RF30BB6602
Bespoke Energy Efficient 3-Door French Door Refrigerator
(30 cu. ft.) with Beverage Center
™
Design
• Customizable Door Colors
• Modern Design
• Recessed Handle
Performance
• Dual Ice Maker with Ice Bites
• 30 cu. ft. Capacity
• Twin Cooling Plus
Technology
• Beverage Center
™
• Wi-Fi Enabled
ADA Compliant
ADA
Compliant
Rating
ENERGY STAR
®
rated:
545 kWh/yr
Bespoke 3-Door French Door Standard Color Models
Signature Features
Our Most Efcient Model Ever
This refrigerator uses 545 kw/year, a 22% reduction in energy consumption
compared to similar models.
Customizable Door Colors
Customize the design of your refrigerator with changeable door panels.
Choose from a variety of colors and two nishes to create a space that
ts your style.
Beverage Center
™
Quick access to refreshingly cool, ltered water two ways. Choose from
an internal dispenser or a built-in pitcher that automatically rells, with
the option to infuse with a avor.
Stainless Steel - All Panels
Actual color may vary. Design, specifications, and color availability are subject to change without notice. Non-metric weights and measurements are approximate.
©2022 Samsung Electronics America, Inc., 85 Challenger Road, Ridgeeld Park, NJ 07660. Tel: 800-SAMSUNG. samsung.com. Samsung is a registered trademark of Samsung Electronics Co., Ltd.
RF30BB6602
Bespoke Energy Efficient 3-Door French Door Refrigerator
(30 cu. ft.) with Beverage Center
™
Installation Specifications
Dimensions
Measure height
including flooring.
Be sure to allow
for hinge clearance
height if needed.
Measure width
including
countertop
overhang.
Measure depth
including
molding or trim.
21 3/8"
3 3/8"
35 3/4"
7⁄ 16"
55 1/8"
29 7/8"
33 3/4"
36 1/4"
1 3/8"
22 1⁄ 4" 9 1⁄ 16"
69 7⁄ 8"
35 1⁄ 8"
5/8"
7/16"
2 3/8"
1. Measure the height, width and depth of the opening, making sure to include baseboards,
molding tile, countertop overhang, etc. Check to be sure there is enough room to open
the door (consider walls, islands or other obstacles when measuring).
2. Refer to illustration below to determine dimensions.
3. Allow 2.5" of clearance on hinge side of refrigerator when installing next to a wall
where handle may make contact.
4. Allow 1" minimum clearance at rear for proper air circulation and water/electrical
connections. Allow a 3/8" minimum clearance at sides and top for ease of installation.
5. Ensure each door and entryway in the home is wide enough for the refrigerator
to be moved through easily.
For optimal usage and ability to open refrigerator doors completely,
do not install next to a wall.
Please note: The following dimension and cutout information is for planning purposes only.
For complete installation details, consult manual packed with product, or download manual
online at samsung.com.
Dimensions
58
1
/
2
"
11
3
/
8
"
125° 125°
2"
29
3
/
8
"
A
B
35
3
/
4
"
6
8
7
/
8
"
D
70"
34
1
/
4
"
53
1
/
4
"
48
1
/
²
"
35
3
/
4
"
2
1
/
8
"
29
3
/
8
"
58
1
/
2
"
11
3
/8"
125° 125°
2"
29
3
/
8
"
A
B
35
3
/
4
"
68
7
/
8
"
D
70"
34
1
/
4
"
53
1
/
4
"
48
1
/²"
35
3
/
4
"
2
1
/
8
"
29
3
/
8
"
58
1
/
2
"
11
3
/8"
125° 125°
2"
29
3
/
8
"
A
B
35
3
/
4
"
68
7
/
8
"
D
70"
34
1
/
4
"
53
1
/
4
"
48
1
/²"
35
3
/
4
"
2
1
/
8
"
29
3
/
8
"
Total Capacity: 30.1 cu. ft.
Refrigerator: 21.1 cu. ft.
• 4 Tempered Glass Spill-Proof Shelves
• 2 Clear Drawers, Including Crisper+
• 2 Large Pantry Drawers
• 8 Door Bins
Right: 1 Gallon Bin, 3 Regular Bins
Left: 4 Regular Bins
• Surface Lighting
Freezer: 9.0 cu. ft.
• Dual Ice Maker in Freezer (Cubed Ice AND Ice Bites)
• Ice Bucket with Cover and 1 Scoop
• Produces up to 5.3 lbs ice/day, stores up to 9.9 lbs
• High Efciency LED Lighting
Accessories
Water Filter: HAF-QIN
Warranty
One (1) Year Parts and Labor on Refrigerator
Five (5) Years Parts and Labor on
Sealed Refrigeration System Only*
Ten (10) Years Parts and Five (5) Years
Labor on Digital Inverter Compressor
*Compressor, evaporator, condenser, drier and connecting tubing.
Product Dimensions
Dimensions (WxHxD with hinges and doors):
35
3
/
4
" x 70" x 34
1
/
4
"
Dimensions (WxHxD without hinges and door):
35
3
/
4
" x 68
7
/
8
" x 29
3
/
8
"
Shipping Dimensions (WxHxD)
Dimensions: 38
1
/
4
" x 75
3
/
4
" x 36
1
/
4
"
Stainless Steel -
All Panels
RF30BB6602QL 887276794297 332.9 357.1
Color Model # UPC Code Product & Shipping
Weight (lbs)
