en Safety
2
Futher information and explanations are available
online:
Table of contents
1 Safety....................................................................2
2 Preventing material damage ...............................3
3 Environmental protection and saving en-
ergy .......................................................................4
4 Familiarising yourself with your appliance ........5
5 Basic operation ....................................................5
6 Childproof lock.....................................................6
7 Basic settings.......................................................6
8 Cleaning and servicing........................................7
9 Troubleshooting...................................................8
10 Disposal................................................................9
11 Customer Service.................................................9
1 Safety
Observe the following safety instructions.
1.1 General information
¡ Read this instruction manual carefully.
¡ Keep the instructions, the appliance pass
and the product information safe for future
reference or for the next owner.
¡ Do not connect the appliance if it has been
damaged in transit.
1.2 Intended use
Only a licensed professional may connect ap-
pliances without plugs. Damage caused by in-
correct connection is not covered under the
warranty.
Only use this appliance:
¡ To prepare meals and drinks.
¡ Under supervision. Never leave the appli-
ance unattended when cooking for short
periods.
¡ In private households and in enclosed
spaces in a domestic environment.
¡ Up to an altitude of max. 2000m above
sea level.
Do not use the appliance:
¡ With an external timer or a separate remote
control. This does not apply if operation
with appliances included in EN 50615 is
switched off.
1.3 Restriction on user group
This appliance may be used by children aged
8 or over and by people who have reduced
physical, sensory or mental abilities or inad-
equate experience and/or knowledge,
provided that they are supervised or have
been instructed on how to use the appliance
safely and have understood the resulting
dangers.
Children must not play with the appliance.
Children must not perform cleaning or user
maintenance unless they are at least 15 years
old and are being supervised.
Keep children under the age of 8 years away
from the appliance and power cable.
1.4 Safe use
WARNING‒Risk of fire!
Leaving fat or oil cooking on an unattended
hob can be dangerous and may lead to fires.
▶ Never leave hot oil or fat unattended.
▶ Never attempt to extinguish a fire using wa-
ter; instead, switch off the appliance and
then cover with a lid or a fire blanket.
The cooking surface becomes very hot.
▶ Never place flammable objects on the
cooking surface or in its immediate vicinity.
▶ Never place objects on the cooking sur-
face.
The appliance will become hot.
▶ Do not keep combustible objects or aero-
sol cans in drawers directly underneath the
hob.
Hob covers can cause accidents, for example
due to overheating, catching fire or materials
shattering.
▶ Do not use hob covers.
Preventing material damage en
3
Food may catch fire.
▶ The cooking process must be monitored. A
short process must be monitored continu-
ously.
WARNING‒Risk of burns!
The appliance and its parts that can be
touched become hot during use, particularly
the hob surround, if fitted.
▶ Caution should be exercised here in order
to avoid touching heating elements.
▶ Young children under 8 years of age must
be kept away from the appliance.
Hob protective grilles may cause accidents.
▶ Never use hob protective grilles.
The appliance becomes hot during operation.
▶ Allow the appliance to cool down before
cleaning.
WARNING‒Risk of electric shock!
Incorrect repairs are dangerous.
▶ Repairs to the appliance should only be
carried out by trained specialist staff.
▶ Only use genuine spare parts when repair-
ing the appliance.
▶ If the power cord of this appliance is dam-
aged, it must be replaced by trained spe-
cialist staff.
If the appliance or the power cord is dam-
aged, this is dangerous.
▶ Never operate a damaged appliance.
▶ If the surface is cracked, you must switch
off the appliance in order to prevent a pos-
sible electrical shock. To do this, switch off
the appliance via the fuse in the fuse box
rather than at the main switch.
▶ Call customer services. →Page9
An ingress of moisture can cause an electric
shock.
▶ Do not use steam- or high-pressure clean-
ers to clean the appliance.
The insulation on cables of electrical appli-
ances may melt if it touches hot parts of the
appliance.
▶ Never bring electrical appliance cables into
contact with hot parts of the appliance.
WARNING‒Risk of injury!
Saucepans may suddenly jump due to liquid
between the saucepan base and the hotplate.
▶ Always keep hotplates and saucepan
bases dry.
WARNING‒Risk of suffocation!
Children may put packaging material over
their heads or wrap themselves up in it and
suffocate.
▶ Keep packaging material away from chil-
dren.
▶ Do not let children play with packaging ma-
terial.
Children may breathe in or swallow small
parts, causing them to suffocate.
▶ Keep small parts away from children.
▶ Do not let children play with small parts.
2 Preventing material damage
ATTENTION!
Rough pot and pan bases will scratch the ceramic.
▶ Check your cookware.
Boiling pans dry may damage cookware or the appli-
ance.
▶ Never place empty pans on a heated hotplate or al-
low to boil dry.
Incorrectly positioned cookware can cause the appli-
ance to overheat.
▶ Never place hot pots or pans on the controls or the
hob surround.
Damage can occur if hard or pointed objects fall onto
the hob.
▶ Do not let hard or pointed objects fall onto the hob.
Non heat-resistant materials will melt on heated hot-
plates.
▶ Do not use oven protective foil.
▶ Do not use aluminium foil or plastic containers.
2.1 Overview of the most common damage
Here you can find the most common types of damage
and tips on how to avoid them.
Damage Cause Measure
Stains Food boiling
over
Remove boiled-over food
immediately with a glass
scraper.
Stains Unsuitable
cleaning
products
Only use cleaning
products that are suitable
for glass ceramic.
Scratch
es
Salt, sugar or
sand
Do not use the hob as a
work surface or storage
space.
Scratch
es
Rough pot or
pan bases
Check your cookware.
Discol-
ouration
Unsuitable
cleaning
products
Only use cleaning
products that are suitable
for glass ceramic.
en Environmental protection and saving energy
4
Damage Cause Measure
Discol-
ouration
Pan abrasion,
e.g. aluminium
Lift pots and pans to
move on the hob.
Damage Cause Measure
Blisters Sugar or food
with a high
sugar content
Remove boiled-over food
immediately with a glass
scraper.
3 Environmental protection and saving energy
3.1 Disposing of packaging
The packaging materials are environmentally compat-
ible and can be recycled.
▶
Sort the individual components by type and dispose
of them separately.
3.2 Saving energy
If you follow these instructions, your appliance will use
less energy.
Select the cooking zone to match the size of your
pan. Centre the cookware on the hob.
Use cookware whose base diameter is the same dia-
meter as the hotplate.
Tip:Cookware manufacturers often give the upper
diameter of the saucepan. It is often larger than the
base diameter.
¡
Unsuitable cookware or incompletely covered cook-
ing zones consume a lot of energy.
Cover saucepans with suitable lids.
¡
Cooking without a lid consumes considerably more
energy.
Lift lids as infrequently as possible.
¡
When you lift the lid, a lot of energy escapes.
Use a glass lid.
¡
You can see into the pan through a glass lid
without having to lift it.
Use pots and pans with flat bases.
¡
Uneven bases increase energy consumption.
Use cookware that is suitable for the quantity of food.
¡
Large items of cookware containing little food need
more energy to heat up.
Cook with only a little water.
¡
The more water that is contained in the cookware,
the more energy is required to heat it up.
Turn down to a lower power level early on.
¡
If you use an ongoing power level that is too high,
you will waste energy.
Take advantage of the hob's residual heat. With
longer cooking times switch off the hotplate
5-10minutes before the end of cooking.
¡
Unused residual heat increases energy consump-
tion.
Product Information according (EU) 66/2014 can be
found on the attached appliance pass and online on
the product page for your appliance.
Familiarising yourself with your appliance en
5
4 Familiarising yourself with your appliance
The instruction manual is the same for various different hobs.
4.1 Control panel
You can use the control panel to configure all functions of your appliance and to obtain information about the operat-
ing status.
4.2 Indicators/symbols
The indicators/symbols show selected values and func-
tions.
Indicator/
symbol
Name
- Heat settings
Residual heat
4.3 Touch fields
Touch fields are touch-sensitive surfaces. To select a
function, touch the relevant field.
Touch
field
Name
Main switch
Touch
field
Name
Hotplate selection
Adjustment fields
Notes
¡ Always keep the control panel dry. Moisture impairs
the function.
¡ Do not pull pans close to the displays and touch
fields. The electronics may overheat.
4.4 Residual heat indicator
The hob has a residual heat indicator for each hot-
plate.
Hotplates remain hot while the residual heat indicator is
lit up. Do not touch hotplates.
Note:They can be used e.g. to keep small meals hot
or to melt cooking chocolate.
5 Basic operation
5.1 Switching the hob on or off
The main switch is used to switch the hob on and off.
5.2 Switching on the hob
▶
Touch .
a The indicator lamp above lights up.
a The displays light up.
a The hob is ready for use.
5.3 Switching off the hob
The hob will switch off automatically when all hotplates
have been switched off for a while (10-60seconds).
▶
Touch .
a The indicator lamp above goes out.
a The displays go out.
a All hotplates are switched off.
a The residual heat indicator remains on until the hot-
plates have cooled down sufficiently.
en Childproof lock
6
5.4 Information on the hotplates
Dark areas in the glow pattern of the hotplate are part
of the technical design. They do not affect the function-
ality of the hotplate.
The hotplate regulates the temperature by switching the
heat on and off. The heat may also switch on and off
when at the highest setting.
Reasons:
¡ Easily damaged components are protected against
overheating.
¡ The appliance is protected against electrical over-
load.
5.5 Setting the hotplates
To set a hotplate, it has to be selected.
Heat setting
1 Lowest setting
9 Highest setting
5.6 Selecting heat settings
Requirement:The hob is switched on.
1.
Select the hotplate with .
a lights up in the heat setting indicator.
2.
Within the next 10 seconds, touch or .
The basic setting appears.
– Heat setting 9
– Heat setting 4
5.7 Changing heat settings
1.
Select the hotplate with .
2.
Touch or until the required heat setting ap-
pears.
5.8 Switching off the hotplate
There are 2 ways to switch off the hotplate.
1.
Touch twice.
a appears in the heat setting indicator.
a After approx. 10seconds the residual heat indicator
appears.
2.
Select the hotplate and touch or until ap-
pears on the heat setting indicator.
a After approx. 10seconds the residual heat indicator
appears.
Note:The hotplate last selected remains activated. You
can adjust the hotplate without selecting it again.
6 Childproof lock
You can use the childproof lock to prevent children
from switching on the hob.
6.1 Activating the childproof lock
Requirement:The hob is switched off.
▶
Simultaneously press and hold and for approx.
4seconds.
a lights up for approx. 10seconds in the heat set-
ting indicators.
a The hob is locked.
6.2 Deactivating the childproof lock
▶
Simultaneously press and hold and for approx.
4seconds.
a The lock is released.
7 Basic settings
You can configure the appliance to meet your needs.
7.1 Overview of the basic settings
You can find an overview of the basic settings and the
default factory settings here.
Dis-
play
Selection
Automatic childproof lock
– Switched off
1
– Switched on
– Manual and automatic childproof lock are
switched off.
1
Factory setting
Dis-
play
Selection
Signal tone
– Confirmation signal and operating error
signal are switched off. The main switch sig-
nal remains switched on.
– Only the operating error signal is
switched on.
– Only the confirmation signal is switched
on.
– Confirmation signal and operating error
signal are switched on.
1
1
Factory setting
Cleaning and servicing en
7
Dis-
play
Selection
Time for selecting hotplates
– Unlimited: The last hotplate selected can
always be adjusted without having to select it
again.
1
– You can adjust the last hotplate selected
within 10seconds after selecting it. After this
time you have to select the hotplate again be-
fore adjusting it.
Resetting to the factory settings
– Switched off.
1
– Switched on.
1
Factory setting
7.2 Changing basic settings
Requirement:The hob is switched off.
1.
Switch on the hob.
2.
Within the next 10seconds press and hold and
for 4seconds.
a and flash alternately on the lower display.
a lights up on the upper display.
3.
Touch repeatedly until the required indicator ap-
pears on the lower display.
4.
Use or to set the required value.
5.
Simultaneously press and hold and for
4seconds.
a The setting is activated.
Tip:To exit the basic settings without saving, switch off
the hob using . Switch the hob on again and reset.
8 Cleaning and servicing
To keep your appliance working efficiently for a long
time, it is important to clean and maintain it carefully.
8.1 Cleaning products
You can obtain suitable cleaning products and glass
scrapers from customer service, the online shop or a
retailer.
ATTENTION!
Unsuitable cleaning products may damage the sur-
faces of the appliance.
▶ Never use unsuitable cleaning products.
Unsuitable cleaning products
¡ Undiluted detergent
¡ Detergent intended for dishwashers
¡ Abrasive cleaners
¡ Aggressive cleaning products such as oven spray
or stain remover
¡ Abrasive sponges
¡ High-pressure or steam jet cleaners
8.2 Cleaning the glass ceramic
Clean the hob after every use to stop cooking residues
from getting burnt on.
Note:Note the information on unsuitable cleaning
products. →Page7
Requirement:The hob has cooled down.
1.
Remove heavy soiling using a glass scraper.
2.
Clean the hob with a cleaning product for glass
ceramic.
Follow the cleaning instructions on the product
packaging.
Tip:You can achieve good cleaning results using a
special sponge for glass ceramic.
en Troubleshooting
8
9 Troubleshooting
You can rectify minor faults on your appliance yourself.
Read the troubleshooting information before contacting
after-sales service. This will avoid unnecessary costs.
WARNING‒Risk of injury!
Improper repairs are dangerous.
▶ Repairs to the appliance should only be carried out
by trained specialist staff.
▶ If the appliance is defective, call Customer Service.
WARNING‒Risk of electric shock!
Incorrect repairs are dangerous.
▶ Repairs to the appliance should only be carried out
by trained specialist staff.
▶ Only use genuine spare parts when repairing the
appliance.
▶ If the power cord of this appliance is damaged, it
must be replaced by trained specialist staff.
WARNING‒Risk of burns!
The hotplate heats up but the display does not work.
▶ Switch off the fuse in the fuse box.
▶ Call the customer service.
WARNING‒Risk of fire!
The hob switches off automatically and can no longer
be operated. It may switch on unintentionally at a later
point.
▶ Switch off the fuse in the fuse box.
▶ Call the customer service.
9.1 Information on display panel
Fault Cause and troubleshooting
None There has been a power cut.
1.
Check the household fuse for the appliance.
2.
Check whether there has been a power failure by trying other electrical appliances.
All displays flash The control panel is wet or objects are lying on it.
▶
Dry the control panel or remove the object.
Several hotplates have been used over a prolonged period at high power settings. The hot-
plate has been switched off to protect the electronics.
1.
Wait a while.
2.
Touch any touch field.
a When the message no longer appears, the electronics have cooled down sufficiently.
You can continue to cook.
Despite being switched off by , the electronics have become hot again. All hotplates have
therefore been switched off.
1.
Wait a while.
2.
Touch any touch field.
a When the message no longer appears, the electronics have cooled down sufficiently.
You can continue to cook.
and the heat set-
ting flash alternately.
A signal sounds.
Hot pot near the control panel. There is a risk that the electronics will overheat.
▶
Remove the pan.
a The display goes out shortly afterwards.
and audible signal Hot pot near the control panel. The hotplate has been switched off to protect the electron-
ics.
1.
Remove the pot.
2.
Wait a while.
3.
Touch any touch field.
a When the message no longer appears, the electronics have cooled down sufficiently.
You can continue to cook.
The hotplate was on for too long and has switched off automatically.
You can switch the hotplate back on again immediately.
and hotplates do
not heat up
Demo mode is activated.
1.
Disconnect the appliance from the power supply for 30seconds by briefly switching off
the circuit breaker in the fuse box.
2.
Touch any touch field within the next threeminutes.
Disposal en
9
Fault Cause and troubleshooting
A message with "E"
appears on the dis-
play, e.g. E0111.
The electronics have detected a fault.
1.
Switch the appliance off and on again.
a If the fault was a one-off, the message disappears.
2.
If the message appears again, call the after-sales service. Please specify the exact error
message when calling.
→"Customer Service", Page9
10 Disposal
Find out here how to dispose of old appliances cor-
rectly.
10.1 Disposing of old appliance
Valuable raw materials can be reused by recycling.
▶
Dispose of the appliance in an environmentally
friendly manner.
Information about current disposal methods are
available from your specialist dealer or local author-
ity.
This appliance is labelled in accord-
ance with European Directive
2012/19/EU concerning used elec-
trical and electronic appliances
(waste electrical and electronic equip-
ment - WEEE).
The guideline determines the frame-
work for the return and recycling of
used appliances as applicable
throughout the EU.
11 Customer Service
If you have any queries on use, are unable to rectify
faults on the appliance yourself or if your appliance
needs to be repaired, contact Customer Service.
Function-relevant genuine spare parts according to the
corresponding Ecodesign Order can be obtained from
Customer Service for a period of at least 10 years from
the date on which your appliance was placed on the
market within the European Economic Area.
Note:Under the terms of the manufacturer's warranty
the use of Customer Service is free of charge.
Detailed information on the warranty period and terms
of warranty in your country is available from our after-
sales service, your retailer or on our website.
If you contact Customer Service, you will require the
product number (E-Nr.) and the production number
(FD) of your appliance.
The contact details for Customer Service can be found
in the enclosed Customer Service directory or on our
website.
11.1 Product number (E-Nr.) and production
number (FD)
You can find the product number (E-Nr.) and the pro-
duction number (FD) on the appliance's rating plate.
The rating plate can be found:
¡ on the appliance certificate.
¡ on the lower section of the hob.
Make a note of your appliance's details and the Cus-
tomer Service telephone number to find them again
quickly.
Thank you for buying a
Bosch Home Appliance!
Register your new device on MyBosch now and profit directly from:
• Expert tips & tricks for your appliance
• Warranty extension options
• Discounts for accessories & spare-parts
• Digital manual and all appliance data at hand
• Easy access to Bosch Home Appliances Service
Free and easy registration – also on mobile phones:
www.bosch-home.com/welcome
Looking for help?
You'll find it here.
Expert advice for your Bosch home appliances, help with problems
or a repair from Bosch experts.
Find out everything about the many ways Bosch can support you:
www.bosch-home.com/service
Contact data of all countries are listed in the attached service directory.
*9001604768*
9001604768 (020126)
en
BSH Hausgeräte GmbH
Carl-Wery-Straße 34
81739 München, GERMANY
www.bosch-home.com
A Bosch Company
Valid within Great Britain:
Imported to Great Britain by
BSH Home Appliances Ltd.
Grand Union House
Old Wolverton Road
Wolverton, Milton Keynes
MK12 5PT
United Kingdom
