OPPERATING INSTRUCTIONS
PWMA230BT
www.pyleUSA.com
PARAMETER
Wireless Portable Bluetooth PA Speaker System,
Built-in Rechargeable Battery, Wireless Microphone, 400 Watt
System Features:
Bluetooth Connectivity:
Technical Specs:
Accessories Included:
Rugged & Compact Public Address PA Sound System
Bluetooth Wireless Music Streaming Ability
Built-in Rechargeable Battery for Portability
(2) 1/4'' Microphone Inputs + (2) 1/4'' Guitar/Instruments Inputs
Ability to Connect & Stream Audio From External Devices
Wireless Microphone Included
Connect up to (3) Mics Simultaneously for a Karaoke Party
Ported Enclosure for Increased Bass Response
Full Range Stereo Sound Reproduction
Independent Channel Volume Controls
Audio Configuration: Echo, Bass and Treble Controls
Telescoping Handle & Caster Wheels
35mm Speaker Stand Mount
8'' Full Range Speaker
LED Indicator Lights
Wireless Microphone Included
External 12V Power DC Input Connector
Perfect for Karaoke, Public Events, Crowd Control, etc.
Built-in Bluetooth for Wireless Music Streaming
Works with All of Your Favorite Devices
(iPhone, Android, Smartphone, iPad, Tablet, Computer, etc.)
Bluetooth Wireless Network Name: Pyle Speaker
Bluetooth Version: 3.0
Bluetooth Wireless Range: 100 Ft.
Wireless Dynamic Microphone
1/4'' to Aux (3.5mm) Audio Cable + Adapter
Battery Terminal Alligator Clamp Cables
RCA Connection Cable
Power Cable
Max Power Output: 400 Watt
RMS Power Output: 200 Watt
VHF Band Signal System Transmission
Wireless Mic Operation Range: 100 ft.
System Battery Life: Approx. 10 Hours
Average Charging Time: 8 - 10 Hours
Battery Type: Lead Acid, 12V (4.5A)
Operating Frequency: 254.6kH
Frequency Response: 35-20kHz
SPL: 94dB (1W/M)
T.H.D.: <1%
Battery Powered Wireless Mic: Requires 2 x 'AA' Batteries
Power: 110/220 Voltage Switchable
Dimensions (L x W x H): 14.7'' x 10.6'' x 11.2''
