10
Please read the instructions carefully and keep for future reference. Information may be
updated from time to time so please refer to the manual online for the latest version of the manual.
OWNER’S MANUAL
OUTDOOR REFRIGERATOR
MODEL - OR 460
Equator Appliances undertakes to the consumer-owner to repair or, at
our option, to replace any part of this product which proves to be defective
in workmanship or material under normal personal, family or household
use, in USA and Canada, for a period of one year from the date of original
purchase. For commercial use, the product is warranted for a period of
90 Days. During this period, we will provide all labor and parts necessary
to correct such defect, free of charge, if the appliance has been Installed
and operated in accordance with the written instructions with the appliance.
Ready access to the appliance, for service, is the responsibility of the
consumer-owner. Services would be provided from Monday to
Friday between normal business hours.
In no event shall Equator Appliances be liable for incidental or
consequential damages or for damages resulting from external
causes such as abuse, misuse, incorrect voltage or acts of God. This
warranty does not cover service calls which do not involve defective
workmanship or materials covered by this warranty. Accordingly,
diagnosis and repair costs for a service call which does not involve
defective workmanship or materials will be the responsibility of the
consumer-owner.
Warranty
Exclusions
Specifically, the following work is not covered under
warranty and does not constitute warranty work:
Installation - e.g. Installing as built-in
Maintenance - e.g. Cleaning the appliance using solvents
Mishandling - e.g. Breakage of door or shelves
Most work is covered. The defining factor is, has the machine
malfunctioned (Equator Appliances is responsible) or has the customer
omitted or done something to cause the machine to malfunction
(customer is responsible). Some states do not allow the exclusion or
limitation of incidental or consequential damages, so the above limitation
of exclusion may not apply to you.
You can register your Warranty by either of the following methods:
Call: 1-800-776-3538
Email: [email protected]
Web: www.ApplianceDesk.com
Business hours: 9:00 am to 5:00 pm weekdays
For Service:
This warranty is given by:
Equator Appliances
10222 Georgibelle Drive, Suite 200
Houston, Texas 77043-5249
Since it is a responsibility of the consumer-owner to establish
the warranty period by verifying the original purchase date,
Equator Appliances recommends that a receipt, delivery slip or
some other appropriate payment record be kept for that purpose.
This warranty gives you specific legal rights, and you may also
have other rights which vary from State to State.
WARRANTY SERVICE
GENERAL
1. Open Smart Phone
2. Open Camera
3. Scan QR Code
4. Click the Link
QR Code
1. Scan QR Code
2. Register online at ApplianceDesk.com/Warranty
Safety
1
Refrigerant and foaming material is flammable. Take precautions
during handling, installation, and maintenance.
Ensure that the refrigerant circuit is not damaged.
Keep ventilation openings clear of obstructions.
When positioning the appliance, ensure the electrical cord is not
trapped or damaged.
Do not place multiple portable socket-outlets at the rear of the
appliance.
Do not use a damaged power cord.
Do not use an extension cord.
Children should be supervised to ensure that they do not climb
on or play with the appliance.
This appliance is not intended for use by persons (including
children) with reduced physical, sensory or mental capabilities,
or lack of experience and knowledge, unless they have been
given supervision or instruction.
Never unplug the appliance by pulling on the power cord.
Grip the plug firmly and pull straight out from wall socket.
Do not store explosive substances such as aerosol cans with a
flammable propellant in this appliance.
Safe Disposal
Before discarding the appliance, remove the door in order to
prevent risk of child entrapment. Leave the shelves in place.
Dispose o ffthis appliance in accordance with local regulations.
2
Placement and Operation
Do not tilt the Refrigerator at an angle of more than 45° when
moving it.
The Refrigerator is designed for outdoor use and can withstand
temperatures between 32℉ -101℉ (0℃ to 38℃).
Place the Outdoor Refrigerator in a covered area to protect
from direct sunlight and heavy rainfall.
Place the Refrigerator on a flat level surface.
If placing against a wall, leave at least 3 inches (8 cm) between
the back of the Refrigerator and the wall to allow for adequate
ventilation.
Check the plug and cable before you connect the power and
ensure it is the correct 110 voltage.
Once in place, ensure that the feet are adjusted to make the
appliance level.
After moving the Outdoor Refrigerator in place, wait at least
10 minutes before turning it on, in order to allow the coolant
to settle.
3
Temperature Setting
Press the Power ON/OFF button to turn the appliance on.
Press the Light ON/OFF button to turn on the LED light inside
the Outdoor Refrigerator.
The temperature range of the appliance is 34℉-50℉ (1℃-10℃).
Increase or decrease the temperature by pressing the Up and
Down arrows.
Pressing the Up and Down temperature arrows for 5 seconds
at the same time will change the temperature between ℃ & ℉.
The Outdoor Refrigerator comes equipped with a built-in lock
on the side and a key is included.
Maintenance
Make sure the power cord is unplugged before moving or
cleaning the back of the appliance.
Clean the outside and inside of the appliance regularly, using
water and mild detergent.
The Control Panel is located inside the Outdoor Refrigerator.
The temperature can be set as shown below.
Power
On/Off
Light
On/Off
Temperature
Display
Lower
Temperature
Increase
Temperature
12
4
Not Working
Door seal is damaged.
Check the fuse in the electrical panel
Check if it is plugged in correctly to the
power source.
Temperature is not set correctly.
Adjust the temperature.
Move it if near a heat source or in
direct sunlight.
Door opened frequently or is not
shut properly.
Troubleshooting
Check for proper ventilation and that
air inlet or outlet is not blocked.
Not Cooling
Check the door seal.
Shelves are not positioned properly.
Adjust the shelves.
Door does not
close properly
Too much
noise
Appliance not placed on flat surface or
not level.
Some parts are loose causing rattling.
Possible Cause and SolutionProblem
The following phenomenon is normal:
· Moisture on the glass door – wipe with dry cloth
· Sound of fluid is the compressor when it is starting or stopping
· Flowing sound of refrigerant in the refrigeration system
· Condensation forming inside the cabinet – wipe with dry cloth
5
WARNING: This product contains chemicals known to the State of California to cause cancer
and birth defects or other reproductive harm.
Technical Specifications
Model
Capacity
Voltage
Current
Refrigerant
Temperature Range
Net Weight (lbs)
Product Dimensions (HxWxD)
OR 460
4.6 cu.ft
110~115V / 60Hz
0.4 A
R600a
33.8 F - 50 F
86
34.25 x 23.42 x 22.24 (inch)
O O
California Proposition 65
