Steering Wheel Control Instruction & Setup:
1.Connect your vehicle’s existing steering wheel control cables
to the unit, then navigate to the receiver’s CAR SETTINGS
menu:
2.Once in CAR SETTINGS, navigate to STEERING WHEEL:
3.Select STEERING WHEEL and the interface will appear
as below:
4.Select BEGIN LEARN for the system to begin automatically
programing the buttons and functions, syncing your steering
wheels controls to the receiver system:
5.A steering wheel control button has been successfully
programed, or “learned”, once there is a green icon displayed
to the left of the button’s icon. You may have to press and hold
the desired icon buttons to initiate the programing between the
steering wheels controls and the receiver system -- press and
hold the desired icon buttons until the green icon is displayed:
Wiring
6.Once the desired buttons are “learned” and programmed,
press END LEARN to save (your vehicle may not feature all of
the buttons listed on the receiver system display, therefore
some buttons may be unable to be successfully programmed):
Steering Wheel Control
Wiring
Trouble Shooting
