Bluetooth
®
Moisture Sensor Pairing :
Set Moisture Levels :
25417-EDAMZ-INS
Bluetooth
Moisture Sensor
If you purchased a Bluetooth
®
Timer which
has the Moisture Sensor function capability, in
the app, it will show moisture sensor symbol
example in the diagram of 4-valve timer paired
with 2 Moisture Sensors for Valve 1 & 2.
Please follow the Bluetooth
®
Moisture Sensor pairing instruction to
set up.
You can add Moisture Sensor (not included) to pair with your
Bluetooth
®
Timer.
The moisture sensor can be used to reduce your water use. Pairing
can only be done with one zone at a time.
First, obtain 2 fresh AA Alkaline batteries and insert them into the
battery tray of the sensor. Once they are inserted, press the button
on your sensor for about 5 seconds to start the pairing with the
timer. Press the co-ordinating zone button on your timer for 5
seconds. You will notice on your timer that the sensor has been
paired. The indicator light will ash blue. Repeat this step for every
sensor you want to add for the rest of valves.
Then place the sensor into the soil at the location you want to
monitor the moisture from. The sensor will show the moisture levels
after a few minutes have expired.
Additional sensors can be added for multi zoned timers using the
same above instructions.
You can setup the moisture levels according to your soil requirement.
10% increments are selectable up to 100%.
The current status will be shown once a Bluetooth
®
moisture sensor
is connected. Please wait three minutes to receive a sensor reading.
Noted that more Moisture Sensors are connected to the timer, the
more battery use will be used. The center light is a battery indicator.
If it is ashing red, change the batteries.
*Noted Eden moisture sensor is specific designed and programmed
to work with the Eden brand Bluetooth
®
Timer only. Other brands
moisture sensor will cause the timer/the App work incorrectly.
Moisture Sensor Spec : CAN ICES-3 (B)/NMB-3(B) Canada Statement :
This device complies with Industry Canada’s licence-exempt RSSs.
Operation is subject to the following two conditions:
( 1 ) This device may not cause interference; and ( 2 ) This device
must accept any interference, including interference that may cause
undesired operation of the device.
Le présent appareil est conforme aux CNR d'Industrie Canada
applicables aux appareils radio exempts de licence. L'exploitation est
autorisée aux deux conditions suivantes : ( 1 ) l'appareil ne doit pas
produire de brouillage, et ( 2 ) l'utilisateur de l'appareil doit accepter
tout brouillage radioélectrique subi, même si le brouillage est
susceptible d'en compromettre le fonctionnement
The device meets the exemption from the routine evaluation limits in
section 2.5 of RSS 102 and compliance with RSS-102 RF exposure,
users can obtain Canadian information on RF exposure and
compliance.
Le dispositif rencontre l'exemption des limites courantes d'évaluation
dans la section 2.5 de RSS 102 et la conformité à l'exposition de
RSS-102 rf, utilisateurs peut obtenir l'information canadienne sur
l'exposition et la conformité de rf
FCC Statement :
This device complies with part 15 of the FCC Rules.
Operation is subject to the following two conditions:
( 1 ) This device may not cause harmful interference, and ( 2 ) this
device must accept any interference received, including interference
that may cause undesired operation.
Caution: Any changes or modications not expressly approved by our
Yuan Mei Corp. could void the user's authority to operate the
equipment.
Note: This equipment has been tested and found to comply with the
limits for a Class B digital device, pursuant to part 15 of the FCC
Rules. These limits are designed to provide reasonable protection
against harmful interference in a residential installation. This
equipment generates, uses and can radiate radio frequency energy
and, if not installed and used in accordance with the instructions,
may cause harmful interference to radio communications. However,
there is no guarantee that interference will not occur in a particular
installation. If this equipment does cause harmful interference to
radio or television reception, which can be determined by turning the
equipment o and on, the user is encouraged to try to correct the
interference by one or more of the following measures:
- Reorient or relocate the receiving antenna.
- Increase the separation between the equipment and receiver.
- Connect the equipment into an outlet on a circuit dierent from
that to which the receiver is connected.
- Consult the dealer or an experienced radio/TV technician for help.
To comply with FCC RF exposure requirements, the device and the
antenna for this device must be installed to ensure a minimum
separation of 20cm or more from a person’s body. Other operating
congurations should be avoided.
For outdoor use with cold water only!
Not for use with household appliances
Do not mix Alkaline, carbon-zinc, or rechargeable batteries
Used or dead batteries must be removed from the timer and
disposed properly
Model: 25417-EDAMZ
Range: 30 m (100 ft) without interference
Temperature Operating: 32 - 110° F (0 - 45° C) T45
Operating Frequency: 915 MHz (N. Amer.)
Max Power: < 10 dbm
FCC ID: 2ASWP - 254S1
IC: 24967-254S1
Power: 3V DC 2 x AA LR6 / 1.5V
Should your unit need replacement after extended use, do not
dispose of it with the household waste, but in an environmentally
safe way.
Waste produced by electrical machine items should not
be handled like normal household garbage. Please recycle
where recycle facilities exist. Check with your local
authority or retailer for recycling advice.
Disposal:
- For outdoor use with cold water only
- Do not spray near electrical connections
- When not in use, rinse the tool with water to remove most of the
dirt, dry your tool, and store indoors
m CAUTION m
mWARNING: This product can expose you to chemicals including lead,
which is known to the State of California to cause cancer and birth defects
reproductive harm, and styrene which is known to the State of California to
cause cancer. For more information go to www.P65Warnings.ca.gov
