USER MANUAL
WQE5600, WQE5650, WQE5660
REFRIGERATOR
2 www.westinghouse.com
WE’RE THINKING OF YOU
Thank you for choosing Westinghouse. We have designed this product to make your life
simpler and deliver impeccable performance for many years. Please spend a few minutes
reading this document to get the best from your new Westinghouse appliance.
Visit our website to:
Get usage advice or service information:
www.westinghouse.com
Register your product for better service:
www.westinghouse.com/support/register-warranty
Buy Accessories, Consumables and Original spare parts for your appliance:
https://shop.westinghouse.com.au/
CUSTOMER CARE AND SERVICE
Always use original spare parts.
When contacting our Authorised Service Centre, ensure that you have the following
data available: Model, PNC, Serial Number.
The information can be found on the rating plate.
Customer care cantact : Call 13 13 49
Warning / Caution-Safety information.
General information and tips.
Environmental information.
Subject to change without notice.
Register your product for better service:
www.electrolux.com/productregistration
Buy Accessories, Consumables and Original spare parts for your appliance:
www.electrolux.com/shop
Warning / Caution-Safety information.
General information and tips.
Environmental information.
Thank you for choosing this Electrolux product. We have created it to give you
impeccable performance for many years, with innovative technologies that help
make life simpler features you might not find on ordinary appliances. Please spend
a few minutes reading to get the very best from it.
Always use original spare parts.
When contacting our Authorised Service Centre, ensure that you have the follow-
The information can be found on the rating plate.
CONTENTS
1. SAFETY INFORMATION ....................................................................................................................3
2. DESCRIPTION OF THE APPLIANCE ..............................................................................................5
3. INSTALLING YOUR NEW APPLIANCE ..........................................................................................8
4. TEMPERATURE CONTROL .............................................................................................................. 11
5. STORAGE FEATURES ....................................................................................................................... 16
6. CONNECTING THE WATER SUPPLY............................................................................................ 19
7. AUTOMATIC ICE &WATER DISPENSER ....................................................................................... 21
8. GENERAL INFORMATION ...............................................................................................................23
9. FOOD STORAGE GUIDE ..................................................................................................................25
10. TROUBLESHOOTING .................................................................................................................... 26
11. NOISES ............................................................................................................................................... 30
3EN
1. SAFETY INFORMATION
Note: You must read these warnings carefully
before installing or using the refrigerator. If you
need assistance, contact your customer care centre.
The manufacturer will not accept liability, should
these instructions or any other safety instructions
incorporated in this book be ignored.
WARNING
• It is essential the electric outlet is properly
earthed to ground. Consult a qualified
electrician if you are unsure.
• Do not use electrical appliances inside the
food storage compartments of the
appliance, unless they are of the type
recommended by the manufacturer.
• Unplug the refrigerator before cleaning or
moving it to avoid electric shock.
• Never unplug the refrigerator by pulling the
electrical cord as this may damage it. Grip
the plug firmly and pull straight out.
• If the power cord is damaged, it must be
replaced by the manufacturer, its service
agent or similarly qualified persons in order
to avoid a hazard.
• Don’t use a steam cleaner. If livecomponents
come into contact with condensing steam,
they may short-circuit or cause an electric
shock.
• Do not store explosive substances such as
aerosol cans with a flammable propellant
this appliance. If pressurised aerosol
containers bear the word ‘flammable’ and/or
a small flame symbol, do not store them
inside any refrigerator or freezer.If you do so
you may cause an explosion.
• Do not damage the refrigerant circuit.
• This appliance contains insulation formed
with flammable blowing gases. Avoid safety
hazards by carefully disposing of this
appliance.
• If you wish to discard this refrigerator, please
contact your local authorities and ask for the
correct method of disposal.
• When you dispose of your old refrigerators
and freezers, remove any doors. Children
can suocate if they get trapped inside.
• When positioning the appliance, ensure the
supply cord is not trapped or damaged.
• Do not locate multiple portable socket-
outlets or portable power supplies at the rear
of the appliance.
WARNING
R600a refrigerant warning
This appliance contains flammable
R600a refrigerant. Avoid safety
hazards by carefully installing,
handling, servicing and disposing
of this appliance.
• Ensure that the tubing of the refrigerant
circuit is not damaged during transportation
and installation.
• Leaking refrigerant may cause eye injuries or
ignite.
• The room for installing appliance must be
at least 1m
3
per 8g of refrigerant.The amount
of refrigerant in the appliance can be found
on the rating plate inside the appliance.
• If you are unsure of the refrigerant check the
rating plate inside the refrigerator compartment.
• It is hazardous for anyone other than an
Authorised Service Person to service this
appliance. In Queensland Australia the
Authorisation Service Person MUST hold
a Gas Work Authorisation for hydrocarbon
refrigerants to carry out servicing or repairs
which involve the removal of covers.
• Keep ventilation openings in the appliance
enclosure or in the built-in structure, clear of
obstruction.
• Do not use mechanical devices or other
means to accelerate the defrosting process,
other than those recommended by the
manufacturer.
• The maximum inlet water pressure 689 kPa
(100 psi), the minimum inlet water pressure
206 kPa (30 psi), if this is necessary for the
correct operation of the appliance.
4 www.westinghouse.com
GENERAL WARNINGS
Read the following carefully to avoid damage
or injury. It is important to use your refrigerator
safely. Check these safety points before using your
refrigerator.
• The appliance must be plugged into its own
dedicated electrical outlet.
• The plug must be accessible when the
refrigerator is in position.
• It is essential the powerpoint is properly
earthed to ground. Consult a qualified
electrician if you are unsure.
• Don’t use extension cords or adapter plugs
with this refrigerator.
• If the supply cord is damaged, it must be
replaced by the manufacturer, its service
agent or similarly qualified persons in order
to avoid a hazard.
• Unplug the appliance before cleaning and
before changing the light bulb(when fitted) to
avoid electric shock.
• Never unplug the refrigerator by pulling the
electrical cord as this may damage it. Grip
the plug firmly and pull straight out.
• Choose a location for your refrigerator that
isn’t too cold. The ambient room temperature
should be above 10°C.
• Stand your refrigerator in a dry place avoid
areas of high moisture or humidity.
• Don’t put the refrigerator in frosty or
unprotected areas like a garage or on the
verandah.
• Don’t plug your refrigerator into a timer fitted
to the powerpoint.
• Do not put the refrigerator in direct sunlight,
near stoves, fires or heaters.
• Do not put the refrigerator on an uneven
surface.
• Do not store flammable materials on or
under the appliance, e.g. aerosols.
• Do not store explosive substances such as
aerosol cans with a flammable propellant in
this appliance.
• Never store fizzy drinks in the freezer
compartment.
• Never try to repair the refrigerator yourself,
only use a qualified or authorised service
person for repairs.
• Never use electric heaters or dryers to
defrost the freezer because you can receive
an electric shock.
• When transporting and installing the
refrigerator, care should be taken to ensure
that no parts of the refrigerating circuit are
damaged.
• When installed correctly, your refrigerator
should:
– Have adequate space at the back and
sides for air circulation.
– Be vertically aligned to the surrounding
cupboards.
– Have doors that will self-close from a
partially open position.
• The appliance is not to be used by persons
(including children) with reduced physical,
sensory or mental capabilities, or lack of
experience and knowledge, unless they have
been given supervision or instruction concerning
use of the appliance by a person responsible for
their safety.
• Children being supervised not to play with
the appliance.
NOTE: You must read these warnings carefully
before installing or using the refrigerator. If you
need assistance, contact your Customer Care
Department. The manufacturer will not accept
liability, should these instructions or any other safety
instructions incorporated in this book be ignored.
ENVIRONMENTAL INFORMATION
This appliance is intended to be used in
household and similar applications such as,
• The kitchen areas in shops, offices and
other working enviroments;
• Farm house and by clients in hotels,
motels and other residential type
enviroments;
• Bed and breakfast type environments;
• Catering and similar non-retail
applications;
5EN
2.1 QUATTRO FRENCH DOOR REFRIGERATOR FEATURES
WQE5600 illustrated
1
1
2
3
1
1
1
3
12
13
1313
1313
4
5
5
6
7
8 8
10
11
9 9
1
Door Bins*
2
Door Bin Small*
3
Bottle Storage Bins
4
Egg Tray
5
Spillsafe™ Glass shelves
6
Wine Rack
7
UI Control Panel (on the left side wall)
8
Fresh Seal Manual Humidity Control Drawer
9
Fresh Drawer
10
Twist & Serve
11
Ice Bin
12
Ice Storage Bin
13
Freezer Drawer
2. DESCRIPTION OF THE APPLIANCE
NOTE:
* Door bin (2) is the slighly smaller than Door bin (1) ,Position must be installed as per above picture.
6 www.westinghouse.com
2.2 QUATTRO FRENCH DOOR WITH ICE & WATER REFRIGERATOR FEATURES
WQE5650 illustrated
1
11
2
2
3
2
2
2
12
4 4
13
5
15
14
15
15
6
15
15
7
7
8
10
9
11
10
1
Water Dispenser
2
Door Bins*
3
Door Bin Small*
4
Bottle Storage Bins
5
Egg Tray
6
Water Filter
7
Spillsafe™ Glass shelves
8
Wine Rack
9
UI Control Panel (on the left side wall)
10
Fresh Seal Manual Humidity Control Drawer
11
Fresh Drawer
12
Automatic Ice Maker
13
Ice Storage Small
14
Ice Storage Bin
15
Freezer Drawer
NOTE:
* Door bin (3) is the slighly smaller than Door bin (2) ,Position must be installed as per above picture.
7EN
2.3 QUATTRO FRENCH DOOR WITH TANK ICE & WATER REFRIGERATOR FEATURES
WQE5660 illustrated
1
11
2
2
3
2
2
2
12
5
13
6
15
14
15
15
15
15
7
7
8
10
9
11
10
4
1
Water Dispenser
2
Door Bins*
3
Door Bin Small*
4
Water Tank
5
Bottle Storage Bins
6
Egg Tray
7
Spillsafe™ Glass shelves
8
Wine Rack
9
UI Control Panel (on the left side wall)
10
Fresh Seal Manual Humidity Control Drawer
11
Fresh Drawer
12
Automatic Ice Maker
13
Ice Storage Small
14
Ice Storage Bin
15
Freezer Drawer
NOTE:
* Door bin (3) is the slighly smaller than Door bin (2) ,Position must be installed as per above picture.
8 www.westinghouse.com
Product Dimensions
Total width (W) mm 896
Total depth (D) mm 726
Maximum height (H) mm 1795
Cabinet width (W1) mm 890
Cabinet depth (D1) mm 640
Depth door open 90° (D2) mm 1104
When positioned in a corner area, spacing of at
least 285mm on the hinge side will allow the doors
to open enough to enable the removal of bins and
shelves.
Installation options for optimal aesthetics :
Minimum side clearance kitchen cabinet
Fridge body must sit 10mm proud of kitchen
cabinetry.
Minimum cabinetry opening (WxDxH) :
900mm x 649mm x 1800mm
Front of fridge body in line with kitchen cabinet
Side clearance must be 25mm either side of fridge
body, to have the fridge doors siting proud of the
kitchen cabinetry.
Minimum cabinetry opening (WxDxH) :
940mm x 659mm x 1800mm
3. INSTALLING YOUR NEW APPLIANCE
Unpacking
ENVIRONMENT
Most of the packing materials are
recyclable. Please dispose of those
materials through your local recycling
depot or by placing them in appropriate
collection containers.
Important – check for any damages or marks.
If you find the refrigerator is damaged or marked,
you must report it within 7 days should you wish to
claim for damage/ marks under the manufacturers
warranty. This does not aect your statutory rights.
Clean your refrigerator thoroughly following the
instructions in the “Cleaning” section and wipe o
any dust that has accumulated during shipping.
Locating the refrigerator
CAUTION
Automatic aerosol systems (such as
insect control) should not be located
adjacent to the product as the spray
may cause long term damage to the
external plastics of the appliance.
Do not put the refrigerator in a location that is too
cold or is unprotected, for example in a garage or
on a veranda. The ambient temperature should be
above 10°C.
Put the refrigerator in a dry place avoiding areas of
high moisture or humidity.
Ensure the refrigerator is located on an even
surface.
Installing your refrigerator
W1
D2
D1D
90
°
W
H
126°
Fresh food door
126°
Fresh food door
120°
Freezer door
120°
Freezer door
285
mm
285
mm
30 mm
5 mm
10mm
5 mm
30 mm
25 mm 25 mm
Note : Spacers supplied to assist
9EN
5. If you find your refrigerator rocks from corner
to corner, it means your floor is uneven. Find a
piece of plastic or hardboard etc. and pack it
firmly under the roller.
6. You may now need to fine-tune the installation
by repeating steps 3, 4 and 5.
7. When you have the appliance in its final position,
it needs to be stabilised. Wind the stability foot
under the door hinge down to the floor until
it just makes contact with the floor. Lift the
front of the appliance to take the weight o
the stability foot, then turn it half a turn further
to ensure firm contact with the floor. Wind the
large height adjusting nut back up to ensure
all the weight is now on the front stability foot.
Wind the large height adjusting nut back up to
ensure all the weight is now on the front stability
foot.
8. Repeat step 7 for the stability foot on the handle
side. Whenever you need to move the appliance,
be sure to wind the feet back up so that the
appliance can roll freely and be sure to reset it
when reinstalling.
9. Plug your refrigerator straight into its own power
point and never use a double adapter. If you
need to roll the refrigerator to get to the plug,
remember to raise the stability foot first.
10. Before you put any food in your refrigerator,
it’s recommended you leave it on for 2 or 3
hours to check it is running properly.
Fridge door flush with the cabinetry
Side clearance must be 90mm either side of the
fridge body, to have the fridge doors siting flush
with the kitchen cabinetry.
Minimum cabinetry opening (WxDxH) :
1070mm x 741mm x 1800m
Note : Top gap all 5 mm.
1. Roll the refrigerator into place.
The rollers are designed for forward or backward
movement only. They are not castors. Moving
the refrigerator sideways may damage your floor
and the rollers. Before moving your refrigerator
ensure height adjusting nut and the stability foot
are fully wound up o the floor.
2. Wind the large height adjusting nut under door
hinge down until the refrigerator is tilted back
by 10mm (see diagram).
3. Wind the large height adjusting nut on the
handle side down until the refrigerator is level
and stable. If you have difficulty winding the nut
or height adjusting foot down, have someone tilt
the refrigerator back so you have better access.
4. Check the alignment of the refrigerator to the
surrounding cupboards to see if it is level. You
can adjust the level as detailed in step 2 and 3.
stability foot
wound up
stability foot
wound down
Front view
nut
For adjustment
where floor is not level
10-33mm
30 mm
90 mm 90 mm
10 www.westinghouse.com
2. Ensure both doors are bind-free with their seals
touching the cabinet on all four sides and that
cabinet is stable.
Flipper Mullion
Adjust Flipper Mullion for proper connection with
the mullion guide by ensuring the flipper mullion
is folded and perpendicular to the fresh food door.
If the mullion guide is not in the correct position, it
could prevent the door from closing completely.
Door opening
Your refrigerator should be positioned to allow easy
access to a counter when removing food. For best
use of refrigerator drawers and freezer baskets,
the refrigerator should be in a position where both
door can be fully opened.
WARNING
LED lighting
Your appliance is fitted with long life LED
lighting. In the unlikely event the LED lights
should fail, then the LED lights should be
serviced by the service agent, to avoid a
safety hazard. Refer to the warranty page
for contact details.
Cabinet Leveling & Refrigerator Door
Alignment (if necessary)
All four corners of the cabinet must rest firmly on
the floor
• The front should be slightly elevated to ensure
that doors close and seal properly.
• Doors should align with each other and be level.
Most of these conditions can be met by raising or
lowering the adjustable front rollers.
To level the cabinet using the front rollers:
1. Lower anti-tip legs until they are both touching
the floor. Use a pair of pliers to adjust.
To raise: turn leg clockwise.
To lower: turn leg counterclockwise.
Door Door
Anti-Tip
Legs
11EN
4. TEMPERATURE CONTROL
The following pages explain the various functions of the user interface to help you better understand how to
get the most out of your new refrigerator.
IMPORTANT
NOTE: When you set a temperature, you set an average temperature for the whole refrigerator
cabinet. Ensuring that you make only small adjustments and wait at least 24 hours to see if the new
temperature is correct to your liking.
Checking the softness of ice cream is a good indication that your freezer is the right temperature,
while checking the temperature of water kept in the refrigerator is a good way of checking the
temperature of the food compartment.
Temperatures inside each compartment may vary, depending on how much food you store and
where you place it.
High or low room temperature may also aect the actual temperature inside the refrigerator.
1
Fast Ice Control
2
Auto Ice Maker Control
3
Fridge Temp Tontrol
4
Freezer Temp Control
5
Drinks Chill Button
6
Water Filter Reset Button
7
Quick Chill Control
8
Quick Freeze Control
4.1 Functions of the user interface
WQE5600 WQE5650 WQE5660
1
2
3
4
5
6
7
8
3
4
5
1
2
3
4
5
12 www.westinghouse.com
Function Icon Operation (depending on model)
1
Fast Ice Botton
Fast Ice indicator
Tap on Fast ice button.
When Fast ice is ON, the Fast Ice indicator lights up.
When Fast ice is OFF, the Fast ice indicator turns o.
2
Auto Ice Maker
Control
Ice O Alert indicator
Water O Alert
indicator
Tap on Ice Maker on/o button.
When Ice maker is ON, the button LED lights up .
When Ice maker is OFF, the button LED turns o. Ice O
alert lights up.
Press and hold on Ice Maker On/O button for 3 secods.
When it is ON, water can be dispensed when the water
dispensar paddle is pressed.
When it is OFF, water cannot be dispensed when the water
dispensar paddle is pressed.
3
Fridge Temp
Control
Taps on the display to cycle through the temperature
range supported by the Fridge.
From 7°C
To 1°C
Default 4°C
4
Freezer Temp
Control
Taps on the display to cycle through the temperature
range supported by the Freezer
From -14°C
To -23°C
Default -18°C
13EN
Function Icon Operation (depending on model)
5
DrinksChill
Drinks Chill timer
indicator
The Drinks Chill timer is used to quickly chill a bottle
inside the freezer compartment and to warn the user
when it ends.
Tap on Drinks Chill button,
Freezer display shows 20 ,"Min" and Drink Chill LED
turns on.
The timer option is from 20 minutes and the user can
add time in 5 min intervals up to 45 minutes. After it
starts the timer will show the countdown minute by
minute.
NOTE:
When timer countdown is in progress, the timer duration
cannot be adjusted. User will need to deactivate Drinks
Chill and activate Drinks chill again to set a new timer.
6
Water Filter
Alert and
Reset
"GOOD" LED turns on is mean the filter used
for 0-4 months.
"ORDER" LED turns on is mean the filter used
for 5 months , to remind user to order new water filter.
"REPLACE" LED turns on is mean the filter used
for 6 months,
Press and hold Water filter for 3 seconds to reset.
Status will reset to GOOD.
7
Quick Chill
Control
Standard model
I&W model
Quick chill indicator
For Standard model
Tap on Quick chill button.
For I&W model
Press & Hold on Fridge digits for 3 seconds.
Tap on Fridge digits to adjust temperature.
When Quick chill is ON,
the Quick chill indicator lights up.
When Quick chill is OFF,
the Quick chill indicator turns o.
Use the Quick Chill when you add a large amount of
food to the refrigerator compartment after grocery
shopping or to quickly cooled your drink. When Quick
chill is on, the cold air circulate into the refrigerator to
temporarily reduce the temperature to 1°C for 6 hours,
Freezer compartment continue to run at set
temperature.
Quick chill auto turn o on either of this condition:
- 6 hours has elasped
- Fridge temp is adjusted
14 www.westinghouse.com
Function Icon Operation (depending on model)
8
Quick Freeze
Control
Standard model
I&W model
Quick Freeze indicator
For Standard model
Tap on Quick Freeze button.
For I&W model
Press & Hold on Freezer digits for 3 seconds.
Tap on Freezer digits to adjust temperature.
When Quick freeze is ON,
the Quick Freeze indicator lights up.
When Quick freeze is OFF,
the Quick Freeze indicator turns o.
Use the Quick freeze function when you add a large
amount of food to the freezer compartment after
grocery shopping, to speed up the freezing process.
When Quick freeze is on, the compressor will run
continuously for 6 hours. Fridge compartment continue
to run at set temperature.
Quick freeze auto turn o on either of this condition:
- 6 hours has elasped
- Freezer temp is adjusted
NOTE: Quick Freeze and Fast Ice cannot be activated at
the same time. If Fast ice is ON, Quick Freeze cannot be
activated.
4
+
5
Sabbath mode
Press and hold Freezer and Drinks chill for 5 seconds
and "Sb" shows on Fridge disply.
When activated, all lights and UI will not work until
Sabbath Mode is deactivated.
The Sabbath Mode is a feature that disables portions
of the refrigerator and its controls in accordance
with observance of the weekly Sabbath and religious
holidays within the Orthodox Jewish Community.
NOTE: All alarm functions are deactivated except
High temperature alarm is not disabled for health
reasons. If high temp alarm active, The alarm will sound
intermittently for 10 minutes. The alram will silence on
its own.
The unit stays in Sabbath Mode after power outage
recovery. It must be deactivated by the user.
15EN
Check water Alert
When water tank is empty, the Ice maker
senses the lack of warm water feeding in,
and will turn o the ice maker.
This trigger will also displays the "Check
water alert". The intention is the alert user that Ice
maker has been turn o due to the lack of water.
The alert can be dismissed by turning on Ice maker.
If no water is detected again, ice maker will be turn
o again, and the check water alert turns on.
Error codes
Both Fridge & Freezer displays are used to
communicate problems by code.
When error codes are displayed in the numeric
display, the unit requires service attention.
"Er" shows up on Fridge display
Various error codes on Freezer display
Error code table
Communication error CE
FZ Cavity NTC T1
FZ Evaporator NTC T2
FF Cavity NTC T3
Third cavity NTC T5
FZ Ice maker NTC T8
4.2 Alert and Alarms
Door Alarm
When any of the door is left open for 2 minutes.
The alarm will sound, and all LEDs that are
currently on.
• The alarm is turned o by closing the door or
resetting the countdown by pressing any key on
the control panel.
High Temperature alert
In the event of high temperature condition, audio
alarm is played every 10 seconds until the alert is
acknowledged.
The alarm by pressing any key on the control panel.
Display and blink “HI” in the correspondent
compartment display, whichever is in the high
temperature condition.
ECO indicator
Eco mode indicator will light up
automatically to 100% when the
fridge and freezer compartments
are set within a temperature range.
Fridge range: 4°C to 7°C
Freezer range: -18°C to -14°C
Selecting any of these mode: Quick Freeze, Quick
Chill, Fast Ice or Drinks Chill will deactivate the Eco
mode, the Eco icon will fade.
Water Filter Alert and Reset
Water Filter alert warns user that the Water filter
have to be changed as soon as possible.
When water filter is used for 6 months or 120
gallons (about 454 litres) of water has been
dispensed since the last filter reset, LED "Replace"
will automatically illuminate.
Note:
1. Users could reset the filter when alert is not
visible. Play tone_Confirm once it is reset.
2. LED "Replace" remains visible during sleep mode,
except when door is closed
High Temp indicator
on Fridge display
High Temp indicator
on Freezer display
16 www.westinghouse.com
SpillSafe™ glass shelves
To remove the shelves, gently pull them forward
until the shelf comes clear of the shelf guides.
To return the shelf, make sure there is nothing
behind that may obstruct movement. Gently push
the shelf, into the cabinet and back into position.
CAUTION
To avoid personal injury or property
damage, handle tempered glass shelves
carefully. Shelves may break suddenly if
nicked, scratched, or exposed to sudden
temperature change. Allow the glass
shelves to stabilize to room temperature
before cleaning. Do not wash in
dishwasher.
Drawer
Your refrigerator includes a variety of storage
drawers.
Crisper (with humidity control)
Crisper drawers are designed for storing fruits,
vegetables, and other fresh produce. Crispers have
humidity control (Change the humidity by sliding
the humidity control, less humidity conditions are
recommended for fruit, while more humidity
conditions recommended for vegetables)
5. STORAGE FEATURES
To remove the crisper for cleaning:
1. Pull the drawer out until it stops.
2. Lift the front slightly and remove the drawer.
Doors
Storage bins
The doors to your fresh food compartment use
a system of modular storage bins. All of these
bins are removable for easy cleaning. Bins can be
adjusted to your needs.
Door bins are ideal for storing jars, bottles, cans,
and large drink containers. They also enable quick
selection of frequently used items.
To remove the door bin:
1. lift and unlock from lugs to remove.
2. Replace by lift up and push bin down until the
support lugs lock it in place.
Opening the Crisper Drawer
Removing Crisper
Removing glass shelves
Adjust the humidity control
17EN
Water Tank
CAUTION
BEFORE REMOVE; to empty the water in
the tank.
To remove the water tank and disassembly
cleanable parts follow these steps:
1. Life up water tank until locking release.
2. Pull water tank forward.
3. Remove water tank lid ( 1 ), water tank tube ( 2 )
and filter ( 3 ).
Reverse the step to assembly the water tank and
return to its place. Reverse the step to assembly the
water tank and return to its place.
NOTE: The water tank for WQE5660 model only
Freezer storage
To remove freezer drawers:
All freezer drawers are removable.
1. Open doors completely to gain access to
drawers.
2. Pull the drawer to the stopper. Lift up and pull to
remove it from the cabinet.
3. Reverse the steps to reinstall drawer.
Removing Freezer Drawer
Removing the water tank
filter
1
2
3
Disassembly water tank
Removing door bin
18 www.westinghouse.com
Twist & Serve Ice Bin:
1. Prior the first use clean the ice tray.
2. Fill the water up to max level of the ice tray.
3. Put the ice tray in place.
4. Rotate ice twist clockwise to release the ice from
ice tray.
Water
19EN
6. CONNECTING THE WATER SUPPLY
WARNING
Connect to potable water supply
only. If using tank or bore water it is
recommended to also use an external filter
(not supplied).
The new hose-sets supplied with the appliances
must be used and old hose-sets should not be
reused.
Never connect the appliance to a hot water supply.
Do not use with water that is microbiologically
unsafe or with water of unknown quality without
adequate disinfection.
Water Filter
It should not be used on water that is micro
biologicallyunsafe or with water of unknown
quality. The service life of the filter may be
reduced in water supplies that contain an excess
of particles or other impurities. Reduced flow rate
is an indication that a new filter is required. Failure
to replace the filter when required can aect the
function of the ice maker. Service calls caused by
a failure to replace the filter are not covered by
warranty. Replacement water filters are available
from Electrolux Home Products Spare Parts Centres
and can be posted to you for your convenience
(refer to spare parts contact numbers on the
warranty page).
Contents of installation kit
Water supply and plumbing
A drinkable water supply to suit a 1/2” tap fitting
is required adjacent to the refrigerator. It is
recommended that a licensed plumber install a
new water supply outlet nearer to the appliance
should the tubing supplied not be long enough. It
is not recommended that the tubing be extended
as this could adversely aect the flow of water to
the ice maker or water dispenser. If there is a risk of
flow rate higher than the maximum flow rate 2.46
L/min, a flow controller should be installed. The
water dispenser and automatic ice maker require
a drinkable water supply with a pressure range of
between 206kPa and 689kPa (30psi and 100psi). If
the water supply is above 100psi a pressure limiting
valve should be installed.
4 metres of water tubing 1 x 1/2” tap fitting
It is recommended that a noise reduction valve
also be fitted in the water supply line. This will
reduce water hammer and its eects from quick
action household taps and fast acting valves on
appliances.
The refrigerator water valve is pre-fitted with a
push-fit connector for inserting the water tube.
When the tap connection is other than 1/2”,
adapters can be purchased from plumbing supply
stores or good hardware stores.
Please read before beginning installation.
The appliance complies with the relevant backflow
prevention requirements specified in AS/NZS
2845.1.
The water connection to your ice and water product
can be self installed. However, it is recommended
that you seek advice from a licensed plumber
before commencing the installation.
IMPORTANT
Check for water leaks at all water
connection points in the first 2 to 3 hours
after installation, and correct it in case of
any water leak. Recheck after 24 hours;
if leak still occurs, it is recommended to
contact a licensed plumber for advice.
Water is to be connected as per diagram below.
Step 1 Ensure that the refrigerator is disconnected
from power supply.
Step 2 Connect tap fitting to water supply tap. Tap
must be close to the refrigerator.
sink
mains
water
inlet
kitchen cupboard
½" tap
fitting
20 www.westinghouse.com
Step 3 Push the tube into tap fitting past insertion
mark.
Step 4 Connect other end of tube to inlet on rear
of refrigerator.
Step 5 Turn on water and check all joints and
tubes for leaks.
Step 6 Reconnect the power.
Step 7 Move the refrigerator back into place being
careful not to kink or split the tubing.
Step 8 Switch ON Water
Dispenser. By referring
to Ice & Water on/o
function. Using a large
container, run the water
dispenser to clear air
from lines. This may take
a few minutes. Purge and
dispense a minimum of 2
litres of water. Initial water
may be black in colour.
This is residual carbon dust from the filter and is
non-toxic. If the water is slow to shut o or the
dispenser is dripping, air may still be in the lines.
Either purge more water through the system to
remove this air or allow some time for the air to be
removed over subsequent dispensing. For normal
use, water dispenser will automatically shut o
after 2 minutes of continuous operation.
IMPORTANT
As the water cut o is not instant, leave
glass under dispenser briefly until water
has stopped flowing to avoid spills. Clean
and empty the dispenser drip tray regularly
to avoid overflow. Flushing system about 2
minutes after period of non-use exceeding
30 days.
Step 9 Switch ON Ice Maker. Once the refrigerator
has been running for at least 24 hours remove the
ice bin and dispose of the first few batches of ice
to ensure that impurities have been flushed from
the system.
CAUTION
Water dispenser should not be used for
extended periods of time. After 2 minutes
of continuous use the water dispenser will
automatically shut o.
Party Ice
When the Ice Bin is removed from the cabinet the
Auto Ice Maker will continue to dispense ice into
the top freezer drawer.
IMPORTANT
• Always fit the filter as per manufacturer’s
instructions.
• If you need to replace water tube, only
use approved water quality piping that
meets the pressure requirements.
• Make sure your refrigerator is level to
avoid uneven ice cubes.
• Replace filter at suggested intervals
to avoid water/ice reduction and
irregularities in taste.
• Remove and clean ice bin once a month,
discarding unused ice cubes. This will
ensure fresh, clean ice and smooth
operation of your ice maker.
• Clean and empty the dispenser drip tray
regularly to avoid overflow.
21EN
Note: The water dispenser has a built-in device
that shuts o the water flow after three minutes of
continuous use. To reset this shut-o device, simply
release the dispenser paddle. Only the first 750 ml
of dispensed water is chilled.
CAUTION
Do not fill the Water tank with anything
other then clean water (Filtered or Mineral
water). Soft drink, juice, tea or hot water
etc, can damage your automatic icemaker.
The Water tank can withstand a maximum
water temperature of 60°C
TIP AND USEFUL INFORMATION
Remove and clean ice bin and water tank
once a month, discarding unused ice and
water. This will ensure fresh ice and smooth
operation of your icemaker.
Make sure your refrigerator is level to avoid
uneven ice cubes.
Ice maker operation & care
After the refrigerator is installed properly and has
cooled for several hours, the ice maker can produce
ice within 24 hours. The ice maker will fill the ice bin
from the rear. You must dispense some ice to force
the ice forward in the bin. This will allow the bin to
fill completely.
Ice Maker and Storage Bin Capacity
This ice maker should produce 1 kg of ice per 24
hours. The ice bin will hold about 1.8 kg of ice.
Turning the ice maker on and o
IMPORTANT
Your ice maker is turned on at the factory
so it can work as soon as you install your
refrigerator. If you do not fill the water
tank, set the ice maker’s On/O feature
to O; otherwise, the ice maker’s fill valve
may make a loud chattering noise when it
attempts to operate without water.
Ice production is controlled by the ice maker’s On/
O feature on the control panel. Pressing the On/
O feature turns the ice maker on & o.
Note: The ice maker also has a built-in plastic signal
arm that automatically stops ice production when
the ice bin is full. This signal arm should not be used
to manually stop the ice maker.
7. AUTOMATIC ICE &WATER DISPENSER
Using the ice maker after installation
Before making ice for the first time, be sure
to prime the water supply system. Air in new
plumbing lines can result in two or three empty
ice maker cycles. Furthermore, if the system is not
flushed, the first ice cubes may be discolored or
have an odd flavor.
Refilling the water tank
• The water tank must be placed on the door.
• Pour potable water through the funnel at the lid
of water tank.
• Ensure that ice maker and dispenser is switched
on.
Priming the water supply system
1. Begin filling the system by pressing and holding
a drinking glass against the dispenser.
2. Keep the glass in this position until water comes
out of the dispenser. It may take about 1½
minutes.
3. Continue dispensing water for about four
minutes to flush the system and plumbing
connections of any impurities (stopping to
empty the glass as necessary).
Water
22 www.westinghouse.com
IMPORTANT
Turning o the ice maker simply disables
ice making. You will still be able to
dispense existing ice, and you will still be
able to dispense water.
Ice maker/dispenser tips
• If your refrigerator is not connected to a water
supply or the water supply is turned o, turn
o the ice maker as described in the previous
section.
• The following sounds are normal when the ice
maker is operating:
- Motor running
- Ice dropping into ice bin
- Water valve opening or closing
- Running water
• If you need a large quantity of ice at one time, it
is best to get cubes directly from the ice bin.
• Ice cubes stored too long may develop an odd
flavor. Empty the ice bin as explained below.
• It is normal to have a small quantity of little
pieces along with the whole cube.
• It is normal for ice to fill to the top of the ice bin.
Water dispenser tips
• Check on the display make sure dispenser on.
• Keep the glass in this position until water come
out of the dispenser
CAUTION
If the water supply to your refrigerator is
softened, be sure the softener is properly
maintained. Chemicals from a water
softener can damage the ice maker.
CAUTION
It mayremain water drop after your
dispenser.
Cleaning the ice maker
Clean the ice maker and ice bin at regular intervals,
especially prior to vacation or moving.
1. Turn o the icemaker.
2. Remove the ice bin by pulling straight out.
3. Empty and carefully clean the ice bin with mild
detergent. Do not use harsh or abrasive cleaners.
Do not place in dishwasher. Rinse with clear
water.
4. Allow the ice bin to dry completely before
placing it back into the freezer.
5. Place ice bin back into position. Turn the ice
maker on.
23EN
8. GENERAL INFORMATION
8.1 CLEANING YOUR REFRIGERATOR
WARNING
BEFORE CLEANING: Turn the refrigerator
o at the power point and unplug the cord
to prevent any chance of electrocuting
yourself.
Doors and exterior
You should only clean the doors with lukewarm
soapy water and a soft cloth.
Interior
Clean the inside of your refrigerator regularly with
a soft cloth, unscented mild soap and lukewarm
water. Thoroughly dry all surfaces and removable
parts and avoid getting water on the controls.
Replace removable parts, plug power cord in and
switch the power on before returning the food.
Door seals
Always keep door seals clean by washing them
with a mild detergent and warm water, followed by
a thorough drying. Sticky food and drink can cause
seals to stick to the cabinet and tear when you
open the door.
Never use hot water, solvents, commercial kitchen
cleaners, aerosol cleaners, metal polishes, caustic
or abrasive cleaners, or scourers to clean your
refrigerator. Many commercially available cleaning
products and detergents contain solvents that will
damage your refrigerator. Use only a soft cloth with
an unscented mild soap and lukewarm water.
CAUTION
To clean a crisper or freezer bin with
telescopic extension slides, simply wipe
with a damp cloth and warm soapy water.
Never immerse the cover in water, as this
could aect the operation of the slide.
Switching o your refrigerator
If you switch o your refrigerator for an extended
period, follow these steps to reduce the chances
of mould.
1. Remove all food.
2. Remove the power plug from the power point.
3. Thoroughly clean and dry the Interior.
4. Ensure that all the doors are wedged open
slightly for air circulation.
8.2 Water Filter
Your refrigerator is equipped with a water filtering
system. The water filtering system filters all
dispensed drinking water, as well as the water used
to produce ice. The water filter is located at the top
right side of the fresh food compartment.
In general, you should change the water filter every
six months to ensure the highest possible water
quality. Water filter status on the user interface
prompts you to replace the filter after a standard
amount of water (750 litres) has flowed through
the system.
If your refrigerator has not been used for a period
of time (during moving for example), change the
filter before reinstalling the refrigerator
Note: When ordering your replacement filter,
please reorder the same filter type that is currently
in your refrigerator.
WARNING
Use the appliance with water filter supplied
by Electrolux Home Products Pty Ltd or its
authorized service agent only.
For correct operation of this appliance it
is essential to observe the manufacturer’s
instructions.
Replacing the Water Filter
It is not necessary to turn the water supply o to
change the filter. Be ready to wipe up any small
amounts of water released during the filter
replacement.
1. Ensure that the ice maker is turned o.
2. Remove the filter by turning anti-clockwise 180˚
3. Slide the old water filter cartridge straight out of
the housing and discard it.
4. Unwrap the new filter cartridge and using the
alignment guide, slide it gently into filter housing
until it stops against the filter connection at the
back of the housing.
24 www.westinghouse.com
5. Engage the filter by firmly rotating clockwise
until the filter snaps into position (once engaged
the filter cannot be rotated further).
6. Press a drinking glass against the water
dispenser while checking for any leaks at the
filter housing. Any spurts and sputters that occur
as the system purges air out of the dispenser
system are normal.
7. After filling one glass of water, continue flushing
the system for about four minutes.
8. Turn on the ice maker.
9. When the filter has been replaced press and hold
the ‘Reset Water Filter’ button for three seconds
to reset the filter replace timer.
10. Replace the filter, don't take o filter cover.
8.3 Ice and water
Clean the components of the ice maker/water
dispenser regularly with a soft cloth, unscented
mild soap and rinsing thoroughly with lukewarm
water.For further information on the care and
cleaning of your ice maker, ice dispenser of water
dispenser refer to the section “Ice and Water
Models
8.4 Water tank
The water tank is intended to be removed only for
cleaning purposes, to fill the portable water only,
the tank must be placed on the door and the funnel
on the lid has to be used.
Clean the inside of the water tank regularly with a
soft cloth and the filter use the soft brush to clean,
unscented mild soap and rinse thoroughly with
lukewarm water to completely remove any soap
residue.
NOTE: When customer assembled tank to door.
To avoid water leaks ensure that tank nozzle fully
engaged with housing socket.
25EN
9. FOOD STORAGE GUIDE
IMPORTANT
Please note, use this information as a guide only, actual storage times will vary depending on how
you use your refrigerator, climatic conditions and the freshness of the food.
CATEGORY FREEZER
REFRIGERATOR
STORAGE TIPS
Meat Sausages and Mince 1-2 Days 2-3 Months
Chops and Steak 4-6 Months3-4 Days
Cold Meats
Keep cold meat at the back of the
refrigerator where it is coldest.
4-6 Months
3-5 Days
Roasts
12 Months3-5 Days
Plastic can cause meat to sweat if
stored in refrigerator for more than
a day.
Poultry Chicken 2 Months1-2 Days
Roast Chicken 12 Months3-5 Days
Eggs 6 Weeks Not Suitable
If poultry takes on a smell or colour
you are unsure about it is best to
throw it out.
Seafood Whole fish and fillets 2 Months2-3 Days
Whole eggs are not suitable for
freezing, slightly beaten eggs may
be frozen for four months.
Store in an airtight container or foil.
Lobster and crabs 2 Months1-2 Days
Prawns 2 Months1-2 Days
Dairy Milk
Never freeze prawns in salty water
as this will dehydrate the flesh.
Yoghurt Not Suitable7-10 Days
Hard Cheeses
If dairy takes on a smell or colour
and you are unsure about it, it is
best to throw it out.
2 Weeks – 2
Months
2 Months
(Grated)
Soft Cheeses Not Suitable1-2 Weeks
Butter
Depending on the variety hard
cheese can last from 2 weeks to
2 months.
12 Months8 Weeks
Fruit &
Vegetables
8-12 Months
When freezing
chop and
blanch in
small
portions.
Every fruit and vegetable has a
different shelf life. Some stay fresh
for a couple of days e.g beans,
others can last for a couple of
months e.g. onions.
Keep vegetables in the crisper and
away from the air vents to avoid
freezing.
Don’t wash fruit and vegetables
before storing them in the
refrigerator as this can make them
susceptible to rotting.
PRODUCT
7-10 Days Not Suitable
Roast can take up to 48 hours to
defrost properly, transfer frozen
roast to the refrigerator 2 days
before use.
Left Overs
Homemade meals
3-4 Days
2-6 Months
Store in sealed container.
Freeze meals in small portion
sizes to limit wastage.
26 www.westinghouse.com
10. TROUBLESHOOTING
CONCERN WHAT TO DO
Refrigerator is too warm • Adjust the refrigerator to a colder setting
• Ensure food is allowed to cool before placing inside the refrigerator.
• Ensure the appliance is set up as per instructions
• Ensure that contents are not obstructing the cooling vents.
• Ensure the door is not held open or is being opened too frequently.
Freezer is too warm • Adjust temperature to a colder setting.
• Ensure food is allowed to cool before placing inside the freezer.
• Ensure the appliance is set up as per instructions
• Ensure that contents are not obstructing the cooling vents.
• Ensure the door is not held open or is being opened too frequently.
Food is freezing in the
refrigerator
• Adjust temperature to a warmer setting.
• Ensure that fruit and vegetables are stored in the crisper. Items with
a high water content should not be placed near the cooling vents.
Unable to change
temperature settings
• Refer to sections “temperature control” and “about the user interface”.
• Ensure that user interface is in “awake” mode before trying to adjust
temperature settings.
Appliance does not operate at desired temperature
In a modern frost free refrigerator / freezer, cold air is circulated around the various compartments through
air vents using a high efficiency fan.
Appliance noise
Your new refrigerator may make sounds that your old one didn’t make. Because the sounds are new to you,
you might be concerned about them. Most of the new sounds are normal. Hard surfaces, like the floor, walls
and cabinets, can make the sounds seem louder than they actually are. The following describes the kinds of
sounds and what may be making them.
CONCERN WHAT TO DO
Motor noise (compressor) Nothing. This is normal as your new refrigerator uses a high-speed
compressor which switches on and o during operation.
Note that the compressor noise may seem louder at the start of the on
cycle.
Motor noise (compressor); These refrigerators are fitted with a variable speed compressor and fan.
At start up and on warm days they run at a higher speed to provide
additional cooling. When less cooling is required the compressor and
fan will run at a lower speed. As a result it is normal for sound levels to
change depending on operating conditions.
A clicking noise heard just
before the compressor starts.
Nothing. This is normal as your new refrigerator has an automatic
switching action of the temperature control, turning the compressor on
and o.
Occasional gurgling, similar to
water boiling.
Nothing. As each cycle ends, you may hear a gurgling sound due to the
refrigerant flowing in your refrigerator system.
Nothing, this is normal as your new refrigerator uses high efficiency
fans to circulate air. Fan speed and noise may increase during periods of
heavy usage or hot weather.
27EN
Crisper Operation
CONCERN WHAT TO DO
Rattling and other noises. • Ensure that the cabinet is level and stable, refer to Installation
Instructions
• Check the surrounds of the appliance to ensure there is nothing
touching or placed on top of the appliance.
• Ensure that contents of the appliance are not placed in such a way
that they are vibrating (such as bottles).
CONCERN WHAT TO DO
Excess moisture build up in
crisper
It is normal for there to be
some moisture and humidity
in the crisper bin.
• Ensure that the crisper is not over packed.
• Adjust crisper humidity slides.
Crisper bin can not be
removed
• If crisper bin interferes with the door bins, remove door bins before
removing crisper.
• Position cabinet so that the door can be fully opened.
Freezing items in the crisper • Adjust temperature to a warmer setting.
Refrigerator operation
CONCERN WHAT TO DO
Appliance will not run
It is normal for the freezer
fan not to operate during
the automatic defrost cycle,
or for a short time after the
appliance is switched on.
• Ensure that the cord is plugged into a live power outlet and outlet is
switched on.
• Ensure that the household circuit breaker has not tripped or that the
fuse has not blown.
• The appliance maybe in defrost mode, check again in half an hour.
Compressor motor seems to
run too long
At normal room
temperatures, expect your
motor to run about 40%
to 80% of the time. Under
warmer conditions, expect it
to run more often.
• Ensure that the doors are not held open.
• Check that large amounts of warm food have not just been placed
inside the appliance.
• Note that the appliance will run more than normal just after you
install it or when adjusting the temperature setting changes.
Compressor motor seems
to run too long. These
appliances use a variable
speed compressor, which
by design can run for long
periods of time, this is normal
• The variable speed compressor and fan that at start up and on warm
days, runs at high speeds to provide additional cooling. When less
cooling is required the compressor and fan will run at a lower speed,
but still may not switch o. This is normal.
• It is possible that the only time the compressor and fan will stop is
when the refrigerator is defrosting which is approximately once per
day.
28 www.westinghouse.com
CONCERN WHAT TO DO
The exterior of the appliance
is warm or hot to touch
This is normal because the
appliance transfers heat from
the inside out through the
outer panels and the divider
between the doors.
• Ensure the appliance has the external clearances recommended in
the section “Installing your new appliance”.
• The exterior of the cabinet will be much warmer on warmer days it
may even feel hot to touch, as the appliance is working harder.
User interface will not
respond
To ensure settings are not
accidentally changed the
user interface will go into
sleep mode when not in use.
Press any button to wake user
interface
• Check that the user interface is in awake mode, refer to section
“About the user interface”.
• Check that the user interface is not locked, refer to section “About
the user interface”.
• If the user interface is frozen turn the appliance o for five minutes
for the memory to clear, then turn back on.
• Check that the user interface is not in Sabbath Mode, refer to control
instructions. (I&W models only).
Alarms Sounding • Check that all doors are fully closed.
• Ensure that the over temperature alarm is not being activated by hot
food placed in the freezer.
• Check if the drinks timer has ended, refer control instructions.
Frost build up • Check that all doors are fully closed.
• Ensure that the doors are not opened too often.
• Ensure that the return air vents are not blocked with packaging.
• Ensure the seals are clean and not obstructed.
Odours • The interior may need cleaning, refer to cleaning guide.
• Ensure that food is stored correctly as some food, containers and
wrapping can produce odours.
• Check appliance for old or unusual food.
Lights not working
The LED lighting is esigned
to turn on gradually. The
LED lighting is designed
to dim automatically if the
door is left opened for more
than 5 minutes and turn o
completely if the door is open
for more than 7 minutes.
Closing the door will reset
the timer.
• Ensure that the cord is plugged into a live power outlet and outlet is
switched on.
• Ensure that the household circuit breaker has not tripped or that the
fuse has not blown.
• Check that the user interface is not in Sabbath Mode, refer to control
instructions.
• Check the appliance features section to determine lighting
configuration for your model.
29EN
Door operation
CONCERN WHAT TO DO
Freezer door pops open. • This is normal and should re-close. This happens when the
refrigerator door is closed too quickly.
• If the freezer door stays open, it indicates that the appliance needs
to be tilted backwards a little further. Refer to section “Installing your
new appliance”.
Self close not working. • Check if your appliance has self closing hinges as not all models do.
• It indicates that the appliance needs to be tilted backwards a little
further. Refer to section “Installing your new appliance”.
Door not sealing properly • Ensure there is nothing that is preventing the door from closing such
as appliance contents or items placed near the appliance.
• Ensure that the crisper/freezer bin is closed completely. Refit if
required as referred to in the section “Using your refrigerator”.
• Ensure the appliance is set up as per recommendations.
Door difficult to open and
close
• If the door is difficult to open just after you have closed it this is due
to the pressure equalising, the door will open normally after a few
minutes.
If you still require service
If you have a problem, and the problem persists after you have made the checks mentioned, contact your
nearest Electrolux approved Service Centre or the dealer you bought the refrigerator from. Be ready to
quote the model number, the 9-digit PNC and 8-digit serial number, which is stated on the label inside the
refrigerator compartment.
30 www.westinghouse.com
BRRR
!
HISSS!
CLICK!
BLUBB!
CRACK!
SSSRR
R!
OK
CLICK!
CLICK!
SSSRRR!
SSSRRR!
BRRR!
BRRR!
HISSS!
HISSS!
BLUBB!
BLUBB!
CRACK!CRACK!
11. NOISES
Appliance noise
Your new refrigerator may make sounds that your old one didn’t make. Because the sounds are new to you,
you might be concerned about them. Most of the new sounds are normal. Hard surfaces, like the floor, walls
and cabinets, can make the sounds seem louder than they actually are. The following describes the kinds of
sounds and what may be making them.
This document sets out the terms and conditions of the product
warranties for Westinghouse Appliances. It is an important
document. Please keep it with your proof of purchase documents
in a safe place for future reference should there be a manufacturing
defect in your Appliance. This warranty is in addition to other rights
you may have under the Australian Consumer Law.
1. In this warranty:
(a) ‘ACL’ or ‘Australian Consumer Law’ means Schedule 2 to the
Competition and Consumer Act 2010;
(b) ‘Appliance’ means any Electrolux product purchased by you and
accompanied by this document;
(c) ‘ASC’ means Electrolux’s authorised serviced centres;
(d) ‘Westinghouse’ is the brand controlled by Electrolux Home Products
Pty Ltd of 163 O’Riordan Street, Mascot NSW 2020, ABN 51 004
762 341 in respect of Appliances purchased in Australia and Electrolux
(NZ) Limited (collectively “Electrolux”) of 3-5 Niall Burgess Road, Mount
Wellington, in respect of Appliances purchased in New Zealand;
(e) ‘WarrantyPeriod’meanstheperiodspeciedinclause3ofthis
warranty;
(f) ‘you’ means the purchaser of the Appliance not having purchased
the Appliance for re-sale, and ‘your’ has a corresponding meaning.
2. Application: This warranty only applies to new Appliances, purchased
and used in Australia or New Zealand and is in addition to (and does not
exclude, restrict, or modify in any way) other rights and remedies under
a law to which the Appliances or services relate, including any non-
excludable statutory guarantees in Australia and New Zealand.
3. Warranty Period: Subject to these terms and conditions, this warranty
continues for in Australia for a period of 24 months and in New Zealand
for a period of 24 months, following the date of original purchase of the
Appliance.Speciccomponentsarewarrantedagainstmanufacturing
defects in Australia and New Zealand for the periods listed below;
• Comp essor – Further 3 years parts only,
• Exte nal Condenser – Further 3 years parts only
• Evaporator – Further 3 years parts onl
• Drier – Further 3 years parts onl
4. Repair or replace warranty: During the Warranty Period, Electrolux
or its ASC will, at no extra charge if your Appliance is readily accessible
for service, without special equipment and subject to these terms and
conditions, repair or replace any parts which it considers to be defective.
Electrolux may, in its absolute discretion, choose whether the remedy
oeredforavalidwarrantyclaimisrepairorreplacement.Electroluxorits
ASC may use refurbished parts to repair your Appliance. You agree that
any replaced Appliances or parts become the property of Electrolux.
5. Travel and transportation costs: Subject to clause 7, Electrolux will
bear the reasonable cost of transportation, travel and delivery of the
Appliance to and from Electrolux or its ASC. Travel and transportation will
be arranged by Electrolux as part of any valid warranty claim.
6. Proof of purchase is required before you can make a claim under this
warranty.
7. Exclusions: You may not make a claim under this warranty unless the
defect claimed is due to faulty or defective parts or workmanship. This
warranty does not cover:
(a) lightglobes,batteries,ltersorsimilarperishableparts;
(b) parts and Appliances not supplied by Electrolux;
(c) cosmeticdamagewhichdoesnotaecttheoperationofthe
Appliance;
(d) damage to the Appliance caused by:
(i)i) negligence or accide
(ii)ii) misuse or abuse, including fa e to properly maintain or service;
(iii) improper, negligent or faulty servicing or repair works done by
anyone other than an Electrolux authorised repairer or ASC;
(iv)iv) normal wear and t
(v)v) power surges, electrical storm damage or inc ect power supply;
(vi)vi) incomplete or oper installation;
(vii)vii) i ect, improper or inappropriate operation;
(viii)viii) insect or vermin infest
(ix) failure to comply with any additional instructions supplied with
the Appliance;
In addition, Electrolux is not liable under this warranty if:
(a) the Appliance has been, or Electrolux reasonably believes that the
Appliance has been, used for purposes other than those for which
the Appliance was intended, including where the Appliance has
been used for any non-domestic purpose;
(b) theApplianceismodiedwithoutauthorityfromElectroluxinwriting;
(c) the Appliance’s serial number or warranty seal has been removed
or defaced.
8. How to claim under this warranty: To enquire about claiming under
this warranty, please follow these steps:
(a) carefully check the operating instructions, user manual and the
terms of this warranty;
(b) have the model and serial number of the Appliance available;
(c) have the proof of purchase (e.g. an invoice) available;
(d) telephone the numbers shown below.
9. Australia: For Appliances and services provided by Electrolux in
Australia: Electrolux goods come with guarantees that cannot be
excluded under the Australian Consumer Law. You are entitled to a
replacement or refund for a major failure and for compensation for any
other reasonably foreseeable loss or damage. You are also entitled to
have the Appliance repaired or replaced if the Appliance fails to be of
acceptable quality and the failure does not amount to a major failure.
‘Acceptable quality’ and ‘major failure’ have the same meaning as
referred to in the ACL.
10. New Zealand: For Appliances and services provided by Electrolux
in New Zealand, the Appliances come with a guarantee by Electrolux
pursuant to the provisions of the Consumer Guarantees Act, the Sale
of Goods Act and the Fair Trading Act. Where the Appliance was
purchased in New Zealand for commercial purposes the Consumer
Guarantee Act does not apply.
11.Condentiality: You accept that if you make a warranty claim, Electrolux
and its agents including ASC may exchange information in relation to you
to enable Electrolux to meet its obligations under this warranty.
Warranty
FOR SALES IN AUSTRALIA AND NEW ZEALAND
APPLIANCE: WESTINGHOUSE REFRIGERATORS AND FREEZERS
Important Notice
Before calling for service, please ensure that the steps listed in clause 8 above have been followed.
FOR SERVICE
ortondtheaddressofyournearest
authorised service centre in Australia
PLEASE CALL 13 13 49
For the cost of a local call (Australia only)
AUSTRALIA
ELECTROLUX HOME PRODUCTS
163 O’Riordan Street, Mascot NSW 2020
electrolux.com.au
FOR SPARE PARTS
ortondtheaddressofyournearest
spare parts centre in Australia
PLEASE CALL 13 13 50
For the cost of a local call (Australia only)
FOR SERVICE
ortondtheaddressofyournearest
authorised service centre in New Zealand
PLEASE CALL 0800 10 66 10
(New Zealand only)
NEW ZEALAND
ELECTROLUX (NZ) Limited
3-5 Niall Burgess Road, Mount Wellington
electrolux.co.nz
FOR SPARE PARTS
ortondtheaddressofyournearest
spare parts centre in New Zealand
PLEASE CALL 0800 10 66 20
(New Zealand only)
WFridgeFreezer_Warr_Jun17
email:
web:
customer[email protected]om.au
westinghouse.com.au
email:
NEW ZEALAND
phone: 0800 436 245
fax: 0800 225 088
For more information on all Westinghouse
appliances, or for dimension and installation
information, call into your retailer, phone or email
our customer care team or visit our website:
AUSTRALIA
phone: 1300 363 640
fax: 1800 350 067
web:
customer[email protected]o.nz
westinghouse.co.nz
TOP SERVICE
Top Service encompasses the after sales service
provided by The Electrolux Group to consumers
including delivery, home service and spare parts.
and WESTINGHOUSE are trademarks of Westinghouse Electric Corporation.
Used under license. All Rights Reserved.
© 2017 Electrolux Home Products Pty Ltd.
ABN 51 004 762 341
A12081690-C-132023
