FCC STATEMENT
Potential for Radio/Television interference
This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions:
(1) This device may not cause harmful interference, and
(2) this device must accept any interference received,
including interference that may cause undesired operation.
This product has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of
the FCC rules.
These limits are designed to provide reasonable protection against harmful interference in a residential installation.
The product generates, uses, and can radiate radio frequency energy and, if not installed and used in accordance
with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that
the interference will not occur in a particular installation. If the product does cause harmful interference to radio or
television reception, which can be determined by turning the product on or off, the user is encouraged to try to
correct the interference by one or more of the following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the product and the receiver.
• Connect the product into an outlet on a circuit different from that to which the receiver is connected.
• Consult the dealer or an experienced radio/TV technician for help.
• Changes or modifications not expressly approved by the party responsible for compliance could void the user’s
authority to operate the equipment.
WARRANTY INFORMATION
FCC STATEMENT
PLEASE READ AND SAVE THESE IMPORTANT INSTRUCTIONS
Instruction Manual
36'' DIGITAL
TOWER FAN
CLEANING/MAINTENANCE INSTRUCTIONS
Follow these instructions to correctly and safely care for
your fan. Please remember:
REPLACEABLE FUSE
If your (2.5 Amp, 125 Volt)
replaceable fuse blows, please
visit our website at
www.getholmesfans.com for
information on how to order
a new fuse. Follow the below
instructions to replace the
fuse on the plug.
User Servicing Instructions
1. Unplug your fan. Grasp plug and remove from the
receptacle or other outlet device. Do not unplug by
pulling on cord.
2. Open fuse cover, located on the top of the plug, by
using your thumb or a flathead screwdriver to slide
the cover down towards the prongs.
NOTE: Ensure that fuse cover is completely open
before attempting to remove fuse.
3. Remove fuse carefully by using a small screwdriver
to pry the fuse out of the compartment by the metal
ends of the fuse. (see Figure 5)
4. Place plug on a solid, flat surface. Insert new
2.5 Amp, 125 Volt fuse into fuse compartment and
use a small screwdriver to secure the metal ends of
the fuse into the compartment.
CAUTION: Risk of fire. Replace fuse only with
2.5 Amp, 125 Volt fuse.
5. Slide fuse cover closed completely. If fuse cover is
difficult to close, make sure fuse is secured in place
completely by pressing down on metal ends of the
fuse.
6. Risk of fire. Do not replace attachment plug. Contains
a safety device (fuse) that should not be removed.
Discard product if the attachment plug is damaged.
FAN CLEANING
• Always unplug the fan before cleaning.
• Do not allow water to drip on or enter into fan
housing.
• Be sure to use a soft cloth moistened with a mild
soap solution.
• Do not use gasoline, thinner or benzene as a
cleaner.
Clean the fan grill, housing and base with a soft, damp
cloth. Do not attempt to remove the fan blade. Please
use caution around the motor housing area. Do not allow
the motor or other electrical components to be exposed
to water.
FAN STORAGE
When storing your fan in the off season, it is important
to keep it in a safe dry location. It is important to protect
the fan head from dust.
CLEANING AND MAINTENANCE
Figure 5
Fuse
Metal ends
Fuse cover
If you have any questions regarding your product
or would like to learn more about other Holmes
®
products, please visit our website at
www.getholmesfans.com or call customer service:
1-866-769-3166 (8:30 am - 5:00 pm E.S.T.) or send
an email to info@getholmesfans.com. For inquiries
regarding recycling and proper disposal of this
product, please contact your local waste management
facility.
Printed In China
© 2021 Sunbeam Products, Inc. All rights reserved. HOLMES
®
is a registered trademark of
Sunbeam Products, Inc. used under license.
Distributed by Star Elite Inc., Montreal, Canada H3B 3X9
SEH005-111721
3 YEAR LIMITED WARRANTY
This device has a limited warranty of 3 year from the original date of purchase against workmanship and defects
in material. If under normal use, your product fails to operate, please contact our customer service department at
[email protected]. A refund or replacement will be provided to you with proof of purchase. Star Elite Inc.
may deny claims of damage caused by misuse or modications of this product.
How to Obtain Warranty Service
If you have any problems, please do not contact the store.
Contact our customer service at 1-866-769-3166 (8:30 am - 5:00 pm EST) Monday - Friday
or contact us at info@getholmesfans.com.
Our customer service will be happy to assist you.
www.getholmesfans.com
Item: 17038
Model: 32510021
PLEASE READ AND SAVE THESE
IMPORTANT SAFETY INSTRUCTIONS
FEATURES - OPERATIONS FEATURES - OPERATIONS
When using electrical appliances, basic safety precautions
should always be taken including the following:
1. Read all instructions before using this appliance.
2. Use fan only for purposes described in the instruction
manual. This fan is not for continuous operation or
equivalent.
3. To protect against electrical shock do not immerse
unit, plug or cord in water or spray with liquids and
plug the appliance directly into a 120V AC electrical
outlet.
4. Close supervision is necessary when any appliance is
used by or near children.
5. Unplug from outlet when not in use, when moving
fan from one location to another, before putting on
or taking off parts and before cleaning.
6. Avoid contact with moving parts.
7. Do not operate in the presence of explosive and/or
flammable fumes.
8. To avoid fire hazard, NEVER place the cord under
rugs or any parts near an open flame, cooking or
other heating appliance.
9. Do not operate any appliance with a damaged cord
or plug after the appliance malfunctions, or has been
dropped/damaged in any manner. Discard fan or
return to an authorized service facility for
examination and/or repair.
10. Do not run cord under carpeting. Do not cover cord
with throw rugs, runner, or similar coverings. Do not
route cord under furniture or appliances. Arrange
cord away from traffic area and where it will not be
tripped over.
11. The use of attachments not recommended or sold by
the appliance manufacturer may cause hazards.
12. Do not let the cord hang over the edge of a table,
counter or come in contact with hot surfaces or leave
exposed to high traffic areas.
13. Do not use outdoors.
14. To disconnect, grip plug and pull from wall outlet.
Never yank on cord.
15. Always use on a dry, level surface.
16. Do not operate fan until fully assembled with all
parts properly in place.
17. This product is intended for household use ONLY and
not for commercial or industrial applications.
18. WARNING: To reduce the risk of electrical shock
and injury to persons, do not use in window.
19. WARNING: To reduce the risk of fire or electric
shock, do not use this fan with any solid-state speed
control device.
20. This product employs overload protection (fuse). A
blown fuse indicates an overload or short-circuit
situation. If the fuse blows, unplug the product from
the outlet. Replace the fuse as per the user servicing
instructions (follow product marking for proper fuse
rating) and check the product. If the replacement fuse
blows, a short circuit may be present and the product
should be discarded or returned to an authorized
service facility for examination and/or repair.
!
WARNING: Chemical Burn Hazard. Keep batteries
away from children.
This product contains a lithium button/coin cell battery. If
a new or used lithium button/coin cell battery is
swallowed or enters the body, it can cause severe internal
burns and can lead to death in as little as 2 hours.
Always completely secure the battery compartment. If
the battery compartment does not close securely, stop
using the product, remove the batteries, and keep it
away from children. If you think batteries might have
been swallowed or placed inside any part of the body,
seek immediate medical attention.
PLEASE READ AND SAVE THESE
IMPORTANT SAFETY
INSTRUCTIONS
ASSEMBLY INSTRUCTIONS: (SEE FIGURE 1 & 2)
Estimated assembly time: 5-10 minutes
Tool-Free, 3 thumb screws included
NOTE: MAKE SURE YOU REMOVE ALL CONTENTS FROM
THE PACKAGE. PLEASE CHECK PACKAGING MATERIALS FOR
PARTS THAT COULD BE REQUIRED TO OPERATE YOUR FAN.
1. Assemble base halves around power cord. To secure
the base halves together, slide the posts of one base
half into the slots of the second base half. Refer to
Figure 2.
2. Line up the screws holes of the base halves with the
holes located on the bottom of the fan housing.
Secure with the three screws included with the
product. Refer to Figure 2.
3. Secure power cord as shown in Figure 2.
4. Turn fan right side up and place on a dry and level
surface.
OPERATING INSTRUCTIONS: (SEE FIGURE 3)
1. Plug the cord into a standard 120 volt AC outlet.
2. To turn the fan on, press the POWER button located
on the control panel or remote control. The fan will
start running in the lowest setting
"1" ( LOW ).
3. Press the SPEED button to cycle through the below 3
speed settings in sequence. The corresponding
indicator light will illuminate to confirm the selection:
1-Low
2-Medium
3-High
4. To turn the oscillation on and off, press the
OSCILLATION button located on the control panel or
remote control.
THIS APPLIANCE HAS A POLARIZED PLUG (one blade is wider than the
other). To reduce the risk of electric shock, this plug is intended to fit in
a polarized outlet only one way. If the plug does not fit fully in the
outlet, reverse the plug. If it still does not fit, contact a qualified
electrician to install the proper outlet.
DO NOT ATTEMPT TO MODIFY THIS PLUG OR DEFEAT THIS
SAFETY FEATURE IN ANY WAY.
FEATURES - OPERATIONS
5. To set your fan to automatically shut off, press the TIMER button located on the control panel or the remote
control. When set, the fan will run and automatically shut off after the set duration of time (1-7.5 hours) has
expired.
6. To turn the fan off press the POWER button located on the control panel or remote control.
NOTE: Your fan features a LED display panel. When a specific feature is activated on your fan, the LED panel will
illuminate with the corresponding text showing which features have been activated.
REMOTE CONTROL: (SEE FIGURE 4)
NOTE: PLEASE REMOVE THE PROTECTIVE STICKER FROM THE REMOTE CONTROL BATTERY BEFORE OPERATION.
This unit includes one lithium battery, CR2025/3V. Remove battery before discarding the remote.
Battery Replacement
The cells should be disposed of properly, including keeping them away from children. Even used cells may cause
injury.
a) Locate the battery compartment on the bottom back of the remote control handset. Push tab and pull battery
tray.
b) Remove old battery.
c) Place new battery into battery compartment.
d) Slide battery compartment into the remote control
handset.
NOTES:
• Remove the battery from the equipment when it is not being used for an extended period of time.
• Remove the used battery promptly.
• Do not discard used batteries into household trash containers. Contact your local government for disposal or
recycling practices in your area.
A. Power Button
B. Speed Button
C. Timer Button
D. Oscillation Button
E. Speed Setting Indicator Lights
F. Timer Indicator Lights
Figure 3
Figure 4
POWER
TIMER OSC
SPEED
A
C
B
D
POWER
LOW
MED
HIGH
4H
2H
1H
0.5H
TIMER
OSC
SPEED
A
E
C
D
B
F
POWER
TIMER OSC
SPEED
A
D
E
B
C
A. Control Panel
B Fan Housing
C. Base Halves
D. Remote Control
Storage
E. Remote Control
Figure 1
B
C
Power Cord
Figure 2
Power Cord
Thumb
Screws
PLEASE READ AND SAVE THESE
IMPORTANT SAFETY INSTRUCTIONS
FEATURES - OPERATIONS FEATURES - OPERATIONS
When using electrical appliances, basic safety precautions
should always be taken including the following:
1. Read all instructions before using this appliance.
2. Use fan only for purposes described in the instruction
manual. This fan is not for continuous operation or
equivalent.
3. To protect against electrical shock do not immerse
unit, plug or cord in water or spray with liquids and
plug the appliance directly into a 120V AC electrical
outlet.
4. Close supervision is necessary when any appliance is
used by or near children.
5. Unplug from outlet when not in use, when moving
fan from one location to another, before putting on
or taking off parts and before cleaning.
6. Avoid contact with moving parts.
7. Do not operate in the presence of explosive and/or
flammable fumes.
8. To avoid fire hazard, NEVER place the cord under
rugs or any parts near an open flame, cooking or
other heating appliance.
9. Do not operate any appliance with a damaged cord
or plug after the appliance malfunctions, or has been
dropped/damaged in any manner. Discard fan or
return to an authorized service facility for
examination and/or repair.
10. Do not run cord under carpeting. Do not cover cord
with throw rugs, runner, or similar coverings. Do not
route cord under furniture or appliances. Arrange
cord away from traffic area and where it will not be
tripped over.
11. The use of attachments not recommended or sold by
the appliance manufacturer may cause hazards.
12. Do not let the cord hang over the edge of a table,
counter or come in contact with hot surfaces or leave
exposed to high traffic areas.
13. Do not use outdoors.
14. To disconnect, grip plug and pull from wall outlet.
Never yank on cord.
15. Always use on a dry, level surface.
16. Do not operate fan until fully assembled with all
parts properly in place.
17. This product is intended for household use ONLY and
not for commercial or industrial applications.
18. WARNING: To reduce the risk of electrical shock
and injury to persons, do not use in window.
19. WARNING: To reduce the risk of fire or electric
shock, do not use this fan with any solid-state speed
control device.
20. This product employs overload protection (fuse). A
blown fuse indicates an overload or short-circuit
situation. If the fuse blows, unplug the product from
the outlet. Replace the fuse as per the user servicing
instructions (follow product marking for proper fuse
rating) and check the product. If the replacement fuse
blows, a short circuit may be present and the product
should be discarded or returned to an authorized
service facility for examination and/or repair.
!
WARNING: Chemical Burn Hazard. Keep batteries
away from children.
This product contains a lithium button/coin cell battery. If
a new or used lithium button/coin cell battery is
swallowed or enters the body, it can cause severe internal
burns and can lead to death in as little as 2 hours.
Always completely secure the battery compartment. If
the battery compartment does not close securely, stop
using the product, remove the batteries, and keep it
away from children. If you think batteries might have
been swallowed or placed inside any part of the body,
seek immediate medical attention.
PLEASE READ AND SAVE THESE
IMPORTANT SAFETY
INSTRUCTIONS
ASSEMBLY INSTRUCTIONS: (SEE FIGURE 1 & 2)
Estimated assembly time: 5-10 minutes
Tool-Free, 3 thumb screws included
NOTE: MAKE SURE YOU REMOVE ALL CONTENTS FROM
THE PACKAGE. PLEASE CHECK PACKAGING MATERIALS FOR
PARTS THAT COULD BE REQUIRED TO OPERATE YOUR FAN.
1. Assemble base halves around power cord. To secure
the base halves together, slide the posts of one base
half into the slots of the second base half. Refer to
Figure 2.
2. Line up the screws holes of the base halves with the
holes located on the bottom of the fan housing.
Secure with the three screws included with the
product. Refer to Figure 2.
3. Secure power cord as shown in Figure 2.
4. Turn fan right side up and place on a dry and level
surface.
OPERATING INSTRUCTIONS: (SEE FIGURE 3)
1. Plug the cord into a standard 120 volt AC outlet.
2. To turn the fan on, press the POWER button located
on the control panel or remote control. The fan will
start running in the lowest setting
"1" ( LOW ).
3. Press the SPEED button to cycle through the below 3
speed settings in sequence. The corresponding
indicator light will illuminate to confirm the selection:
1-Low
2-Medium
3-High
4. To turn the oscillation on and off, press the
OSCILLATION button located on the control panel or
remote control.
THIS APPLIANCE HAS A POLARIZED PLUG (one blade is wider than the
other). To reduce the risk of electric shock, this plug is intended to fit in
a polarized outlet only one way. If the plug does not fit fully in the
outlet, reverse the plug. If it still does not fit, contact a qualified
electrician to install the proper outlet.
DO NOT ATTEMPT TO MODIFY THIS PLUG OR DEFEAT THIS
SAFETY FEATURE IN ANY WAY.
FEATURES - OPERATIONS
5. To set your fan to automatically shut off, press the TIMER button located on the control panel or the remote
control. When set, the fan will run and automatically shut off after the set duration of time (1-7.5 hours) has
expired.
6. To turn the fan off press the POWER button located on the control panel or remote control.
NOTE: Your fan features a LED display panel. When a specific feature is activated on your fan, the LED panel will
illuminate with the corresponding text showing which features have been activated.
REMOTE CONTROL: (SEE FIGURE 4)
NOTE: PLEASE REMOVE THE PROTECTIVE STICKER FROM THE REMOTE CONTROL BATTERY BEFORE OPERATION.
This unit includes one lithium battery, CR2025/3V. Remove battery before discarding the remote.
Battery Replacement
The cells should be disposed of properly, including keeping them away from children. Even used cells may cause
injury.
a) Locate the battery compartment on the bottom back of the remote control handset. Push tab and pull battery
tray.
b) Remove old battery.
c) Place new battery into battery compartment.
d) Slide battery compartment into the remote control
handset.
NOTES:
• Remove the battery from the equipment when it is not being used for an extended period of time.
• Remove the used battery promptly.
• Do not discard used batteries into household trash containers. Contact your local government for disposal or
recycling practices in your area.
A. Power Button
B. Speed Button
C. Timer Button
D. Oscillation Button
E. Speed Setting Indicator Lights
F. Timer Indicator Lights
Figure 3
Figure 4
POWER
TIMER OSC
SPEED
A
C
B
D
POWER
LOW
MED
HIGH
4H
2H
1H
0.5H
TIMER
OSC
SPEED
A
E
C
D
B
F
POWER
TIMER OSC
SPEED
A
D
E
B
C
A. Control Panel
B Fan Housing
C. Base Halves
D. Remote Control
Storage
E. Remote Control
Figure 1
B
C
Power Cord
Figure 2
Power Cord
Thumb
Screws
PLEASE READ AND SAVE THESE
IMPORTANT SAFETY INSTRUCTIONS
FEATURES - OPERATIONS FEATURES - OPERATIONS
When using electrical appliances, basic safety precautions
should always be taken including the following:
1. Read all instructions before using this appliance.
2. Use fan only for purposes described in the instruction
manual. This fan is not for continuous operation or
equivalent.
3. To protect against electrical shock do not immerse
unit, plug or cord in water or spray with liquids and
plug the appliance directly into a 120V AC electrical
outlet.
4. Close supervision is necessary when any appliance is
used by or near children.
5. Unplug from outlet when not in use, when moving
fan from one location to another, before putting on
or taking off parts and before cleaning.
6. Avoid contact with moving parts.
7. Do not operate in the presence of explosive and/or
flammable fumes.
8. To avoid fire hazard, NEVER place the cord under
rugs or any parts near an open flame, cooking or
other heating appliance.
9. Do not operate any appliance with a damaged cord
or plug after the appliance malfunctions, or has been
dropped/damaged in any manner. Discard fan or
return to an authorized service facility for
examination and/or repair.
10. Do not run cord under carpeting. Do not cover cord
with throw rugs, runner, or similar coverings. Do not
route cord under furniture or appliances. Arrange
cord away from traffic area and where it will not be
tripped over.
11. The use of attachments not recommended or sold by
the appliance manufacturer may cause hazards.
12. Do not let the cord hang over the edge of a table,
counter or come in contact with hot surfaces or leave
exposed to high traffic areas.
13. Do not use outdoors.
14. To disconnect, grip plug and pull from wall outlet.
Never yank on cord.
15. Always use on a dry, level surface.
16. Do not operate fan until fully assembled with all
parts properly in place.
17. This product is intended for household use ONLY and
not for commercial or industrial applications.
18. WARNING: To reduce the risk of electrical shock
and injury to persons, do not use in window.
19. WARNING: To reduce the risk of fire or electric
shock, do not use this fan with any solid-state speed
control device.
20. This product employs overload protection (fuse). A
blown fuse indicates an overload or short-circuit
situation. If the fuse blows, unplug the product from
the outlet. Replace the fuse as per the user servicing
instructions (follow product marking for proper fuse
rating) and check the product. If the replacement fuse
blows, a short circuit may be present and the product
should be discarded or returned to an authorized
service facility for examination and/or repair.
!
WARNING: Chemical Burn Hazard. Keep batteries
away from children.
This product contains a lithium button/coin cell battery. If
a new or used lithium button/coin cell battery is
swallowed or enters the body, it can cause severe internal
burns and can lead to death in as little as 2 hours.
Always completely secure the battery compartment. If
the battery compartment does not close securely, stop
using the product, remove the batteries, and keep it
away from children. If you think batteries might have
been swallowed or placed inside any part of the body,
seek immediate medical attention.
PLEASE READ AND SAVE THESE
IMPORTANT SAFETY
INSTRUCTIONS
ASSEMBLY INSTRUCTIONS: (SEE FIGURE 1 & 2)
Estimated assembly time: 5-10 minutes
Tool-Free, 3 thumb screws included
NOTE: MAKE SURE YOU REMOVE ALL CONTENTS FROM
THE PACKAGE. PLEASE CHECK PACKAGING MATERIALS FOR
PARTS THAT COULD BE REQUIRED TO OPERATE YOUR FAN.
1. Assemble base halves around power cord. To secure
the base halves together, slide the posts of one base
half into the slots of the second base half. Refer to
Figure 2.
2. Line up the screws holes of the base halves with the
holes located on the bottom of the fan housing.
Secure with the three screws included with the
product. Refer to Figure 2.
3. Secure power cord as shown in Figure 2.
4. Turn fan right side up and place on a dry and level
surface.
OPERATING INSTRUCTIONS: (SEE FIGURE 3)
1. Plug the cord into a standard 120 volt AC outlet.
2. To turn the fan on, press the POWER button located
on the control panel or remote control. The fan will
start running in the lowest setting
"1" ( LOW ).
3. Press the SPEED button to cycle through the below 3
speed settings in sequence. The corresponding
indicator light will illuminate to confirm the selection:
1-Low
2-Medium
3-High
4. To turn the oscillation on and off, press the
OSCILLATION button located on the control panel or
remote control.
THIS APPLIANCE HAS A POLARIZED PLUG (one blade is wider than the
other). To reduce the risk of electric shock, this plug is intended to fit in
a polarized outlet only one way. If the plug does not fit fully in the
outlet, reverse the plug. If it still does not fit, contact a qualified
electrician to install the proper outlet.
DO NOT ATTEMPT TO MODIFY THIS PLUG OR DEFEAT THIS
SAFETY FEATURE IN ANY WAY.
FEATURES - OPERATIONS
5. To set your fan to automatically shut off, press the TIMER button located on the control panel or the remote
control. When set, the fan will run and automatically shut off after the set duration of time (1-7.5 hours) has
expired.
6. To turn the fan off press the POWER button located on the control panel or remote control.
NOTE: Your fan features a LED display panel. When a specific feature is activated on your fan, the LED panel will
illuminate with the corresponding text showing which features have been activated.
REMOTE CONTROL: (SEE FIGURE 4)
NOTE: PLEASE REMOVE THE PROTECTIVE STICKER FROM THE REMOTE CONTROL BATTERY BEFORE OPERATION.
This unit includes one lithium battery, CR2025/3V. Remove battery before discarding the remote.
Battery Replacement
The cells should be disposed of properly, including keeping them away from children. Even used cells may cause
injury.
a) Locate the battery compartment on the bottom back of the remote control handset. Push tab and pull battery
tray.
b) Remove old battery.
c) Place new battery into battery compartment.
d) Slide battery compartment into the remote control
handset.
NOTES:
• Remove the battery from the equipment when it is not being used for an extended period of time.
• Remove the used battery promptly.
• Do not discard used batteries into household trash containers. Contact your local government for disposal or
recycling practices in your area.
A. Power Button
B. Speed Button
C. Timer Button
D. Oscillation Button
E. Speed Setting Indicator Lights
F. Timer Indicator Lights
Figure 3
Figure 4
POWER
TIMER OSC
SPEED
A
C
B
D
POWER
LOW
MED
HIGH
4H
2H
1H
0.5H
TIMER
OSC
SPEED
A
E
C
D
B
F
POWER
TIMER OSC
SPEED
A
D
E
B
C
A. Control Panel
B Fan Housing
C. Base Halves
D. Remote Control
Storage
E. Remote Control
Figure 1
B
C
Power Cord
Figure 2
Power Cord
Thumb
Screws
PLEASE READ AND SAVE THESE
IMPORTANT SAFETY INSTRUCTIONS
FEATURES - OPERATIONS FEATURES - OPERATIONS
When using electrical appliances, basic safety precautions
should always be taken including the following:
1. Read all instructions before using this appliance.
2. Use fan only for purposes described in the instruction
manual. This fan is not for continuous operation or
equivalent.
3. To protect against electrical shock do not immerse
unit, plug or cord in water or spray with liquids and
plug the appliance directly into a 120V AC electrical
outlet.
4. Close supervision is necessary when any appliance is
used by or near children.
5. Unplug from outlet when not in use, when moving
fan from one location to another, before putting on
or taking off parts and before cleaning.
6. Avoid contact with moving parts.
7. Do not operate in the presence of explosive and/or
flammable fumes.
8. To avoid fire hazard, NEVER place the cord under
rugs or any parts near an open flame, cooking or
other heating appliance.
9. Do not operate any appliance with a damaged cord
or plug after the appliance malfunctions, or has been
dropped/damaged in any manner. Discard fan or
return to an authorized service facility for
examination and/or repair.
10. Do not run cord under carpeting. Do not cover cord
with throw rugs, runner, or similar coverings. Do not
route cord under furniture or appliances. Arrange
cord away from traffic area and where it will not be
tripped over.
11. The use of attachments not recommended or sold by
the appliance manufacturer may cause hazards.
12. Do not let the cord hang over the edge of a table,
counter or come in contact with hot surfaces or leave
exposed to high traffic areas.
13. Do not use outdoors.
14. To disconnect, grip plug and pull from wall outlet.
Never yank on cord.
15. Always use on a dry, level surface.
16. Do not operate fan until fully assembled with all
parts properly in place.
17. This product is intended for household use ONLY and
not for commercial or industrial applications.
18. WARNING: To reduce the risk of electrical shock
and injury to persons, do not use in window.
19. WARNING: To reduce the risk of fire or electric
shock, do not use this fan with any solid-state speed
control device.
20. This product employs overload protection (fuse). A
blown fuse indicates an overload or short-circuit
situation. If the fuse blows, unplug the product from
the outlet. Replace the fuse as per the user servicing
instructions (follow product marking for proper fuse
rating) and check the product. If the replacement fuse
blows, a short circuit may be present and the product
should be discarded or returned to an authorized
service facility for examination and/or repair.
!
WARNING: Chemical Burn Hazard. Keep batteries
away from children.
This product contains a lithium button/coin cell battery. If
a new or used lithium button/coin cell battery is
swallowed or enters the body, it can cause severe internal
burns and can lead to death in as little as 2 hours.
Always completely secure the battery compartment. If
the battery compartment does not close securely, stop
using the product, remove the batteries, and keep it
away from children. If you think batteries might have
been swallowed or placed inside any part of the body,
seek immediate medical attention.
PLEASE READ AND SAVE THESE
IMPORTANT SAFETY
INSTRUCTIONS
ASSEMBLY INSTRUCTIONS: (SEE FIGURE 1 & 2)
Estimated assembly time: 5-10 minutes
Tool-Free, 3 thumb screws included
NOTE: MAKE SURE YOU REMOVE ALL CONTENTS FROM
THE PACKAGE. PLEASE CHECK PACKAGING MATERIALS FOR
PARTS THAT COULD BE REQUIRED TO OPERATE YOUR FAN.
1. Assemble base halves around power cord. To secure
the base halves together, slide the posts of one base
half into the slots of the second base half. Refer to
Figure 2.
2. Line up the screws holes of the base halves with the
holes located on the bottom of the fan housing.
Secure with the three screws included with the
product. Refer to Figure 2.
3. Secure power cord as shown in Figure 2.
4. Turn fan right side up and place on a dry and level
surface.
OPERATING INSTRUCTIONS: (SEE FIGURE 3)
1. Plug the cord into a standard 120 volt AC outlet.
2. To turn the fan on, press the POWER button located
on the control panel or remote control. The fan will
start running in the lowest setting
"1" ( LOW ).
3. Press the SPEED button to cycle through the below 3
speed settings in sequence. The corresponding
indicator light will illuminate to confirm the selection:
1-Low
2-Medium
3-High
4. To turn the oscillation on and off, press the
OSCILLATION button located on the control panel or
remote control.
THIS APPLIANCE HAS A POLARIZED PLUG (one blade is wider than the
other). To reduce the risk of electric shock, this plug is intended to fit in
a polarized outlet only one way. If the plug does not fit fully in the
outlet, reverse the plug. If it still does not fit, contact a qualified
electrician to install the proper outlet.
DO NOT ATTEMPT TO MODIFY THIS PLUG OR DEFEAT THIS
SAFETY FEATURE IN ANY WAY.
FEATURES - OPERATIONS
5. To set your fan to automatically shut off, press the TIMER button located on the control panel or the remote
control. When set, the fan will run and automatically shut off after the set duration of time (1-7.5 hours) has
expired.
6. To turn the fan off press the POWER button located on the control panel or remote control.
NOTE: Your fan features a LED display panel. When a specific feature is activated on your fan, the LED panel will
illuminate with the corresponding text showing which features have been activated.
REMOTE CONTROL: (SEE FIGURE 4)
NOTE: PLEASE REMOVE THE PROTECTIVE STICKER FROM THE REMOTE CONTROL BATTERY BEFORE OPERATION.
This unit includes one lithium battery, CR2025/3V. Remove battery before discarding the remote.
Battery Replacement
The cells should be disposed of properly, including keeping them away from children. Even used cells may cause
injury.
a) Locate the battery compartment on the bottom back of the remote control handset. Push tab and pull battery
tray.
b) Remove old battery.
c) Place new battery into battery compartment.
d) Slide battery compartment into the remote control
handset.
NOTES:
• Remove the battery from the equipment when it is not being used for an extended period of time.
• Remove the used battery promptly.
• Do not discard used batteries into household trash containers. Contact your local government for disposal or
recycling practices in your area.
A. Power Button
B. Speed Button
C. Timer Button
D. Oscillation Button
E. Speed Setting Indicator Lights
F. Timer Indicator Lights
Figure 3
Figure 4
POWER
TIMER OSC
SPEED
A
C
B
D
POWER
LOW
MED
HIGH
4H
2H
1H
0.5H
TIMER
OSC
SPEED
A
E
C
D
B
F
POWER
TIMER OSC
SPEED
A
D
E
B
C
A. Control Panel
B Fan Housing
C. Base Halves
D. Remote Control
Storage
E. Remote Control
Figure 1
B
C
Power Cord
Figure 2
Power Cord
Thumb
Screws
FCC STATEMENT
Potential for Radio/Television interference
This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions:
(1) This device may not cause harmful interference, and
(2) this device must accept any interference received,
including interference that may cause undesired operation.
This product has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of
the FCC rules.
These limits are designed to provide reasonable protection against harmful interference in a residential installation.
The product generates, uses, and can radiate radio frequency energy and, if not installed and used in accordance
with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that
the interference will not occur in a particular installation. If the product does cause harmful interference to radio or
television reception, which can be determined by turning the product on or off, the user is encouraged to try to
correct the interference by one or more of the following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the product and the receiver.
• Connect the product into an outlet on a circuit different from that to which the receiver is connected.
• Consult the dealer or an experienced radio/TV technician for help.
• Changes or modifications not expressly approved by the party responsible for compliance could void the user’s
authority to operate the equipment.
WARRANTY INFORMATION
FCC STATEMENT
PLEASE READ AND SAVE THESE IMPORTANT INSTRUCTIONS
Instruction Manual
36'' DIGITAL
TOWER FAN
CLEANING/MAINTENANCE INSTRUCTIONS
Follow these instructions to correctly and safely care for
your fan. Please remember:
REPLACEABLE FUSE
If your (2.5 Amp, 125 Volt)
replaceable fuse blows, please
visit our website at
www.getholmesfans.com for
information on how to order
a new fuse. Follow the below
instructions to replace the
fuse on the plug.
User Servicing Instructions
1. Unplug your fan. Grasp plug and remove from the
receptacle or other outlet device. Do not unplug by
pulling on cord.
2. Open fuse cover, located on the top of the plug, by
using your thumb or a flathead screwdriver to slide
the cover down towards the prongs.
NOTE: Ensure that fuse cover is completely open
before attempting to remove fuse.
3. Remove fuse carefully by using a small screwdriver
to pry the fuse out of the compartment by the metal
ends of the fuse. (see Figure 5)
4. Place plug on a solid, flat surface. Insert new
2.5 Amp, 125 Volt fuse into fuse compartment and
use a small screwdriver to secure the metal ends of
the fuse into the compartment.
CAUTION: Risk of fire. Replace fuse only with
2.5 Amp, 125 Volt fuse.
5. Slide fuse cover closed completely. If fuse cover is
difficult to close, make sure fuse is secured in place
completely by pressing down on metal ends of the
fuse.
6. Risk of fire. Do not replace attachment plug. Contains
a safety device (fuse) that should not be removed.
Discard product if the attachment plug is damaged.
FAN CLEANING
• Always unplug the fan before cleaning.
• Do not allow water to drip on or enter into fan
housing.
• Be sure to use a soft cloth moistened with a mild
soap solution.
• Do not use gasoline, thinner or benzene as a
cleaner.
Clean the fan grill, housing and base with a soft, damp
cloth. Do not attempt to remove the fan blade. Please
use caution around the motor housing area. Do not allow
the motor or other electrical components to be exposed
to water.
FAN STORAGE
When storing your fan in the off season, it is important
to keep it in a safe dry location. It is important to protect
the fan head from dust.
CLEANING AND MAINTENANCE
Figure 5
Fuse
Metal ends
Fuse cover
If you have any questions regarding your product
or would like to learn more about other Holmes
®
products, please visit our website at
www.getholmesfans.com or call customer service:
1-866-769-3166 (8:30 am - 5:00 pm E.S.T.) or send
an email to [email protected]. For inquiries
regarding recycling and proper disposal of this
product, please contact your local waste management
facility.
Printed In China
© 2021 Sunbeam Products, Inc. All rights reserved. HOLMES
®
is a registered trademark of
Sunbeam Products, Inc. used under license.
Distributed by Star Elite Inc., Montreal, Canada H3B 3X9
SEH005-111721
3 YEAR LIMITED WARRANTY
This device has a limited warranty of 3 year from the original date of purchase against workmanship and defects
in material. If under normal use, your product fails to operate, please contact our customer service department at
[email protected]. A refund or replacement will be provided to you with proof of purchase. Star Elite Inc.
may deny claims of damage caused by misuse or modications of this product.
How to Obtain Warranty Service
If you have any problems, please do not contact the store.
Contact our customer service at 1-866-769-3166 (8:30 am - 5:00 pm EST) Monday - Friday
or contact us at info@getholmesfans.com.
Our customer service will be happy to assist you.
www.getholmesfans.com
Item: 17038
Model: 32510021
FCC STATEMENT
Potential for Radio/Television interference
This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions:
(1) This device may not cause harmful interference, and
(2) this device must accept any interference received,
including interference that may cause undesired operation.
This product has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of
the FCC rules.
These limits are designed to provide reasonable protection against harmful interference in a residential installation.
The product generates, uses, and can radiate radio frequency energy and, if not installed and used in accordance
with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that
the interference will not occur in a particular installation. If the product does cause harmful interference to radio or
television reception, which can be determined by turning the product on or off, the user is encouraged to try to
correct the interference by one or more of the following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the product and the receiver.
• Connect the product into an outlet on a circuit different from that to which the receiver is connected.
• Consult the dealer or an experienced radio/TV technician for help.
• Changes or modifications not expressly approved by the party responsible for compliance could void the user’s
authority to operate the equipment.
WARRANTY INFORMATION
FCC STATEMENT
PLEASE READ AND SAVE THESE IMPORTANT INSTRUCTIONS
Instruction Manual
36'' DIGITAL
TOWER FAN
CLEANING/MAINTENANCE INSTRUCTIONS
Follow these instructions to correctly and safely care for
your fan. Please remember:
REPLACEABLE FUSE
If your (2.5 Amp, 125 Volt)
replaceable fuse blows, please
visit our website at
www.getholmesfans.com for
information on how to order
a new fuse. Follow the below
instructions to replace the
fuse on the plug.
User Servicing Instructions
1. Unplug your fan. Grasp plug and remove from the
receptacle or other outlet device. Do not unplug by
pulling on cord.
2. Open fuse cover, located on the top of the plug, by
using your thumb or a flathead screwdriver to slide
the cover down towards the prongs.
NOTE: Ensure that fuse cover is completely open
before attempting to remove fuse.
3. Remove fuse carefully by using a small screwdriver
to pry the fuse out of the compartment by the metal
ends of the fuse. (see Figure 5)
4. Place plug on a solid, flat surface. Insert new
2.5 Amp, 125 Volt fuse into fuse compartment and
use a small screwdriver to secure the metal ends of
the fuse into the compartment.
CAUTION: Risk of fire. Replace fuse only with
2.5 Amp, 125 Volt fuse.
5. Slide fuse cover closed completely. If fuse cover is
difficult to close, make sure fuse is secured in place
completely by pressing down on metal ends of the
fuse.
6. Risk of fire. Do not replace attachment plug. Contains
a safety device (fuse) that should not be removed.
Discard product if the attachment plug is damaged.
FAN CLEANING
• Always unplug the fan before cleaning.
• Do not allow water to drip on or enter into fan
housing.
• Be sure to use a soft cloth moistened with a mild
soap solution.
• Do not use gasoline, thinner or benzene as a
cleaner.
Clean the fan grill, housing and base with a soft, damp
cloth. Do not attempt to remove the fan blade. Please
use caution around the motor housing area. Do not allow
the motor or other electrical components to be exposed
to water.
FAN STORAGE
When storing your fan in the off season, it is important
to keep it in a safe dry location. It is important to protect
the fan head from dust.
CLEANING AND MAINTENANCE
Figure 5
Fuse
Metal ends
Fuse cover
If you have any questions regarding your product
or would like to learn more about other Holmes
®
products, please visit our website at
www.getholmesfans.com or call customer service:
1-866-769-3166 (8:30 am - 5:00 pm E.S.T.) or send
an email to info@getholmesfans.com. For inquiries
regarding recycling and proper disposal of this
product, please contact your local waste management
facility.
Printed In China
© 2021 Sunbeam Products, Inc. All rights reserved. HOLMES
®
is a registered trademark of
Sunbeam Products, Inc. used under license.
Distributed by Star Elite Inc., Montreal, Canada H3B 3X9
SEH005-111721
3 YEAR LIMITED WARRANTY
This device has a limited warranty of 3 year from the original date of purchase against workmanship and defects
in material. If under normal use, your product fails to operate, please contact our customer service department at
[email protected]. A refund or replacement will be provided to you with proof of purchase. Star Elite Inc.
may deny claims of damage caused by misuse or modications of this product.
How to Obtain Warranty Service
If you have any problems, please do not contact the store.
Contact our customer service at 1-866-769-3166 (8:30 am - 5:00 pm EST) Monday - Friday
or contact us at info@getholmesfans.com.
Our customer service will be happy to assist you.
www.getholmesfans.com
Item: 17038
Model: 32510021
FCC STATEMENT
Potential for Radio/Television interference
This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions:
(1) This device may not cause harmful interference, and
(2) this device must accept any interference received,
including interference that may cause undesired operation.
This product has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of
the FCC rules.
These limits are designed to provide reasonable protection against harmful interference in a residential installation.
The product generates, uses, and can radiate radio frequency energy and, if not installed and used in accordance
with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that
the interference will not occur in a particular installation. If the product does cause harmful interference to radio or
television reception, which can be determined by turning the product on or off, the user is encouraged to try to
correct the interference by one or more of the following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the product and the receiver.
• Connect the product into an outlet on a circuit different from that to which the receiver is connected.
• Consult the dealer or an experienced radio/TV technician for help.
• Changes or modifications not expressly approved by the party responsible for compliance could void the user’s
authority to operate the equipment.
WARRANTY INFORMATION
FCC STATEMENT
PLEASE READ AND SAVE THESE IMPORTANT INSTRUCTIONS
Instruction Manual
36'' DIGITAL
TOWER FAN
CLEANING/MAINTENANCE INSTRUCTIONS
Follow these instructions to correctly and safely care for
your fan. Please remember:
REPLACEABLE FUSE
If your (2.5 Amp, 125 Volt)
replaceable fuse blows, please
visit our website at
www.getholmesfans.com for
information on how to order
a new fuse. Follow the below
instructions to replace the
fuse on the plug.
User Servicing Instructions
1. Unplug your fan. Grasp plug and remove from the
receptacle or other outlet device. Do not unplug by
pulling on cord.
2. Open fuse cover, located on the top of the plug, by
using your thumb or a flathead screwdriver to slide
the cover down towards the prongs.
NOTE: Ensure that fuse cover is completely open
before attempting to remove fuse.
3. Remove fuse carefully by using a small screwdriver
to pry the fuse out of the compartment by the metal
ends of the fuse. (see Figure 5)
4. Place plug on a solid, flat surface. Insert new
2.5 Amp, 125 Volt fuse into fuse compartment and
use a small screwdriver to secure the metal ends of
the fuse into the compartment.
CAUTION: Risk of fire. Replace fuse only with
2.5 Amp, 125 Volt fuse.
5. Slide fuse cover closed completely. If fuse cover is
difficult to close, make sure fuse is secured in place
completely by pressing down on metal ends of the
fuse.
6. Risk of fire. Do not replace attachment plug. Contains
a safety device (fuse) that should not be removed.
Discard product if the attachment plug is damaged.
FAN CLEANING
• Always unplug the fan before cleaning.
• Do not allow water to drip on or enter into fan
housing.
• Be sure to use a soft cloth moistened with a mild
soap solution.
• Do not use gasoline, thinner or benzene as a
cleaner.
Clean the fan grill, housing and base with a soft, damp
cloth. Do not attempt to remove the fan blade. Please
use caution around the motor housing area. Do not allow
the motor or other electrical components to be exposed
to water.
FAN STORAGE
When storing your fan in the off season, it is important
to keep it in a safe dry location. It is important to protect
the fan head from dust.
CLEANING AND MAINTENANCE
Figure 5
Fuse
Metal ends
Fuse cover
If you have any questions regarding your product
or would like to learn more about other Holmes
®
products, please visit our website at
www.getholmesfans.com or call customer service:
1-866-769-3166 (8:30 am - 5:00 pm E.S.T.) or send
an email to info@getholmesfans.com. For inquiries
regarding recycling and proper disposal of this
product, please contact your local waste management
facility.
Printed In China
© 2021 Sunbeam Products, Inc. All rights reserved. HOLMES
®
is a registered trademark of
Sunbeam Products, Inc. used under license.
Distributed by Star Elite Inc., Montreal, Canada H3B 3X9
SEH005-111721
3 YEAR LIMITED WARRANTY
This device has a limited warranty of 3 year from the original date of purchase against workmanship and defects
in material. If under normal use, your product fails to operate, please contact our customer service department at
[email protected]. A refund or replacement will be provided to you with proof of purchase. Star Elite Inc.
may deny claims of damage caused by misuse or modications of this product.
How to Obtain Warranty Service
If you have any problems, please do not contact the store.
Contact our customer service at 1-866-769-3166 (8:30 am - 5:00 pm EST) Monday - Friday
or contact us at [email protected].
Our customer service will be happy to assist you.
www.getholmesfans.com
Item: 17038
Model: 32510021
