User Manual Tripp Lite PDU3MV6L2120LV 48 pages

Owner's Manual

For PDU3MV6L2120LV. Also, The document are for others Tripp Lite models: PDU3XV6G20, PDU3V6L2130, PDU3V6L2120LV, PDU3V6H50A, PDU3V6H50, PDU3MV6L2130A, PDU3XMV6L2220, PDU3XMV6G20, PDU3MV6H50A, PDU3MV6L2120, PDU3MV6L2120B, PDU3MV10L2120B, PDU3MV6L2130, PDU3MV6H50

Owner’s Manual

3-Phase Metered and Basic

Power Distribution Units

Important Safety Insructions 2

Installation 3

Digital Load Meter 6

Features 7

Service 8

Warranty and Product Registration 9

Español 10

Français 19

Pyccкий 28

Deutsch 37

TrippLite.Eaton.com/support

PDU3MV6L2120

(Series Number: AGPD8414)

PDU3MV6L2120LV

(Series Number: AGPD8414)

PDU3MV6L2120B

(Series Number: AGPD8414)

PDU3MV10L2120B

(Series Number: AGPD8414)

PDU3MV6L2130

(Series Number: AGPD8415)

PDU3MV6H50

(Series Number: AGPD8416)

PDU3MV6H50A

(Series Number: AGPD8417)

PDU3XMV6G20

(Series Number: AGPD8420)

PDU3XMV6L2220

(Series Number: AGPD8420)

PDU3MV6L2130A

(Series Number: AG-00E3)

PDU3V6H50

(Series Number: AGPD8416)

PDU3V6H50A

(Series Number: AGPD8417)

PDU3V6L2120LV

(Series Number: AGPD8414)

PDU3V6L2130

(Series Number: AGPD8415)

PDU3XV6G20

(Series Number: AGPD8420)

WARRANTY REGISTRATION

automatically entered to win an ISOBAR

surge protector in our monthly drawing!

tripplite.com/warranty

Loading ...

Specifications

Brand: Tripp Lite

Model: PDU3MV6L2120LV

Category: Tools - Home Improvement

PDU Input Voltage: 208

Maximum Input Amps: 16

Maximum Input Amps Details: Agency de-rated to 16A continuous

Frequency Compatibility: 50 / 60 Hz

Output Nominal Voltage: 120V

Input Cord Length (ft.): 6

Shipping Dimensions (hwd / in.): 5.40 x 6.80 x 76.00

Shipping Weight (lbs.): 14.60

Unit Dimensions (hwd / in.): 70.000 x 2.200 x 1.930

Unit Weight (lbs.): 12.7

Material of Construction: Metal

Operating Temperature Range: 32° to 104°F (0° to 40°C)

Storage Temperature Range: -22° to 140°F (-30° to 60°C)

Relative Humidity: 5% to 95% non-condensing

Operating Elevation (ft.): 0-10,000

Operating Elevation (m): 0-3000

Tripp Lite PDU3MV6L2120LV 5.7kW 3-Phase Local Metered PDU, 120V Outlets (42 5-15/20R), 208V L21-20P input, 6 ft. (1.83 m) Cord, 0U Vertical, TAA
