[en] Instruction manual
NIV...B...
Ú Table of contents[en] Instruction manual
: Safety precautions
Please read this manual carefully. Please keep the instruction and installation manual as well as the appliance certificate in a safe place for later use or for subsequent owners.
Check the appliance after removing it from the packaging. If it has suffered any damage in transport, do not connect the appliance, contact the Technical Assistance Service and provide written notification of the damage caused, otherwise you will los...
This appliance must be installed according to the installation instructions included.
This appliance is intended for domestic use only. The appliance must only be used for the preparation of food and drink. The appliance must be supervised during operation. Only use this appliance indoors.
Do not use covers. These can cause accidents, due to overheating, catching fire or materials shattering, for example.
Do not use inappropriate child safety shields or hob guards. These can cause accidents.
This appliance is not intended for operation with an external clock timer or a remote control.
This appliance may be used by children over the age of 8 years old and by persons with reduced physical, sensory or mental capabilities or by persons with a lack of experience or knowledge if they are supervised or are instructed by a person responsi...
Children must not play with, on, or around the appliance. Children must not clean the appliance or carry out general maintenance unless they are at least 8 years old and are being supervised.
Keep children below the age of 8 years old at a safe distance from the appliance and power cable.
We advise that you exercise caution using or standing near an induction hob while it is in operation, if you wear a pacemaker or a similar medical device. Consult your doctor or the device manufacturer concenring its conformity or any possible incomp...
Risk of fire!
■ Hot oil and fat can ignite very quickly. Never leave hot fat or oil unattended. Never use water to put out burning oil or fat. Switch off the hotplate. Extinguish flames carefully using a lid, fire blanket or something similar.
Risk of fire!
■ The hotplates become very hot. Never place combustible items on the hob. Never place objects on the hob.
Risk of fire!
■ The appliance gets hot. Do not keep combustible objects or aerosol cans in drawers directly underneath the hob.
Risk of burns!
■ The hotplates and surrounding area (particularly the hob surround, if fitted) become very hot. Never touch the hot surfaces. Keep children at a safe distance.
Risk of burns!
■ The hotplate heats up but the display does not work. Switch off the circuit breaker in the fuse box. Contact the after-sales service.
Risk of burns!
■ Metal objects on the hob quickly become very hot. Never place metal objects (such as knives, forks, spoons and lids) on the hob.
Risk of burns!!
■ Always switch the hob off using the controls after each use. Do not wait until the hob turns off automatically after the pan is removed.
Risk of electric shock!
■ Incorrect repairs are dangerous. Repairs may only be carried out and damaged power cables replaced by one of our trained after-sales technicians. If the appliance is defective, unplug the appliance from the mains or switch off the circuit breaker...
Risk of electric shock!
■ Do not use any high-pressure cleaners or steam cleaners, which can result in an electric shock.
Risk of electric shock!
■ A defective appliance may cause electric shock. Never switch on a defective appliance. Unplug the appliance from the mains or switch off the circuit breaker in the fuse box. Contact the after-sales service.
Risk of electric shock!
■ Cracks or fractures in the glass ceramic may cause electric shocks. Switch off the circuit breaker in the fuse box. Contact the after-sales service.
Malfunction risk!
The hob is equipped with a fan in the lower section. If there is a drawer under the hob it should not be used to store small objects or paper, since they could damage the fan or interfere with the cooling if they are sucked into it.
There should be a minimum of 2 cm between the contents of the drawer and fan intake.
Risk of injury!
■ When cooking in a bain marie, the hob and cooking container could shatter due to overheating. The cooking container in the bain marie must not directly touch the bottom of the water-filled pot. Only use heat-resistant cookware.
Risk of injury!
■ Saucepans may suddenly jump due to liquid between the pan base and the hotplate. Always keep the hotplate and saucepan bases dry.
Elements that may damage the appliance
Caution!
Overview
Protecting the environment
Environmentally-friendly disposal
Energy-saving advice
Induction cooking
Advantages of induction cooking
Cookware
Unsuitable pans
Characteristics of the pan base
Absence of pan or unsuitable size
Empty pans or those with a thin base
Pan detection
Getting to know your appliance
The control panel
Control panels
Note
The hotplates
Residual heat indicator
Programming the hob
Switching the hob on and off
Set the hotplate
Selecting the power level
Switch off the hotplate
Note
Cooking guidelines table
Flexible zone
Advice on using cookware
Warnings
Consisting of two independent zones
How to activate
As one hotplate
How to activate
1. Place the cookware and select the desired power level with one of the two controls in the flexible zone.
2. Press the å symbol. The indicator lights up.
Changing the power level
Adding more cookware
Notes
How to deactivate
Note
Return to using two hotplates
Note
Childproof lock
Activating and deactivating the childproof lock
The hob is locked
Childproof lock
Activating and deactivating
Powerboost function
Use limitations
Note
How to activate
1. Select the desired power level.
2. Press the boost G symbol for the selected hotplate.
How to deactivate
Note
Time programming function
Turning off a hotplate automatically
Program the cooking time.
1. Select the power level on the desired hotplate.
2. Press the 0 symbol. The Ú indicator on the hotplate lights up. ‹‹ is displayed on the time program function display.
3. Press the + or - symbol. The basic setting appears:
+ symbol: 30 minutes.
- symbol: 10 minutes.
4. Press the + or - symbol until the desired cooking time appears.
Note
Changing or cancelling the time
Once the time has elapsed
Notes
The timer
How to program
1. The timer can be selected in two different ways:
2. Press the + or - symbol. The basic setting appears.
+ symbol: 10 minutes.
3. Set the desired time using the + or - symbols.
Changing or cancelling the time
Once the time has elapsed
Automatic time limitation
Basic settings
Accessing the basic settings
1. Select power level 1 on the front left-hand hotplate.
2. Within the next 10 seconds, press and hold the D symbol for 4 seconds approximately.
3. Press the D symbol several times until the desired function indicator appears.
4. Then select the required setting with the + and - symbols.
5. Press the D symbol again for approximately 4 seconds.
Exit the basic settings without changing them
Care and cleaning
Hob
Cleaning
Hob frame
Fixing malfunctions
Normal noise while the appliance is working
After-sales service
To book an engineer visit and product advice
Tested dishes
Ø 14.5 cm
