Wireless BT Streaming
Active-Powered Loudspeaker Cabinet
Wireless Music Streaming PA Speaker System,
FM Stereo Radio, USB/SD Readers, 1500 Watt, 15'' Subwoofer
(Includes Speaker Stand, Wired Microphone)
PPHP155ST
PPHP155ST
1. LCD Screen
2. MP3 Control
MODE: USB/SD/BT/FM Convertor
: Play/Pause
: Repeat one / Repeat all / Random
FOL (FOLDER): Press and hold for 5 seconds to enter the folder option
function model (press the previous/next songs button to choose the folder)
: Previous song, Press and hold for 2 seconds to lower the volume,
Press and hold the volume will go down to zero
: Next song, Press and hold for 2 seconds to increase the volume,
Press and hold the volume will go up to 25
3. SD card input
4. USB Input
5. Clip LED indicator
6. Power LED indicator
7. Mic 1 input level control
8. Mic 2 input level control
9. Line input level control
10. Volume control
11. Treble control
12. Bass control
13. XLR microphone input
14. 6.35mm microphone input
15. RCA phono (R+L) line input
16. 6.35mm line output
17. XLR line input
18. XLR line output
19. Speaker out 8 Ohm
20. Fused IEC mains inlet
21.120 - 240V Switch
22. Main power switch
www.PyleUSA.com
2
www.PyleUSA.com
3
120V
240V
120V 240V
www.PyleUSA.com
4
PPHP155ST
Wireless BT Streaming Active-Powered Loudspeaker Cabinet
Wireless Music Streaming PA Speaker System, FM Stereo Radio,
USB/SD Readers, 1500 Watt, 15'' Subwoofer
(Includes Speaker Stand,Wired Microphone)
System Features:
• Versatile High-Powered Mobile Cabinet Speaker System
• Rugged, Durable & Reliable Sound
• Bluetooth Wireless Music Streaming Ability
• Speaker System: 15'' Woofer, 1.0'' Tweeter
• Compression Driver with Titanium Diaphragm
• 2-Way Full Range Audio Projection
• Built-in Digital Audio Amplier
• XLR Microphone Input
• 1/4'' (6.35mm) Microphone Input
• RCA (L/R) Stereo Line Input Connectors
• XLR Guitar / Instrument Input
• 8 Ohm (SpeakOn) Speaker Output
• XLR Line Output
• Connect & Stream Audio from External Devices
• USB Flash Drive & SD Memory Card Readers
• USB Reader Doubles as Device Charging Port
• FM Radio with Digital LCD Display
• ID3 Tag Song Readout Info: LCD Displays Song Title/Song Artist
• Rear Panel Rotary Dial & Button Control Center
• Master Volume, Mic Volume, Treble, Bass Setting
• Convenient Carry Handles
• 35mm Speaker Stand Mount
• Engineered Heavy Duty ABS Housing
What's in the Box:
• Power Cable
• Speaker Stand
• Wired Microphone
www.PyleUSA.com
5
Bluetooth Wireless Streaming:
• Instantly Stream Music from Your Bluetooth Devices
• Works with All Your Favorite Bluetooth Devices
(iPhone, Android, Smartphone, iPad, Tablet, PC, etc.)
• Bluetooth Version: 4.0
• Bluetooth Wireless Range: 100'+ Feet
• Bluetooth Network Name: 'Pyle Audio'
Speaker Stands:
• Eectively Elevates Speaker for Optimum Sound Performance
• Universal Speaker Compatibility (35mm Insert)
• Easy Setup and Quick Adjustment Control
• Reinforced Steel Support Construction
• Speaker Support Arm Extension
• Rugged and Reliable
• Safety Lock-in Pin
• Foldable for Quick Storage and Transport
• Rubber Capped Tripod Feet Base
• Perfect for On-Stage or Studio Use
• For Professional or Beginner Applications
• Speaker Height Adjustable: 59.1'' to 82.7''
• MAX. Load Capacity: 100 lbs. (50 kgs.)
Technical Specs:
• Max Power Output: 1500 Watt
• Amplier Class: AB
• Impedance: 8 Ohm
• T.H.D.: <1%
• Sensitivity: 98dB (+/-2dB)
• Mic Input Level: <15mV
• Line Input/Output Level: >250mV
• Frequency Response: 40-18kHz
• Digital Audio File Compatibility: MP3, WMA
• Maximum SD/USB Flash Memory Support: 32GB
• Power: 120/240V
• Dimensions (L x W x H): 13.8'' x 17.0'' x 27.0''
