IPORT CONNECT DOCK Install Manual
Whats in box:
1 - IPORT CONNECT DOCK
1 - IPORT POWER SUPPLY
1 - Info Card
POWER SPECS
INPUT: 110-240V | AC 50/60 Hz
CRADLE OUTPUT 1: 5V 3A, PD 9V 3A
CRADLE OUTPUT 2: 5V 1.5A
(Output 2 is for electronic accessories and requires
a CONNECT PRO Case with accessories installed)
Thank you for purchasing the all new IPORT
CONNECT Platform. We hope you enjoy this
revolutionary new system and if at any time you
need more assistance please contact IPORT Tech
Support via Online chart or through our help desk.
- IPORT Team
FCC PART 15B CLASS B
AS/NZS 60950
AS/NZS CISPR22
EN 55032:2015+A11:2020
BS EN 55035:2017+A11:2020
CONNECT
DOCK
3
1. Remove DOCK and Power Supply from
the box and place on a table.
2. Insert the barrel connecto into the
bottom side of the dock.
CONNECT
DOCK
4
3. Rotate the wire retention clip
towards the front of the dock. Run
the wire around the retention post
and rotate the clip back into place.
CONNECT
DOCK
5
4. Place the CONNECT Dock in the
desired location. Plug in the power
adapter into AC power and place IPORT
CONNECT Case onto a Dock to initiate
charging.
