Please Read These Instructions Carefully Before Use!
Installation Manual
DELUXE POND KIT
WITH SOLAR LIGHT
KSPK-400G-SL
ASSEMBLING YOUR PUMP
1
2
4
7
5
6
3
Place desired fountain head (1) on riser (2)
pushing down until snug.
Adjust the size of the waterbell by turning
the round piece (3) on top.
Put riser (2) into diverter (4), pushing down
until the hole is no longer visible.
Some light force may be required.
Adjust the flow of water to your fountain
head by turning the diverter knob (5).
Attach all to the pump (6) by pushing
down the diverter into the hole located on
top of the pump (6).
FOR A HIGHER FOUNTAIN HEAD
Extend the tube extention (7) found
inside the riser (2).
FOR A WATERFALL
Place clamp over tubing.
Fit tubing over diverter.
Tighten clamp over tubing with a Flat
Head Screwdriver.
Note
Do NOT plug in your pump until it is fully immersed in water. Never run your pump dry!
12/2018-v3
H1S120
Warranty
This KOOLATRON product is warranted to the retail customer for 90 days from
date of retail purchase, against defects in material and workmanship.
WHAT IS COVERED
Replacement parts and labour.
Transportation charges to customer for the repaired product.
WHAT IS NOT COVERED
Damage caused by abuse, accident, misuse, or neglect.
Transportation of the unit or component from the customer to Koolatron.
MPLIED WARRANTIES
Any implied warranties, including the implied warranty of merchantability are also
mited to the duration of 90 days from the date of retail purchase.
WARRANTY AND SERVICE PROCEDURE
Keep the original, dated, sales receipt with this manual. If you have a problem
with your PRODUCT, or require replacement parts, please telephone the following
number for assistance:
North America 1-800-265-8456
Koolatron has Master Service Centres at these locations:
U.S.A.
4330 Commerce Dr.
Batavia, NY 14020-4102
Canada
139 Copernicus Blvd.
Brantford, ON N3P 1N4
A Koolatron Master Service Centre must perform all warranty work.
