Connect hard wire power supply from
dishmachine to power box.
MODEL AH REAR VIEW
11-2005
DRAIN HOSE
HARD WIRE
FOUR WIRE
POWER SUPPLY
1
2
3
4
Connect the drain pipe from scrap
accumulator to floor or wall drain.
Connect dishmachine to hot water source
recommended 140
0
temperature. (120
0
minimum temperature required).
3
STEP
1
STEP
WALL
DRAIN
FLOOR DRAIN
2
STEP
Insert tube stiffener with chemical tubing into
corresponding chemical dispensers.
BLUE
RED
WHITE
4
STEP
TUBE
STIFFENER
AUTO START
SWITCH
POWER SWITCH
2" DRAIN
OUTLET
CHEMICAL
TUBING
3/4" WATER
INLET
3
HARD WIRE
POWER SUPPLY
2
4
4
Models AH, C, B, CB
Quick Setup
Instructions
1
7"
60"
11"
MODEL AH FRONT VIEW
11-2005
DRAIN HOSE
POLY PRO
TM
SCRAP
ACCUMULATOR
1
PRIMER
SWITCHES
6
PERISTALTIC
PUMP
FILL/START
SWITCH
7
DOOR
HANDLE
8
Models AH, C, B, CB
Quick Setup
Instructions
7
STEP
Press and hold the Fill/Start Switch until
the water level is approximately 1/2" to
3/4" below the overflow hole in the PVC
standpipe.
F
ILL
6
STEP
Press and hold down the three Primer
Toggle Switches for the chemical pumps
until product is discharging into the machine.
FI
LL
To start machine close the doors. The
machine will automatically start and run
through its cycle.
8
STEP
Level dishmachine by adjusting leveling
legs. Dishmachine must be level front
and back.
5
STEP
LEVELING
LEGS
5
