SHOWER HEAD INSTALLATION INSTRUCTION
Parts List
You Will Need The Following Tools
Ø6ｍｍ
Ax1
Bx1
Cx4
D１x4 D２x4
Ex4 Fx1
Template not included, create your own if needed.
According to drilling drawing sheet to (B) mark the 4 drilling positions ①, then use
the Ø6mm drill to drill holes on the wall according to the marked hole position.
Inset the plug(D2) into the hole, hold the fix base (C) use the tapping screw (D1)
through fix base(C) holes, tighten the tapping screw (D1) tighten the top shower
fixed bar(E) and the inlet hose (F) with the fix base (C)
① ②
D2
C
D1
E
F
B
Fixed the top shower with the top shower fixed bar (E) , then connect with the inlet
hose (F) .
The installation is completed.
E
A
F
