AR Blue Clean AR2N1 2050 Psi, 1.4 Gpm, 13 Amps Electric Pressure Washer

Product's Documents

Below are documents related to this product, you can read online or download:

ASSEMBLY, CARE AND USE INSTRUCTIONS

This is the main product document for model AR2N1. Additionally, the document applies to other AR Blue Clean models: AR 2N1-Q

The file format is pdf, 20 pages, you can download this manual here .

background
Questions, problems, missing parts?
Before returning to your retailer, call (1-866-235-5112)
or email (info@arnorthamerica.com) our customer
service department. They are available from 8:00 a.m. -
5:00 p.m., CST, Monday - Friday. www.arblueclean.com
ASSEMBLY, CARE AND
USE INSTRUCTIONS
Model AR 2N1-Q
READ CAREFULLY
IMPORTANT: RETAIN THESE INSTRUCTIONS
AND ATTACH RECEIPT TO MANUAL FOR FUTURE
REFERENCE.
94641-KN
2050 PSI
Electric Pressure Washer
background
2
TABLE OF CONTENTS
PRODUCT SPECIFICATIONS
TABLE OF CONTENTS
PRODUCT SPECIFICATIONS
Product Specications ...................................................................................................... 2
Package Contents ............................................................................................................. 3
Hardware Contents ........................................................................................................... 3
Safety Information ............................................................................................................. 4
Assembly Instructions ....................................................................................................... 6
Operating Instructions .....................................................................................................11
Care and Maintenance ................................................................................................... 14
Pump Saver ..................................................................................................................... 15
Troubleshooting ............................................................................................................... 16
Limited Warranty ............................................................................................................. 17
Replacement Parts List .................................................................................................. 18
SPECIFICATIONS
Model
Max PSI
(lbs/sq. in.)
Max GPM
(Gal/per min) Cold Water Volts
Frequerry
(H
z) Amps
Weight (lbs.)
AR 2N1-Q 2050 1.4
120 60 13 36.8
background
3
PACKAGE CONTENTSPACKAGE CONTENTSPACKAGE CONTENTS
HARDWARE CONTENTS
PART DESCRIPTION QUANTITY
K Spray Gun 1
L Spray Gun Trigger Lock 1
M Spray Gun Holster 1
N High Pressure Hose 1
O Nozzle Cleaning Wire 1
P Foam Cannon 1
AA Axle Pins 2
BB Screws 2
CC Screws 2
DD Cotter Pins 2
PART DESCRIPTION QUANTITY
A Hose Holder 1
B Handle 1
*C Rotary Nozzle 1
D O-Ring Replacement Kit 1
*E Quick Connect Nozzles 4
F Power Washer Unit 1
G Lower Frame 1
H Nozzle Holder 1
*I Extension Lance 1
J Wheels 2
AA
BB
CC
DD
Screws
Qty. 2
Axle Pins
Qty. 2
Screws
Qty. 2
Cotter Pins
Qty. 2
2050
MAX PSI
1.4
MAX GPM
B
F
M
A
N
K
J
*C
*I
L
H
G
O
AA
BB
CC
DD
D
PW909383SS
*E
Soap – Black
0° – Red
15° – Yellow
25° – Green
P
*Packaged on the power washer unit.
background
4
SAFETY INFORMATIONSAFETY INFORMATIONSAFETY INFORMATION
Please read and understand this entire manual before
attempting to assemble and operate the product.
This manual contains information that relates to
PROTECTING PERSONAL SAFETY and PREVENTING
EQUIPMENT PROBLEMS. It is very important to read this
manual carefully and understand it thoroughly before
using the product. The symbols listed below are used to
indicate this information.
DANGER
Potential hazard that will result in serious injury or
loss of life.
WARNING
Hazard that could result in serious injury or loss of
life.
CAUTION
Potential hazard that may result in moderate injury
or damage to equipment.
Note:
The word “Note” is used to inform the reader of
something the operator needs to know about the tool.
WARNING
To reduce the risk of injury, the user must read
and understand the instructions before using
this product.
1. Warning – When using this product, basic
precautions should always be followed, including the
following.
2. Read all the instructions before using the product.
3. Know how to stop the product and bleed pressures
quickly. Be thoroughly familiar with the controls.
4. Keep operating area clear of persons.
5. Do not overreach or stand on unstable support. Keep
good footing and balance at all times.
6. Follow the maintenance instructions as specied in
the manual.
7. To avoid personal injury and/or damage to property
and to maximize your power washer experience,
carefully follow all of the safety tips, instructions,
warnings and safeguards and become familiar with
all of the controls. Be sure you know how to quickly
bleed off the pressure from all parts of your power
washer and how to turn off the power washer.
8. This power washer conforms to CSA and other safety
and consumer standards. DO NOT modify or rebuild
any part of your power washer.
9. DO NOT use your power washer when you are under
the inuence of alcohol or drugs. Use this power tool
carefully and only when you are alert.
10. Watch your balance and footing while using your
power washer. Surfaces become slippery when wet
and are extra slippery when using a detergent or
cleaner.
11. NEVER operate the power washer in bare feet,
sandals, or open-toed shoes.
12. When using the power washer near children, make
sure they are closely supervised by an adult to avoid
injury. NEVER let a child use the power washer.
13. Keep ngers, hands, feet and any part of your body
clear of the stream of high pressure water. The
powerful spray can cause blindness or blast holes in
the skin. It can break a window if you are too close
when you pull the trigger on the spray gun.
14. ALWAYS wear eye protection to prevent injury to
eyes when operating the power washer.
15. To avoid mishaps or injury, ALWAYS use the trigger
safety lock when not using the power washer even if
only stopping briey.
16. The power washer is equipped with a Ground Fault
Circuit Interrupter (GFCI) which greatly reduces the
chance of electric shock while the unit is in use. If
replacement of the plug or cord is needed, use only
identical replacement parts.
17. Point the spray gun in a safe direction when
beginning a power washer session.
18. Warning- NEVER spray directly at a person, animal,
electrical device or the unit itself.
19. When rst using the spray gun, hold the spray gun
and lance with two hands when pulling the trigger
(one hand to pull the trigger and the other to
stabilize the gun assembly) until you get used to the
“kickback” from the spray gun.
20. When you turn the power switch off, water pressure
may remain in the system. To discharge the
pressure, point the spray gun in a safe direction and
pull the trigger.
21. NEVER spray ammable liquids.
22. NEVER use the power washer in areas that contain
combustible dust, liquids or vapors.
23. Avoid contact of the pressure hose with sharp
objects and examine the hose regularly. Replace
if damaged. Due to the high pressure involved, it
cannot be repaired if cut or damaged.
24. Only use detergent specically formulated for power
washers and follow instructions on the detergent’s
label. Dish or laundry soap is too thick and will
clog the nozzle of your detergent bottle.
background
5
SAFETY INFORMATIONSAFETY INFORMATIONSAFETY INFORMATION
Double Insolated Product
KEEP THESE INSTRUCTIONS FOR FUTURE REFERENCE.
25. Protect eyes, lungs, and skin from exposure to
detergent.
26. Warning-If connection is made to a potable water
system, the system should be protected against
backow.
CAUTION
Store the power washer indoors to prevent the
water in the unit from expanding under freezing
conditions. When the water freezes and expands,
your power washer will be damaged and become
inoperable. Or, if storing outdoors, it is
recommended you use pump saver (not included)
to protect pumps.
27. NEVER use hot water with your power washer. It will
overheat and damage the high pressure pump.
28. NEVER leave the power washer unattended while it
is powered “ON”.
29. ALWAYS turn the water supply on before turning the
power washer power to on. Running the pump dry
will cause damage to the internal components.
30. NEVER use a water supply to your power washer
that exceeds 150 PSI maximum.
31. NEVER disconnect the high pressure hose from the
power washer while the system is pressurized.
32. NEVER permanently engage the trigger mechanism
on the spray gun.
33. NEVER operate the power washer unless all
components are properly and securely connected.
34. NEVER allow the power washer pump to run for
more than one minute after you have turned off the
water supply. This can cause the motor and pump to
overheat and fail.
35. NEVER use lances or other parts that are not
compatible for this specic AR Blue Clean unit.
36. NEVER use an extension power cord since it defeats
the effectiveness of the GFCI and increases the
chance of electrocuting the operator.
37. NEVER spray any electrical outlet with your power
washer.
38. Inspect the power cord before using. DO NOT use it
if it is damaged.
Servicing of a Double-Insulated Appliance
Ground Fault Circuit Interrupter Protection:
This pressure washer is equipped with a ground-fault
circuit-interrupter (GFCI) built into the plugs of the
power-supply cord. This device provides additional
protection from the risk of electric shock. Should
replacement of the plug or cord become necessary,
use only identical replacement parts that include GFCI
protection.
In a double-insulated product, two systems of insulation
are provided instead of grounding. Grounding means
are not provided for a double insulated product, nor
should grounding means be added to the product.
Servicing a double-insulated product requires extreme
care and knowledge of the system, and should only be
done by qualied service personnel.
Replacement parts for a double-insulated product must
be identical to the original parts.
A double-insulated product is marked with the words
“Double Insulation” or “Double Insulated”. Product may
also be marked with symbol shown here
.
background
6
PREPARATION
PREPARATION
Before beginning assembly of product, make sure all
parts are present. Compare parts with package contents
list and hardware contents list. If any part is missing or
damaged, DO NOT attempt to assemble the product.
Please call customer service at 1-866-235-5112.
Replacement parts will be sent no charge.
Estimated Assembly Time: 5 minutes.
Tools Required for Assembly (not included): Phillips
screwdriver.
ASSEMBLY INSTRUCTIONS
PREPARATION
Place a foot on the pad at the front of the lower
frame (G) and then lift the power washer unit (F) off
the frame. Set pressure washer (F) to the side.
2
1
1
F
G
Axle Pins
x 2
AA
1
1
2
2
G
J
AA
DD
Hardware Used:
Frame Assembly
Install axel pins (AA) and wheels (J) to lower frame (G).
Secure with cotter pins (DD).
DD
Cotter Pins
x 2
background
7
ASSEMBLY INSTRUCTIONS
1
3
2
G
H
BB
4
3
2
2
1
G
B
Install nozzle holder (H) to lower frame (G). Secure with
two screws (BB).
1
5
2
A
CC
B
Press buttons on lower frame (G) extensions and install
handle (B). Lower frame extensions will click when
handle is in proper position.
Install hose holder (A) onto back side of upper handle
(B). Secure with two screws (CC).
Screws
x 2
BB
Hardware Used:
Screws
x 2
CC
Screws
Hardware Used:
background
8
PREPARATIONASSEMBLY INSTRUCTIONS
6
B
M
Slide spray gun holster (M) into place on the
upper handle (B).
Place power washer unit (F) into position on the lower
frame (G).
7
F
G
8
1
2
F
G
Pull upward on latches that are located on
sides of lower frame (G). Once upper latch is ush with
the lower lip, push down until lower latch clicks into
place.
3
2
9
1
K
N
N
Pull back on collar at one end of the high pressure hose
(N). Push the center post on hose rmly into the spray
gun (K), then twist the collar on to secure the connec-
tion. Conrm the hose is locked into spray gun by trying
to lightly pull it away from the gun.
background
9
ASSEMBLY INSTRUCTIONS
Locking Spray Gun (before Lance installation) To lock
trigger of spray gun (K), point gun away from you and
turn dial to lock (“3” and “9” position). Squeeze or pull
trigger to make sure it is locked. Always leave in locked
position when not in use. This ensures the gun is in
“safe” mode until it is ready for use. Turn dial to unlock
(“12” and “6” position) to release spray gun trigger.
Note: The trigger lock prevents trigger from being
accidentally engaged.
10
K
1
Locked
Unlocked
ASSEMBLY INSTRUCTIONS
11
*I
K
1
2
12
*I
*E
*C
P
1
2
13
*I
*E
*C
P
Extension Lance installation
While spray gun (K) is in the locked position, insert
lance (*I) into the end of the spray gun and turn
clockwise until fully in place. To remove, turn
counterclockwise.
To remove nozzle (*E), foam cannon (P) or rotary nozzle
(*C), pull back on collar of lance (*I) and pull out nozzle,
foam cannon or rotary nozzle.
Attach nozzle (*E), foam cannon (P) or rotary nozzle (*C)
into end of lance (*I) by pressing selected nozzle, foam
cannon or rotary nozzle into place. It will make a “click”
sound when rmly in place.
Note: Always push safety lock button to lock trigger
when changing lances and nozzles to ensure that they
do not accidentally eject with force during removal.
background
10
ASSEMBLY INSTRUCTIONS
3
14
1
2
N
F
N
16
NF
Pull back on the collar at the other end of the high
pressure hose (N). Push the exposed center post of
the hose rmly into the power washer’s water outlet on
the right side of the machine, then twist the collar to
secure it. Conrm the hose is secure by trying to lightly
pull it away from the machine.
Insert extension lance (*I) into nozzle holder (H), and
press spray gun (K) with extension lance (*I) into spray
gun holster (M).
2
1
M
*I
K
15
P
A
17
Attach a garden hose to built in garden hose
adapter. The water is now connected to your power
washer.
Note: Flush out garden hose before connecting to
garden hose adapter.
Insert foam cannon (P) into hose holder (A) by pressing
into the slot in the back nozzle.
You have now completed the assembly and are ready
to begin using your electric power washer. Read and
observe all safety instructions.
background
11
OPERATING INSTRUCTIONS
Push the power button to turn the unit on (green
power light will turn on). The unit will turn on for 1 - 2
seconds and shut off. This is a normal function of
the auto start feature.
Begin power washing by squeezing the trigger on the
spray gun all the way into the handle.
Release the spray gun trigger to stop the power
washer.
Allow the motor to come to a complete stop before
squeezing the trigger again.
OPERATING INSTRUCTIONSOPERATING INSTRUCTIONS
Make sure the power switch is off.
Unwind the power cord completely and plug
into a grounded 120 volt outlet.
Turn on water supply at the faucet to completely
open.
Turn the safety lock button on the spray gun to
unlocked. While pointing the spray gun in a safe
direction, squeeze the trigger on the spray gun until
there is a steady stream of water, letting the water
and air out of the hose.
OFF ON
K
lock
Squeezing and releasing the trigger rapidly will cause
the auto start feature to miss an on/off cycle that
may prevent it from turning on properly. Use slow,
deliberate trigger pulls to avoid this.
Always test a small area to avoid chance of damaging
the surface.
background
12
OPERATING INSTRUCTIONS
When using the foam cannon, ll it with a properly
formulated detergent or cleaner with water ratio
according to instructions on the container.
The power washer will pull a ratio of water to
detergent of 10:1 or 10 parts water to 1 part
detergent. The detergent concentration can be
adjusted by turning the detergent knob on the top of
the machine. Turn it left for more concentration or
turn it right for less concentration.
DO NOT use thick gel-like detergents as they will clog
the soap nozzle or the foam cannon and can cause
damage.
OPERATING INSTRUCTIONS
When using detergent (not included), ll the
detergent tank with a properly formulated detergent
or cleaner with water ratio according to instructions
on the container. Close detergent tank when done
lling.
When removing the detergent tank, squeeze the
clamp and remove the small hose from detergent
tank. Pull the detergent tank straight out. To replace
tank, push straight in and then reattach hose with
clamp.
When using detergent tank, use soap nozzle to
draw detergent from tank. Do NOT use with Foam
Cannon.
background
13
OPERATING INSTRUCTIONSOPERATING INSTRUCTIONS
3
2
1
Removing Power Washer Unit from Frame for
Handheld Operation
Locate latches on the lower side of frame. Unlock
latches by pulling downward on the latches. Place a
foot on the pad at the front of the lower frame and
then lift the power washer unit off the frame.
Operation Tips
If you hear the motor run intermittently when the
trigger is not being squeezed, that is normal.
The pump is priming itself so it is ready to operate
when the trigger is squeezed. Turn off the power
washer if not being used after ve minutes.
Keep the nozzle cleaning wire for use in unclogging
the nozzle. If you lose the cleaning wire, a
straightened paper clip also works.
How to Avoid Damaging Surfaces
Damage to surfaces being cleaned occurs because
the impact force of the water pressure exceeds
the durability of the surface. Bare wood can be
penetrated, paint can be peeled off, etc. You can vary
the force of your power washer by controlling:
1. The angle of the surface being cleaned.
2. The distance of the nozzle from the surface being
cleaned.
Never use a narrow high pressure stream of water on
soft surfaces susceptible to damage.
Use the 25˚ angle quick connect nozzle when
cleaning windows. Be sure to place the nozzle
approximately 4 to 5 ft. away from the window with
the nozzle at 45° angle. Squeeze the trigger and vary
the spray pattern and angle until optimum cleaning
efciency is achieved.
Using Power Cord
Remove the power cord from the unit by swiveling the
cord hook to the right or left. The power cord then can
be slid off to either side of the power washer unit.
Swivel cord hook back to center when ready to wrap
the cord back into place for storage.
background
14
OPERATING INSTRUCTIONS
Cleaning Garden Hose Adapter
The screen inside the adapter should be cleaned
periodically. Remove it by dragging a thumb over the
screen with enough pressure to pull the screen and
washer out. Rinse it with clean water and then place
it back in the adapter.
Cleaning Nozzles
A clogged or partially clogged nozzle can cause
signicant reduction of water pressure coming out
of the nozzle and/or cause the unit to pulsate while
spraying.
Turn off the unit.
Turn off the water supply to the unit.
Relieve any pressure trapped in the hose by
squeezing the trigger 2 - 3 times, then lock the spray
gun by turning the dial to lock (“3” and “9” position).
• Remove the nozzle from the spray gun.
Using the nozzle cleaner wire provided (or an unfolded
paper clip), insert the wire into the nozzle hole and
move back and forth until debris is dislodged.
Back ush water through the nozzles using garden
hose and highest pressure available (either standard
water nozzle or use your thumb over the nozzle to
create water pressure for back ush).
Detergents
Use detergents designed for power washers.
Hardware stores or home centers also have power
washer detergents for different cleaning projects. The
cleaning solution should be the consistency of water
in order to prevent clogging your detergent bottle and
nozzle.
This system applies detergent under low pressure.
The cleaning power of the detergents is enhanced
when applied with low pressure and enough time is
given to break down dirt and grime. The combination
of low pressure and chemical action is very effective
and can be better than scrubbing if applied properly.
Always spray detergent on a dry
surface. Do not pre-soak area. Wetting the surface
rst dilutes the detergent and reduces its cleaning
ability. Do not allow detergent to dry on surface. On
vertical surfaces being cleaned, apply detergent
to lower surfaces and work your way up to prevent
detergent from causing streaks in the dirt and grime.
Rinse detergent by pressure washing from bottom up
for same reason.
If a stain is particularly tough, it may be necessary
to reapply the detergent and use a bristled brush to
scrub the stain. Power washing after brushing should
successfully clear the stain.
CARE AND MAINTENANCE
background
15
OPERATING INSTRUCTIONS
Storage
When your pressure washer session has been
completed, turn off the power switch. Unplug the
power cord from the outlet. Turn off the water supply.
Pull the trigger on the spray gun 2-3 seconds to drain
out the excess water and to release any remaining
water pressure. Do not allow the power washer to run
with no water owing through it.
Remove high pressure hose from spray gun and
unscrew the other end of the high pressure hose from
the power washer.
Remove lance from the gun. Place the gun in the
holster on the side.
Make sure to discard any remaining detergent from
the tank. Residual chemical will stick to the container
which could become contaminated, and can cause
the detergent injector to clog and not function
properly. Flush the tank and nozzle head with clear
water to prevent clogging.
Wind the power cord around the L-shaped hooks
located on the top of the machine.
The pressure hose is stored on the hose hook located
on the back of the handle.
DO NOT store the power washer where it is
exposed to freezing temperatures unless you use
an antifreeze designed for pumps. Store the power
washer indoors to prevent the water in the unit from
expanding under freezing conditions. When the
water freezes and expands, your power washer will
be damaged and become inoperable. Or, if storing
outdoors, it is recommended you use pump saver (not
included) to protect pumps.
CARE AND MAINTENANCE
OPERATING INSTRUCTIONSVERPUMP SAVER
Pump Saver is a product that protects and prolongs
the life of the pump. This will keep the internal parts
of the pump lubricated and protected from freezing
while being stored in ALL climates. It also assists with
protection from internal corrosion. The AR Blue Clean
part #is: PW64511(16oz. bottle). Order online at
www.arblueclean.com
Pump Saver Instructions
Turn unit off and disconnect the hose and gun before
adding pump saver. Unscrew threaded top from bottle
to remove seal and reattach threaded top to bottle.
Remove black cap from bottle.
1) Place top of pump saver bottle onto the garden hose
adapter previously installed on the pressure washer
inlet.
2) Secure pump saver bottle by turning in a clockwise
direction.
3) Turn the power on.
Note: Instructions on Pump Saver Bottle are generic and
not model specic.
4) Squeeze bottle to help it into the pump.
5) Turn power off when pump saver exits the machine’s
water outlet.
1
2
background
16
TROUBLESHOOTING
PROBLEM CORRECTIVE ACTION
Unit will not turn on.
1. The GFCI module on the end of the power cord must be plugged directly into an outlet.
2. Do not use an extension cord.
3. With the GFCI connected make sure the power switch is turned on.
Note: When power switch is turned on, the power washer will turn on by itself for 1-2
seconds and shut off. This is normal.
The unit is running
but there is no water
ow.
1. Power should NOT be turned on until water comes through the spray gun. Doing so will
damage the motor.
2. Check the water source.
3. Eject the nozzle from the lance to determine if clog is coming from the nozzle. (If nozzle
is clogged, see nozzle cleaning instructions under “Cleaning nozzles”.)
4. Take off the lance and just spray out of the spray gun. This will indicate if the problem is
with the lance.
5. Check garden hose adapter for loose connection and the lter for debris.
Why is water leaking
where the high
pressure hose
connects to the spray
gun?
1. Make sure there is an o-ring at the end of the metal tip of the high pressure hose.
If no o-ring is present, the connection between the hose and spray gun will leak. A
Replacement O-Ring Kit is included in your parts. If you require additional O-rings,
O-Ring Kits are available online at www.arblueclean.com or call Customer Service at
1-866-235-5112 to place an order.
The power washer
turns on for
2 seconds, shuts
off, and will not turn
back on. Do I have a
defective unit?
1. When the water is connected, the accessories are assembled properly, and the power
is turned on, the power washer may turn on for 1 - 2 seconds to prime the pump. It
automatically shuts off and waits for the spray gun trigger to be pressed. When the
trigger is pressed, water starts owing through the pump. The water sensor in the pump
“senses” the moving water and automatically turns the power washer on.
2. To perform a “reset”. Turn the power switch to off. Hold the trigger on the spray gun so
that you have a steady stream of water. While still holding the trigger, turn the power
switch on.
TROUBLESHOOTING
If you have any questions regarding the product, please call customer service at 1-866-235-5112
background
17
TROUBLESHOOTINGLIMITED WARRANTY
This product has a 2 (two) year warranty. Please read the following carefully to understand what each warranty
entails:
This product is under warranty to the original retail consumer against defects in material and workmanship for a
period 1 (one) year and is a complete “bumper to bumper” warranty including the spray gun, the high pressure
hose and all accessories from the date of purchase. The warranty is not transferable or assignable. This warranty
covers replacement parts. This limited one year warranty applies only to products used in consumer applications
and is void in rental or any commercial application. Reasonable care must be used in conformity with operation
and maintenance instructions in the owner’s manual. Failure to follow these instructions will void this warranty. This
warranty gives you special legal rights and you may also have other rights which vary from state to state.
The second year of the warranty only covers manufacturer defects.
Warranty Process
Keep your original receipt of purchase in case of warranty claim.
If your power washer develops a problem, contact Customer Service:
Call our toll-free number at
1-866-235-5112. Customer Service is available Monday - Friday, 8:00 a.m. - 5:00 p.m.,
Central Standard Time (CST). A Customer Service Representative will work with you to x the problem.
If the power washer needs to be returned for repair, shipping costs must be paid by the customer. A Return
Merchandise Authorization (RMA) Number will be issued for the return. Upon receiving the power washer, the
company will repair or replace the unit. We will send unit back to customer at no charge.
Please note: Power washers sent to the company without an RMA Number will NOT be accepted and will be
shipped back at the expense of the sender.
background
18
REPLACEMENT PARTS LIST
Printed in China
PART DESCRIPTION PART #
H 0° QC Nozzle PW4221430
I 15° QC Nozzle PW4221440
J 25° QC Nozzle PW4221450
K Axle Pin PW4620370
L Cotter Pin PW4620380
M Garden Hose Adapter PW4221580
N Foam Cannon PW4620260
PART DESCRIPTION PART #
A Rotary Nozzle PW4220680
B O-Ring Replacement Kit PW909383SS
C Extension Lance PW3400960
D Wheel PW4620430
E Spray Gun PW4620420
F High Pressure Hose PW4221550
G Soap QC Nozzle PW4221470
Soap – Black
0° – Red
15° – Yellow
25° – Green
F
K
G
B
PW909383SS
A
E
C
M
D
L
H
I
J
N
For replacement parts, call our customer service department at 1-866-235-5112, 8:00 a.m. - 5:00 p.m., CST,
Monday - Friday or order online at www.arblueclean.com
background
19
background
20

Specifications

AR Blue Clean AR2N1 Questions and Answers
