GO20 White/Grey
Catalogue
1
1
- - - - - - - - - - - - - - - - - - - - - - -
What's Inside
2
2
- - - - - - - - - - - - - - - - - - - - - - - - - - -
Operation
3
10
- - - - - - - - - - - - - -
Care And Maintenance
4
11
- - - - - - - - - - -
Error Codes & Solutions
5
13
- - - - - - - - - -
Warranty & Return Policy
6
14
- - - - - - - - - - -
Troubleshooting (Q & A)
7
19
- - - - - - - - - - - - - - - - - - - - - - -
APP Control
8
21
- - - - - - - - - - - - - - - -
Safety Instructions
What's Inside
Refrigerator x1
7 Feet 80W
Universal
AC Adapter x1
8 Feet 12/24V
DC Cigarette
Lighter Plug Cable x1
01
1
MODEL GO20 Series
External dimensions(LxWxH)
Net weight
Storage volume
Supply voltage
Temperature setting
Insulation
Shell material
10.8 Kg (23.8 lbs)
20 liters (21 quarts)
DC 12V/24V
C-pentane
ABS
570x320x315 mm
(22.4x12.6x12.4 inch)
-18°C to + 10°C (0°F to 50°F)
Operation
2
: "Locked" or
"Unlock" Button
: Left-Compt Temperature
Adjustment
: Power ON / OFF Button
: Function Button
(Fast Cooling Mode)
: Right-Compt Temperature
Adjustment
02
L
R
Power On
With your fridge plugged in, press and hold the
A (Power) Button for 3 seconds.
Power Off
Press and hold the A (Power) Button for 3
seconds.
03
2.1 Switched-on/off
NOTICE: If the partition is removed from
your fridge, it will function as a single zone
unit, and only one temperature setting will
become available.
04
2.2 Fast Cooling Mode
With the fridge turned on, you can press the
Button B to toggle between Fast and Normal
cooling modes.
Under the fast cooling mode, the left bin will
receive all of the fridge’s cooling power for the
1 15 minutes, and the right bin will maintain
its current temperature during this period. Then
when you switch back to the normal cooling
mode, the right bin will go back to its set
temperature.
st
With the fridge powered on, press and hold the
Button C to unlock the fridge’s control interface.
05
The fridge will lock its control interface after
90 seconds of no control inputs, to prevent
accidental changes from being made.
You can press and hold the Button C (Unlock)
for 3 seconds to unlock the control interface.
2.3 Unlock Button
06
NOTICE: When the temperature is set,
the display will return to show the current
temperature inside the refrigerator.
2.4 Switch Between °C to °F
In standby mode (fridge
turned off but plugged into
power), press and hold the
Temp.
Up and Down Buttons
on display E (Right Compt.)
at the same time for 3 seconds,
and you should be able to
toggle between Battery
Protection Levels and C/F
settings using the Button A.
Once you see either a C or F,
you can use UP/DOWN Button
switch between this two scales.
07
In standby mode (fridge turned
off but plugged into power),
press and hold the Temp. Up
and Down Buttons on display
E (Right Compt.) at the same
time for 3 seconds, and you
should be able to toggle
between Battery Protection
Levels and C/F settings using
the Button A.
The Battery Protection Levels
are represented by 3 dashes
on the display. There are 3
protection levels available and
you can select it using the
UP/DOWN Button on display.
NOTICE: Details of Battery Protection
Mode could be found in Page 16.
2.5 Battery Protection Mode
08
In standby mode (fridge turned
off but plugged into power),
press and hold the Temp. Up
and Down buttons on display
D (Left Compt.) at the same
time for 3 seconds, and you
should be able to switch
between F1/F2/F3 off-set
values for both compartments
by pressing the Button A.
NOTICE: We do not recommend our
customer to adjust the temperature off-set
value unless necessary or there is an
obvious temperature measurement deviation
from actual temperature.
2.6 Off-Set Value
The following chart details the temperature
zones each setting parameter affects, as well
as their default values.
OFF-SET
-2°C
(28°F)
F1
F2
F3
FUNCTION
VALUE
DEFAULTED
LEEF BIN
WHEN
SHIPMENT
RIGHT BIN
-3°C
(27°F)
-2°C
(28°F)
-3°C
(27°F)
-1°C
(30°F)
-4°C
(25°F)
Set temperature≥0°C,
temperature compensation
value
-1°C≥Set temperature≥-14°C,
temperature compensation
value
Set temperature≤-15°C,
temperature compensation
value
09
Care And Maintenance
3
Please use a wet cloth and warm water mixed
with gentle non-abrasive detergents to clean
the interior and exterior of your fridge.
Please power off and unplug the unit before
cleaning
Please use non-abrasive detergent to cleaning
the interior/exterior of the fridge
Please don't scrap the interior of the fridge to
defrost/de-ice the fridge
Please don't pressure-wash/spray the fridge
with a running water hose
3.1 Cleaning
3.2 DOs and DON'Ts
10
Error Codes & Solutions
4
Description
The cooling fan overloads with more than
1A of current.
E2
Motor start error
The motor of compressor is blocked or the
pressure difference in the refrigeration
system is too high.
E3
Minimum motor speed error
The compressor overloads and the motor
can not maintain its minimun speed 1850
rpms.
E4
Thermal cut-out of electronic unit
Thermal cut-out error If the refrigeration
system overloads, or the ambient
temperature is too high, the thermal
sensoris overheated.
E5
The DC voltage is under the protection
setting and the battery protection mode is
activated.
E1
NTC failure
Open circuit or short circuit.
E6
Code
11
Solutions
If this error code appears when the fridge is
operating on 12V DC, please try to lower the
battery protection setting and see if the error
is resolved. The battery protection mode may
be triggered prematurely on certain vehicles
due to small wiring imperfections, contributing
to a measured DC voltage drop at compressor
start-up. Lowering the battery protection
setting may resolve this issue.
Please also care about the reading of your
battery voltage to make sure it is not
depleted/discharged.
If possible, please connect the AC power to try
if the refrigerator appears error code.
Please contact us directly if the error persists.
12
Warranty & Return Policy
5
30 days refund guarantee.
5 years Compressor Warranty.
1 year General Warranty.
For returns or exchanges, please fill out the
following return and exchange registration
form in the package as a proof of return. All
materials must be returned in the original
condition and packaging. Thank you for your
cooperation.
If the product is received damaged or
defective during transportation, you need to
contact our customer service within 2
business days. Make sure to provide
relevant photos or videos, your order ID
number and your name. A customer service
agent will help assist into solving the issue
at a timely manner. (Return, Exchange, or
Discount Compensation) A free return label
will be provided if needed.
13
Troubleshooting (Q & A)
6
1. Heat resistance & water resistance
ICECO refrigerators are engineered to operate at
an ambient temperature of up to 55 °C(131 °F).
Heat resistance
ICECO refrigerators can operate under light rain
conditions. Please keep the vents above clear
of water, and please add some clearances to
the bottom of the fridge if the ground is wet.
Weather Proof
We DO NOT recommend exposing the fridge
to moderate or heavy rain.
As with all electrical appliances, over-exposure
to moisture may shorten the fridge’s life.
14
2. How long can the ICECO refrigerator
keep the temperature after powering
off?
The following data only represented the result of
the lab experiment with empty box. Everything
is based on the actual situation.
Insulation Performance
Model Insulation Test
GO20
Ambient temperature of 25°C (77°F)，
refrigerator temperature from -18°C
(0°F) to 20°C (68°F) needs about
3 hours on average.
3. Why did it change back to the original
temperature after setting the
temperature?
The Solid/Non-Flashing number on the display
is the CURRENT interior temperature.
The Flashing number is your SET temperature
after adjustment. The compressor will shut off
when the SET temperature is reached.
15
4. What should I do if the refrigerator is
upside down when it is delivered?
Please leave your refrigerator upright for 24
hours to allow the compressor lubricant to
resettle before powering on the fridge.
Otherwise it may contribute to certain operation
abnormalities.
5. What is the function of triple battery
protection? How do they work?
The triple battery protection is designed to
prevent over-discharge and battery depletion.
When the measured DC voltage is below the
set value, the compressor is shut off to prevent
battery depletion.
LOW
VOLTAGE
PROTECTION
POSITION
DISPLAY
12V
CUT OFF
(V)
CUT IN
(V)
CUT OFF
(V)
CUT IN
(V)
24V
1 Bar
2 Bars
3 Bars
9.6 10.9 21.3 22.7
10.4 11.7 22.8 24.2
11.1 12.4 24.3 25.7
MED
HIGH
16
17
For example, when you switch to a LOW MODE,
the battery voltage is under 9.6 volts, the
refrigerator will automatically cut the power OFF;
The refrigerator will start again till the battery
voltage reached back to 10.9 volts.
6. What is the power draw in max/ fast
cooling mode?
Model
Electrical
Power
GO12
50W
Model
Electrical
Power
JP42
55W
GO20
50W
VL35
Series
65W
JP Series
60W
VL Series
85W
This data is only suitable for laboratory testing,
and the actual power is subject to actual
conditions.
VL45 ProS
45W
VL60 ProS
47W
VL75 ProD
57W
VL90 ProD
61W
8. What kind of cable do I need to use in
the car and at home?
The DC cable is provided. You can power it
from your vehicle's cigarette lighter plug using
the DC cable. You can also power it at home,
but you need to use with AC cable as
precondition.
9. What is the specification of the fuse
of the refrigerator?
The supply line is protected by a 15A fuse
located in the refrigerator.
Because of the sinking nature of cold air, the
different temperatures may exist in different
locations in the refrigerator (the temperature of
the bottom will be the lowest). The panel only
shows the average temperature of the refrigerator.
7. Why is there a temperature difference
(between the actual temperature of the
refrigerator and the set temperature)?
18
App Control
7
Google-Play
App-Store
APP Download and Installation:
Users of Android mobile phone can download in
Android market, and iPhone users can download
from IOS App Store.
Register/Log Into APP
Register with your phone number
Become a member of us
Log into the APP after registration
Instruction:
Log into the APP, with Bluetooth on, and click
“Add Devices”. The APP will search for available
fridge, and enter the instruction display when it
connects with your fridge.
19
[State]
Click “ ” to control turning on/off of the fridge.
When it is on, its working state can be checked,
including the temp, voltage, electric quantity,
mode, temp graph.
[Setting]
Temperature control: the temp can be
adjusted from -18°C to 10°C(0°F to 50°F).
Click or slide to control.
Celsius and Fahrenheit switch: Celsius and
Fahrenheit can be switched. Click or slide to
switch.
Battery protection mode: three modes—high,
medium, low. Click or slide to change. Do
not change it optionally. The mode should
be set according to your vehicle battery, and
medium is recommended.
After finishing the setting, switch to “state”
display to check the state information of the
fridge.
20
Safety Instruction
8
SAFETY INSTRUCTIONS
Please read the user manual and safety
instructions carefully before using the appliance.
By ignoring the safety instructions, the
manufacturer cannot be held responsible for
the damage.
The use of accessories that are not
recommended by manufacturer can cause
injuries and will invalidate any warranty that
you may have.
The appliance shall not be exposed to
moderate/heavy rain.
Place the refrigerator on a dry, secure surface,
with adaquate ventilation.
21
Do not leave the refrigerator unattended
in uncovered, outdoor areas exposed to
the elements.
！
Do not use this appliance near direct
heatsources, such as an open flame or
radiator.
！
Do not place open containers of liquid
inside the fridge.
！
Please don't put hot/warm food into the
fridge directly without letting it cooling
off. Place/arrange the content of your
fridge securely when using the refrigerator
inside a moving vehicle.
！
To maximize energy savings, please make sure
the lid is closed and secure, and only open the
fridge when you need to.
The power cable must only be replaced by
qualified technical personnel and by an
assistant body authorized by the manufacturer.
Before carrying out any maintenance operations
on the refrigerator, disconnect all power sources
from the fridge.
This appliance is suitable for camping use.
22
WARNING!
Please keep the fridge in a well ventilated
area.
！
Do not use mechanical devices or other
means to accelerate the defrosting
process, other than those recommended
by the manufacturer.
！
Do not use electrical devices inside the
food storage compartments of the
appliance, unless approved/recommended
by the manufacturer.
！
Do not store explosive items, such as
aerosol cans with a flammable propellant
in this appliance.
！
Risk of fire and electrical shock.
！
Do not let hot items touch the plastic parts
of the appliance.
！
Do not put flammable products or items in,
near or on the appliance.
！
23
Do not touch the compressor or the
condenser when the fridge is operating.
They may be very hot.
！
When setting up the appliance, ensure
the supply cord is not trapped or
damaged.
！
Further information is provided on the
technical data label inside the product.
1. This appliance is not intended for use by
persons (including children) with reduced
physical, sensory or mental capabilities, or lack
of experience and knowledge, unless they have
been given supervision or instruction concerning
use of the appliance by a person responsible for
their safety.
2. Children should be supervised to ensure that
they do not play with the appliance.
24
3. This appliance is intended to be used in
household and similar applications such as
staff kitchen areas in shops, offices and
other working environments;
farm houses and by clients in hotels, motels
and other residential type environments;
bed and breakfast type environments;
catering and similar non-retail applications.
4. If the supply cord is damaged, it must be
replaced by the manufacturer, its service agent
or similarly qualified person in order to avoid a
hazard.
5. Do not store explosive substances such as
aerosol cans with a flammable propellant in this
appliance.
6. DANGER: Risk of child entrapment. Before
you throw away your old refrigerator or freezer:
Take off the doors.
Leave the shelves in place so that
childrenmay not easily climb inside.
*
*
25
Cooler Than A Cooler
