Introduction .................................................3
Dear customer ...............................................................3
About this user manual ..............................................3
What’s in the box ..........................................................3
Customer service centre ............................................3
1 General safety information ............... 4
Setting up the product .............................................. 4
Repairs ............................................................................ 4
Power supply .................................................................5
2 Overview ................................................5
Top view ...........................................................................5
Front view ....................................................................... 6
Rear view ........................................................................ 6
Remote control............................................................. 6
3 Initial setup ............................................ 7
Place the projector.......................................................7
Connect to power supply ..........................................7
Prepare the remote control ..................................... 8
Power on and set up the projector ....................... 8
Placement ...................................................................... 9
Set up Android TV .......................................................11
4 Use Android TV ................................... 12
Navigate Android TV .................................................. 12
Configure Android TV ................................................ 12
Use a wired keyboard/mouse ................................12
Use a Bluetooth device ............................................ 12
Cast content to Android TV ..................................... 13
5 Connect to playback devices ........... 13
Connect to devices through HDMI .......................13
Connect to devices through USB-C ..................... 14
Connect to devices through AV .............................14
Connect to devices through SPDIF ...................... 14
Connect to external speakers or headphones 15
6 Change settings ..................................16
Change Android TV settings ...................................16
Change projector settings ....................................... 17
7 Maintenance........................................19
Cleaning .........................................................................19
Update software .........................................................19
8 Troubleshooting ................................20
9 Appendixes ......................................... 22
Technical data ............................................................ 22
CE statement .............................................................. 23
FCC statement ............................................................ 23
Canada regulatory compliance ............................ 23
Other notice ................................................................. 24
Table of contents
Introduction 3
Introduction
Dear customer
Thank you for purchasing this projector.
We hope you enjoy this product and the many
functions it offers!
About this user manual
The quick start guide supplied with this product
allows you to start using this product quickly
and easily. Detailed descriptions can be found
in the following sections of this user manual.
Read the entire user manual carefully. Follow
all safety instructions in order to ensure proper
operation of this product (see General safety
information, page 4). The manufacturer
accepts no liability if these instructions are not
followed.
Symbols used
Notice
This symbol indicates tips that will help
you use this product more effectively
and easily.
DANGER!
Danger of personal injury!
This symbol gives warning of danger
of personal injury. Physical injury or
damage can result from improper
handling.
CAUTION!
Damage to the product or loss of data!
This symbol gives warning of damage
to the product and possible loss of
data. Damage can result from improper
handling.
What’s in the box
a
NeoPix Ultra 2
TV+
projector (NPX644/INT)
b
Android TV remote control with 2 AAA
batteries
c
Lens cover
d
Quick Start Guide
e
AC power cable with plug x 4
f
HDMI cable
g
USB-C cable
Quick Start
Guide
Quick Start
Guide
Quick Start
Guide
Quick Start
Guide
OK
a
b
c
d
e
Customer service centre
The Support page, warranty card, and user
manuals can be found here:
Web: www.philips.com/support
Support Contacts:
International Phone: +41 215 391 665
Please ask your provider for international call
costs!
Mail: philips.projector.eu@screeneo.com
Access our FAQ websites:
https://support.philipsprojection.com
https://community.philipsprojection.com
4 Philips · NeoPix Ultra 2
TV+
1 General safety
information
Take note of all warning and safety notes
indicated. Do not make any changes or settings
that are not described in this user manual.
Incorrect operation, and improper handling can
lead to physical injury, damage to the product
or loss of data.
Setting up the product
This product is for indoor use only. Place the
product securely on a stable, flat surface.
To help avoid possible injuries to persons or
damage to the product itself, position all cables
in such a way that no one will trip over them.
Do not operate the product in damp rooms.
Never touch the mains cable or the mains
connection with wet hands.
Never operate the product immediately after
moving it from a cold location to a hot location.
When the product is exposed to such a change
in temperature, moisture may condense on the
crucial internal parts.
The product must have sufficient ventilation
and must not be covered. Do not put the
product in closed cabinets, boxes, or other
enclosures when in use.
Protect the product from direct sunlight,
heat, intense temperature fluctuations and
moisture. Do not place the product in the
vicinity of heaters or air conditioners. Observe
the information on temperature listed in the
technical data (see Technical data, page 22).
Prolonged operation of the product causes the
surface to become hot. In case of overheating,
the product automatically switches to standby
mode.
Do not allow liquids to leak into the product.
Turn off the product and disconnect it from the
mains supply if liquids or foreign substances
leaked into the product. Have the product
inspected by an authorised service centre.
Always handle the product with care. Avoid
touching the lens. Never place heavy or sharp
objects on the product or on the power cable.
If the product gets too hot or emits smoke,
shut it down immediately and unplug the
power cable. Have your product checked by
an authorised service centre. Keep the product
away from open flames (e.g. candles).
DANGER!
Risk of explosion with incorrect type
of batteries!
There is a risk of explosion if the wrong
battery type is used.
Do not expose the batteries (battery pack or
embedded batteries) to excessive heat such as
sunshine, or open fire.
Under the following conditions, a layer of
moisture can appear inside the product which
can lead to malfunctions:
• if the product is moved from a cold to a
warm area;
• after a cold room is heated;
• when the product is placed in a damp
room.
Proceed as follows to avoid any moisture
buildup:
1 Seal the product in a plastic bag before
moving it to another room, in order for it to
adapt to room conditions.
2 Wait one to two hours before you take the
product out of the plastic bag.
The product should not be used in a very dusty
environment. Dust particles and other foreign
objects may damage the product.
Do not expose the product to extreme
vibrations. This may damage the internal
components.
Do not allow children to handle the product
without supervision. The packing materials
should be kept out of the hands of children.
For your own safety, do not use the product
during thunderstorms with lightning.
Repairs
Do not repair the product yourself. Improper
maintenance can result in injuries or damage to
the product. The product must be repaired by
an authorised service centre.
Please find the details of authorised service
centres on the warranty card supplied with this
product.
Do not remove the type label from this product,
as this will void the warranty.
Overview 5
Power supply
Use only a power adapter which is certified for
this product (see Technical data, page 22).
Check whether the mains voltage of the power
supply matches the mains voltage available at
the setup location. This product complies with
the voltage type specified on the product.
The power outlet shall be installed near the
product and shall be easily accessible.
CAUTION!
Always use the button to turn the
projector off.
Turn off the product and unplug from the
power outlet before cleaning the surface
(see Cleaning, page 19). Use a soft, lint-
free cloth. Never use liquid, gaseous or easily
flammable cleaners (sprays, abrasives, polishes,
alcohol). Do not allow any moisture to reach
the interior of the product.
DANGER!
Risk of eye irritation!
This product is equipped with a high
power LED (Light Emitting Diode),
which emits very bright light. Do not
look directly into the projector lens
during operation. This could cause eye
irritation or damage.
2 Overview
Top view
NeoPix
Ultra 2
TV+
ab cde
f
a
• Switch the projector on or to standby.
• When the projector is on, the LED lights
up in white. When the projector is on
standby, the LED lights up in red.
b
Return to the previous screen or exit the
current screen.
c
• Navigate menu options.
• Increase volume.
d
• Navigate menu options.
• Decrease volume
e
• Select projector settings options.
• Confirm a selection or entry.
f
Focus adjustment knob
Adjust image sharpness.
6 Philips · NeoPix Ultra 2
TV+
Front view
a b
a
Projection lens
b
Front IR sensor
Rear view
HDMI
SPDIF
USB
AV
ab c d f g
eh
a
Rear IR sensor
b
SPDIF
Connect to the digital SPDIF audio input on
an HiFi audio system.
c
USB port
• Connect to power USB devices like
Amazon Fire TV stick®, Roku® streaming
stick (it also works for mass storage if
you install an app like VLC).
• Connect to a wired keyboard or mouse.
d
3.5 mm audio/video input; connect to the
analogue audio jacks and/or composite
video jack on a playback device.
e
3.5 mm audio output; connect to external
speakers or headphones.
f
USB-C
Connect to a USB-C output on a playback
device.
g
Connect to an HDMI output on a playback
device.
h
Power socket
Connect to an AC power supply.
Remote control
OK
a
b
c
d
e
f
g
h
l
j
i
k
a
Access the voice command or search
function (Google Assistant).
b
Confirm a selection or entry, or turn an
option on or off.
c
Display installed apps and access the app
store.
d
+/-
Increase or decrease the volume.
e
Quick access to the Netflix service.
f
Quick access to the Amazon Prime Video
service.
g
Access or exit the projector settings options.
h
Return to the previous screen or exit the
current screen.
i
Access the Android TV home screen.
j
Navigation buttons (Up, Down, Left, Right)
• Navigate items on the screen.
• Press / to move backward or forward
Initial setup 7
in the current video
.
k
LED indicator
• Each time you press a button on the
remote control, the LED lights up briefly
then off.
• Blue light indicates the remote control
is in Android TV mode and you can
use it to navigate the Android TV user
interface.
• Red light indicates the remote control is
accessing the projector settings options
and you cannot use it to navigate the
Android TV user interface.
l
Switch the projector on or to standby.
3 Initial setup
Notice
Make sure all devices are disconnected
from their power supplies before
establishing or changing any
connections.
Place the projector
Place the projector on a flat surface such as a
table in front of the projection surface.
You can also install the projector in different
configurations (see Placement, page 9).
Connect to power supply
CAUTION!
Always use the button to turn the
projector on and off.
1 Select a supplied power cable with the
correct plug (EU/UK/US/CH).
2 Connect one end of the power cable to the
power socket on the back of the projector
and the other end to an electrical socket.
• The LED on the projector lights up in
red.
HDMI
SPDIF
USB
AV
8 Philips · NeoPix Ultra 2
TV+
Prepare the remote control
CAUTION!
The improper use of batteries can
lead to overheating, explosion, risk of
fire and injury. Leaking batteries can
possibly damage the remote control.
Never expose the remote control to
direct sunlight.
Avoid deforming, dismantling or
charging the batteries.
Avoid exposure to open fire and water.
Replace empty batteries immediately.
Remove the batteries from the remote
control if not in use for long periods of
time.
1 Open the battery compartment.
2 Insert the supplied batteries (type AAA)
with correct polarity (+/- ) indicated.
3 Close the battery compartment.
• When using the remote control with infrared
signals, point the remote control at the IR
sensor on the projector, and make sure
there is no obstacle between the remote
control and the IR sensor.
Power on and set up the
projector
1 Press
to turn on the projector. The LED
on the projector turns from red to white.
• To turn off the projector, press
twice. The
projectors enters standby mode and its LED
turns from white to red. To fully shut down
the projector, disconnect the power cable
from the electrical socket.
• The distance between the projector and the
projection surface determines the actual
screen size.
Screen size adjustment
The projection screen size (or size of images) is
determined by the distance between the lens
of the projector and the projection surface.
This projector has a projection distance of 80
cm to 200 cm, and thus creates a screen size of
20" to 120".
Digital zooming
You can use the digital zoom to reduce the
screen size.
1 Press
to access the projector
settings options and select Digital Zoom.
2 Press / to adjust the screen size.
Screen height adjustment
You can adjust the screen height when placing
the projector on a flat surface such as a table.
1 Find the height adjustment foot and the
foot release slider on the bottom of the
projector.
To unlock the height adjustment foot,
push the foot release slider in the direction
of the arrow shown below and hold the
slider. Then the foot will extend outwards
when the bottom of the projector points
downwards.
Adjust the length of the foot when the foot
is unlocked and extends outwards.
2 Release the slider to lock the foot when the
desire screen height is reached.
Initial setup 9
Height
adjustment
foot
Foot
release
slider
Image focus adjustment
To adjust image focus, turn the focus
adjustment knob at the top of the projector.
NeoPix
Ultra 2
TV+
Image shape adjustment
Auto correction
You can turn on auto keystone correction to
automatically make the image rectangular.
1 Press
to access the projector
settings options and select Geometry
Corrections - Auto.
Manual correction
You can manually correct the keystone and
make the image rectangular.
1 Press
to access the projector
settings options and select Geometry
Corrections - Manual.
2 On the image shape adjustment screen,
press the OK button on the remote control
to switch between different angles, and
press the navigation buttons on the remote
control to adjust image shape.
Placement
You can install the projector in four different
configurations. Follow the guidelines below
when installing the projector.
Notice
For overhead mounting on ceiling,
purchase a projector mount
recommended by an installation
professional and follow the instructions
that come with the mount.
Before mounting on the ceiling, make
sure the ceiling can support the weight
of the projector and mounting kit.
For ceiling installation, this product
must be securely attached to the ceiling
in accordance with the installation
instructions. An improper ceiling
installation may result in accident, injury
or damage.
10 Philips · NeoPix Ultra 2
TV+
Desktop front
1 Place the projector on a table in front of the
projection screen. This is the most common
way to position the projector for quick
setup and portability.
2 The projector automatically adjusts for the
correct projection orientation.
If the projection orientation is incorrect,
press
to access the projector
settings options and select Projection Mode
- Desktop Front.
Ceiling front
1 Mount the projector on the ceiling with
upside up in front of the projection screen.
A projector mount is required to mount the
projector on the ceiling.
2 The projector automatically adjusts for the
correct projection orientation.
If the projection orientation is incorrect,
press
to access the projector
settings options and select Projection Mode
- Ceiling Front.
Desktop rear
1 Place the projector on a table behind the
projection screen. A special rear projection
screen is required.
2 The projector automatically adjusts for the
correct projection orientation.
If the projection orientation is incorrect,
press
to access the projector
settings options and select Projection Mode
- Desktop Rear.
Ceiling rear
1 Mount the projector on ceiling with upside
up behind the projection screen. To mount
the projector on the ceiling behind the
screen, a projector mount and a special rear
projection screen are required.
2 The projector automatically adjusts for the
correct projection orientation.
If the projection orientation is incorrect,
press
to access the projector
settings options and select Projection Mode
- Ceiling Rear.
Initial setup 11
Set up Android TV
When you turn on the projector for the first
time or after it was reset to its factory default
settings, Android TV will start and prompt you
to set it up by making some basic settings.
After the setup, Android TV will sign in to
your Google account and connect to a Wi-Fi
network.
What you need
• A Wi-Fi internet connection
• A Google account
Step 1: Pair the remote control
with the projector
Follow the on-screen instructions to pair the
remote control with the projector.
After the pairing, the Welcome screen appears
and you can use this remote control to navigate
the on-screen user interface of Android TV and
initiate voice commands or search queries.
Tip: Press
on the remote control to
switch to Android TV mode if the buttons on
the remote control are invalid for Android TV
navigation.
Step 2: Select the display
language
To select the display language for Android TV,
press the down or up navigation button on
the remote control to select your preferred
language and press the OK button to confirm.
Note: The default display language is English
(United States) and not all languages are
available.
Step 3: Set up your Android TV
There are 2 options to set up your Android TV:
• Quick Start with an Android phone
• Set up with the remote control
Set up with Quick Start
1 When your Android TV says, “Quickly set up
your TV with your Android phone?”, use the
remote control to choose Continue.
2 Ensure your Android phone has the Google
app
installed and is connected to a Wi-
Fi network.
3 On your phone, open the Google app
and sign in if you haven't already.
4 Type or say “set up my device.”
5 Follow the instructions on your phone until
you get a code. Enter the code on your
Android TV.
6 On your phone, tap the name of your
Android TV when it shows up.
7 To finish setup, follow the instructions on
your Android TV screen.
Tip: After the setup, your Android TV
automatically signs in to your Google Account
and connects to the same Wi-Fi network as
your phone.
Set up with the remote control
1 When your Android TV says, “Quickly set up
your TV with your Android phone?”, use the
remote control to choose Skip.
2 Connect your Android TV to a Wi-Fi
network. Note: Your Android TV may need
some time to update after it is connected to
the internet.
3 Choose Sign in.
4 Sign in to your Google Account.
5 To finish setup, follow the on-screen
instructions.
12 Philips · NeoPix Ultra 2
TV+
4 Use Android TV
You will see the Android TV home screen similar
to the one below after completing the setup.
The Android TV home screen is the jumping-off
point for starting all activities on your Android
TV entertainment device. On this screen, you
can browse for shows and movies to watch.
You’ll also find the shows and movies you’ve
started, suggested videos, and personalized
recommendations.
Android TV offers you various features, such as:
• Watch a wide range of movies and shows
from across your favourite apps.
• Stream music from music apps.
• Get apps from Google Play.
• Play online games from Google Play
Games.
• Voice input for commands and universal
search across multiple services.
Navigate Android TV
You can use the dedicated Android TV remote
control to navigate the on-screen user interface
of Android TV and initiate voice commands or
search queries.
• Press
on the remote control to
switch to Android TV mode if the buttons on
the remote control are invalid for Android
TV navigation.
• Press
on the remote control to access
the Android TV home screen.
• Press
on the remote control to display
the installed apps and access the app store.
• Press
on the remote control to access
voice search function.
Configure Android TV
On the home screen (press
), you can
navigate to select in the upper right corner
of the screen and access various Android TV
related settings, e.g. apps/privacy/security
management, picture and sound settings (see
Change Android TV settings, page 16).
Use a wired keyboard/
mouse
• Connect the USB plug of your wired
mouse or keyboard to the USB port on the
projector.
• Use the keys on the keyboard for screen
navigation, selection and text input, just like
the keyboard operation with a computer.
• Use the wheel and left button on the
mouse for navigation and selection. Press
the right button on the mouse to return to
the previous screen.
Use a Bluetooth device
You can pair a Bluetooth device (keyboard,
mouse, gamepad, speaker, etc.) with the
projector. After completing the pairing, you can
use the Bluetooth device with your Android TV.
To pair a Bluetooth device, follow the steps
below:
1 On your Android TV, go to the home screen.
2 Select
in the upper right corner of the
screen.
3 Select Remotes & Accessories and then
Add accessory. On your screen, you’ll see a
list of nearby Bluetooth devices.
4 Put your Bluetooth device in pairing mode.
The device will be added to the on-screen
list.
5 Select your Bluetooth device.
6 When your Android TV says, “Pair with this
device?”, choose Pair. The device will be
paired within a few seconds.
Connect to playback devices 13
Cast content to Android TV
Your Android TV has Chromecast built-in. This
allows you to cast content (e.g. videos, photos
and music) from a mobile device (Android or
iOS device) to your Android TV.
Important: You can only cast from the latest
version of a Chromecast-enabled app or a
Chrome browser on a device connected to the
same Wi-Fi network as your Android TV.
To start casting, follow the steps below:
1 Connect your device to the same Wi-Fi
network as your Android TV.
2 Open the app that has the content you
want to cast.
3 In the app, find and select Cast
.
4 On your device, select the name of your
Android TV.
5 When Cast
changes color, you’re
successfully connected.
To stop casting, on your device, select Cast
and then Disconnect.
Notice
For better casting performance, use a
5GHz Wi-Fi network.
Copy-protected (DRM) content cannot
be cast.
Tip: For more tips about using Android TV, visit
https://support.google.com/androidtv.
Google, Google Play, YouTube, Android TV and
other marks are trademarks of Google LLC.
Google Assistant is not available in certain
languages and countries.
5 Connect to
playback devices
Notice
Make sure all devices are disconnected
from their power supplies before
establishing or changing any
connections.
Connect to devices through
HDMI
You can connect a playback device (e.g. a Blu-
ray player, gaming console, camcorder, digital
camera or PC) to the projector through HDMI
connection. With this connection, images are
shown on the projection screen, and audio is
played on the projector.
1 Using the supplied HDMI cable, connect
the HDMI port on the projector to the HDMI
output port on a playback device.
HDMI
SPDIF
USB
AV
2 The projector automatically switches to
HDMI input when an HDMI connection is
made. The projection screen shows images.
If the projection screen does not show
images, select HDMI input manually. Press
to access the projector settings
options and select Input Source - HDMI.
14 Philips · NeoPix Ultra 2
TV+
Connect to devices through
USB-C
You can connect a playback device (e.g. a
mobile phone or PC) to the projector through
USB-C connection. With this connection,
images are shown on the projection screen,
and audio is played on the projector.
1 Using the supplied USB-C cable, connect
the USB-C port on the projector to the
USB-C output port on a playback device.
HDMI
SPDIF
USB
AV
2 The projector automatically switches to
USB-C input when an USB-C connection is
made. The projection screen shows images.
If the projection screen does not show
images, select USB-C input manually. Press
to access the projector settings
options and select Input Source - TYPE-C.
Connect to devices through
AV
You can connect a playback device (e.g. a DVD
player, gaming console, camcorder or digital
camera) to the projector through AV connection.
With this connection, images are shown on the
projection screen, and audio is played on the
projector.
1 Using a RCA cable with 3.5 mm plug (not
included in the box), connect the AV jack
(3.5 mm) on the projector to the analogue
audio output jacks (red and white) and/or
composite video output jack on a playback
device.
HDMI
SPDIF
USB
AV
2 The projector automatically switches to AV
input when an AV connection is made. The
projection screen shows images.
If the projection screen does not show
images, select AV input manually. Press
to access the projector settings
options and select Input Source - AV.
Connect to devices through
SPDIF
Connect a digital device (e.g. a home cinema
system or sound bar) to the projector through
SPDIF connection. With this connection, audio
is streamed to the connected digital device.
1 Using an SPDIF optical cable (not included
in the box), connect the SPDIF connector
on the projector to the SPDIF input on a
digital device.
• The SPDIF input on a digital device
might be labeled OPTICAL or OPTICAL
IN.
Connect to playback devices 15
HDMI
SPDIF
USB
AV
2 To output audio to the external device,
make sure external speaker output is
activated. Press
to access the
projector settings options and select Audio
Output - SPDIF.
Connect to external
speakers or headphones
You can connect external speakers or
headphones to the projector. With this
connection, audio from the projector is played
through the external speakers or headphones.
DANGER!
Danger of hearing damage!
Before connecting the headphones,
turn down the volume on the projector.
Do not use the projector over a longer
time at high volume – especially when
using headphones. This could lead to
hearing damage.
1 Using a 3.5 mm audio cable (not included
in the box), connect the
jack on the
projector to the analogue audio input (3.5
mm jack, or red and white jacks) on external
speakers. Or connect the
jack on the
projector to headphones.
• The internal speakers of the projector
are deactivated automatically when
external speakers or headphones are
connected to the projector.
HDMI
SPDIF
USB
AV
2 After connecting the speakers or
headphones, press the volume control
buttons on the remote control to adjust the
volume to the desired level.
16 Philips · NeoPix Ultra 2
TV+
6 Change settings
This section helps you change the settings of
the following two systems:
• Android TV
• Projector
Change Android TV settings
1 On the home screen (press
), use the
Navigation buttons on the remote control
to select
in the upper right corner and
then press the OK button to access various
setting options.
2 Use
the Navigation buttons and the OK
button to select and change settings.
Wi-Fi settings
Go to Network & Internet to connect the
projector to a Wi-Fi network. Use the pop-up
virtual keyboard or voice input to input letters
and digits.
Google account settings
Go to Accounts & Sign In to sign in or add a
Google account.
Language settings
Go to Device Preferences - Language to select
a language for on-screen menus.
Date and time settings
Go to Device Preferences - Date & time to
access the following settings.
• Automatically update date and time, or
manually set date, time and time zone.
Keyboard settings
Go to Device Preferences - Keyboard to access
various settings for keyboard.
Bluetooth settings
Go to Remotes & Accessories to pair the
projector with the projector's remote control,
or a Bluetooth keyboard/mouse/gamepad/
speaker.
Apps settings
Go to Apps to access the following settings.
• View all the installed and system apps, and
the storage used by each app.
• Set various permissions for the installed
apps, e.g. location, contacts, camera,
microphone, phone and SMS.
• Set security and restrictions for app
installation.
• Check an app's version, storage used,
cache size, etc.
• Clear an app's cache, disable or uninstall
an app, view an app's permissions, etc.
Display settings
Go to TV settings - Display to access the
following settings.
• Screen resolution: Select a screen
resolution to best support your video.
• Screen position: Scale down the projection
image.
Sound options
Internal speaker
Go to Device Preferences - Sound to access the
following settings.
• System Sound: Turn the system sound on or
off.
• Surround Sound: Enable or disable
surround sound. You can let Android TV
automatically select the formats supported
by the projector or manually select the
formats.
Audio output
Go to TV settings - Audio Output to access the
setting below.
• Dolby DRC Mode: Select a DRC (Dynamic
Range Compression) mode for reducing
dynamic range of sound output. You can
therefore watch movies without having to
constantly readjust the volume with the
remote control.
Display Netflix activation code
• Go to TV settings - Netflix ESN to display
the Netflix activation code.
Factory reset Android TV Dongle
1 Go to Device Preferences - About - Factory
reset and select Factory reset.
2 Follow the on-screen instructions to start
factory resetting the built-in Android TV
Change settings 17
Dongle.
Notice
A factory reset erases all your personal
information and downloaded apps and
you can't reverse this action.
Other system settings
Go to Device Preferences to access the
following settings.
• About: View information about, update, or
reset the built-in Android TV Dongle.
• Storage: Check the total, used and
available space of the internal storage and
removable storage.
• Home screen: Customize and organize the
home screen.
• Google Assistant: Select the active Google
account and customize Google Assistant's
behaviour.
• Chromecast built-in: View information
about Chromecast.
• Screen saver: Set the type of screen saver
and how soon to activate the screen saver
or put the built-in Android TV Dongle to
sleep.
• Location: Check your location status and
view the recent location requests.
• Usage and Diagnostics: Choose whether
you want the built-in Android TV Dongle to
automatically send diagnostic information
to Google.
• Accessibility: Configure a variety of
accessibility options, including captions
and text to speech.
• Reboot: Restart the built-in Android TV
Dongle.
Change projector settings
1 Press
on the remote control to
access the projector settings options.
2 Use
the navigation buttons and the OK
button to select an option.
3 P
ress / or / to select a value.
4 Press
the OK button to make the change.
Note: For some options such as Digital Zoom
and brightness, the change takes effect once
you select a different value.
5 Press to exit the projector settings
options.
Input source selection
Go to Input Source to access the following
settings.
• Auto: Automatically switch to the correct
input source.
• Android TV: Select this when no playback
device is connected.
• HDMI: Select this when an HDMI device is
connected.
• TYPE-C: Select this when a USB-C device is
connected.
• AV: Select this when an AV device is
connected.
Image options
You can access the following image setting
options.
• Picture Mode: Select a predefined color
brightness setting for picture and video
display, or select User to customize color
values on contrast, brightness, color, tint
and sharpness.
18 Philips · NeoPix Ultra 2
TV+
• Color Temperature: Set to Warm to enhance
hotter colors such as red; set to Cool to
make picture bluish; set to Medium for a
moderate color temperature.
• Geometry Corrections: Select an option to
correct the keystone and make the image
rectangular.
• Auto: Enable or disable auto correction
of the image shape.
• Manual: Manually correct the image
shape.
• Off: Disable correction of the image
shape.
• Projection Mode: Adjust the projection to
the correct position based on different
installations of the projector.
• Digital Zoom: Scale down the projection
image.
• Aspect Ratio: Toggles between the
available aspect ratios (16:9 and 4:3).
Sound options
You can access the following sound setting
options.
• Volume: Adjust volume of the projector.
Note: You must press
+/- to adjust
volume.
• Sound Mode: Select a preset sound effect
or select User to manually adjust bass and
treble.
• Audio Output: Switch the audio output
between Internal Speaker and SPDIF. Select
SPDIF if you want to output audio through
SPDIF connection to a digital device (e.g.
home cinema system or AV receiver).
Scheduled shutdown
Go to Sleep Timer to select a period of time
after which the projector turns off automatically.
The default value is Disable.
Other options
You can also access the following options.
• OSD Language: Select a language for on-
screen menus.
• Software Version: Check software version of
this product.
• Hardware Version: Check hardware version
of this product.
• Firmware Upgrade: Software update via a
USB device (see Update software through
USB, page 19).
• Factory Reset: Restore the product to its
factory default settings.
Maintenance 19
7 Maintenance
Cleaning
DANGER!
Instructions for cleaning!
Use a soft, lint-free cloth. Never use
liquid or easily flammable cleansers
(sprays, abrasives, polishes, alcohol,
etc.). Do not allow any moisture to
reach the interior of the projector.
Do not spray the projector with any
cleaning fluids.
Wipe over the surfaces gently. Be
careful that you do not scratch the
surfaces.
Cleaning the lens
Use a soft brush or lens cleaning paper for
cleaning the lens of the projector.
DANGER!
Do not use any liquid cleaning agents!
Do not use any liquid cleaning
agents for cleaning the lens, to avoid
damaging the coating film on the lens.
Update software
The latest software for the projector can be
found on
www.philips.com/support for you
to get the best features and support from the
projector.
Before you update the software of the
projector, check the current software version.
To learn how to do so, see Other options, page
18.
CAUTION!
Do not turn off the projector or remove
the USB flash drive during a software
update.
Update software through USB
1 Check the latest software version on www.
philips.com/support. Find your product
(model number: NPX644/INT), and locate
‘Software and drivers’.
2 Download the zipped software file, then
unzip and save it in the root directory of the
USB flash drive.
3 Connect the USB flash drive (FAT32
formatted) to the projector.
4 Press
to access the projector
settings options and select Firmware
Upgrade.
5 Follow the on-screen instructions to
complete the update.
20 Philips · NeoPix Ultra 2
TV+
8 Troubleshooting
Power cycling
If a problem occurs and you cannot resolve it using the instructions in this user manual, try the
following steps to resolve the problem.
1 Turn the projector off by pressing
twice.
2 Wait at least ten seconds.
3 Turn the projector on by pressing
once.
4 If the problem persists, contact our technical service center or your dealer.
Problems Solutions
The projector cannot be turned on. • Disconnect and reconnect the power cable, and
try to turn the projector on again.
The projector cannot be turned off.
• Press and hold
longer than ten seconds. If this
does not work, disconnect the power cable.
The remote control does not work. • The remote control is not paired with the
projector. Pair the remote control with the
projector (see Step 1: Pair the remote control with
the projector, page 11).
• The remote control is not in Android TV mode for
Android TV menu navigation. Press
on
the remote control to switch the remote control to
Android TV mode (if the remote control is paired
with the projector).
When the remote control is in Android TV mode,
the LED on the remote control flashes blue once
each time you press a button on the remote
control.
• Check the batteries of the remote control.
No sound output to the connected digital
device.
• Check the cables to the external device.
• Check that the sound output is activated on the
projector. Press
on the remote control to
access the projector settings options and select
Audio Output - SPDIF.
No image from the external HDMI device. • Check if the correct HDMI input is selected.
• Disconnect the HDMI cable or switch off the
HDMI device.
• Wait three seconds.
• Reconnect the HDMI cable or switch on the HDMI
device again.
No sound from external HDMI output
device.
• On the HDMI output device, set the audio setting
to Multichannel (Raw data) & Stereo (PCM).
No sound when you connect your
computer via HDMI cable.
• Check that the sound is activated on the
computer.
Cannot stream video from an app on my
mobile phone.
• Make sure the correct setup is made and the
app is Chromecast-enable (see Cast content to
Android TV, page 13).
Troubleshooting 21
Problems Solutions
When I view videos, the sound or the
picture is sometimes distorted or the sound
is not synchronized to the picture.
• The available WiFi bandwidth is insufficient for
sending the video flawlessly from the smartphone
to the projector. This can happen if one or more
WiFi networks operate in the same frequency
range nearby. Certain IoT devices (e.g. ZigBee
enabled devices) also operate in this frequency
range.
• Your smartphone is not fast enough to compress
the data and send it simultaneously over WiFi.
The temperature of the projector’s surface
is warm.
• For this projector it is normal to generate
moderate heat during operation.
The projector turns itself off. • When the projector is running for a long period of
time, the surface becomes hot.
• Check that the power cable is connected correctly.
What to do if the projector does not work
when connecting to a notebook PC?
• Check that the HDMI cable is plugged in correctly.
• Make sure that the notebook PC has been
switched to projector display.
22 Philips · NeoPix Ultra 2
TV+
9 Appendixes
Technical data
Technology/optical
Display technology .............................................. LCD
Light source ............................................................LED
Color space ........................................100% REC 709
Resolution .................................. 1920 × 1080 pixels
LED lifetime ...............................over 30,000 hours
Contrast ratio .................................................... 3000:1
Aspect ratio ............................................................16:9
Throw ratio .............................................................. 1.4:1
Screen size (diagonal) .......................... 20" to 120"
Screen distance ......80 cm - 200 cm / 24”- 60”
Keystone correction ......... automatic (vertical) or
manual (vertical and horizontal)
Projection modes ...........front, rear, front, ceiling
Focus adjustment ..........................................manual
Digital zoom ......................................yes (60-100%)
Auto rotate ............................................................... yes
Sound
Built-in speakers ............................................2 x 10W
Surround sound ..................................................... yes
Built-in powerful DSP .......................................... yes
Connection
Wi-Fi ..... ...................802.11a/b/g/n/ac, 2.4+5GHz,
................................................ Chromecast built in
Bluetooth ........................................................................
connection for remote control, keyboard,
mouse, gamepad, earphones, etc.
USB ................................................................................ x1
HDMI ............................................................................. x1
USB-C ........................................................................... x1
AV in .............................................................................. x1
Audio output ............................. SPDIF (optical out)
....................................... 3.5 mm headphone jack
Power source
Power consumption ....................operating: 100 W
........................................................ standby: 0.3 W
Power supply ....................... 100-240V
~
, 50/60Hz
Apps
Pre loaded apps ............................... Android TV
TM
/
full catalog of apps
Internal 4K Android TV™
CPU ................................................... Amlogic S905Y2
Operating system .............................Android™ 10.0
DRAM .............................................................DDR 2GB
Flash ............................................................eMMC 8GB
Product details
Dimensions (W × D × H) ..... .. 391 x 351 x 203 mm
Weight ...................................................................4.3 kg
Operating temperature.......................... 5 °C - 35 °C
Storage temperature ...................................... < 60 °C
Package content
1. NeoPix Ultra 2
TV+
projector
2. Smart remote control with mic
3. Power cables (EU, UK, US, CH)
4. HDMI cable
5. USB-C cable
6. Lens cover
7. AAA batteries for the remote control
8. Quick Start Guide
9. Warranty card
Model
NPX644/INT
EAN: 7640186961042
UPC: 793565993459
Appendixes 23
CE statement
• The product shall only be connected to a
USB interface of version USB 2.0 or higher.
• Adapter shall be installed near the
equipment and shall be easily accessible.
• The operating temperature of the EUT can’t
exceed 35°C and shouldn’t be lower than
5°C.
• The plug is considered as disconnect device
of adapter.
• The UNII Band 5150-5250 MHz is for indoor
use only.
• The device complies with RF specifications
when the device is used at 20 cm from your
body.
Hereby, Screeneo Innovation SA declares that
this product is in compliance with essential
requirements and other relevant provisions of
Directive 2014/53/EU.
The Declaration of Compliance can be
consulted on the site www.philips.com.
Frequency bands Maximum output
power
BT EDR (EIRP) 9.09 dBm
BT BLE (EIRP) 4.85 dBm
Wi-Fi 2.4GHz (EIRP) 17.88 dBm
Wi-Fi 5GHZ (EIRP) 17.89 dBm
FCC statement
15.19 Labeling requirements.
This device complies with part 15 of the FCC
Rules. Operation is subject to the following
two conditions: (1) This device may not cause
harmful interference, and (2) this device must
accept any interference received, including
interference that may cause undesired
operation.
15.21 Information to the user.
Any changes or modifications not expressly
approved by the party responsible for
compliance could void the user’s authority to
operate the equipment.
15.105 Information to user.
This equipment has been tested and found
to comply with the limits for a Class B digital
device, pursuant to Part 15 of the FCC Rules.
These limits are designed to provide reasonable
protection against harmful interference in
a residential installation. This equipment
generates, uses and can radiate radio
frequency energy and, if not installed and used
in accordance with the instructions, may cause
harmful interference to radio communications.
However, there is no guarantee that interference
will not occur in a particular installation. If this
equipment does cause harmful interference
to radio or television reception, which can be
determined by turning the equipment off and
on, the user is encouraged to try to correct the
interference by one or more of the following
measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the
equipment and receiver.
• Connect the equipment into an outlet on
a circuit different from that to which the
receiver is connected.
• Consult the dealer or an experienced radio/
TV technician for help.
During operation, the separation distance
between the user and the antenna shall be
at least 20 cm. This separation distance will
ensure that there is sufficient distance from a
properly installed externally-mounted antenna
to satisfy the RF exposure requirements.
FCC ID: 2ASRT-NPX644/INT
Canada regulatory
compliance
This device complies with Industry Canada CAN
ICES-3 (B)/NMB-3(B)
RSS-Gen & RSS-247 statement: This device
complies with Industry Canada RSS standard(s).
Operation is subject to the following two
conditions:
1 This device may not cause interference, and
2 This device must accept any interference,
including interference that may cause
undesired operation of the device.
RF Radiation Exposure statement: The
device meets the exemption from the routine
evaluation limits in section 2.5 of RSS102 and
users can obtain Canadian information on RF
24 Philips · NeoPix Ultra 2
TV+
exposure and compliance.
This device should be installed and operated
with a minimum distance of 7.8 inches
(20 centimetres) between the device and your
body.
Other notice
Preservation of the environment as part
of a sustainable development plan is an
essential concern of Screeneo Innovation SA.
The desire of Screeneo Innovation SA is to
operate systems respecting the environment
and consequently it has decided to integrate
environmental performances in the life cycle
of these products, from manufacturing to
commissioning use and elimination.
Packaging: The presence of the logo (green
dot) means that a contribution is paid to an
approved national organisation to improve
package recovery and recycling infrastructures.
Please respect the sorting rules set up locally
for this kind of waste.
Batteries: If your product contains batteries,
they must be disposed of at an appropriate
collection point.
Product: The crossed-out waste bin symbol on
the product means that the product belongs
to the family of electrical and electronic
equipment. In this respect, the European
regulations ask you to dispose of it selectively:
• At sales points in the event of the
purchase of similar equipment.
• At the collection points made available
to you locally (drop-off centre, selective
collection, etc.).
In this way you can participate in the reuse
and upgrading of Electrical and Electronic
Equipment Waste, which can have an effect on
the environment and human health.
The paper and cardboard packaging used can
be disposed of as recyclable paper. Have the
plastic wrapping recycled or dispose of it in
the non-recyclable waste, depending on the
requirements in your country.
Trademarks: The mentioned references in
this manual are trademarks of the respective
companies. The lack of the trademarks ®
and ™ does not justify the assumption that
these dedicated terminologies are free
trademarks. Other product names used herein
are for identification purposes only and may
be trademarks of their respective owners.
Screeneo Innovation SA disclaims any and all
rights in those marks.
Neither Screeneo Innovation SA nor its affiliates
shall be liable to the purchaser of this product
or third parties for damages, losses, costs, or
expense s incurred by the purchaser or third
parties as a result of accident, misuse, or abuse
of this product or unauthorised modifications,
repairs, or alterations to this product, or failure
to strictly comply with Screeneo Innovation SA
operating and maintenance instructions.
Screeneo Innovation SA shall not be liable for
any damages or problems arising from the use
of any options or any consumable materials
other than those designated as original
Screeneo Innovation SA/PHILIPS products or
Screeneo Innovation SA/PHILIPS approved
products.
Screeneo Innovation SA shall not be held liable
for any damage resulting from electromagnetic
interference that occurs from the use of any
interface cables other than those designated as
Screeneo Innovation SA/PHILIPS products.
All rights reserved. No part of this publication
may be reproduced, stored in a retrieval
system or transmitted in any form or by any
means, electronic, mechanical, photocopying,
recording, or otherwise, without the prior
written permission of Screeneo Innovation SA.
The information contained herein is designed
only for use with this product. Screeneo
Innovation SA. is not responsible for any use of
this information as applied to other devices.
This user manual is a document that does not
represent a contract.
Errors, printing errors and changes are reserved.
Copyright © 2021 Screeneo Innovation SA.
Appendixes 25
Screeneo Innovation SA
Route de Lully 5c - 1131 Tolochenaz - Switzerland
Philips and the Philips Shield Emblem are registered trademarks of Koninklijke Philips N.V. used
under license. Screeneo Innovation SA is the warrantor in relation to the product with which this
booklet was packaged.
2021 © Screeneo Innovation SA. All rights reserved.
NeoPix Ultra 2
TV+
EN
