Installation Instructions
WARRANTY REGISTRATION
Register your product today and be automatically entered
to win an ISOBAR
®
surge protector in our monthly drawing!
tripplite.com/warranty
12-Port Wall-Mount Box
for UTP Keystone Jacks
Model: N062-012-KJ-WM
Este manual está disponible en español en la página
de Tripp Lite: tripplite.com
Ce manuel est disponible en français sur le site Web
de Tripp Lite : tripplite.com
Русскоязычная версия настоящего руководства
представлена на веб-сайте компании Tripp Lite по
адресу: tripplite.com
Dieses Handbuch ist in deutscher Sprache auf der
Tripp Lite-Website verfügbar: tripplite.com
2
1
Remove top panel
A
from wall-mount panel
B
by unlatching each of the four side clasps.
Installation
A
B
3
2
Complete cable termination on each desired
RJ45 module.
3
Align the keystone latch upwards. Insert the
assembled RJ45 modules into each port from
the rear of the panel.
Installation
Cable tie
Solid cable
4
4
Screw the wall-mount bracket into place where
desired with user-supplied hardware.
5
Upon installing all desired modules, mount the
front panel back onto the bracket by clicking all
four clasps into place.
Installation
4
5
5
6
Rotatable module instruction
6A
Positioning
Rotate the bezel to desired direction until
it clicks.
6B
Adjustment
Press the clip-on bezel to release the bezel
and change the direction.
Installation
6A
6B
6
Warranty and
Product Registration
Lifetime Limited Warranty
Seller warrants this product, if used in accordance with
all applicable instructions, to be free from original defects
in material and workmanship for its lifetime. If the product
should prove defective in material or workmanship within that
period, Seller will repair or replace the product, in its sole
discretion. Service under this Warranty can only be obtained
by your delivering or shipping the product (with all shipping
or delivery charges prepaid) to: TRIPP LITE; 1111 W. 35th
Street, Chicago, IL 60609. Seller will pay return shipping
charges. Visit tripplite.com/support before sending any
equipment back for repair.
THIS WARRANTY DOES NOT APPLY TO NORMAL
WEAR OR TO DAMAGE RESULTING FROM ACCIDENT,
MISUSE, ABUSE OR NEGLECT. SELLER MAKES NO
EXPRESS WARRANTIES OTHER THAN THE WARRANTY
EXPRESSLY SET FORTH HEREIN.
EXCEPT TO THE EXTENT PROHIBITED BY APPLICABLE
LAW, ALL IMPLIED WARRANTIES, INCLUDING ALL
WARRANTIES OF MERCHANTABILITY OR FITNESS, ARE
LIMITED IN DURATION TO THE WARRANTY PERIOD
SET FORTH ABOVE; AND THIS WARRANTY EXPRESSLY
EXCLUDES ALL INCIDENTAL AND CONSEQUENTIAL
DAMAGES. (Some states do not allow limitations on how
long an implied warranty lasts, and some states do not allow
the exclusion or limitation of incidental or consequential
damages, so the above limitations or exclusions may not
apply to you. This Warranty gives you specic legal rights,
and you may have other rights which vary from jurisdiction
to jurisdiction.)
7
Warranty and
Product Registration
WARNING: The individual user should take care to
determine prior to use whether this device is suitable,
adequate or safe for the use intended. Since individual
applications are subject to great variation, the manufacturer
makes no representation or warranty as to the suitability or
tness of these devices for any specic application.
PRODUCT REGISTRATION
Visit tripplite.com/warranty today to register your new
Tripp Lite product. You’ll be automatically entered into a
drawing for a chance to win a FREE Tripp Lite product!*
* No purchase necessary. Void where prohibited. Some
restrictions apply. See website for details.
Regulatory Compliance Identication Numbers
For the purpose of regulatory compliance certications and
identication, your Tripp Lite product has been assigned a
unique series number. The series number can be found on
the product nameplate label, along with all required approval
markings and information.
When requesting compliance information for this product,
always refer to the series number. The series number should
not be confused with the marketing name or model number
of the product.
Tripp Lite has a policy of continuous improvement.
Specications are subject to change without notice.
