Thank you for choosing SYNCO Mic-D1,
Please read this manual carefully before use and follow all instructions mentioned herein.
Mic-D1 Microphone
User Manual
Block 15th, No.200 Fangcun Avenue East, Liwan District, Guangzhou, China, 510000
support@syncoaudio.com
www.syncoaudio.com
https://www.facebook.com/syncomicrophones
Guangzhou Zhiying Technology Co., Ltd
Package List.....................................................................................................................................1
Feature Introduction.......................................................................................................................2
Caring For Your SYNCO Mic-D1 Microphone................................................................................2
Mounting the Shotgun Mic............................................................................................................3
Specications..................................................................................................................................4
① Polar Pattern
② AA Battery/ 48V Phantom Power
③ Performance Parameter
Warranty...........................................................................................................................................5
Contents
1 www.syncoaudio.com www.syncoaudio.com 2
Feature Introduction
Package List
Caring For Your SYNCO Mic-D1 Microphone
Designed for Video Production and Broadcast (ENG/EFP) Audio Acquisition.
Hyper Cardioid Polar Pattern, Pickup the Purest Sound Source.
Adopt 180Hz 12dB High-pass Filter, Minimizing The Unwanted Noise.
Powered by 48V Phantom Power or One AA Battery.
CNC Brass Tube, Highly Anti-Interference.
Gold-plated 3-Pin XLR Connector for interference-free signal transfer.
Mini MIC Holder with 3/8” to 5/8” Connector.
Suitable for Filmmaking, Broadcast and Video Shooting.
Please keep the product in a dry, clean, dust-free environment.
Keep corrosive chemicals, liquids and heat source away from the product to prevent mechanics
damage.
Use only a soft and dry cloth for cleaning the product.
Malfunction may be caused by dropping, impact of external force.
Do not attempt to disassemble the product. Doing so voids warranty.
Please have the product checked or repaired by authorized technicians if any malfunctions happened.
Remove the battery for long time storage.
Failure to follow all the instructions may result in mechanics damage.
Warranty does not apply to human errors.
SYNCO Mic-D1 Microphone x1
XLRF-3.5MM Cable x1
Mic Holder
with 5/8"-3/8" Connector x1
XLRM-XLRF Cable x1
User Manual x1
Protection Box x1
3/8" Cold Shoe x1
Foam Windscreen x1
(Package includes the following items)
User Manual
1 www.syncoaudio.com www.syncoaudio.com 2
Feature Introduction
Package List
Caring For Your SYNCO Mic-D1 Microphone
Designed for Video Production and Broadcast (ENG/EFP) Audio Acquisition.
Hyper Cardioid Polar Pattern, Pickup the Purest Sound Source.
Adopt 180Hz 12dB High-pass Filter, Minimizing The Unwanted Noise.
Powered by 48V Phantom Power or One AA Battery.
CNC Brass Tube, Highly Anti-Interference.
Gold-plated 3-Pin XLR Connector for interference-free signal transfer.
Mini MIC Holder with 3/8” to 5/8” Connector.
Suitable for Filmmaking, Broadcast and Video Shooting.
Please keep the product in a dry, clean, dust-free environment.
Keep corrosive chemicals, liquids and heat source away from the product to prevent mechanics
damage.
Use only a soft and dry cloth for cleaning the product.
Malfunction may be caused by dropping, impact of external force.
Do not attempt to disassemble the product. Doing so voids warranty.
Please have the product checked or repaired by authorized technicians if any malfunctions happened.
Remove the battery for long time storage.
Failure to follow all the instructions may result in mechanics damage.
Warranty does not apply to human errors.
SYNCO Mic-D1 Microphone x1
XLRF-3.5MM Cable x1
Mic Holder
with 5/8"-3/8" Connector x1
XLRM-XLRF Cable x1
User Manual x1
Protection Box x1
3/8" Cold Shoe x1
Foam Windscreen x1
(Package includes the following items)
User Manual
3 www.syncoaudio.com www.syncoaudio.com 4
1. Mount the Mic-D1 microphone on a boom pole
through the mic holder with 3/8" - 5/8" connector.
2. Put the foam windscreen on the Mic-D1
microphone.
3. Connect the Mic-D1 microphone to Camcorder/
Mixer using a XLRM-XLRF cable.
4. Connect the Mic-D1 microphone to Camera
using a 3.5mm-XLRF cable.
Mounting the Shotgun Mic
1. Polar Pattern: Hyper Cardioid
Specications
2. AA Battery/ 48V Phantom Power
SYNCO Mic-D1 runs on 48V phantom power, or is
powered by one AA battery for about 100 hours.
AA battery
48V phantom power
3. Performance Parameter
Model
Element
Polar Pattern
Frequency Response
Signal to Noise Ratio
Sensitivity
Max.Input SPL
Mic-D1
Back Electret Condenser
Hyper-Cardioid
40Hz - 20,000Hz
78dB（1KHz at 1Pa）
-34dB/-32dB±2dB（1dB=1V/Pa at 1kHz）
130dB
3 www.syncoaudio.com www.syncoaudio.com 4
1. Mount the Mic-D1 microphone on a boom pole
through the mic holder with 3/8" - 5/8" connector.
2. Put the foam windscreen on the Mic-D1
microphone.
3. Connect the Mic-D1 microphone to Camcorder/
Mixer using a XLRM-XLRF cable.
4. Connect the Mic-D1 microphone to Camera
using a 3.5mm-XLRF cable.
Mounting the Shotgun Mic
1. Polar Pattern: Hyper Cardioid
Specications
2. AA Battery/ 48V Phantom Power
SYNCO Mic-D1 runs on 48V phantom power, or is
powered by one AA battery for about 100 hours.
AA battery
48V phantom power
3. Performance Parameter
Model
Element
Polar Pattern
Frequency Response
Signal to Noise Ratio
Sensitivity
Max.Input SPL
Mic-D1
Back Electret Condenser
Hyper-Cardioid
40Hz - 20,000Hz
78dB（1KHz at 1Pa）
-34dB/-32dB±2dB（1dB=1V/Pa at 1kHz）
130dB
5 www.syncoaudio.com www.syncoaudio.com 6
WARRANTY
Warranty Period
Thank you for purchasing SYNCO products.
1. Customers are entitled to free replacement or repair service in case of quality defect(s) found in the
product under normal use within 30 days upon receipt of the product.
2. Original SYNCO products are entitled to 24-month limited warranty service. The warranty period begins
on the date of purchase of brand new, unused products by the rst end-user.
Within the warranty period, if product defect or failure is attributable to material defection or
technological problem, the defective product or defective part will be repaired or replaced without charge
(service and materials fee).
Warranty Exclusions and Limitations
Faults resulted from inappropriate use of a product without following its operation specication
Articial damage, e.g. crash, squeeze, scratch, or soaking
Modications to a product by its user or a third party without prior written consent of SYNCO, e.g.
replacement of element or circuit, label alteration
The code on product is inconsistent with that of warranty certicate, or the code on the product or
warranty certicate is altered or torn o
All consumable accessory attached to a product, like cable, wind mu, battery
Faults as a result of force majeure, such as re, ood, lightning, etc.
Warranty Claim Procedure
If failure or any problem occurs to your product after purchase, please contact a local agent for
assistance, or you can always contact SYNCO’s customer service through email at
support@syncoaudio.com.
Please retain your sales receipt and warranty certicate as proof of purchase. If any of these documents
is missing, only sales return or chargeable service will be provided.
If the SYNCO product is out of the warranty coverage, the service and the parts cost will be charged.
Dynamic Range
Power Requirements
Battery Runtime
Output Impedance
Output Connector
Low Frequency Roll-o
Dimensions (L x Diam)
Weight
106dB/91dB 11kHZ at MAX SPL
Phantom Power 48V/1.5V AA Battery
100 hours
500Ω/600Ω（48V/1.5V）
XLR 3-Pin Male
High-pass Filter
11.22 x 0.83 inches
7.3 oz/207g
5 www.syncoaudio.com www.syncoaudio.com 6
WARRANTY
Warranty Period
Thank you for purchasing SYNCO products.
1. Customers are entitled to free replacement or repair service in case of quality defect(s) found in the
product under normal use within 30 days upon receipt of the product.
2. Original SYNCO products are entitled to 24-month limited warranty service. The warranty period begins
on the date of purchase of brand new, unused products by the rst end-user.
Within the warranty period, if product defect or failure is attributable to material defection or
technological problem, the defective product or defective part will be repaired or replaced without charge
(service and materials fee).
Warranty Exclusions and Limitations
Faults resulted from inappropriate use of a product without following its operation specication
Articial damage, e.g. crash, squeeze, scratch, or soaking
Modications to a product by its user or a third party without prior written consent of SYNCO, e.g.
replacement of element or circuit, label alteration
The code on product is inconsistent with that of warranty certicate, or the code on the product or
warranty certicate is altered or torn o
All consumable accessory attached to a product, like cable, wind mu, battery
Faults as a result of force majeure, such as re, ood, lightning, etc.
Warranty Claim Procedure
If failure or any problem occurs to your product after purchase, please contact a local agent for
assistance, or you can always contact SYNCO’s customer service through email at
support@syncoaudio.com.
Please retain your sales receipt and warranty certicate as proof of purchase. If any of these documents
is missing, only sales return or chargeable service will be provided.
If the SYNCO product is out of the warranty coverage, the service and the parts cost will be charged.
Dynamic Range
Power Requirements
Battery Runtime
Output Impedance
Output Connector
Low Frequency Roll-o
Dimensions (L x Diam)
Weight
106dB/91dB 11kHZ at MAX SPL
Phantom Power 48V/1.5V AA Battery
100 hours
500Ω/600Ω（48V/1.5V）
XLR 3-Pin Male
High-pass Filter
11.22 x 0.83 inches
7.3 oz/207g
WARRANTY CERTIFICATE
USER
INFORMATION
SALES
INFORMATION
REPAIR
RECORD
RESULT
Please register your warranty. Meanwhile, you are welcomed to contact us via Email：
support@syncoaudio.com
Customer Name:
Phone Number:
Email:
Address:
Sales Date:
Model:
Product Code:
Dealer:
Service Date:
Technician:
Issue:
Solved Unsolved Returned(Replaced)
WARRANTY CERTIFICATE
USER
INFORMATION
SALES
INFORMATION
REPAIR
RECORD
RESULT
Please register your warranty. Meanwhile, you are welcomed to contact us via Email：
support@syncoaudio.com
Customer Name:
Phone Number:
Email:
Address:
Sales Date:
Model:
Product Code:
Dealer:
Service Date:
Technician:
Issue:
Solved Unsolved Returned(Replaced)
Thank you for choosing SYNCO Mic-D1,
Please read this manual carefully before use and follow all instructions mentioned herein.
Mic-D1 Microphone
User Manual
Block 15th, No.200 Fangcun Avenue East, Liwan District, Guangzhou, China, 510000
support@syncoaudio.com
www.syncoaudio.com
https://www.facebook.com/syncomicrophones
Guangzhou Zhiying Technology Co., Ltd
