SPECIFICATIONS
Occasional refinements may be made to existing products without notice,
but will always meet or exceed original specifications unless otherwise
stated.
*Trademarks of Dolby Laboratories.
DTS is a registered trademark of Digital Theater Systems, Inc.
PB10 PB12
Amplifier
Power (RMS): 150 Watts 250 Watts
Driver: 10" Pure-Cellulose Fiber 12" Pure-Cellulose Fiber
Inputs: Line Level (switchable to LFE) Line Level (switchable to LFE)
and Speaker Level with and Speaker Level with
gold-plated 5-way binding posts gold-plated 5-way binding posts
Outputs: Speaker Level, High-Pass with Speaker Level, High-Pass with
gold-plated 5-way binding posts gold-plated 5-way binding posts
Low-Pass
Frequency: Continuously variable Continuously variable
from 50Hz – 150Hz from 50Hz – 150Hz
High-Pass
Frequency: 150Hz when using 150Hz when using
speaker-level output speaker-level outputs
Frequency
Response: 27Hz – low-pass 25Hz – low-pass
crossover setting crossover setting
Dimensions
(H x W x D): 14" (16"with feet) x 14" x 15" 15-1/2" (17-1/2"with feet) x 15" x 16"
356mm (406mm with feet) x 394mm (445mm with feet) x
356mm x 381mm 381mm x 406mm
Weight: 35 lb/15.9kg 40 lb/18.2kg
JBL Consumer Products
250 Crossways Park Drive, Woodbury, NY 11797
8500 Balboa Boulevard, Northridge, CA 91329
800-336-4JBL (4525) (USA only)
www.jbl.com
©2001 JBL, Incorporated. JBL is a registered trademark
of JBL, Incorporated.
Part No.
338129-001
DESIGN GOAL: Bring the thrill of live performance and movie sound to
the home environment bycalling on JBL’s professional engineering leadership.
WOOFER TYPE:
Pure cellulose fiber
PORT DESIGN: FreeFlow™ flared
PROFESSIONAL REFERENCE: Cinema Loudspeaker Series
OWNER’S GUIDE
PRO SOUND
COMES HOME
™
PRODUCT LINE:
PowerBass
™
Series
MODEL
PB10, PB12
NUMBER:
