NS-MB32050B22
50W | 20,000 mAh
NS-MB32750B22
50W | 26,800 mAh
NS-PB32785B22B
85W | 26,800 mAh
NS-PB32065B22B
65W | 20,000 mAh
FEATURES
CHARGING YOUR LOW POWER DEVICES
Press and hold the button for three seconds or press
twice to enter low power device mode (<100 mA). Four
LEDs blink one by one during this mode.
After two hours, your portable battery automatically
resumes to normal charge mode.
Note: To exit this charging mode during the two hours, press and
hold the button for three seconds.
CHARGING YOUR DEVICES
WARNING: Do not charge devices while your portable battery is
recharging.
Note: If your device requires a dierent connector than the one
provided, use the cable that came with your device.
CHARGING YOUR PORTABLE BATTERY
Note: All four LEDs light when your portable battery is fully charged.
PACKAGE CONTENTS
• Portable Battery
• 1 ft. USB-C charging/sync cable
• Quick Setup Guide
SAFETY INFORMATION/CAUTION
• Do not expose your portable battery to heat, re, or water.
• Do not modify, disassemble, open, drop, crush, puncture, or shred the internal
battery.
• This is not a toy. Young children should be supervised to make sure that they do not
play with the portable battery.
• Do not charge devices while the portable battery is recharging.
• Recharge the portable battery if it has not been used for more than 90 days.
• Risk of res and burns. Do not open, crush, heat above 140° F (60° C), or incinerate.
Follow the manufacturer’s instructions.
• Operating environment temperatures: 32 ~ 95° F (0 ~ 35° C)
This product is safe for regular use under normal conditions. As with any device using
electrical power, some situations may be unsafe and injuries or damages could result. To
minimize or avoid unsafe conditions, read and follow the instructions before using.
WARNING
The following represents a typical, but not exhaustive list of advice to be provided to the
end-user.
a) Do not drop, disassemble, open, crush, bend, deform, puncture, shred, microwave,
incinerate, paint, submerge in a liquid, or insert foreign objects into the power bank.
b) Keep power banks out of the reach of children. Children should be supervised when
a power bank is in use.
c) Do not expose power banks to heat or re. Do not store in direct sunlight or in a
vehicle.
d) Do not use or charge a damaged power bank. In the event of a power bank leaking,
keep away from skin and eyes. Wash any aected area with large amounts of water
and seek medical attention.
e) Power banks need to be charged before use. Always use the correct cable and refer
to the power bank manufacturer’s instructions for proper charging instructions.
f) Do not use any cable other than that specically provided or recommended by the
power bank manufacturer.
g) Do not use a damaged cable to charge or discharge a power bank.
h) Do not leave a power bank on prolonged charge when not in use. Disconnect the
power bank from the charging source once full.
i) Observe the dedicated input and output ports for receiving and providing power on
the power bank and the device to be charged to ensure correct use.
j) Do not use any power bank which is not designed for use with the device you wish
to charge. Refer to the device’s manual for proper charging instructions.
k) When possible, detach cable(s) from power bank when not in use.
l) Only use the power bank in the application for which it was intended.
m) Store the power bank in a cool, dry place when not in use. When a power bank is not
used for prolonged periods, the power bank should be charged periodically in order
to maintain power bank life.
n) Dispose of power bank properly.
o) Keep all instructions provided with the power bank for future reference.
QUICK SETUP GUIDE
V30 series
Portable
Battery
NS-MB32050B22 / NS-MB32750B22
NS-PB32065B22B / NS-PB32785B22B
Before using your new product, please read these instructions to prevent any damage.
Final at size: 10.2 in × 5.12 in (259 × 130 mm)
Final fold size: 2.55 × 5.12 in (65 × 130 mm)
60W
• NS-PB32785B22B
USB-C Cable
USB out
(12W max)
USB-C out
(20W max
Indicators
LED Status Button
Share 20W
USB-C in/out (Yellow)
30W
• NS-MB32050B22
• NS-MB32750B22
45W
• NS-PB32065B22B
●●●● 4 LEDs = 75-100% power
○●●● 3 LEDs = 50-75% power
○○●● 2 LEDs = 25-50% power
○○○● 1 LED = 5-25% power
○○○ Blinking LED = < 5% power
○○○○ No LEDs = 0% power
Use 30W wall charger
• NS-MB32050B22: ~ 4 hours
• NS-MB32750B22: ~ 5 hours
Use 45W wall charger
• NS-PB32065B22B: ~ 3 hours
Use 65W wall charger
• NS-PB32785B22B: ~ 2 hours
Recharge time
All ports available
NS-MB32050B22_750_PB32065B22B_32785_21-1039_QSG_V1_EN_Final.ai 1 1/20/2022 3:35:54 PMNS-MB32050B22_750_PB32065B22B_32785_21-1039_QSG_V1_EN_Final.ai 1 1/20/2022 3:35:54 PM
NS-MB32050B22
50W | 20,000 mAh
NS-MB32750B22
50W | 26,800 mAh
NS-PB32785B22B
85W | 26,800 mAh
NS-PB32065B22B
65W | 20,000 mAh
FEATURES
CHARGING YOUR LOW POWER DEVICES
Press and hold the button for three seconds or press
twice to enter low power device mode (<100 mA). Four
LEDs blink one by one during this mode.
After two hours, your portable battery automatically
resumes to normal charge mode.
Note: To exit this charging mode during the two hours, press and
hold the button for three seconds.
CHARGING YOUR DEVICES
WARNING: Do not charge devices while your portable battery is
recharging.
Note: If your device requires a dierent connector than the one
provided, use the cable that came with your device.
CHARGING YOUR PORTABLE BATTERY
Note: All four LEDs light when your portable battery is fully charged.
PACKAGE CONTENTS
• Portable Battery
• 1 ft. USB-C charging/sync cable
• Quick Setup Guide
SAFETY INFORMATION/CAUTION
• Do not expose your portable battery to heat, re, or water.
• Do not modify, disassemble, open, drop, crush, puncture, or shred the internal
battery.
• This is not a toy. Young children should be supervised to make sure that they do not
play with the portable battery.
• Do not charge devices while the portable battery is recharging.
• Recharge the portable battery if it has not been used for more than 90 days.
• Risk of res and burns. Do not open, crush, heat above 140° F (60° C), or incinerate.
Follow the manufacturer’s instructions.
• Operating environment temperatures: 32 ~ 95° F (0 ~ 35° C)
This product is safe for regular use under normal conditions. As with any device using
electrical power, some situations may be unsafe and injuries or damages could result. To
minimize or avoid unsafe conditions, read and follow the instructions before using.
WARNING
The following represents a typical, but not exhaustive list of advice to be provided to the
end-user.
a) Do not drop, disassemble, open, crush, bend, deform, puncture, shred, microwave,
incinerate, paint, submerge in a liquid, or insert foreign objects into the power bank.
b) Keep power banks out of the reach of children. Children should be supervised when
a power bank is in use.
c) Do not expose power banks to heat or re. Do not store in direct sunlight or in a
vehicle.
d) Do not use or charge a damaged power bank. In the event of a power bank leaking,
keep away from skin and eyes. Wash any aected area with large amounts of water
and seek medical attention.
e) Power banks need to be charged before use. Always use the correct cable and refer
to the power bank manufacturer’s instructions for proper charging instructions.
f) Do not use any cable other than that specically provided or recommended by the
power bank manufacturer.
g) Do not use a damaged cable to charge or discharge a power bank.
h) Do not leave a power bank on prolonged charge when not in use. Disconnect the
power bank from the charging source once full.
i) Observe the dedicated input and output ports for receiving and providing power on
the power bank and the device to be charged to ensure correct use.
j) Do not use any power bank which is not designed for use with the device you wish
to charge. Refer to the device’s manual for proper charging instructions.
k) When possible, detach cable(s) from power bank when not in use.
l) Only use the power bank in the application for which it was intended.
m) Store the power bank in a cool, dry place when not in use. When a power bank is not
used for prolonged periods, the power bank should be charged periodically in order
to maintain power bank life.
n) Dispose of power bank properly.
o) Keep all instructions provided with the power bank for future reference.
QUICK SETUP GUIDE
V30 series
Portable
Battery
NS-MB32050B22 / NS-MB32750B22
NS-PB32065B22B / NS-PB32785B22B
Before using your new product, please read these instructions to prevent any damage.
Final at size: 10.2 in × 5.12 in (259 × 130 mm)
Final fold size: 2.55 × 5.12 in (65 × 130 mm)
60W
• NS-PB32785B22B
USB-C Cable
USB out
(12W max)
USB-C out
(20W max
Indicators
LED Status Button
Share 20W
USB-C in/out (Yellow)
30W
• NS-MB32050B22
• NS-MB32750B22
45W
• NS-PB32065B22B
●●●● 4 LEDs = 75-100% power
○●●● 3 LEDs = 50-75% power
○○●● 2 LEDs = 25-50% power
○○○● 1 LED = 5-25% power
○○○ Blinking LED = < 5% power
○○○○ No LEDs = 0% power
Use 30W wall charger
• NS-MB32050B22: ~ 4 hours
• NS-MB32750B22: ~ 5 hours
Use 45W wall charger
• NS-PB32065B22B: ~ 3 hours
Use 65W wall charger
• NS-PB32785B22B: ~ 2 hours
Recharge time
All ports available
NS-MB32050B22_750_PB32065B22B_32785_21-1039_QSG_V1_EN_Final.ai 1 1/20/2022 3:35:54 PMNS-MB32050B22_750_PB32065B22B_32785_21-1039_QSG_V1_EN_Final.ai 1 1/20/2022 3:35:54 PM
V1 ENGLISH 21-1039
SPECIFICATIONS
Portable battery capacity will be less than built-in cell capacity. Performance will vary based on settings and environmental conditions, and
will decrease over time and with use.
LEGAL NOTICES
Declaration of Conformity:
Brand name/model number: INSIGNIA NS-MB32050B22 / NS-MB32750B22,
NS-PB32065B22B / NS-PB32785B22B
This device complies with Part 15 of the FCC Rules. Operation is subject to the
following two conditions:
(1) this device may not cause harmful interference, and (2) this device must
accept any interference received, including interference that may cause undesired
operation.
Suppliers Name: Best Buy Purchasing, LLC. Suppliers Address (USA): 7601 Penn
Ave South, Richeld, MN 55423 U.S.A. Suppliers phone number: 1-877-467-4289.
FCC Caution:
Changes or modications not expressly approved by the party responsible for
compliance could void the user’s authority to operate the equipment.
FCC Statement:
Note: This equipment has been tested and found to comply with the limits for a
Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are
designed to provide reasonable protection against harmful interference in a
residential installation.
This equipment generates, uses, and can radiate radio frequency energy and, if not
installed and used in accordance with the instructions, may cause harmful
interference to radio communications. However, there is no guarantee that
interference will not occur in a particular installation. If this equipment does cause
harmful interference to radio or television reception, which can be determined by
turning the equipment o and on, the user is encouraged to try and correct the
interference by one or more of the following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and receiver.
• Connect the equipment into an outlet on a circuit dierent from that to which
the receiver is connected.
• Consult the dealer or an experienced technician for help.
ONE-YEAR LIMITED WARRANTY
Visit www.insigniaproducts.com for details.
CONTACT INSIGNIA:
For customer service, call 1-877-467-4289 (U.S. and
Canada)
www.insigniaproducts.com
iPhone is a trademark of Apple Inc., registered in the U.S. and other countries.
INSIGNIA is a trademark of Best Buy and its aliated companies
Distributed by Best Buy Purchasing, LLC
7601 Penn Ave South, Richeld, MN 55423 U.S.A.
©2022 Best Buy. All rights reserved.
Model #
Battery
Capacity
Input
Output
Charge
times for
compatible
devices
Dimensions
(H x W x D)
Cable
length
Weight
NS-PB32065B22B
20,000 mAh
45 W
Total output 65 W max
USB-C1 (yellow color): PD 45 W
USB-C2: PD 20 W
USB-A: 12 W
C2+A: 20W shared power
iPhone13 Pro
88 hours video playtime
iPad Pro 12.9”
15 hours video playtime
Macbook Pro 13”
14 hours movie playtime
6.2 × 2.7 × 1.2 in.
(15.7 × 6.8 × 3 cm)
1 ft. (30 cm)
0.9 lbs. (420 ± 10 g)
NS-PB32785B22B
26,800 mAh
65 W
Total output 85 W max
USB-C1 (yellow color): PD 65 W
USB-C2: PD 20 W
USB-A: 12W
C2+A: 20 W shared power
iPhone13 Pro
110 hours video playtime
iPad Pro 12.9”
20 hours video playtime
Macbook Pro 13”
20 hours movie playtime
5 × 3 × 1.7 in.
(12.7 × 7.6 × 4.3 cm)
1 ft. (30 cm)
1.1 lbs. (505 ± 10 g)
NS-MB32050B22
20,000 mAh
30 W
Total output 50 W max
USB-C1 (yellow color): PD 30 W
USB-C2: PD 20 W
USB-A: 12 W
C2+A: 20 W shared power
iPhone13 Pro
88 hours video playtime
iPad Pro 12.9”
15 hours video playtime
6.2 × 2.7 × 1.2 in.
(15.7 × 6.8 × 3 cm)
1 ft. (30 cm)
0.8 lbs. (385 ± 10 g)
NS-MB32750B22
26,800 mAh
30 W
Total output 50 W max
USB-C1 (yellow color): PD 30 W
USB-C2: PD 20 W
USB-A: 12 W
C2+A: 20 W shared power
iPhone13 Pro
110 hours video playtime
iPad Pro 12.9”
20 hours video playtime
5 × 3 × 1.7 in.
(12.7 × 7.6 × 4.3 cm)
1 ft. (30 cm)
1.0 lbs. (475 ± 10 g)
NS-MB32050B22_750_PB32065B22B_32785_21-1039_QSG_V1_EN_Final.ai 2 1/20/2022 3:35:54 PMNS-MB32050B22_750_PB32065B22B_32785_21-1039_QSG_V1_EN_Final.ai 2 1/20/2022 3:35:54 PM
V1 ENGLISH 21-1039
SPECIFICATIONS
Portable battery capacity will be less than built-in cell capacity. Performance will vary based on settings and environmental conditions, and
will decrease over time and with use.
LEGAL NOTICES
Declaration of Conformity:
Brand name/model number: INSIGNIA NS-MB32050B22 / NS-MB32750B22,
NS-PB32065B22B / NS-PB32785B22B
This device complies with Part 15 of the FCC Rules. Operation is subject to the
following two conditions:
(1) this device may not cause harmful interference, and (2) this device must
accept any interference received, including interference that may cause undesired
operation.
Suppliers Name: Best Buy Purchasing, LLC. Suppliers Address (USA): 7601 Penn
Ave South, Richeld, MN 55423 U.S.A. Suppliers phone number: 1-877-467-4289.
FCC Caution:
Changes or modications not expressly approved by the party responsible for
compliance could void the user’s authority to operate the equipment.
FCC Statement:
Note: This equipment has been tested and found to comply with the limits for a
Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are
designed to provide reasonable protection against harmful interference in a
residential installation.
This equipment generates, uses, and can radiate radio frequency energy and, if not
installed and used in accordance with the instructions, may cause harmful
interference to radio communications. However, there is no guarantee that
interference will not occur in a particular installation. If this equipment does cause
harmful interference to radio or television reception, which can be determined by
turning the equipment o and on, the user is encouraged to try and correct the
interference by one or more of the following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and receiver.
• Connect the equipment into an outlet on a circuit dierent from that to which
the receiver is connected.
• Consult the dealer or an experienced technician for help.
ONE-YEAR LIMITED WARRANTY
Visit www.insigniaproducts.com for details.
CONTACT INSIGNIA:
For customer service, call 1-877-467-4289 (U.S. and
Canada)
www.insigniaproducts.com
iPhone is a trademark of Apple Inc., registered in the U.S. and other countries.
INSIGNIA is a trademark of Best Buy and its aliated companies
Distributed by Best Buy Purchasing, LLC
7601 Penn Ave South, Richeld, MN 55423 U.S.A.
©2022 Best Buy. All rights reserved.
Model #
Battery
Capacity
Input
Output
Charge
times for
compatible
devices
Dimensions
(H x W x D)
Cable
length
Weight
NS-PB32065B22B
20,000 mAh
45 W
Total output 65 W max
USB-C1 (yellow color): PD 45 W
USB-C2: PD 20 W
USB-A: 12 W
C2+A: 20W shared power
iPhone13 Pro
88 hours video playtime
iPad Pro 12.9”
15 hours video playtime
Macbook Pro 13”
14 hours movie playtime
6.2 × 2.7 × 1.2 in.
(15.7 × 6.8 × 3 cm)
1 ft. (30 cm)
0.9 lbs. (420 ± 10 g)
NS-PB32785B22B
26,800 mAh
65 W
Total output 85 W max
USB-C1 (yellow color): PD 65 W
USB-C2: PD 20 W
USB-A: 12W
C2+A: 20 W shared power
iPhone13 Pro
110 hours video playtime
iPad Pro 12.9”
20 hours video playtime
Macbook Pro 13”
20 hours movie playtime
5 × 3 × 1.7 in.
(12.7 × 7.6 × 4.3 cm)
1 ft. (30 cm)
1.1 lbs. (505 ± 10 g)
NS-MB32050B22
20,000 mAh
30 W
Total output 50 W max
USB-C1 (yellow color): PD 30 W
USB-C2: PD 20 W
USB-A: 12 W
C2+A: 20 W shared power
iPhone13 Pro
88 hours video playtime
iPad Pro 12.9”
15 hours video playtime
6.2 × 2.7 × 1.2 in.
(15.7 × 6.8 × 3 cm)
1 ft. (30 cm)
0.8 lbs. (385 ± 10 g)
NS-MB32750B22
26,800 mAh
30 W
Total output 50 W max
USB-C1 (yellow color): PD 30 W
USB-C2: PD 20 W
USB-A: 12 W
C2+A: 20 W shared power
iPhone13 Pro
110 hours video playtime
iPad Pro 12.9”
20 hours video playtime
5 × 3 × 1.7 in.
(12.7 × 7.6 × 4.3 cm)
1 ft. (30 cm)
1.0 lbs. (475 ± 10 g)
NS-MB32050B22_750_PB32065B22B_32785_21-1039_QSG_V1_EN_Final.ai 2 1/20/2022 3:35:54 PMNS-MB32050B22_750_PB32065B22B_32785_21-1039_QSG_V1_EN_Final.ai 2 1/20/2022 3:35:54 PM
