GPW2600 GAS PRESSURE WASHER MANUAL
Green-Power America, LLC
GPW2600 GAS PRESSURE WASHER
Products Service Information
Green-Power America LLC thanks you for choosing a Green-Power America
LLC product.
Please register your product within 10 days of purchase to ensure that you
receive optimal service. Always keep copy of your original receipt.
By registering your product, you are protected:
1. You have a record of the product purchase,
2. Customer Service can Better serve you on Warranty related issues
3. Green-Power America will be able to contact you in the unlikely event
that a product recall notification is necessary.
You can register your product in one of two ways follows:
Option 1: go to the Green Power America website at www.green-
poweramerica.com/service (or www.g-poweramerica.com/service ) and
follow the instruction to register online.
Option 2: Fill out the form on the Warranty Card included in the box, and
return via standard mail to Green Power America, LLC at 840 9th Street
suite H, Upland CA 91786. Please note that postage is required to mail the
registration form back to Green-Power America, LLC.
If you still have any questions regarding the usage or operation of the product
after you have read the manual, or if you have any quality issue during
operation, please call our toll-free service number shown below:
For any issues related to LCT Engine, the parts include recoil starter, air filter,
spark plug, and all the other parts fixed to the engine, please go to (LCT
website) www.lctusa.com or call Toll-Free number:
800-558-5402
For any issues related with the remaining parts except for the LCT Engine
parts, including pump, Spay Gun, Pressure hose, wand, and other parts,
please call Toll-Free number:
888-834-4218
You may reach us by visiting our web www.green-poweramerica.com (or
www.g-poweramerica.com ) or sending us emails to:
service@green-poweramerica.com
GPW2600 GAS PRESSURE WASHER
CONTENTS
SPECIFITIONS .................................................................................................................... 4
SAFTY INSTRUCTION ..................................................................................................... 5-8
INTRODUCTION .................................................................................................................. 9
PART LIST .................................................................................................................... 10-11
ASSEMBLY INSTRUCTIONS ............................................................................................ 12
PREPARATION ............................................................................................................. 13-14
OPERATING INSTRUCTION ........................................................................................ 15-20
TROUBLESHOOTING .................................................................................................. 21-22
MAINTENANCE ............................................................................................................ 23-24
STORAGE ..................................................................................................................... 25-26
GPW2600 GAS PRESSURE WASHER
4
1, SPECIFITIONS
Model Number
GPW2600
Maximum Pressure
2600 psi
Rated Pressure
2000 psi
Rated volume
2.0gpm
Minimum Inlet Pressure
30 psi
Maximum Inlet Pressure
100 psi
Pump
Heavy-duty maintenance-free axial cam
Thermal Relief Valve
Included
Minimum Temperature of
Pumped Water
41°F(5°C)
Maximum Temperature of
Pumped Water
140°F(60°C)
Inlet & Discharge Ports
3/4" (19 mm) standard garden hose connector
High Pressure Hose Length
25' (7.6 m)
Engine Displacement
208 cc
Engine Power
7.0 HP
Engine Running Speed
(without load)
3600rpm
Fuel type
Unleaded Gasoline
Fuel tank capacity
2.7 L
Oil type
SAE 10W-30
Oil capacity
0.6 L
Wheel
9”
Detergent tank
0.79 G (3.0 L)
GPW2600 GAS PRESSURE WASHER
5
2, SAFETY INSTRUCTIONS
WARNING
To reduce the risk of serious injury, read all instructions and precautions
before operating this machine.
SYMBOL MEANINGS:
TOXIC
This symbol warns you of possible toxic gases
which can be harmful to your health or deadly if
you are exposed to them.
FLAMMABLE
AND
COMBUSTABLE
MATERIALS
This symbol warns of materials/gases which are
present and extremely flammable. When you see
this symbol, be very cautious not to ignite the
material/gases.
VERY
POISONOUS
This symbol warns of materials, gases, etc. which
are very poisonous and would cause serious
bodily harm or death. When you see this symbol,
please take proper precautions.
HOT SURFACE
This symbol warns of a hot surface which could
cause damage to material and/or damage to
human skin if touched. Please take proper
precautions when you see this symbol.
GENERAL
WARNING
This symbol indicates that serious bodily injury or
death could occur if proper precautions are not
taken. These are warning statements which do
not fall into the above categories
EXHAUST FUMES ARE DANGEROUS
• Never operate unit in enclosed areas such as garages, basements, storage, sheds,
or in any location occupied by humans or animals. Never operate the engine in a
closed area or it may cause unconsciousness and death within a short time. Operate
pressure washer in clean, dry, well-ventilated area.
• Keep children, pets and others away from area of operating unit. Breathing exhaust
fumes will cause serious injury or death.
WARNING - Gasoline engines produce toxic carbon monoxide exhaust fumes.
GPW2600 GAS PRESSURE WASHER
6
INADEQUATE VENTILATION
• Materials placed against or near the pressure washer or operating in areas where
the temperature exceeds 40°C ambient (such as storage rooms or garages) can
interfere with its proper ventilation features causing overheating and possible ignition
of the materials or buildings.
• Operate pressure washer in a clean, dry, well-ventilated area a minimum of 4’ (1.2
m) from any building, object or wall. DO NOT OPERATE UNIT INDOORS OR IN
ANY CONFINED AREA.
FUEL IS HIGHLY FLAMMABLE AND POISONOUS
• Always turn off the engine when refuelling.
• Never refuel while smoking or in the vicinity of an open flame.
• When operating or manoeuvring this pressure washer, be sure to keep it upright. If it
tilts, fuel may leak from the carburettor or fuel tank.
DO NOT ATTEMPT TO FILL GASOLINE TANK WHILE ENGINE
IS RUNNING
• Gasoline and gasoline vapours can become ignited by coming into contact with hot
components such as the muffler, engine exhaust gases, or from an electrical spark.
• Turn engine off and allow it to cool before adding fuel to the tank. Equip the area of
operation with a fire extinguisher certified to handle gasoline or fuel fires.
SPARKS, FIRE, HOT OBJECTS
• Cigarettes, sparks, fires, or other hot objects can cause gasoline or gasoline
vapours to ignite.
GPW2600 GAS PRESSURE WASHER
7
ENGINE AND MUFFLER MAY BE HOT
• Place the pressure washer in an appropriate location, away from children and
pedestrians.
• Avoid placing any flammable materials near the exhaust outlet during operation or
shortly thereafter.
• Keep a 4’ (1.2 m) clearance from buildings or other equipment around the pressure
washer to prevent overheating.
• WARNING - The engine muffler will be very hot during and after use, avoid
touching the engine or muffler while they are still hot.
HOT MUFFLER & HIGH PRESSURE HOSE
• Muffler will become very hot during operation. DO NOT TOUCH MUFFLER WHILE
IN USE OR SHORTLY THERE AFTER.
• Keep hose away from the hot muffler or it may damage the hose. Do not use a
damaged high pressure hose. Do not kink the high pressure hose.
NEVER OPERATE UNDER THE FOLLOWING CONDITIONS
• When a noticeable change in engine speed occurs.
• Engine misfires.
• Loss of water pressure.
• Smoke or flames in the area.
• Excessive vibration.
WATER SPRAY
• Never direct the water spray towards ANY person, animal, electrical wiring or the
pressure washer itself.
• DO NOT spray too close to the surface or damage could occur.
• The vendor is not responsible for damage caused by improper use.
GPW2600 GAS PRESSURE WASHER
8
PREVENT ACCIDENTAL WATER SPRAY
• To prevent accidental water spray, the wand trigger should be placed in the locked
position when not in use.
KEEP HANDS AWAY
• Keep hands and other body parts away from high pressure water stream as water
pressure will cause severe bodily harm.
SAFETY GLASSES
• Always wear safety glasses while operating.
DETERGENTS
• Only use recommended detergents for pressure washers. Using detergents not
specifically recommended for use with pressure washers can cause damage to
pump and other pressure washer components.
• DAMAGE CAUSED TO PRESSURE WASHER UNIT BY USING NON-
RECOMMENDED DETERGENT IS NOT COVERED UNDER WARRANTY.
COLD WEATHER STARTS
• Do not operate this pressure washer in temperatures below 5°C. Operating pressure
washer under the temperature of 5°C may cause damage to pump and other
pressure washer parts.
• DAMAGE TO PRESSURE WASHER UNIT BY USER MISUSE IS NOT COVERED
UNDER WARRANTY.
SAFETY FEATURES
• Thermal Relief Valve
Protects the pump from overheating in case nozzle becomes clogged. This system
should not be abused. Make every effort to prevent the pump from overheating.
• Low-Oil Auto Shut-Off
This pressure washer is equipped with a low oil shut-off system. If the engine oil
level goes below the recommended oil level, the pressure washer will automatically
shut-off. This protects your engine and prevents operating without proper lubrication.
GPW2600 GAS PRESSURE WASHER
9
PREVENT PUMP DAMAGE
• Do not run the pressure washer engine for more than 5 minutes without pressing the
wand trigger or damage to the pump may result.
• Never let the machine run unless connected to the water supply. Ensure water
supply is running water through the pressure washer before attempting to start
engine.
• Never run caustic fluids or acid through this machine.
GPW2600 GAS PRESSURE WASHER
10
3, INTRODUCTION
Ref.
Description
Ref.
Description
1
Spray gun
11
Fuel tank
2
Nozzles
12
Hand cord
3
Muffler
13
Engine switch
4
Air filter
14
Oil dipstick
5
Throttle lever
15
Pressure hose
6
Choke lever
16
Detergent suction connector
7
Fuel valve
17
Inlet of pump
8
Detergent tank cap
18
Thermal relieve valve
9
Detergent tank
19
Outlet of pump
10
Fuel tank cap
20
Spark plug
GPW2600 GAS PRESSURE WASHER
11
4, PART LIST
Frame *1
Handle *1
Pressure hose *1
Gun *1
Wand *1
Gun holster *1
Hose hook *1
Wheel *2
Knob*2
Others: Manual *1；Nozzle cleaner*1；Spark plug wrench *1；O-ring*2 (1for
pressure hose，1for spray gun).
WARNING! Before attempting to start pressure washer, ensure you complete the
following important steps.
1) Fill gasoline tank with Unleaded Gasoline. This is a 4-cycle engine with separate
reservoirs for gas and oil. DO NOT use pre-mixed gas! DO NOT use old gas! Fuel must
be purchased separately.
2) Fill oil tank with SAE 10W-30 oil. Running pressure washer without oil will severely
damage engine which is not covered by warranty! Oil must be purchased separately.
GPW2600 GAS PRESSURE WASHER
12
3) Ensure both the pressure hose and garden hose have been correctly attached to the
pressure washer pump. Ensure the water tap is on and water is running through the
hose before attempting to start engine. Not doing this will damage the pump!
GPW2600 GAS PRESSURE WASHER
13
5, ASSEMBLY INSTRUCTIONS
1. Lift the frame with one hand and attach
one of the wheels by pressing the
wheel’s pin and inserting the wheel shaft
into the main frame. Align the pin with the
hole on the frame (A) until it snaps in.
Repeat for the opposite side.
2. Position handle assembly and main
frame and connect them with square
neck bolt, then fasten with the knob.
Repeat this procedure for the opposite
side. When storing the machine, you can
unscrew the knob and fold down the
frame.
3. Slide the upper gun holster all the way
down into the handle assembly.
4. Attach the hose hook to the back of
handle assembly until it slides into place.
5. Assemble the spray gun with the metal
wand. Pull back the rubber piece to
expose the threaded fitting. Then, screw
the two pieces together and move the
rubber piece back.
GPW2600 GAS PRESSURE WASHER
14
6, PREPARATION
1. OIL LEVEL
Check the oil level：
1) Turn the oil gauge dipstick counter
clockwise; remove it and clean it with a
clean cloth.
2) Fully reinsert the oil gauge dipstick and
pull it out to check the oil level.
3) If the oil level is halfway up the dipstick
or below, refill with SAE 10W-30 oil
through the dipstick hole until the oil
level reaches 3/4 up the dipstick or until
it reaches the bottom lip of the dipstick
hole as shown in illustration to the right.
Always use SAE 10W-30 oil.
Oil crankcase capacity: 0.6L
4) Reposition the oil gauge dipstick and tighten it by turning clockwise.
2. FUEL LEVEL
WARNING!
Pressure washer has no oil currently in crankcase! Operating the
unit without the correct amount of oil will damage the engine.
Always check the oil level before starting the engine, make sure the
pressure washer is on a level surface before checking oil level.
WARNING!
Make sure there is enough fuel in the fuel tank before operating.
This is a 4-cycle engine and does not require a gas/oil mixture.
There is a separate reservoir for gas and a separate reservoir for
oil.
GPW2600 GAS PRESSURE WASHER
15
1) If it is necessary to add fuel, first make sure the engine is OFF, and then
remove the fuel cap by turning it counter
clockwise.
2) When refueling, make sure the fuel filter is in
place and keep in mind all safety precautions.
3) Use clean unleaded gasoline with a minimum of
87 octane. DO NOT use old gas. DO NOT mix
oil with gasoline.
Fuel tank capacity: 2.7L..
3. AIR FILTER
1) Screw off the nut on the cover anticlockwise, take down the cover.
2) Remove the air filter, wash filter in kerosene, squeeze kerosene out, soak
filter in engine oil and squeeze engine oil out.
3) Replace filter and replace the air filter cover.
WARNING!
The air filter should be checked after prolonged storage, the
following steps should be done when checking the air filter. It is
recommended to replace the air filter once every spring.
GPW2600 GAS PRESSURE WASHER
16
7, OPERATING INSTRUCTION
1. STARTINGPROCEDURE
➢ Connect garden hose
➢ Connect spray gun and pressure hose
GPW2600 GAS PRESSURE WASHER
17
➢ Open water source
Supply Water
➢ Start engine
WARNING！
Make sure to check the oil level and fuel level to prevent engine
damage.
GPW2600 GAS PRESSURE WASHER
18
Step #1：Turn the engine switch into “ON” position.
Step #2：Locate choke lever to “CLOSE” position.
Step #3：Turn the fuel valve into “ON” position.
Step #4：Put the throttle lever to the “FAST” position.
Step #5：Locate recoil cord and pull slowly until resistance is felt. At this
point, pull rapidly to start engine.
Step #6：After engine starting, locate choke lever to “OPEN” position.
TIPS
：
If unable to start the engine, please repeat the above operation one
or two times.
Step #1
Step #3
Step #4
Step #2
Step #5
Step #6
GPW2600 GAS PRESSURE WASHER
19
NOTICE
：
When the environment temperature is higher such as summer,
or engine is in a hot state, choke valve should be switched to "ON" or
intermediate position, then start the engine.
2. INSTRUCTIONS FOR USE
➢ Cleaning operation
Position the tip of the wand 6-8” (15-20
cm) away from the surface to clean at a
45°angle.
➢ Nozzles
This pressure washer comes with 5
different pattern of nozzles.
RED 0°
：
Thin and powerful stream of
water for difficult stains and debris removal.
YELLOW 15°
：
Thin angled spray for
focused cleaning.
GREEN 25°
：
Medium angled spray for
focused cleaning.
WHITE 40°
：
Large fan pattern for wider
cleaning applications.
BLACK detergent
：
This nozzle must
be used in conjunction with a cleaning
detergent at low pressure. Only use this nozzle when using a detergent or
cleaning solution.
➢ ADJUSTING WATER PRESSURE
GPW2600 GAS PRESSURE WASHER
20
This engine comes with a throttle
lever. The pressure can be adjusted by
changing the speed of engine.
Turning the throttle lever to the left
can increase the speed to get more
pressure.
Turning the throttle lever to the right can decrease the speed to get less
pressure.
➢ DETERGENT INJECTOR (LOW
PRESSURE)
This pressure equips a detergent bottle.
Pure detergent into the bottle, and fit black
nozzle on the wand, then squeeze the
trigger. The detergent will be mixed with
water and sprayed out. It will achieve a
better cleaning effect.
WARNING!
When moving the engine throttle to the minimum (rightmost), the
output power of engine is low. Please don’t operate the machine, if
not, the machine will be flameout stop due to low engine output
power.
WARNING!
This pressure washer is intended for use with pressure washer
detergents only.
Do not use powdered soaps which will clog the injection system.
Follow the detergent manufacturer’s directions.
GPW2600 GAS PRESSURE WASHER
21
➢ Shut down the pressure washer
Step #1：Turn the engine switch into “OFF” position to shut down the
engine.
Step #2：Turn the fuel valve into “OFF” position to cut off the fuel..
Step #3：Squeeze the trigger of spray gun, release the pressure inside
the pump.
Step #4：Cut off the water supply.
Step #5：Squeeze the trigger again to drain the rest water of system.
Step #6：Disconnect the pressure hose and spray gun.
Step #7：Put the gun and hose on the hook.
All done!
WARNING!
Some cleaning jobs can be completed by using only water, but for
most, it is advantageous to use a detergent to penetrate and remove
the dirt more effectively. When using pressure washer approved
detergent, make sure the surface to clean is dry. Wetting the surface
first is not recommended; it will dilute the detergent and will reduce the
cleaning effectiveness.
Avoid hot surfaces or direct sunlight; this will minimize the chances of
the detergent damaging the painted surface.
DO NOT let the detergent dry or it may damage the painted surface.
Allow the detergent to remain on the surface for a short time before
rinsing with clean water under high pressure.
GPW2600 GAS PRESSURE WASHER
22
8, TROUBLESHOOTING
PROBLEM
POSSIBLE CAUSE
SOLUTION
Engine
Engine
doesn’t
start or is
difficult to
start
The engine power switch is in
OFF (o) position
Ensure the switch is in ON (I) position
No fuel
Fill the fuel tank with regular gasoline
Low oil shut down sensor
tripped to protect engine (not
applicable to 2600 psi
pressure washer)
Add oil until it reaches minimum level on
dip stick
Excess water pressure in
pump or hose
Release water pressure by squeezing
trigger on gun
Choke lever not in right
position
1. When cold starting the engine, set the
choke to START or OFF.
2. When warm starting, set the choke to
RUN or ON or try the middle position.
Clogged carburetor
Clean the carburetor. Refer to the
instruction manual
Carbon build-up on spark
plug
Clean the spark plug. Refer to the
instruction manual
Incorrect starting method
Use correct starting method. Refer to the
instruction manual
Engine
stops after
starting
Low oil or no fuel
Check oil and fuel levels
Choke lever in Start position
Move the choke lever to RUN position
immediately after starting the engine
Engine
lacks
power
Clogged air filter
Clean or replace the air filter. Refer to
the instruction manual
Clogged carburetor
Clean the carburetor. Refer to the
instruction manual
Engine
stops
while
moving
or being
tiled
Low oil shut down sensor
tripped to protect engine (not
applicable to 2600 psi
pressure washer)
Do not tilt the machine past 15° when
operating. Check oil level and ensure it
is above the minimum level on the dip
stick
Carburetor
leaks
Carburetor is clogged
Clean the carburetor. Refer to the
instruction manual
Starter
rope
doesn't
recoil
Recoil mechanism is broken
Call customer service toll-free
Engine
sounds
abnormal
or
overloaded
RPM too low
Adjust throttle lever to Fast position
Clogged nozzle
Clean nozzle with tip cleaner
Pressure is too high
Call customer service toll-free
GPW2600 GAS PRESSURE WASHER
23
PROBLEM
POSSIBLE CAUSE
SOLUTION
Pump
No pressure, low
pressure
Nozzle tip not attached
Attach required nozzle tip
Water supply faucet
closed
Turn on faucet. Ensure there are
no kinks or blockage in hose
Water supply pressure is
low
Ensure faucet is fully opened.
Check to make sure water supply
is a minimum 30 psi, 4 GPM
Inlet water filter is
clogged
Clean the water filter. Refer to the
instruction manual
Air in pump
Squeeze trigger to release the air
in pump when the machine is
running
The loaded RPM is not
set to FAST
Set RPM (throttle lever) to FAST
position
Clogged check valve
Call customer service toll-free
Damaged pump
Call customer service toll-free
Pressure too high
Clogged nozzle
Clean nozzle with tip cleaner
Water or oil leaks out of
pump
Damaged seal ring
Call customer service toll-free
Cold water keeps
draining out of thermal
relief valve
Defective thermal relief
valve
Call customer service toll-free
Accessories & Connections
No intake of detergent
The detergent siphon
tube is not connected
Connect detergent siphon tube
properly. Refer to the instruction
manual
Damaged detergent
siphon tube
Replace the detergent siphon tube
Wrong nozzle
Use black nozzle when applying
detergent. Refer to the instruction
manual
Detergent adjustment
knob set to wrong
position
Check adjustment knob. Refer to
the instruction manual
Clogged nozzle
Clean nozzle
Clogged pump detergent
siphon fitting
Detach the detergent siphon tube
and clean the fitting with tip cleaner
Detergent is too thick.
Clogged detergent filter
Use only detergent approved for
use with pressure washer
Only applies to
GPW2600 2600 psi
pressure washer
Clean detergent filter
The trigger can’t be
squeezed
Safety lock is not open
Open the safety lock. Refer to the
instruction manual
There is water leakage at
joints/connections on
gun, hose and/or pump
Damaged seal ring
Change with back-up O-ring or
purchase accessory kit
High pressure hose can’t
be connected to pump or
gun
The O rings are not
lubricated
Put lubricating oil or water on the O
rings
GPW2600 GAS PRESSURE WASHER
24
9, MAINTENANCE
➢ WATER INLET FILTER:
This pressure washer is equipped with a
water inlet filter.
This water filter must be kept clean at all
times or else it will restrict the water flow to
the pressure washer and may damage the
pump.
Remove the quick connect coupling from the water inlet, then remove
and clean water filter.
DO NOT operate this pressure washer without the water inlet filter in
place as deposits could build up internally and affect the functioning of the
unit.
➢ ENGINE MAINTAINENCE:
Engine oil should be replaced after the
first 5 hours of operation.
It should be replaced every 100 hours or
every year.
To replace engine oil: loosen the oil
gauge dipstick. Place an oil pan underneath
drain hex screw, remove hex screw and drain oil. Once all the oil has
completely drained, retighten the hex screw.
***It is recommended to use SAE10W-30 4-stroke gasoline engine oil.
***Fill with clean engine oil through the oil gauge dipstick hole to
recommended level.
HES
SCREW
GPW2600 GAS PRESSURE WASHER
25
➢ CLEANING CARBURETOR
1) Screw down the bolt on the bottom of
carburetor with wrench.
2) Push the float up four to five times, then
clean sediment cup with gas.
3) Put the sediment cup back.
*** Be careful not to miss the O ring.
➢ INSPECTING SPARK PLUG
The spark plug should be checked every
100 hours of operation or every year.
➢ REPLACING AND CLEANNING
SPARK PLUG
1) Dismantle the spark plug wire by pulling
it off the spark plug. Using the supplied
spark plug wrench, undo the spark plug
by turning counter clockwise.
2) Check to see if there is carbon sediment
build-up, if so, remove it. If the carbon sediment is excessive, replace the
spark plug.
3) Measure the electrodes clearance using a feeler gauge. The spark plug
electrode clearance should be 0.7-0.8 mm. If the clearance exceeds 0.8
mm, replace the spark plug.
4) Reinstall spark plug in the reverse order.
GPW2600 GAS PRESSURE WASHER
26
10, STROAGE
➢ FUEL STABILIZER
1) Add fuel stabilizer to fuel tank to
minimize the formation of fuel gum
deposits during storage.
2) Run engine at least 5 minutes after
adding stabilizer to allow it to enter the
fuel system.
NOTE: If a fuel stabilizer is not used, all gasoline must be drained from
the tank and carburetor to prevent gum deposits from forming on these parts
and causing possible malfunction of the engine.
➢ DRAINING FUEL
1) Turn fuel valve to the “OFF” position,
remove drain hex screw from the
carburetor.
2) Now turn fuel valve to the “ON” position
and drain the fuel from the tank, carburetor
and hose.
3) Reposition the carburetor drain hex screw
once the fuel is completely drained.
➢ DRAINING OIL
Refer to →PAGE 19 ENGINE MAINTAINENCE.
FUEL STABILIZER
FUEL TANK
Draining
Bolt
GPW2600 GAS PRESSURE WASHER
27
➢ RUST PROTECTION
1) Pour approximately one teaspoon of
engine oil through the spark plug hole and
pull the recoil starter slowly until you feel
increased pressure which indicates the
piston is on its compression stroke and
leave it in this position. This closes both the
intake and exhaust valves to prevent the
inside of the cylinder from rusting.
2) Cover the pressure washer and store it in a
clean, well ventilated and dry place. Ensure
storage area is at room temperature.
3) In addition, in order to prevent external parts
rust, please daub anti-rust oil to bolts and nuts of machine at least every
one year.
➢ PUMP ANTIFREEZE
If your pressure washer is subjected to freezing temperatures, damage
could occur. This type of damage is not covered under warranty. To avoid
possible damage, a small amount of antifreeze can be used.
1) Place the unit on its side with the water inlet facing upwards, pour 1/4 cup
of antifreeze into the water inlet.
2) Disconnect spark plug wire, and then pull recoil starter several times to
circulate the antifreeze in the pump system. Reconnect spark plug wire.
3) It is also important to make sure the wand and all hoses are
disconnected and drained of all water or they may burst.
When taking pressure washer out of storage, run water through the
system until it runs clear.
Engine
Oil
Spark
Plug
GPW2600 GAS PRESSURE WASHER
28
10.
L
IMITED
W
ARRANTY
Always keep your receipt as proof of purchase.
We’re here to help! If you have any questions or comments, call our Toll-Free 1-
888-834-4218. Have your serial number ready. The serial number can be found
on the back plate, located on the rear of the unit.
This product has a Parts Replacement, Product Exchange and/or Repair
Warranty only.
NO REFUNDS will be provided. Please see stores for Product Exchange details.
One-Year Warranty – Motor
This product is guaranteed to be free from defects in material and workmanship
for one year from the date of its original purchase. If such a defect appears during
the warranty period, upon presentation of proof of purchase, American Warranty
Service (AWS) will repair or replace the product (at its discretion). Shipping
charges may apply.
Ninety-(90)-Day Warranty – Accessories
Trigger gun, hose, spray wands and other accessories are guaranteed for 90
days from the date of purchase. You may purchase accessories directly through
the place of purchase or by calling our Toll-Free number 1-888-834-4218.
This warranty does not cover accidental damage, unreasonable use, normal wear
and tear, use of improper detergents, freezing, neglecter non-compliance with the
operating instructions. The warranty does not cover loss of use or other
consequential damages arising from any of the above, nor does it cover repairs
made or attempted by unauthorized persons.
The warranty is void if the equipment is used for commercial, rental, or industrial
purposes.
If you have further questions, please visit our website (www.green-
poweramerica.com, or www.g-pamerica.com ) or call Toll-Free number 1-888-
834-4218.
