Thank you for purchasing the Rechargeable Power Pack & Hand
Warmer! The Rechargeable Power Pack & Hand Warmer is an
essential multi-use tool designed to be used in the elements. Its
portable, high-capacity power pack can supply power to your
smartphone, MP3 player, and many other USB-powered devices.
WARNING: Read all instructions and warnings thoroughly
before using the Rechargeable Power Pack & Hand
Warmer. Improper use of this product may result
in product damage, excess heat, toxic fumes, fire
or explosion. Do not allow children to use this
product without proper adult supervision.
INCLUDED IN THE BOX ARE:
1 - Rechargeable Power Pack & Hand Warmer
1 - USB cable with Mini USB connection
1 - Soft carrying bag
1 - Upper silicone protective cap
1 - Lower silicone protective cap
RECHARGEABLE POWER PACK & HAND WARMER
1. Mini USB port
2. Green/red LED status indicators
a. Green indicates the Rechargeable Power Pack & Hand
Warmer is charging an external device
b. Red indicates hand warmer mode is on
3. On/off button
4. Blue LED status indicator
a. Blue indicates the Rechargeable Power Pack & Hand
Warmer’s internal battery is charging
5. USB Port
6. Top cap
7. Bottom cap
1. CHARGING THE INTERNAL LITHIUM
ION BATTERY
Your Rechargeable Power Pack & Hand Warmer 2-in-1 device has
an internal, 4400 mAh rechargeable lithium ion battery, which
allows for up to 6 hours of continuous use at a constant
temperature of 40° to 45° Celsius (104° to 113° Fahrenheit).
Your Rechargeable Power Pack & Hand Warmer ships with a
partial charge, but you should charge it completely before using
it for the first time.
Follow these steps to charge the internal battery:
1. Plug the standard USB plug end of the included USB cable
into a USB port on a PC, laptop, car charger or USB 5V-500mA
adapter plug.
2. Once plugged in, the blue LED (4) will start to blink, indicating
that charging is in progress.
3. Charging is complete when the blue LED (4) stops blinking.
NOTE: The Rechargeable Power Pack & Hand Warmer is
designed with overcharge protection to prevent
damage to the internal battery.
2. USING THE HAND WARMER FEATURE
• Press and release the on/off button once (3). The unit will
begin to heat up. In minutes, it will reach its maximum
temperature and you will feel the heat being conducted
through the aluminum housing.
• Press the on/off button twice to turn the Rechargeable Power
Pack & Hand Warmer off.
• Use the included caps when extra protection is needed. These
silicone caps help repel moisture and protect the device should
it be dropped on a hard surface.
3. CHARGING AN EXTERNAL DEVICE
• Plug your device’s USB charging cable into the USB 2.0 port (5)
on the Rechargeable Power Pack & Hand Warmer.
• Press and release the on/off button (3) quickly, then press and
hold the on/off button to begin charging. Your device should
indicate it is charging.
• When charge is complete, the Rechargeable Power Pack &
Hand Warmer will automatically power off.
4. SPECIFICATIONS
BATTERY: Rechargeable lithium polymer – (2) x 2200 mAh
INPUT: Mini USB Connector / 5V- 900 mA
OUTPUT: Standard 2.0 USB Connector / 5V- 1A
INTERNAL BATTERY CHARGE TIME: USB - 5 hours
MINIMUM NUMBER OF RECHARGES: >500
LED STATUS INDICATORS
(1) Green LED/Red LED -
• Green indicates charging external device
• Red indicates hand warmer mode
(1) Blue LED indicates internal battery charging
HAND WARMER TEMPERATURE RANGE
40° TO 45° Celsius (104° TO 113° Fahrenheit)
HAND WARMER CONTINUOUS USE TIME
At least 6 hours continuous use (based on fully charged battery)
OPERATING TEMPERATURE RANGE
0° to 45° Celsius ( 32° to 113° Fahrenheit)
STORAGE TEMPERATURE RANGE
68° to 77° Fahrenheit (optimal)
WEIGHT 5.22 oz. (148 grams)
DIMENSIONS
1.77 in x 3.74 in x .90 in (45mm x 95mm x 23mm)
POWER DELIVERY CHART
iPhone XS (2658 mAh) 1.7 charges
iPad 4th (11,560 mAh) 0.4 charges
GoPro Hero 7 (1200 mAh) 3.6 charges
NOTE: Storage of more than 6 months without use may have detrimental
effects on the condition of the lithium ion battery. It is recommended
that you discharge and recharge fully every 3-4 months to
maintain optimal battery life.
WARNINGS:
Read all instructions and warnings prior to using this product.
Improper use of this product may result in product damage,
excess heat, toxic fumes, fire or explosion, for which damages
you (“Purchaser”), and not Smart Team or Celestron (collectively
“Manufacturer”) are responsible.
• Do not store battery in high temperature environment, including
intense sunlight.
• Do not place battery in fire or other excessively hot
environments.
Model # 48012
ENGLISH
