JBL Consumer Products
250 Crossways Park Drive, Woodbury, NY 11797
8500 Balboa Boulevard, Northridge, CA 91329
800-336-4JBL (4525) (USA only)
www.jbl.com
©2001 JBL, Incorporated.
JBL is a registered trademark of JBL, Incorporated.
Part No.
ai5146
DESIGN GOAL: Bring the thrill of live performance and movie sound to
the home environment bycalling on JBL’s professional engineering leadership.
SATELLITE TYPE: Titanium-laminate-dome tweeter, sealed enclosure
SUBWOOFER TYPE:
Bass-reflex enclosure
PORT DESIGN:FreeFlow™ flared
PROFESSIONAL REFERENCE: Cinema Loudspeaker Series
OWNER’S GUIDE
PRO SOUND
COMES HOME
™
PRODUCT LINE:
Surround Cinema Speakers
MODEL
SCS135
NUMBER:
SPECIFICATIONS
All features and specifications are subject to change without notice.
* Dolby and Pro Logic are trademarks of Dolby Laboratories.
DTS is a registered trademark of Digital Theater Systems, Inc.
SCS135 System
Frequency Response
35Hz – 20kHz (–6dB)
Satellites
Recommended Power
10 – 100 watts
Impedance
8 ohms nominal
Sensitivity
86dB @ 1 watt/1 meter
Tweeter
One 1/2"titanium-laminate
dome, video-shielded
Midrange
One 3" driver, video-shielded
Dimensions (H x W x D)
4-3/8" x 3-3/16" x 3-3/4"
111mm x 81mm x 95mm
Weight
1.1 lb/0.5kg
Center
Recommended Power
10 – 100 watts
Impedance
8 ohms nominal
Sensitivity
86dB @ 1 watt/1 meter
Tweeter
One 1/2"titanium-laminate
dome, video-shielded
Midrange
Dual 3" drivers, video-shielded
Dimensions (H x W x D)
3-1/4" x 7-5/8" x 3-3/4"
83mm x 194mm x 95mm
Weight
1.89 lb/0.86kg
Subwoofer
Amplifier
100 watts RMS
Bass
8" woofer, bass-reflex
enclosure
Dimensions (H x W x D)
15" x 13" x 14"
381mm x 330mm x 356mm
Weight
30 lb/13.6kg
