IMPORTANT SAFETY INSTRUCTIONS
DO NOT DESTROY
HOW TO USE YOUR HEATING PAD OR HEAT WRAP
1.
Make sure Control Connector is securely attached to the Pad Connector (Figure 2). Push both parts together for
a tight fit.
NOTE: Control must be connected to heating pad before plugging unit into outlet.
2.
After control is connected to pad, plug into 120V AC electrical outlet.
3.
To turn the pad ON press the Control/Power Button (Figure 1).
4.
To select desired heat setting, continue pressing the Control Button, or for XpressHeat
®
use the HEAT
▲
or
HEAT
▼
heat setting buttons (Figure 1, Letter F).
5. Wait for the pad to heat up.
6.
To turn the pad OFF, scroll through the remaining heat settings by pressing the Control Button sequentially until
all heat indicator lights are turned off, or for XpressHeat
®
press the Power Button (Figure 1, Letter B).
CAUTION: Avoid sitting on or crushing pad. Avoid folding during use.
DANGER:
TO REDUCE RISKS OF BURNS, ELECTRIC SHOCK,
FIRE, AND PERSONAL INJURY, THIS PRODUCT MUST BE USED IN
Figure 1
XpressHeat
®
A.
Display
B. Power Button
C. Mode Button
Figure 2
A.
Control
Connector
B.
Pad
ACCORDANCE
WITH
THE
FOLLOWING
INSTRUCTIONS:
Control
1.
READ ALL INSTRUCTIONS.
Button
2.
DO NOT USE WHILE SLEEPING.
D. Auto Off Indicator
E.
Heat Meter
F. Heat Setting Buttons
Connector
3.
DO NOT USE ON AN INFANT OR ON AN ANIMAL.
4.
THIS PAD IS NOT TO BE USED ON OR BY AN INVALID, SLEEPING,
HELPLESS OR
UNCONSCIOUS
PERSON, A
PERSON
WITH
DIABETES,
A PERSON WITH POOR BLOOD CIRCULATION OR INSENSITIVITY TO
Auto-Off
AUTO-OFF FEATURE:
CONTROLLER FEATURES
HEAT.
5.
THIS APPLIANCE IS NOT TO BE USED BY CHILDREN. CLOSE
SUPERVISION IS NECESSARY WHEN ANY APPLIANCE IS USED
NEAR CHILDREN. CHILDREN SHOULD NOT PLAY WITH THE
APPLIANCE.
6.
DO NOT USE ON AREAS OF INSENSITIVE SKIN.
7.
BURNS CAN OCCUR REGARDLESS OF CONTROL SETTING, CHECK
SKIN UNDER PAD FREQUENTLY.
8.
IF PROVIDED WITH A REMOVABLE COVER, NEVER USE PAD
WITHOUT COVER IN PLACE.
9.
DO NOT USE IN AN OXYGEN ATMOSPHERE.
10.
DO NOT USE PINS OR OTHER METALLIC MEANS TO FASTEN THIS
PAD IN PLACE.
11.
DO NOT SIT ON, AGAINST, OR CRUSH PAD – AVOID SHARP FOLDS.
PLACE PAD ON TOP OF AND NOT UNDER THE PART OF BODY
NEEDING HEAT.
12.
UNPLUG WHEN NOT IN USE. NEVER LEAVE APPLIANCE
UNATTENDED, ESPECIALLY IF CHILDREN ARE PRESENT.
13.
NEVER PULL THIS PAD BY THE SUPPLY CORD. DO NOT USE THE
CORD AS A HANDLE. DO NOT PINCH CORD.
14.
DO NOT TUCK IN, TRAP, FOLD, CROSS, PINCH OR WRAP CONTROL
OR CORD WITH HEATING PAD DURING USE.
15.
CAREFULLY EXAMINE PAD, COVER, CORD
AND
CONTROLLER
BEFORE EACH USE. DISCARD THE PAD IF ANY SIGN OF
DETERIORATION, WEAR OR DAMAGE. DO NOT TAMPER WITH THIS
PAD IN ANY WAY. THERE ARE
NO
USER
SERVICEABLE
PARTS. IF
PAD DOES NOT FUNCTION SATISFACTORILY, SEE WARRANTY FOR
CUSTOMER CONTACT INFORMATION.
16.
LOOP CORD LOOSELY WHEN STORING, TIGHT WRAPPING MAY
DAMAGE CORD AND INTERNAL PARTS. ALLOW TO COOL BEFORE
STORING AND
DO
NOT
CREASE
BY
PLACING
ITEMS
ON
TOP
OF
IT. STORE IN THE ORIGINAL PACKAGING, IN A COOL, DARK, DRY
PLACE.
17.
USE ONLY WITH THE PROVIDED CONTROLLER.
18.
USE THIS PAD ONLY AT RATED VOLTAGE, AS MARKED ON THE
PRODUCT. DO NOT USE WITH GENERATORS, POWER CONVERTERS,
OR INVERTERS.
19.
DO NOT USE THIS PAD WITH LINIMENT, SALVE OR OINTMENT
PREPARATIONS. SKIN BURNS COULD RESULT.
20.
IF PAD IS PROVIDED WITH MAGNETIC CLOSURES: DO NOT USE
IF YOU HAVE A PACEMAKER, ICD (IMPLANTABLE CARDIOVERTER
DEFIBRILLATOR), INTERNAL INSULIN PUMP OR OTHER MEDICAL
DEVICES SENSITIVE TO MAGNETS.
21.
THIS APPLIANCE IS NOT INTENDED FOR MEDICAL USE IN
HOSPITALS.
22.
SOME MODELS MAY CONTAIN FILLING MATERIALS (PELLETS OR
BEADS), MADE FROM EITHER ABS PLASTIC (NON-MICROWAVABLE
MODELS) OR SILICON DIOXIDE (MICROWAVABLE MODELS). IF
FILLING MATERIAL IS RELEASED DUE TO PRODUCT DAMAGE,
DISCONTINUE USE
OF
PRODUCT. DO
NOT
INGEST
FILLING
MATERIAL. IF FILLING MATERIAL IS INGESTED, SEEK MEDICAL
ATTENTION.
23.
SAVE
THESE
INSTRUCTIONS.
HOUSEHOLD USE ONLY
NORTH AMERICAN MODELS WITH POLARIZED PLUGS:
The Auto-Off feature is designed for convenience and to conserve energy by automatically turning off after 2 hours of
continuous use. Restart the unit by powering On and selecting desired heat setting.
For XpressHeat
®
, Auto-Off is a selectable feature. By pressing the "Mode"/"Auto-Off" button (Figure 1, Letter C), you
can set the timer to "Stay On" continuously, or to 2 hour Auto-Off to shut the pad down automatically after 2 hours of
heat therapy. The Auto-Off Indicator (Figure 1, Letter D) will light up to show selected mode.
NOTE: After a power outage, the Auto-Off feature automatically resets the timer.
FOR MODELS WITH XPRESSHEAT
®
:
Your Sunbeam
®
XpressHeat
®
heating pad features a unique fast-heat technology in which you will feel heat in 30
seconds - for faster pain relief! The light ring around the controls, called the Heat Meter (Figure 1, Letter E), will light
up one side at a time, indicating progress as the pad heats up. All four sides of the Heat Meter will light up within 30
seconds of powering up, indicating the pad is warm and ready for use.
USING MOIST HEAT THERAPY
For deep, penetrating pain relief, use moist heat therapy. When using moist heat therapy, you should protect furniture
and clothing from becoming damp.
Dampen either side of the pad or wrap with water by patting the surface with a wet sponge or cloth or use a spray
bottle to apply a fine mist. Do not thoroughly soak pad or wrap.
DANGER: DO NOT IMMERSE PAD OR WRAP IN WATER OR PLACE UNDER RUNNING WATER TO DAMPEN SURFACE.
FAILURE TO COMPLY MAY RESULT IN PERSONAL INJURY.
NOTICE: If your heating pad or heat wrap has a massage feature, do not use moist heat therapy to prevent damage to
the massagers.
AFTER USE
FOR MODELS WITH COMPACT STORAGE FEATURE:
1.
If model has an integrated pocket and securing tab, place the controller in the pocket, roll up pad, and secure
with the tab for neat storage.
2. If model has elastic straps, place controller and power cord on pad, roll up pad, and secure it in place with the
straps for neat storage.
WASHING INSTRUCTIONS
CAUTION: DO NOT DRY CLEAN! DO NOT BLEACH! DO NOT USE WRINGER!
1.
Disconnect pad from outlet. DO NOT PULL BY THE CORD.
2.
Disconnect controller cord from pad by holding the pad side connector with one hand and pulling firmly on the
cord side connector with the other hand.
3.
Machine wash pad in cold water on gentle cycle or hand wash. Tumble dry on low heat and remove promptly
from dryer or drape to dry.
4.
DO NOT plug in pad and pad connector until completely dry.
TROUBLESHOOTING:
Problem
Solutions
•
No heat
•
No power, controller
lights are Off
•
Verify tight connection between pad and controller.
•
Verify tight connection between unit and wall outlet.
•
Verify AC outlet is functional.
•
Verify no physical damage to the cord, controller or pad.
•
If failure continues, discontinue use. See warranty information to contact
Consumer Services.
•
Pad has no heat and
controller 'Auto-Off' light
is flashing
•
Auto-Off feature is set to turn the unit off after 2 hours of continuous use.
NOTE: For XpressHeat
®
controller, this feature is optional and by pressing the
'Mode' or 'Auto-Off' button on the controller, you can set the timer to 'Stay On'
continuously or to 2 hour Auto-Off.
•
If needed, restart the unit by powering On and selecting desired heat setting.
•
Pad has a hot spot
•
Make sure pad is not folded or bunched in any area.
•
'High' heating setting
light is flashing
•
'F' is flashing on
controller screen
The 'High' heat setting indicator light or 'F' signal will start flashing when
connection is broken between pad and controller while using the product.
•
To reset, simply connect pad and controller together tightly and then power
On and select the desired heat setting.
•
If flashing light or 'F' signal persists, an error has occurred. Discontinue use
of the product and see warranty information to contact Consumer Services.
Sunbeam
®
provides a smarter approach to pain relief that leverages heat therapy to treat pain, and accelerate
tissue healing when used as a part of your relief regimen. Heat therapy helps to relax tight muscles, ease stiffness,
facilitate stretching, and relieve common muscle and joint pain associated with muscle tension and stress.
Suggested treatment time for application of heat is 20-30 minutes, up to three times a day, for persistent pain that
lasts longer than 48 hours, unless otherwise directed.
Note: Always consult with your physician or health professional for recommended treatment of an injury or chronic
muscle or joint pain.
© 2020 Sunbeam Products, Inc. All rights reserved. Distributed by Sunbeam Products, Inc. 2381 NW Executive Center Drive, Boca Raton, Florida 33431.
FCC
COMPLIANT
This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This
device may not cause harmful interference, and (2) this device must accept any interference received, including
interference that may cause undesired operation.
Note: This product has been tested and found to comply with the limits for a Class B digital device, pursuant to part
15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a
residential installation. This product generates, uses and
can
radiate
radio
frequency
energy
and, if
not
installed
and used in accordance with the instructions, may cause harmful interference to radio communications. However,
there is no guarantee that interference will not occur in a particular installation. If this product does cause harmful
interference to radio or television reception, which can be determined by turning the product off and on, the user is
encouraged to try to correct the interference by one or more of the following measures:
•
Reorient or relocate the receiving antenna.
•
Increase the separation between the product and receiver.
•
Connect the product into an outlet on a circuit different from that to which the receiver is connected.
•
Consult the dealer or an experienced radio/TV technician for help.
Changes or modifications not expressly approved by the party responsible for compliance could void the user’s
authority to operate the equipment.
Printed in China. GCDS-SUN-JC PN: 189745 Rev B
www.sunbeam.com
THIS APPLIANCE HAS A POLARIZED PLUG (ONE BLADE IS WIDER THAN THE OTHER).
TO REDUCE THE RISK OF ELECTRIC SHOCK, THIS PLUG IS INTENDED TO FIT IN
A POLARIZED OUTLET ONLY ONE WAY. IF THE PLUG DOES NOT FIT FULLY IN THE
OUTLET, REVERSE THE PLUG. IF IT STILL DOES NOT FIT, CONTACT A QUALIFIED
ELECTRICIAN TO INSTALL THE PROPER OUTLET.
DO NOT ATTEMPT TO MODIFY THIS PLUG OR DEFEAT THIS
SAFETY FEATURE IN ANY WAY.
A
B
E
C
F
D
A
B
5-YEAR LIMITED WARRANTY
Sunbeam Products, Inc. warrants that for a period of five years from the date of purchase, this product will be free from defects in
material and workmanship. Sunbeam, at its option, will repair or replace this product or any component of the product found t o be
defective during the warranty period. Replacement will be made with a new or remanufactured product or component. If the product
is no longer available, replacement may be made with a similar product of equal or greater value. This is your exclusive warranty. Do
NOT attempt to repair or adjust any electrical or mechanical functions on this product. Doing so will void this warranty. This warranty
is valid for the original retail purchaser from the date of initial retail purchase and is not transferable. Keep the original sales receipt.
Proof of purchase is required to obtain warranty performance. Sunbeam dealers, service centers, or retail stores selling Sunbeam
products do not have the right to alter, modify or any way change the terms and conditions of this warranty. This warranty does not
cover normal wear of parts or damage resulting from any of the following: negligent use or misuse of the product, use on improper
voltage or current, use contrary to the operating instructions, disassembly, repair or alteration by anyone other than Sunbeam or an
authorized Sunbeam service center. Further, the warranty does not cover: Acts of God, such as fire, flood, hurricanes and tornadoes.
What are the limits on Sunbeam’s Liability?
Sunbeam shall not be liable for any incidental or consequential damages caused by the breach of any express, implied or statutory
warranty or condition. Except to the extent prohibited by applicable law, any implied warranty or condition of merchantability or
fitness for a particular purpose is limited in duration to the duration of the above warranty.
Sunbeam disclaims all other warranties, conditions or representations, express, implied, statutory or otherwise. Sunbeam shall
not be liable for any damages of any kind resulting from the purchase, use or misuse of, or inability to use the product including
incidental, special, consequential or similar damages or loss of profits, or for any breach of contract, fundamental or otherwise, or
for any claim brought against purchaser by any other party. Some provinces, states or jurisdictions do not allow the exclusion or
limitation of incidental or consequential damages or limitations on how long an implied warranty lasts, so the above limitations or
exclusion may not apply to you. This warranty gives you specific legal rights, and you may also have other rights that vary from
province to province, state to state or jurisdiction to jurisdiction.
How to Obtain Warranty Service
In the U.S.A.
- If you have any question regarding this warranty or would like to obtain warranty service, please call 1-800-435-1250
and a convenient service center address will be provided to you.
PLEASE DO NOT RETURN THIS PRODUCT TO ANY OF THESE ADDRESSES OR TO THE PLACE OF PURCHASE.
L ow
M e d
Hi
Sele ct / O ff
A ut o-O ff
2
H ours
Loading ...
