180°
Wiring Scheme
180°
Wiring Scheme
Installation Instructions
Instrucciones de Instalación / Instructions d'installation /
Installationsanleitung / Istruzioni per l'installazione
Eaton
1000 Eaton Boulevard
Cleveland, OH 44122
United States
Eaton.com
© 2024 Eaton
All Rights Reserved
Publication No. 24-07-123 /
93-4B86_RevA
December 2024
Eaton has a policy of continuous
improvement. Specifications
are subject to change without
notice. Photos and illustrations
may differ slightly from actual
products.
Eaton is a registered trademark.
All trademarks are property
of their respective owners.
N250-012
1
1
4
4
5
5
6
6
2
2
3
3
12-Port Cat6 Wall-Mount
Vertical 110 Patch Panel
Panel de conexión 110 vertical para montaje en pared Cat6 de 12 puertos
Panneau enfichable 110 vertical 12 ports Cat6 pour montage mural
12-Port Cat6 Wandmontage vertikal 110 Patch-Panel
Pannello patch 110 verticale per montaggio a parete Cat6 a 12 porte
Cable tie
Amarre de cable
Attache-câble
Kabelbinder
Fascetta per cavi
Do not use 4/5 pair punchdown
tool. The impact may damage
the 110 clip.
No utilice la herramienta de
compresión de par 4/5. El
impacto puede dañar el clip 110.
N'utilisez pas d'outil de
perforation à 4/5 paires. L'impact
peut endommager le clip 110.
Verwenden Sie kein 4/5-Paar-
Punchdown-Werkzeug. Der Aufprall
kann den 110-Clip beschädigen.
Non utilizzare utensili di punzonatura
per coppie 4/5. L'impatto potrebbe
danneggiare la clip 110.
