1
2015-06-17 #:056-9083-5 (2021-07-09)
50 lb
(22.7 kg)
MAX
PA600CM
Ceiling Mount for NP-PA653U, NP-PA803U, NP-PA853W, NP-PA903X, NP-P506QL, NP-PA653UL, NP-PA703UL,
NP-P525WL,
Compatible
model/series*
ENG
AEC*,
EXT*
NP-PL, NP-PL, NP-PL, NP-P5L
NP-P525UL, NP-P605UL, NP-P547UL, and NP-P627UL Projectors
2
2015-06-17 #:056-9083-5 (2021-07-09)
ENG - This product is designed to be installed on wood joist/beam or solid concrete ceilings. Hardware is
included for wood joist/beam and solid concrete installation. Before installing make sure the supporting surface
will support the combined load of the equipment and hardware. Screws must be tightly secured. Do not
overtighten screws or damage can occur and product may fail. Never exceed the Maximum Load Capacity.
Always use an assistant or mechanical lifting equipment to safely lift and position equipment. This product is
intended for indoor use only. Use of this product outdoors could lead to product failure or personal injury. Be
WARNING
Symbols
ENG
WARNING
ENG
#
Skip to step.
ENG
x3
Screws must get at least three
ENG
ENG
F
Do not overtighten screws.
ENG
3
2015-06-17 #:056-9083-5 (2021-07-09)
5/32"
(4mm)
(8mm)
Tools Needed for Assembly.
ENG
1
2
ENG
To properly tighten screws: Tighten until screw
turn. Do not overtighten screws.
+1/2
4
3
3/8"
4
2015-06-17 #:056-9083-5 (2021-07-09)
Parts (Before beginning, make sure you have all parts shown below).
ENG
Parts List
Part #Description Qty
A projector mount assembly 055-KPRGU-W-5
B connection block 580-4065
C 4mm security allen wrench 560-9646
D concrete anchor 2 590-0320
E 2
F 2
G
H 2 540-2078
I 2mm security allen wrench
J 055-2999
K M4 x 25mm serrated socket pin screw 4
L spacer 4
M
A
(
1
)
projector mount assembly
D
(
2
)
8mm concrete anchor
E
(
2
)
H
(
2
)
washer
G
(
1
)
F
(
2
)
I (1)
2mm security
allen wrench
C (1)
4mm security
allen wrench
B
(
1
)
connection block
J
(
1
)
adaptor plate
M
(
1
)
adaptor plate
K
(
4
)
M4 x 25mm
L
(
4
)
spacer
5
2015-06-17 #:056-9083-5 (2021-07-09)
1
1a
Wood joist/beam
ENG
1c
Concrete Ceiling
ENG
1b-1
Extension Column (not included)
ENG
1a-1
1a-2
Mark mounting holes on stud center lines.
ENG
mark stud center lines.
ENG
A
ENG - When installing Peerless ceiling mounts on a wood joist/beam covered with gypsum board (drywall), verify
that the joists or beams are a minimum of 2" x 4" nominal size. Do not install over gypsum board thicker than 5/8".
WARNING
1a
6
2015-06-17 #:056-9083-5 (2021-07-09)
1a-3
5/32"
(4mm)
1a-4
Drill mounting holes into supporting surface
(2.5" (64mm) minimum depth required).
ENG
Install using wood screws provided.
ENG
Mounting hole must center
on stud.
ENG
2.5"
(64mm)
5/32"
(4mm)
Maximum 80 in-lb (9 N.M).
ENG
WOOD JOISTWOOD JOIST
A
H (2)
E (2)
OPEN END WRENCH
ALLOWS TIGHTENING
E).
OPEN END WRENCH
ALLOWS TIGHTENING
E).
H (2)
E (2)
A
2
7
2015-06-17 #:056-9083-5 (2021-07-09)
1b-1
1b-2
1b-3
2
Loosen.
ENG
Tighten.
ENG
A
C
C
Rotate mount at least three full turns onto EXT or AEC series extension column (sold separately).
ENG
8
2015-06-17 #:056-9083-5 (2021-07-09)
1c
ENG - When installing Peerless ceiling mounts on a concrete ceiling, the ceiling must be at least 8" thick with a
minimum compressive strength of 2000 psi. Never attach concrete expansion anchors to concrete covered with
WARNING
1c-1
Mark mounting holes.
ENG
1c-2
(8mm)
Drill mounting holes into supporting surface (2.5" (64mm)
minimum depth required).
ENG
2.5"
(64mm)
(8mm)
A
PROJECTOR MOUNT
ASSMEBLY INDICATES
9
2015-06-17 #:056-9083-5 (2021-07-09)
2b-41c-4
Install using concrete anchors and wood screws provided.
ENG
Maximum 80 in. ∙ lb (9 N.M.).
ENG
1c-3
D (2)
Insert anchor
ENG
D
A
H (2)
E (2)
10
2015-06-17 #:056-9083-5 (2021-07-09)
2
NP-PA653UL, NP-PA703UL,
NP-PA803UL, NP-PE455WL,
NP-PE455UL, NP-P525WL,
NP-P525UL, and NP-P605UL
only
NP-PA653U, NP-PA803U,
NP-PA853W, NP-PA903X,
and NP-P506QL only
2a-1 2b-1
11
2015-06-17 #:056-9083-5 (2021-07-09)
This page intentionally left blank.
ENG
12
2015-06-17 #:056-9083-5 (2021-07-09)
C
2a-1
F (2)
B
J
Note proper orientation of notch.
ENG
2a-2
K (4)
L (4)
C
x3
3-1
13
2015-06-17 #:056-9083-5 (2021-07-09)
2b-1
2b-2
F (2)
B
M
Note proper orientation of notch.
ENG
C
C
K (4)
L (4)
x3
NP-PA653UL, NP-PA703UL,
and NP-PA803UL only
NP-PE455WL,
NP-PE455UL, NP-P525WL,
NP-P525UL, and NP-P605UL only
K (4)
L (4)
14
2015-06-17 #:056-9083-5 (2021-07-09)
3-1
F
F
Optional security screw.
ENG
3-2
3-3
G
C
Tighten.
ENG
15
2015-06-17 #:056-9083-5 (2021-07-09)
4
Cable management: adjust pitch then route cables as shown.
ENG
Loosen.
ENG
+/- 5°
5-1
C
C
Loosen, adjust, tighten.
ENG
Retighten.
ENG
+15°
Loosen, adjust, tighten.
ENG
NP-PE455WL,
NP-PE455UL, NP-P525WL,
NP-P525UL, and NP-P605UL only
NP-PA653U, NP-PA803U,
NP-PA853W, NP-PA903X,
NP-P506QL, NP-PA653UL,
NP-PA703UL, and NP-PA803UL only
- 20°
16
2015-06-17 #:056-9083-5 (2021-07-09)
-15°
+20°
-20°
+15°
F
5-2
C
Loosen, adjust, tighten.
ENG
F
F
Loosen, adjust, tighten.
ENG
F
NP-PE455WL,
NP-PE455UL, NP-P525WL,
NP-P525UL, and NP-P605UL only
NP-PA653U, NP-PA803U,
NP-PA853W, NP-PA903X,
NP-P506QL, NP-PA653UL,
NP-PA703UL, and NP-PA803UL only
+/- 5°
+/- 5°
17
2015-06-17 #:056-9083-5 (2021-07-09)
+/- 360°
5-3
Loosen, adjust, tighten.
ENG
3/8"
C
ENG
18
2015-06-17 #:056-9083-5 (2021-07-09)
This page intentionally left blank.
ENG
19
2015-06-17 #:056-9083-5 (2021-07-09)
This page intentionally left blank.
ENG
