Safety Instructions & Operator's Manual for
MID MOUNT Z-RIDER
ZERO TURNING
HYDRO DRIVE
SERIES 2
MODELS
NZM19482KWV
NZM21522KWV
NZM25612KWV
NZM27 612KH
MODEL NUMBER EXPLANATION
INI ;
MODEL DESIGNATION ._1
DRIVE SYSTEM TYPE
MOWER ORIENTATION
ENGINE HP *
:1 I1I 1_1431:! I KWVl
I ENGINE TYPE
SERIES DESIGNATION
MOWER DECK SIZE
POWER UNIT
19.0 - Engine Horse Power
21.0 -- Engine Horse Power
25.0 - Engine Horse Power
27.0 - Engine Horse Power
N - Model Designation 48 - 48" Mower Width 2 - Series Designation
Z - Zero Turning - Hydro Drive 52 - 52" Mower Width KW - Kawasaki Engine
M - Mid Mount Mower 61 - 61" Mower Width KH - Kohler Engine
V - Over Head Valve
Thank you for buying a SNAPPER Product! Before operating your machine, read this manual carefully and pay
particular attention to the "IMPORTANT SAFETY INSTRUCTIONS" on Pages 2 - 4. Remember that all power
equipment can be dangerous if used improperly. Also keep in mind that SAFETY requires careful use in
accordance with the operating instructions and common sense!
NOTE: Specifications are correct at time of printing and are subject to change without notice.
* Actual sustained equipment horsepower will likely be lower due to operating limitations and environmental factors.
COPYRIGHT CU2004 SNAPPER .coo°ough,OA.,
SNAPPER A DIVISION OF SIMPLICITY MFG INC
ALL RIGHTS RESERVED
MANUAL No. 7-4408 (Rev. I - 9/3/04)
