for peak
efficiency before leaving the factory. However, if voltage in
your home is too high or low; the clipper power screw may
need adjustment.
ADJUST POWER SCREW TO REDUCE CLIPPER NOISE
(excessive clattering):
1. Turn your clipper “ON”
2. Use the end of the cleaning brush or a screwdriver to turn power screw in a COUNTER
CLOCKWISE direction until clatter goes away.
ADJUST POWER SCREW FOR MAXIMUM POWER SETTING:
1. Turn your clipper “ON”
2. Use the end of the cleaning brush or a screwdriver to turn power screw in a CLOCKWISE
direction until you hear a clattering noise.
3. Then turn power screw in opposite direction (COUNTER CLOCKWISE) until clattering
stops.
CORD:
The cord should not be used to pull the clipper. Since freedom of movement needs to be
maintained, care should be used to keep the cord untwisted and unobstructed.
YOUR CLIPPER HAS A POLARIZED PLUG: To reduce the risk of electric shock, this
appliance has a polarized plug (one plug blade is wider than the other). This plug fits in a
polarized outlet only one way. In the event the plug doesn’t fit fully in the outlet, reverse the
plug. DO NOT CHANGE THE PLUG IN ANY WAY.
CLEANING:
To remove hair from between the blades, use the cleaning brush provided. DO NOT USE
WATER TO CLEAN THE BLADES. For best results, after brush cleaning the blades,
add Wahl clipper oil to the blades.
ALIGNING CLIPPER BLADES:
Your Wahl clipper blades were oiled and aligned before leaving our factory. Blades may need
to be realigned if they have been bumped or removed for cleaning. To determine if realignment
is necessary, compare your clipper blades with this sketch.
1. If your clipper has a taper lever, position the lever in the closest cut (up) position.
2. End of top blade teeth should be approximately 1/32-inch (.64 mm) back from bottom blade.
3. Extreme left-hand tooth of top blade must be covering or to the left of the first small tooth
of bottom blade.
4. Extreme right-hand tooth of top blade must be touching the big tooth on the bottom blade.
If blade alignment is incorrect, add a few drops of Wahl Clipper Oil to the blades, turn clipper
“ON” for a few moments, turn “OFF” and unplug. Loosen screws slightly and adjust. Tighten
screws after blades are aligned. Other than blades, this clipper has no user-serviceable parts.
TAPER LEVER:
The taper lever adds versatility to your clipper by
allowing you to gradually change the closeness of your
cut. (Up position = closest cut; Down position = longest
cut). Should the blades become jammed with hair, move
the taper lever up and down several times. This will help
free up the blades.
fig. C
7
8
5
6
5. Use the attachment guard with the next
highest number than in step 3. Example:If
you used a #6 guard in step 3, select
guard #7.
6. Continue cutting around middle
portion of head as in steps 2 and 3.
7. For cutting top of head, use the guard with
the next highest number than in step 6. Start at
front bang area.
8. Cut across top of head. Comb hair on entire
head to assess if further cutting is necessary.
fig. B
fig. A
Home
Haircutting
When you cut your hair, you should visualize the head as if it were divided into four
sections. Image below shows the different sections. Using proper techniques when
moving from one section to the next will help you blend the sections together for
professional looking results.
• The first time you cut hair, cut only a small amount of hair until you become
accustomed to the length of hair each attachment guard provides.
• For best results, hair should be dry before using clipper.
• For best results, when cutting hair, go through hair at a slow, even speed. Don’t
force the clipper through the hair.
• For best results, go through the hair against the direction of your hair’s growth,
so you can catch more hair with the guard.
• The blades on your new clipper should be oiled every few haircuts.
Section 2:
Under the rim
of the head
Section 4:
Top of
the head
Section 1:
The neckline
Section 3:
The rim
or side
TIPS & TECHNIQUES
1. Comb hair and remove tangles. Attach the
largest attachment guard to the clipper.
2. Start at hairline on side of head and cut
up to middle of head.
Note: If cut hair is too long repeat with next
smaller guard.
3. Continue around head repeating step 2.
4. You are now ready to cut the
middle portion of the hair.
STEP-BY-STEP GUIDE FOR CUTTING HAIR
When you want to blend from one section to the next, you will need to practice moving the
clipper in an upward rocking motion. This motion will leave the hair slightly longer where
the clipper pulls away from the scalp, enabling you to blend between the sections and achieve
a smooth transition from one length of hair to the next. This technique will enhance the
appearance of your haircuts.
1. Blend out any cut lines.
Lines may form where you
change guard sizes. Use the
same guard used in step 3
3. Using the guard used in
step 8 repeat blending the top
outline as needed.
2. Using a rocking motion,
blend out the middle cut line.
Please register your Wahl Clipper online at: grooming.wahl.com
Purchase Confirmation-
With the information you provide, we confirm the date of purchase of your
product. This confirmation is of benefit to you, especially if your original proof
of purchase is lost.
Proof of Ownership-
Your UPC number, item number and other information will be kept in our files
for up to ten years.
WARRANTYBLENDING
3-YEAR LIMITED WARRANTY - CORDED CLIPPER
Valid in U.S.A. Only
If your Wahl product fails to operate satisfactorily within three (3) years from the date of original
purchase or receipt as a gift, Wahl will, at our option, repair or replace it and return it to you
FREE OF CHARGE.
2-YEAR LIMITED WARRANTY - BATTERY TRIMMER
Valid in U.S.A. Only
If your Wahl battery trimmer product fails to operate satisfactorily within two (2) years from the
date of original purchase or receipt as a gift, Wahl will, at our option, repair or replace it and
return it to you FREE OF CHARGE.
Do not return this product to store where purchased. Products needing repair under
this warranty should be returned with postage prepaid to: Wahl Clipper Corp. Attn: Repair
Department - 3001 Locust Street, Sterling, Illinois 61081
Include a note describing the defect and the date of original purchase or receipt as a gift (if in
warranty). Products out of warranty will be repaired at our standard repair charges.
This warranty is void and no repair or replacement will be made under this warranty or otherwise
if: (1) The product is modified in any manner or repaired by anyone other than Wahl Clipper
Corporation or Wahl authorized service center. (2) The product has been used commercially or
subjected to unreasonable use.
This warranty gives you specific legal rights and you may also have other rights which may vary
from state to state. No other written express warranty is given. Any implied warranty, including
any warranty of merchantability which may arise from purchase or use, is limited to the year
period provided in this express warranty. Some states may not allow such limitation, so it may
not apply to you. No responsibility is assumed for incidental or consequential damages of any
type, or for the use of unauthorized attachments. Some states may not allow the exclusion or
limitation of incidental or consequential damages, so the limitation or exclusion may not apply to
you. Outside U.S.A., check with store for Wahl authorized distributor’s warranty.
Question? contact us at:
www.grooming.wahl.com or 1-800-767-9245
© 2017 WAHL CLIPPER CORPORATION
P.O. Box 578, Sterling, Illinois 61081 USA
Printed in China
Part #56527-400 v.2017.01
Clipper Blades
On/Off Switch
Cord Strain Relief
Power Cord
YOUR NEW BATTERY TRIMMER
YOUR NEW CLIPPER
fig. A
fig. A
fig. B
fig. B
To achieve a “tapered” cut around the ears, use the left and right tapered attachment guards
EARS
Some kits do not include ear taper guards.
• Attachment guards help you cut hair
to a desired length by keeping the
blades at set distance from the skin
helping ensure an even hair length
when cutting hair with a clipper. For
reference, each guard is numbered and
also lists what the length of the hair
will be after being cut.
• Attachment guard sizes vary. Always
start with a longer length guard (you
can always use a shorter length guard
if the length is not short enough).
• The first time you cut hair, cut
only a small amount of hair until
you become accustomed to the
length of hair each attachment
guard provides.
EASY-TO-USE ATTACHMENT GUARDS
ADDING GUARDS: Pictured in g A & g B
Some kits do not include all size Wahl guards.
CLIPPER MAINTENANCE
#
1
/2
-
(1.5mm)
1
/16”
#
1
-
(3mm)
1
/8”
#
1
1
/2
-
(4.5mm)
3
/16”
#
2
-
(6mm)
1
/4”
#
3
-
(10mm)
3
/8”
#
4
-
(13mm)
1
/2”
#
5
-
(16mm)
5
/8”
#
6
-
(19mm)
3
/4”
#
7
-
(22mm)
7
/8”
#
8
-
(25mm) 1”
Right Ear Taper
Left Ear Taper
1. No attachments needed.
Start with the sideburns.
2. Continue around ear as
shown.
3. Trim neckline as shown.
Taper Lever
(not on all units)
Home
Haircutting
OUTLINING
grooming.wahl.com
2
3
Middle
4
2) Repeat, except now using the “L” LEFT guard. Attach the “L” LEFT attachment guard to the
clipper.
fig. A) First, starting behind the LEFT ear (so shorter portion of guard fingers are closest
to the ear), move the clipper upward and around towards the front side of the ear.
Repeat as needed.
fig. B) Second, starting on the front of the RIGHT ear, (so shorter portion of guard
fingers are closest to the ear), move the clipper upward and around towards the
back side of the ear. Repeat as needed.
1) Attach the “R” RIGHT attachment guard to the clipper.
fig. A) First, starting behind the RIGHT ear (so shorter portion of guard fingers are
closest to the ear), move the clipper upward and around towards the front side of
the ear. Repeat as needed.
fig B) Second, starting on the front of the LEFT ear, (so shorter portion of guard fingers
are closest to the ear), move the clipper upward and around towards the back
side of the ear. Repeat as needed.
Before adding guards, make sure the on/off switch is
turned to the “0” or “OFF” position.
1. While holding at a slight angle, place the attachment
guard onto the clipper so the tips of the blade rests
into the slots of the guard fingers. (fig A)
2. Using your thumb, push down on the guard, where
the guard size number is located, until you hear a
“SNAP”. (fig B)
REMOVING GUARDS: Pictured in g C
Before removing guards, make sure the on/off switch is
turned to the “0” or “OFF” position.
1. While holding the top of attachment guard, place
your thumb on the underside of the attachment guard
tab. Push up on tab to remove guard from clipper.
(fig C)
BATTERY INSTRUCTIONS
Select clipper kits include a battery trimmer,
your kit may or may not include a trimmer
1. Remove battery cover from trimmer by pushing in and back on the plastic door in the
direction of the arrow.
2. IMPORTANT: Be sure to insert the negative (-) end of each battery first, so that it depresses
the spring at the top of the battery compartment. Then slide the positive (+) end into
position. Do not allow the negative terminal clips to bend and cut the casing of the batteries.
Use alkaline batteries with your Wahl Trimmer. Alkaline batteries will provide the longest
operating time before battery replacement is needed. Trimmer should run approximately three
hours on alkaline batteries.
3. Replace battery cover to its original position.
4. Move switch to “ON” position to use.
5. To maximize battery life, trimmer should be shut “OFF” immediately after using.
