OWNER’S MANUAL
Portable Bluetooth
Speaker
Please read this manual carefully before operating your set and retain it for future
reference.
Model
XL5S
2211_Rev01
www.lg.com
Copyright © 2023 LG Electronics Inc. All Rights Reserved.
2
Portable Bluetooth Speaker Quick
Guide
Connecting and Using the Speaker
b
a
c
- + - +
d
<Android> <iOS>
ECHO 1
ECHO 2
A
B
D
C
C
E
A Handle
B Controls
C Flash Lighting
D Speaker (Tweeter)
E Speaker (Woofer) / Woofer Lighting
a Connect the power cord to the product by opening the rear cover
and charge it before use
3
b Connecting the speaker to a smartphone via Bluetooth ([ See
“Connecting Smartphone to the Speaker via Bluetooth” on page
12.)
A Press the Power
button to turn on the product.
B Press the Function
button on the product repeatedly to select the BT function. The BT LED blinks.
C Tap the Settings
button on your smartphone and select Bluetooth. Turn on the Bluetooth function.
( Off > On)
D From the list of smartphone devices, nd and tap on “LG-XL5S(XX).”
E Once the smartphone is connected to the product via Bluetooth, the BT LED will turn on. Play a desired track
in the music app on your smartphone.
c Playing Music from the USB ([ See “Connecting the product to
a USB storage device” on page 23.)
A Open the back cover of the product and plug the USB storage device into the USB terminal.
B Press the Power
button to turn on the product.
C Press the Function
button on the product repeatedly to select the USB function. The USB LED will turn
on.
D Press the Play/Pause
button to enjoy the music.
d Connecting to the LG XBOOM App ([ See “Installing app” on
page 17.)
A Find the LG XBOOM app on the Google Play or App Store and install it on your smartphone.
B Run the LG XBOOM app and use its functions. (EQ, Wireless Party Link, Lighting, Setting etc.)
e Power Saving ([ See “Power Saving Mode” on page 27.)
If there is no playback or button input for 15 minutes, the product turns off automatically. On the LG XBOOM
app, you can enable or disable [Auto Power Management].
4
Table of Contents
Portable Bluetooth Speaker Quick
Guide
2 Connecting and Using the Speaker
Exploring the Product
5 Top & Front
7 Back
Charge
9 Charging the Battery
11 Checking Battery Status
Connecting to Bluetooth
12 Connecting Smartphone to the Speaker via
Bluetooth
15 Connecting with two smartphones
Connecting to the LG XBOOM
App
17 Installing app
19 Using the Wireless Party Link
Connecting to USB
23 Connecting the product to a USB storage
device
Additional Functions
25 Setting Sound Effects
26 Resetting the product
26 Initializing the Software
27 Power Saving Mode
27 Using Auto power - on.
27 Voice feedback function
Safety Precautions
28 Safety and Regulatory
31 Prevention of product misuse
Things to Check before Reporting
Malfunction
35 Troubleshooting
Appendix
37 Product Specications
38 Registered Trademarks and Licenses
39 Handling the Product
5
Exploring the Product
Top & Front
PARTY LINK
a
b
c
d
e
f
g
h
i
k
i
j
a
SOUND BOOST
Changes sound effect. ([ See “Setting Sound Effects” on page 25.)
b
Lighting
Press the button to select the desired Woofer Lighting.
• You can customize the Woofer Lighting mode as you want by connecting to the LG XBOOM app.
• If you press and hold the Lighting
button for 2 seconds with product, turn the Woofer Lighting,
Flash lighting off.
c
Battery LED
Please check the battery charging level and battery status. ([ See “Checking Battery Status” on page
11.)
d
Power
It turns on/off the product.
• If you press and hold the Power
button for 2 seconds with product turned on, you can see the
battery status on the battery LED.
e
Volume
It controls the volume level.
f
Play/Pause
Press the button to operate the product.
• Play/Pause: Press the button.
• Moving to the next music: Press the button twice quickly.
• Moving to the previous music: Press the button three times quickly.
g
Function LED
Indicates the input mode or Bluetooth connection status.
6
h
Function
Press the button repeatedly to select the desired input mode or function.
• BT: It connects the product via Bluetooth.
• USB: It connects the product to a USB storage device.
• Press the Function
button on the product repeatedly to select the BT function. ([ See
“Connecting Smartphone to the Speaker via Bluetooth” on page 12.)
i
Flash Lighting
Enjoy a ash light to the beat of the music.
j
Speaker (Tweeter)
Tweeter plays accurate and clean high notes.
k
Speaker (Woofer) / Woofer Lighting
Enjoy a powerful Bass sound and colourful light show to the beat of the music.
> CAUTION
• Place the product at a safe distance from the child’s reach. Otherwise it may result in the product falling down
and causing personal injury and/or property damage.
• Be careful that the speaker does not fall down. Otherwise it may result in the speaker malfunctioning and
causing personal injury and/ or property damage.
• It is not good for the eyes to see the lens while the LED is running, do not look at it directly.
7
Back
a
b
c
d
e
f
g
h
h
i
a
MIC
Turns the knob to the right (+) or left (-) to adjust the Microphone sound volume.
Connect a microphone to the MIC jack.
b
GUITAR
Turns the knob to the right (+) or left (-) to adjust the Guitar sound volume.
Connect a guitar to the GUITAR jack.
c
AC IN
Plug in the power cord.
d
USB port
Plug in a USB storage device to enjoy music with the product.
e
MIC ECHO
Press the button to select the desired ECHO mode when the microphone is connected.
• ECHO mode: ECHO 1 / ECHO 2 / Off
f
ECHO LED
Indicates the connection status of ECHO mode.
g
RESET
When the product does not function properly, use a sharp object such as a pin to press the hole.
h
Handle
Use it when carrying the product.
i
Back Cover
Make sure to fully close the back cover after use.
• Ingress Protection: IPX4
- Liquid: Protected against splashing water.
8
> CAUTION
• Be careful not to drop the product when you carry it.
• Disconnect the connected cable before carrying the product.
• Do not step or sit on the product. Otherwise this product may fall down and cause personal injury.
• Be careful that the product should not fall down. Otherwise it may result in malfunction and cause personal
injury and/ or property damage.
• Be careful not to expose the product to sunlight for a long time to prevent discoloration.
• Be careful not to drop the speaker. Mechanical shock may cause deterioration of water-resistant performance.
Note
• Using the back cover open may cause tremors, turn the back cover back as far as possible and x it to the
product before use.
9
Charge
Charging the Battery
This product has a built-in battery. Make sure to charge the battery sufciently before use.
a Open the back cover and plug the power cable into the product.
b Plug the power cable connected to the product into an outlet.
a
b
ECHO 1
ECHO 2
Note
• It takes about 3.5 hours to fully charge the speaker. The charging time may differ depending on the battery
status or the product operation status.
• Once the battery is fully charged, you can use the speaker for about 12 hours.
- Operation time may vary depending on the battery or operation status.
10
Attaching the ferrite core (optional)
A ferrite core may not be provided depending on national standards.
Attaching the ferrite core to the power cord cable
Attach the ferrite core to the cable to reduce radio noise.
a Pull Part [a] to open the ferrite core.
b Wind the power cord cable twice around the ferrite core.
c Close the ferrite core until you hear a click.
11
Checking Battery Status
Charging Status
When the battery of the product starts charging, you can see the charging status in the battery LED.
Battery LED LED Status / Battery Status
It is green. / Charging is complete.
It is red. / Charging is in progress.
Note
• Playing tracks while charging may lengthen the charging time.
• When the speaker’s battery is fully charged with the power off, the battery LED lights up green for 15 seconds
and then off.
Use Status
When the product is turned on, the battery status is displayed on the battery LED for 3 seconds.
If you press and hold the Power
button for 2 seconds with product on, you can see the battery LED for 3
seconds depending on the battery status.
Battery LED LED Status / Battery Status
Turns on in green. / The battery level is above 70 %.
Turns on in amber. / The remaining battery level is 70 to 10 %.
It blinks red continuously and you can hear a notication sound once. /
The battery level is below 10 %, and the battery needs to be charged.
Note
• The battery status cannot be checked while charging.
12
Connecting to Bluetooth
Connecting Smartphone to the Speaker via Bluetooth
You can play music les stored on a Bluetooth device, or run music apps to enjoy the music with this product.
Please check the following rst.
• The following are the Bluetooth specications of the product.
- Bluetooth version: 5.1
- Codec: SBC, AAC
• How to connect the device to the product may differ depending on the type and model of the
Bluetooth device. For information on how to connect the product, refer to the user manual of the
Bluetooth device to be connected.
Select the [Bluetooth] menu on the smartphone's Settings screen. The menu access method may differ
depending on the smartphone manufacturer and model.
a Press the Power
button on the product to turn it on.
b Press the Function
button on the product repeatedly to select the BT function. The BT LED blinks.
PARTY LINK
USB
BT
BT
USB
PARTY LINK
V
c Tap the Setting ( / ) button on your smartphone and select Bluetooth.
(Android Phone)
13
(iPhone)
d Turn on the Bluetooth function. ( Off > On)
e You will see a list of connectable devices on the smartphone screen. Find and tap the name “LG-XL5S(XX)”.
LG-XL5S(XX)
Bluetooth devices
LG Smart Phone
Bluetooth devices
AVAILABLE DEVICES
LG-XL5S(XX)
AVAILABLE DEVICES
f Once the smartphone is connected to the product via Bluetooth, the BT LED will turn on.
PARTY LINK
USB
BT
PARTY LINK
USB
BT
g If "LG-XL5S(XX)" does not appear on the list, tap on the Refresh icon on an Android phone or restart
Bluetooth on an iPhone.
Bluetooth
Speaker
Bluetooth devices
LG Smart Phone
Bluetooth devices
On
AVAILABLE DEVICES
(Android Phone)
14
Not Connected
LG Speaeker1
Not Connected
Not Connected
Not Connected
Settings
LG Speaeker2
LG Speaeker3
LG Speaeker4
MY DEVICES
Now discoverable as “iPhone”
Bluetooth
Bluetooth
(iPhone)
h Select and play a track on the smartphone.
Note
• The closer the Bluetooth device is to the speaker, the better connection you will get.
• If the Bluetooth device is not connected, the BT LED will blink. Connect the product again.
• When using Bluetooth, adjust the volume of the Bluetooth device to an appropriate level.
• XX are the last two digits of the Bluetooth address. An example would be “LG-XL5S(08).”
• When power is connected to this product, if you try to connect to the product via a Bluetooth product with
a connection history, the product will automatically turn on and connect to the Bluetooth device. While the
power cable is connected, you can turn on this product. And, you can control this function in the LG XBOOM
app. ([ See “Using Auto power - on.” on page 27.)
15
Connecting with two smartphones
Pairing (Connecting) Multiple Phones
a Connect the product and a smartphone rst. ([ See “Connecting Smartphone to the Speaker via Bluetooth”
on page 12.)
b Press and hold the Function
button on the product for 2 seconds. The BT LED blinks for 60 seconds.
PARTY LINK
USB
BT
BT
USB
PARTY LINK
V
c Connect an additional smartphone to the product within 60 seconds. ([ See “Connecting Smartphone to
the Speaker via Bluetooth” on page 12.)
16
d When two smartphones and the product are connected, the BT LED turns on.
PARTY LINK
USB
BT
PARTY LINK
USB
BT
Note
• Multi-phone pairing (connecting) connects up to two smartphones.
• Even if two smartphones are connected, the product plays music only on one smartphone. If the music stops on
the currently played smartphone, it can be played on another smartphone.
• When two smartphones are connected and the product is turned off and on, only the last connected
smartphone or the most recently played smartphone is automatically connected.
• Only smartphones support multi phone pairing (connection). (Depending on specications of the connected
smartphones, multi phone pairing (connection) may not be connected.)
17
Connecting to the LG XBOOM App
Installing app
Use the various functions of the speaker on the LG XBOOM app.
To install the LG XBOOM app, scan the QR code with an app or install LG XBOOM app on the Google Play or
App Store.
Please check the following rst.
• The LG XBOOM app is available in the versions listed below.
- Android OS: Version 6.0 or higher
- iOS OS: Version 12.0 or higher
- Minimum supported versions for each OS may change later.
Downloading with a QR code
a Scan the QR code with a QR code scan app.
b You will be directed to the page where you can download the LG XBOOM app. Tap the app to install it.
(Android Phone OS)
(iPhone OS)
18
Downloading in Google Play or App Store
a Find the LG XBOOM app on the Google Play or App Store and install it on your smartphone.
(Android™ Phone)
(iPhone)
b Connect the smartphone to the speaker via Bluetooth. ([ See “Connecting Smartphone to the Speaker via
Bluetooth” on page 12.)
c Open the LG XBOOM app installed on the smartphone.
d Follow the instructions on the LG XBOOM app. Agree to the Terms of Service, notice windows, access
settings, etc.
e Start using the various functions on the LG XBOOM app.
Note
• The menu access method may differ depending on the smartphone manufacturer and OS.
• Google, Android, and Google Play are trademarks of Google LLC.
• The software of this product can be updated with the LG XBOOM app. Do not turn off the power of the
product while updating the software. Once the update is complete, the product power turns off automatically.
- If you turn off the power of the product while the software is being updated, it may cause a product
malfunction.
19
Using the Wireless Party Link
You can connect multiple speakers in the LG XBOOM app's Wireless Party Link. There are two ways for using the
Wireless Party Link: Dual mode and Multi mode.
Dual mode
Wireless Party Link Dual mode lets you enjoy stereo sound with two same model speakers.
Please check the following rst.
• The two speakers of the same model are needed. (e.g. XL5S and XL5S)
a Connect the speaker and a smartphone rst. ([ See “Connecting Smartphone to the Speaker via Bluetooth”
on page 12.)
b Tap the Wireless Party Link in the LG XBOOM app.
c Tap the Dual mode and connect another speaker following the instructions.
d You can see the Dual mode LED on the speakers.
• Main speaker: Party Link LED and BT LED turn on and output Left channel sound.
• Other speaker: BT LED turns on and output Right channel sound.
PARTY LINK
USB
BT
(Main speaker)
PARTY LINK
USB
BT
(Other speaker)
20
Connecting to your TV via Dual mode
a Follow the aforementioned instructions to connect two speakers via Dual mode. ([ See “Dual mode” on
page 19.)
b Press and hold the Function
button on the main speaker for 2 seconds. Then the BT LED will blink for 60
seconds.
c In the TV settings, nd and select the main speaker within 60 seconds. You can listen to the TV sound
through two speakers.
Note
• When using in dual mode with a TV, you cannot control the speakers with the LG XBOOM app.
Multi mode
Wireless Party Link Multi mode lets you enjoy more powerful sound with multiple speakers.
Please check the following rst.
• You can connect multiple LG Bluetooth speakers. (e.g. XL5S and XL7S)
a Connect the speaker and a smartphone rst. ([ See “Connecting Smartphone to the Speaker via Bluetooth”
on page 12.)
b Tap the Wireless Party Link in the LG XBOOM app.
c Tap the Multi mode and toggle the function on.
d Search for nearby speakers and select the speakers you want to connect to.
e You can see the Multi mode LED on the speakers.
• Main speaker: Party Link LED and BT LED turn on and the speaker outputs sound.
• Other speakers: BT LED turns on and speakers output sound in sync with the main speaker.
PARTY LINK
USB
BT
(Main speaker)
PARTY LINK
USB
BT
(Other speakers)
21
Note
• The Main speaker connects only one Bluetooth device.
• When using Dual/Multi mode to connect multiple speakers, the multi phone pairing connection is not
supported.
• When you turn the speakers off and on again, the speakers do not automatically reconnect.
• When you connect multiple speakers in Dual/Multi mode in USB function, it will change to Bluetooth function.
• To change the connected Bluetooth device in Dual/Multi mode, press and hold the Function
button for
2 seconds. When you hear a beep sound and the BT LED blinks, connect to the desired Bluetooth device.
• Keep the distance between the speakers as close as possible each other.
• Depending on the network environment, this function may not work well.
• The screen of a device such as a TV and the sound from the speaker may not match.
• When multiple speakers are connected in Multi mode, volume and EQ linkage between the Main speaker and
Other speakers is not available.
• When using Dual/Multi mode, Voice canceller and Key changer function is disabled.
22
Interworking multiple speakers
This speaker interworks with other LG Bluetooth speakers such as XL7S/XL5S.
Dual mode
Same model
(e.g. XL5S/ XL5S)
Main/Other
Volume O
EQ O
Lighting O
Auto Power Management O
Multi mode
Same series
(e.g. XL5S/ XL7S)
Main/Other
Lighting O
Auto Power Management O
23
Connecting to USB
Connecting the product to a USB storage device
You can enjoy sound by connecting a USB storage device with music les to the product.
a Open the back cover of the product and plug the USB storage device into the USB terminal.
• The product cannot play any devices connected with a USB storage device hub or a USB storage device cable.
• The product cannot be connected to a USB storage device, USB type MP3 player or card reader that requires
a separate device drive to be installed.
ECHO 1
ECHO 2
b Press the Power button to turn on the product.
c Press the Function
button on the product repeatedly to select the USB function. The USB LED will turn
on.
PARTY LINK
USB
BT
BT
USB
PARTY LINK
V
d Press the Play/Pause button to enjoy the music.
24
Note
• USB devices with large storage volume can take several minutes or more to browse les.
• LG Electronics is not responsible for any data loss. Please always back up the data to minimize damage caused
by data loss.
• Only FAT16/FAT32 formats are supported. exFAT/NTFS format is not supported.
• When the USB storage device is not properly recognized, the USB LED will blink. Check if the USB storage
device is supported and plug in again.
• Use the USB port of this product only for playing a media le. You cannot charge external devices with the USB
port.
USB storage devices supported
• USB ash device
• USB 2.0
This product may not recognize some USB storage devices.
Playable file specifications
File extension Sampling frequency / Bitrate
MP3 32 kHz - 48 kHz / 8 kbps - 320 kbps
WMA 32 kHz - 48 kHz / 56 kbps - 128 kbps
• Number of playable les: Up to 2,000
• Maximum number of directories: Up to 200
• This product cannot play les protected by DRM (Digital Rights Management).
• This product cannot play video les from a USB storage device.
25
Additional Functions
Setting Sound Effects
You can select a desired sound effect by using SOUND BOOST
SOUND
BOOST
button.
LED ( Off / On) Function / Description
Standard / You can enjoy High-delity sound with balanced and natural.
Custom / You can adjust the sound as you want. If you want to use
Custom EQ, connect to the LG XBOOM app.
SOUND BOOST / You can enjoy the wide sound eld and powerful sound.
Note
• Because ne-tune sound to provide optimal high-quality sound, It might be a little difference between sound
effect modes.
26
Resetting the product
You can reset the product when it operates improperly.
a Open the back cover of the product and use a sharp object to press the RESET button to power off the
product.
b Turn on by pressing the Power
button.
RESET
ECHO 1
ECHO 2
Initializing the Software
It Initializes the Bluetooth connection and settings of the product.
a Press and hold the Function
button on the product for 7 seconds or longer.
b All function LEDs will blink four times to Initialize the Bluetooth connection and all settings.
Note
• To use the Bluetooth function after Initializing the product, connect the Bluetooth device again.
27
Power Saving Mode
If there is no playback or button input for 15 minutes, the product turns off automatically. You can enable or
disable the power saving mode as follows.
Function How to Use
Enable Set [Auto Power Management] to [Enable] in the LG XBOOM app.
Disable Set [Auto Power Management] to [Disable] in the LG XBOOM app.
Note
• When the power saving function is off, the product turns off only when the Power
button is pressed or the
battery is discharged.
Using Auto power - on.
You can easily use the speaker with your Bluetooth device.
Please check the following rst.
• The speaker has a history of Bluetooth connection with the Bluetooth device.
• The speaker is charging and the power is off.
a Tap the Setting button on your Bluetooth device and select
Bluetooth.
b Turn on the Bluetooth function. (
Off > On)
c You will see a list of connectable devices on the Bluetooth device screen. Find and tap the name “LG-
XL5S(XX)”.
d The speaker power is turned on automatically. Then the Bluetooth device and the speaker are connected
automatically.
Note
• You can turn this function on and off with the LG XBOOM app only.
Voice feedback function
When you select a function or sound, the current status of the product is guided by voice. (English voice only)
You can turn this function on and off with the LG XBOOM app.
28
Safety Precautions
Safety and Regulatory
CAUTION
RISK OF ELECTRIC SHOCK
DO NOT OPEN
CAUTION: TO REDUCE THE RISK OF ELECTRIC SHOCK DO NOT REMOVE COVER (OR BACK) NO USER-
SERVICEABLE PARTS INSIDE REFER SERVICING TO QUALIFIED SERVICE PERSONNEL.
This lightning ash with arrowhead symbol within an equilateral triangle is intended to
alert the user to the presence of uninsulated dangerous voltage within the product’s
enclosure that may be of sufcient magnitude to constitute a risk of electric shock to
persons.
The exclamation point within an equilateral triangle is intended to alert the user to the
presence of important operating and maintenance (servicing) instructions in the literature
accompanying the product.
WARNING:
• TO PREVENT FIRE OR ELECTRIC SHOCK HAZARD, DO NOT EXPOSE THIS PRODUCT TO RAIN OR MOISTURE.
• Do not install this equipment in a conned space such as a book case or similar unit.
CAUTION:
• Do not use high voltage products around this product. (ex. Electrical swatter) This product may malfunction due
to electrical shock.
• No naked ame sources, such as lighted candles, should be placed on the apparatus.
• Do not block any ventilation openings. Install in accordance with the manufacturer’s instructions. Slots and
openings in the cabinet are provided for ventilation and to ensure reliable operation of the product and to
protect it from over heating. The openings should never be blocked by placing the product on a bed, sofa, rug or
other similar surface. This product shall not be placed in a built-in installation such as a bookcase or rack unless
proper ventilation is provided or the manufacturer’s instruction has been adhered to.
• The apparatus should not be exposed to water (dripping or splashing) and no objects lled with liquids, such as
vases, should be placed on the apparatus.
• For safety marking information including product identication and supply ratings, please refer to the main
label on the bottom or the other surface of the product.
• Be careful to make sure children do not put their hands or any objects into the *speaker duct.
- * speaker duct: A hole for plentiful bass sound on speaker cabinet. (enclosure)
29
CAUTION concerning the Power Cord
The Power Plug is the disconnecting device. In case of an emergency, the Power Plug must remain readily
accessible.
Check the specication page of this owner’s manual to be certain of the current requirements.
Do not overload wall outlets. Overloaded wall outlets, loose or damaged wall outlets, extension cords, frayed power
cords, or damaged or cracked wire insulation are dangerous. Any of these conditions could result in electric shock
or re. Periodically examine the cord of your device, and if its appearance indicates damage or deterioration, unplug
it, discontinue use of the device, and have the cord replaced with an exact replacement part by an authorized
service center.
Protect the power cord from physical or mechanical abuse, such as being twisted, kinked, pinched, closed in a door,
or walked upon. Pay particular attention to plugs, wall outlets, and the point where the cord exits the device.
CAUTION when using this product in environments of low humidity
• It may cause static electricity in environments of low humidity.
• It is recommended to use this product after touching any metal object which conducts electricity.
30
For models using a battery
This device is equipped with a portable battery or accumulator.
CAUTION: Risk of re or explosion if the battery is replaced by an incorrect type.
For models using a built-in battery
Do not store or transport at pressures lower than 11.6 kPa (0.116 bar) and at above 15,000 m (9.32 miles)
altitude.
• replacement of a battery with an incorrect type that can defeat a safeguard (for example, in the case of some
lithium battery types);
• disposal of a battery into re or a hot oven, or mechanically crushing or cutting of a battery, that can result in
an explosion;
• leaving a battery in an extremely high temperature surrounding environment that can result in an explosion or
the leakage of ammable liquid or gas; and
• a battery subjected to extremely low air pressure that may result in an explosion or the leakage of ammable
liquid or gas.
Symbols
: Alternating current (AC).
0 : Direct current (DC).
: This is a class II equipment.
1 : Standby power state.
! : The power is turned on.
: Danger voltage.
31
Prevention of product misuse
To prevent misuse of the product, please be sure to check the contents below.
Precautions for installing the product
• Do not install the product in an unstable or vibrating place, such as on a shaking shelf or inclined surface. Install
the product on a rm and level surface.
- Otherwise, the product may fall or tip over and cause injury.
- If you install the product on an unstable surface, the product may not work properly.
• If you install the product on a piece of furniture or shelf, make sure that the bottom front of the product does
not protrude. Always use a piece of furniture or shelf that ts the product size.
- Otherwise, the product may lose its balance and fall, causing injury or product damage.
• Install the product in a safe place. Otherwise, a child may bump into an edge of the product and get injured.
• Install the product in a place free from electromagnetic interference for proper operation.
• If you install the product in a place that does not meet the general use conditions, an unexpected quality
problem may arise. So, make sure that you contact the service center rst before installing the product in such
a place.
• Do not keep the product in a place where the temperature is too high (above 35 °C (95 °F)) or too low (below
5 °C (41 °F)) or a place with too much humidity.
• Avoid places exposed to direct sunlight or heat, e.g., near a heater. Do not use or keep ammable sprays or
substances near the product.
- Otherwise, there is a risk of explosion or re.
• Do not install the product in a place with too much moisture, dust or soot.
- Otherwise, it may cause a re or electric shock.
• Do not install the product in a narrow space, such as inside a bookshelf, that does not ventilate well. Do not
cover the product with a table cover or curtain.
- Otherwise, it may increase the product temperature, causing a breakdown or re.
• Connect the power plug of the product to a power outlet that is easily accessible.
- When a re or other problem occurs in the product, you must be able to remove the power plug quickly.
• Do not connect multiple products to one power outlet at the same time.
- Otherwise, it may cause overheating, resulting in a re.
32
Precautions for using the product
• Do not lift or move the product while it is operating.
- Otherwise, it may cause a breakdown.
• When moving the product, pull out the power cord and all cables connected to the product.
- Otherwise, it may cause a re or electric shock.
• Stop using the product immediately if you notice smoke or a strange odor. In this case, turn off the power
immediately, disconnect the power plug, and contact the service center.
- Using the product in this state may result in a re or electric shock.
• Do not insert metal objects such as coins and hairpins or ammable objects such as paper and matchsticks into
the product. Make sure that you tell any children not to do so.
- Otherwise, it may cause a breakdown.
• If a foreign substance is inserted into the product, disconnect the power plug and contact the service center.
• Do not put a heavy object on top of the product.
- Otherwise, it may tip over or fall, causing injury.
• Make sure that a child does not hang on the product or get on it.
- Otherwise, the product may tip over or fall, causing injury. Make sure that you tell any children not to do so.
• Remove the power plug during thunderstorms.
- Otherwise, it may cause a re.
• Do not place vessels with liquid, such as a vase, pot, cosmetics, or medicine, on top of the product.
- Otherwise, it may result in a re, electric shock, or injury due to its fall, etc.
• Make sure that you connect the power plug rmly. Do not use voltage other than the rated voltage indicated on
the product.
- An insecure connection may result in a re.
• Do not insert a conductor, such as chopsticks, into the groove on the other side of the product while the power
plug is connected to an outlet. Do not touch the power plug immediately after unplugging it from the outlet.
- Otherwise, it may cause electric shock.
• Hold the power plug with dry hands.
- Otherwise, it may cause electric shock.
• Do not move or push the product while holding a product cable such as a power cord.
- The cable may get damaged and cause a breakdown or result in a re or electric shock.
• When removing a cable plugged into the product, make sure that you hold the connector at the end of the
cable. Do not hold the cable line.
- Otherwise, it may result in an injury or the product may fall and cause a breakdown.
• Do not keep the product in a place exposed to heat, e.g., near a heater.
- Otherwise, it may cause a re or malfunction.
• Do not disassemble, repair, or modify the product.
- Otherwise, it may cause a breakdown, resulting in a re, electric shock, or injury.
• Keep plastic wraps out of reach of toddlers.
- Otherwise, toddlers may choke on the plastic wraps.
• Do not drop an object on the product or make an impact on it. Keep the product away from places with severe
vibrations or magnets.
• Do not damage, modify, bend, twist, or heat a power cord.
- Otherwise, it can damage the power cord, resulting in a re or electric shock.
33
• When you are not using the product for a prolonged period, such as when you are away from home, unplug the
power cord from the power outlet.
- If dust accumulates, it can cause heat, resulting in electric shock or re due to a short circuit.
• Do not dispose of waste batteries together with regular waste. Dispose of them separately.
- Otherwise, there is a risk of explosion or re.
• Do not use high voltage products around this product. (ex. Electrical swatter)
- This product may malfunction due to electrical shock.
• Do not touch the power plug immediately after unplugging it from the outlet.
- Otherwise, it may cause electric shock.
• Connect the power plug to a grounded outlet or extension cord. (This does not apply to products without a
ground.)
- Otherwise, it may cause a breakdown or electric shock due to a short circuit.
• In the case of a product with a vent, keeping the product turned on for a prolonged period can result in the vent
getting hot. Do not touch the vent when it is hot. The heat is not a fault of the product and does not cause any
malfunction. So, you may use the product without worry.
• Do not damage the power cable, AC adapter, or power plug. Do not place a heavy object on top of the power
cable or AC adapter.
- Otherwise, it may cause a re or electric shock.
• If dust, dirt, etc. is found on the power plug pins, an AC adapter, or a power outlet, wipe it completely.
- Otherwise, it may cause a re.
• In the case of a product with a power cord or AC adapter, use only genuine power cords and AC adapters
provided by LG Electronics.
- Otherwise, it may cause a re or electric shock.
• If you are using headphones or earphones, do not turn on the volume too loudly or use them for a prolonged
period. [This only applies to models that support headphones or earphones]
- Otherwise, it may negatively affect your hearing ability.
• The software of this product can be updated with the LG XBOOM app. Do not turn off the power of the
product while updating the software. Once the update is complete, the product power turns off automatically.
- If you turn off the power of the product while the software is being updated, it may cause a product
malfunction.
34
The following only applies to models with a remote control
• Do not let children use the remote control. Keep the remote control out of reach of toddlers.
• Do not let children put the remote control in their mouth. Make sure that children don’t swallow the remote
control cover or a battery. If a child swallowed one, consult a physician immediately.
• Beware that children may step on the remote control cover and get injured.
• Remove obstacles between the product and the remote control for the smooth operation of the remote
control.
The following only applies to models that use optical discs
• Do not insert your hand into a disc drive or pull it out forcefully.
• Make sure that children do not insert their hands into the disc drive.
The following only applies to models that able to watch video
• Refrain from watching a 3D video if you didn't have enough sleep or after drinking alcohol.
- Some 3D videos may surprise or excite people.
• If any of the following symptoms occur while watching a video, stop watching it immediately and take a rest.
- If any of the symptoms continue, consult a physician. Vertigo, burning sensation of eyes or face, unconscious
motion, spasm, clouded consciousness, confusion, disorientation, nausea.
• You may suffer a symptom such as a seizure when you watch a certain image in a video or game or a video with
a certain pattern or ashing lights. If you or any of your relatives have a history of epilepsy or seizures, consult a
physician before watching.
• When you watch a 3D video, remove objects that are fragile or can cause injury from your surroundings.
- If you mistake a 3D video as real or move your body with surprise, you or your nearby relatives may get
injured or objects near you may get damaged.
Precautions for cleaning the product
• Do not spray water directly onto the product when cleaning it.
- Otherwise, it may cause a re or electric shock.
• When cleaning the product, make sure that you pull out the power cord rst and wipe the surface of the
product lightly with a dry cloth. Do not use chemicals or detergents when cleaning the product. They may
deteriorate the product surface or peel off the paint from the product (benzene, alcohol, etc.).
35
Things to Check before Reporting
Malfunction
Troubleshooting
If you experience the following symptoms while using the product, please check them again. They may not be
malfunctions.
Symptom Cause and Solution
Power is not
supplied.
• The battery is discharged. Recharge the battery.
- Charge the product by connecting the power cord to the power input terminal.
There is no
sound or
the sound is
distorted.
• The volume of product or the connected Bluetooth device may be set to the
minimum. Adjust the volume of product or the connected Bluetooth device to the
appropriate level.
• Using an external device with the maximised sound may distort the sound. Lower the
volume of the external device to use.
The USB
storage
device is not
recognized.
• The product may not support the le system of the USB storage device. Format the
USB storage device and reconnect it. When formatting, check the supported USB
storage device format available on the product and select an appropriate le system.
([ See “Connecting the product to a USB storage device” on page 23.)
Bluetooth
connection
failed.
• Check if the Bluetooth setting is enabled.
• Turn off the Bluetooth setting and on again on the Bluetooth device.
• Make sure there are no obstacles between product and the Bluetooth device.
• Bluetooth pairing (connecting) may fail depending on the Bluetooth device type and
the surrounding environment.
36
The product
does not
operate
normally.
• Battery discharge may cause the Bluetooth information to be deleted. If the product’s
power supply is blocked, previous settings may not be saved.
• Use this product in a place where the temperature and humidity are not too high or
low. If the problem continues, contact LG Electronics’ Customer Service Center.
• If a problem occurs while charging the battery of the product, the battery LED
alternates between red and amber and charging stops. Unplug the adapter from the
outlet.
The above
solutions do not
work.
• Initializes the settings of the product. Press and hold the Function
button on the
product for 7 seconds or longer. ([ See “Initializing the Software” on page 26.)
• Use a sharp object such as a pin to press the RESET button. ([ See “Resetting the
product” on page 26.)
37
Appendix
Product Specifications
General
Power requirements
Refer to the main label.
Built-in rechargeable battery
Power consumption Refer to the main label.
Dimensions (W x H x D)
Approx. 289 mm X 570 mm X 280 mm
(11.4 inch x 22.4 inch x 11 inch)
Operating Temperature 5 °C - 35 °C (41 °F to 95 °F)
Operating Humidity 5 % - 80 % RH
Ingress protection IPX4
Input
USB
5 V 0 500 mA
Microphone (MIC IN) Sensitivity 20 mV (1 kHz), 6.3 mm jack
Guitar (GUITAR IN) Sensitivity 190 mV (1 kHz), 6.3 mm jack
Battery
Battery capacity Li-ion 14.8 V, 2985 mAh
Operating time
12 hours
Operation time may vary depending on the battery or operation
status.
Charging time
3.5 hours
Charging time may vary depending on the battery or operation
status.
Amplier (RMS output)
Woofer 100 W RMS
Tweeter 50 W RMS x 2
• Design and specications are subject to change without notice.
38
Registered Trademarks and Licenses
All trademarks and trade names are owned by their respective owners.
The Bluetooth® word mark and logos are registered trademarks owned by the Bluetooth SIG, Inc. and any use of
such marks by LG Electronics is under license.
Other trademarks and trade names are those of their respective owners.
“Made for iPhone,” and “Made for iPod” mean that an electronic accessory has been designed to connect
specically to iPhone, or iPod, respectively, and has been certied by the developer to meet Apple performance
standards. Apple is not responsible for the operation of this device or its compliance with safety and regulatory
standards. Please note that the use of this accessory with iPhone or iPod may affect wireless performance.
The system is compatible with the latest iOS. Depending on your iPhone/iPod software version, you may not
control your iPhone/iPod from the unit.
39
Handling the Product
When shipping the Product
Please save the original shipping carton and packing materials. If you need to ship the product, for maximum
protection, re-pack the product as it was originally packed at the factory.
Keeping the exterior surfaces clean
• Do not use volatile liquids such as insecticide spray near the product.
• Wiping with strong pressure may damage the surface.
• Do not leave rubber or plastic products in contact with the product for a long period of time.
Cleaning the product
To clean the product, use a soft, dry cloth. If the surfaces are extremely dirty, use a soft cloth lightly moistened
with a mild detergent solution. Do not use strong solvents such as alcohol, benzine, or thinner, as these might
damage the surface of the product.
