Selecta Collection
Temperature Select Kettle
2
PRODUCT SAFETY
READ CAREFULLY AND KEEP FOR
FUTURE REFERENCE
This appliance can be used
by children aged from 8 years
and above and persons with
reduced physical, sensory
or mental capabilities or
lack of experience and
knowledge if they have
been given supervision or
instruction concerning use
of the appliance in a safe
way and understand the
hazards involved. Children
shall not play with the
appliance. Cleaning and
user maintenance shall
not be made by children
unless they are older than
8 and supervised. Keep the
appliance and its cord out of
the reach of children aged
less than 8 years.
Never use a power base other
than the one supplied with the
appliance.
Never ll the kettle above the
MAX marking. If the kettle is
overlled, boiling water may
be ejected.
If the supply cord is damaged,
it must be replaced by the
manufacturer, its service
agent or similarly qualied
persons in order to avoid a
hazard.
Descale your kettle regularly
(see Cleaning Section).
! This appliance generates heat during
use. Adequate precaution must be taken
to prevent the risk of burns, scalds, res
or other damage to persons or property
caused by touching the exterior whilst in
use or during cooling.
! Never use this appliance for anything
other than its intended use. This
appliance is for household use only. Do
not use this appliance outdoors.
! Always ensure that hands are dry before
handling the plug or switching on the
appliance.
! Always use the appliance on a stable,
secure, dry and level surface.
! This appliance must not be placed on or
near any potentially hot surfaces (such
as a gas or electric hob).
! Do not use the appliance if it has been
dropped, if there are any visible signs of
damage or if it is leaking.
! Ensure the appliance is switched off and
unplugged from the supply socket after
use and before cleaning.
! Always allow the appliance to cool
before cleaning or storing.
! Never immerse any part of the
appliance or power cord and plug in
water or any other liquid.
! Never let the power cord hang over the
edge of a worktop, touch hot surfaces or
become knotted, trapped or pinched.
! Never leave the appliance unattended
when in use.
! Beware of steam coming from the spout
or lid especially during relling. Never
open the lid during the boiling cycle.
! Never ll the appliance when it is
positioned on the power base.
! Never use the kettle without sufcient
water in the kettle for it to operate
correctly.
! Never allow the appliance to boil dry.
3
1. Spout
2. Filter (behind spout)
3. Pull off lid
4. Water level window
5. 360° rotational power base with
cord storage
6. Stop button
7. Count down timer
8. Temperature select buttons
9. Boil temperature button
1
2
3
4
5
6
7
8
9
4
BEFORE FIRST USE
Remove any packaging and promotional
material from your kettle and position it on
a stable, secure, dry and level work surface
away from the edge.
Before connecting to a power source,
make sure your mains supply voltage
is the same as the one indicated on the
appliance. Connect the plug to a suitable
power outlet and make sure that the power
cord does not overhang the work surface.
Excess power cord can be stored in the
power base.
Remove the kettle from the power base
and open the lid. Fill your kettle to the
maximum mark and close the lid.
Place your kettle back onto the power
base. Switch your kettle on, allow it to boil
then discard the water. Repeat twice. This
will remove any residue left over from the
manufacturing process.
USING YOUR KETTLE
If this kettle is lled above the
maximum level mark, hot water may be
ejected from the spout during boiling.
Beware of steam coming from the spout
or lid especially during relling. Never
open the lid when the kettle is boiling.
1. Plug the power base into a suitable
power outlet. NOTE: The kettle will turn
on and enter stand by mode until one of
the buttons on the base unit is pressed.
2. Remove your kettle from the power
base before lling it with water.
3. Fill your kettle with water. You can
ll it through the spout or by opening
the lid. Don’t overll your kettle and
always ensure that there is sufcient
water in your kettle for it to operate
correctly. This is approximately 250ml
or 1 teacup full. Always check the water
level when your kettle is positioned on
its power base.
4. If opened previously, close the lid and
place your kettle back on the base.
5. The temperature touch pad on the base
unit of the kettle allows you to select
your required temperature of water for
the beverage you are making. Choose
your desired temperature by touching
one of the temperature buttons; the
selected temperture will illuminate and
heating will start.
6. The countdown timer on the base of the
unit will indicate the time left until your
kettle reaches the desired temperature.
The length of time the water takes to
get to temperature will vary depending
on the volume of water in the kettle
and the temperature selected. NOTE:
If the selected temperature is changed
during heating the lights and timer on
the base unit will automatically adjust
themselves. NOTE: Due to the variable
way in which heat energy transfers
through water the timer lights may not
extinguish at a steady rate. This is
normal and has no effect on the water
temperature.
7. When your kettle is heating, the
stop button, water level window and
selected temperature will illuminate.
NOTE: During heating the temperature
of the water will be indicated by the
illuminated temperature button. As the
temperature increases the buttons will
illuminate one by one
8. When the water reaches the selected
temperature, your kettle will play a
short tune and the illumination will
ash to indicate the water is ready.
(You have the option to mute the tune
feature if you wish)
9. Heating will switch off automatically
after reaching temperature, or if the
kettle is removed from the base during
heating
10. You may also switch your kettle off
manually at any time by pressing the
stop button again.
11. When the kettle is on the base it
will continue to monitor the water
temperature after the selected
5
temperature has been reached. The
current water temperature will be
indicated on the base unit with a slow
pulsing illumination of the temperature
button. Once the water temperature
drops below 80°C the base unit will
enter standby mode
LOWER TEMPERATURE SELECT
MODE
You can even set a temperature that is
lower than the current temperature while
the kettle is cooling, and the kettle will let
you know when it is ready! For example, if
the kettle has boiled and is indicating 100
degrees you can press (for example) 90
degrees and its light will be permanently
on. When the water has cooled to 90
degrees your kettle will play a short tune
and the illumination will ash to indicate the
water is ready.
ERROR ALERT
If the kettle jug is removed from the base
and you attempt to use the base unit the
kettle will sound an error tone, and the
base unit lights will pulse 3 times. To use
the kettle place the jug back onto the base.
MUTE FUNCTION
This function allows you to mute all
sounds.
The mute function can be activated
by holding down the stop button for 3
seconds. There will be a sound after 3
seconds to conrm the mute setting has
been activated.
To deactivate the mute function, hold the
stop button for 3 seconds. There will be a
sound to conrm the mute setting has been
deactivated.
SUGGESTED WATER
TEMPERATURES
ENERGY SAVING HINTS AND TIPS
A Breville
®
kettle, if used correctly, is a very
energy efcient device. Why not try some
of these energy saving tips:
Only boil the water you need. Overlling
your kettle by one cup is the equivalent to
using an energy saving light bulb for one
hour!
It is not always necessary to re-boil your
kettle. For example, one litre of water will
still be at 90°C after ve minutes - the
perfect temperature for a cup of coffee.
Only heat the water to the temperature
required for your chosen beverage.
IF THE KETTLE BOILS DRY
If the kettle is operated with insufcient
water a built-in fail-safe device will
automatically switch it off.
Unplug your kettle and allow it to cool.
When it has cooled down sufciently the
safety device will reset itself.
Beverage Recommended
Temperature
Green Tea 80°C
White Tea 85°C
Oolong Tea 90°C
Black Tea 90°C-100°C
Herbal Teas 90°C-100°C
Instant Coffee 90°C-100°C
Hot Chocolate 90°C-100°C
6
AFTER SALES SERVICE &
REPLACEMENT PARTS
In the case the appliance does not
operate but is under warranty, return the
product to the place it was purchased for a
replacement. Please be aware that a valid
form of proof of purchase will be required.
For additional support, please contact our
Consumer Service Department at 0800
028 7154 or email:
ELECTRICAL SAFETY
This appliance must be earthed.
If the plug is not suitable for the socket
outlets in your home, it can be removed
and replaced by a plug of the correct type.
If the fuse in a moulded plug needs to be
changed, the fuse cover must be retted.
The appliance must not be used without
the fuse cover tted.
If the plug is unsuitable, it should be
dismantled and removed from the supply
cord and an appropriate plug tted as
detailed. If you remove the plug it must not
be connected to a 13 amp socket and the
plug must be disposed of immediately.
If the plug fuse requires replacement, a
fuse of the same rating as that tted by
the manufacturer must be used. In order
to prevent a hazard do not t a fuse of a
lower or higher rating.
Ensure that the outer sheath of the cable
is rmly held by the clamp
CLEANING
Always unplug the kettle from the
mains supply socket and allow it to
completely cool down before cleaning
or descaling it. Do not immerse the
kettle, power base or power cord and
plug in water or any other liquid.
1. Clean the exterior surface of the kettle
with a damp cloth and then polish with
a soft dry cloth. Do not use steel wool
pads or harsh/abrasive cleaners.
2. Descale your kettle regularly to keep
it working efciently. Use a proprietary
descaling product following the
manufacturer’s instructions carefully.
CLEANING THE FILTER
Before removing or retting the
lter, switch off the kettle and empty it.
Allow it to cool completely, then unplug
the power base from the mains supply
socket. Never operate the kettle without
the lter tted.
• Open the lid and remove the lter from
behind the spout.
• Rinse the lter under a tap whilst
brushing it with a soft brush.
• In hard water areas it may be
necessary to descale the lter using a
descaling product. Use a proprietary
descaling product following the
manufacturer’s instructions carefully.
• The lter may be washed safely in the
cutlery rack of a dishwasher.
• Ret the lter back into your kettle.
TROUBLESHOOTING
For troubleshooting and FAQs visit:
www.breville.co.uk/faqs
7
WASTE DISPOSAL
Waste electrical products should not be
disposed of with household waste. Please
recycle where facilities exist. E-mail us at
[email protected] for further
recycling and WEEE information.
VKT159_19EM2 (UK) P.N. 199108 Rev A
GCDS-BRE-SL
Jarden Consumer Solutions (Europe) Limited
5400 Lakeside, Cheadle Royal Business Park,
Cheadle, SK8 3GQ, United Kingdom
Newell Poland Services Sp. z o.o.,
Plac Andersa 7, Poznan, 61-894, Poland.
e-mail: [email protected]
UK Telephone: 0800 028 7154
© 2020 Jarden Consumer Solutions (Europe) Limited. All rights reserved.
Jarden Consumer Solutions (Europe) Limited, 5400 Lakeside, Cheadle Royal Business Park, Cheadle, Cheshire, SK8 3GQ, United Kingdom.
Newell Poland Services Sp. z o.o., Plac Andersa 7, Poznan, 61-894, Poland.
Jarden Consumer Solutions (Europe) Limited and Newell Poland Services Sp. z o.o. are subsidiaries of Newell Brands Inc.
The product you buy may differ slightly from the one shown on this carton due to continuing product development.
Made in China.
