a WARNING! Read and follow all Safety Rules and
Operating Instructions before using this product.
Failure to do so can result in serious injury.
Instruction Manual
PR5020
Quick-Start Guide
NOTE: Your product may differ slightly from the
item shown.
1
Mix 2.6 oz. of full synthetic 2-Cycle Oil with 1 gallon of gasoline for a
50:1 mixture. Shake well. Pour into fuel tank.
CAUTION: Do not use alternate fuels such as ethanol blends above
10% by volume (E-15, E-85) or any methanol blended fuel.
2
Add bar and chain oil to
oil tank.
3
Make sure chain brake
is off by pulling back the
handguard.
4
Slowly press primer bulb
10 times.
5
Pull blue choke lever out
fully.
6
Place right foot in rear
handle as shown. Using
right hand, pull starter rope
sharply 5 times.
7
Push blue choke lever to
half choke.
8
Pull starter rope until engine
starts.
9
Allow engine to warm for 30
seconds. Squeeze throttle
trigger to set normal idle.
10
Press red switch to STOP
position when nished
using saw.
STARTING A WARM ENGINE
4 + 5 + 7 + 8
IMPORTANT:
• Never let your saw chain come in contact with soil/dirt during operation. This will completely dull your chain and will
require installation of a new chain.
• Checkyourchaintensionpriortoeachtimeyoustartthechainsaw.Checktensiononanewchainaftertherst15
minutes of operation. See the manual for chain tensioning instructions.
LDAV50MC
115817295 Rev. B 2016-05-05
