G3 Scooter
USER MANUAL
ELECTRIC SCOOTER
This user manual will help you assemble and operate
your new electric scooter. Be sure to read ALL OF THE
INFORMATION in this manual before riding.
NOTE TO ALL RIDERS UNDER 18 YEARS OF AGE:
It’s very important that you get parental permission before
riding your electric scooter.
Congratulations
on your purchase!
ALWAYS wear a helmet when riding your electric scooter.
Make sure your scooter has a full battery before taking it out to ride.
Always be aware of local road laws, and follow them.
Do not ride the scooter under the inuence of drugs or alcohol.
Always respect pedestrians.
Do not ride under wet conditions. The scooter may slide from under your feet
causing injury. Wet conditions may damage the electronics and void the warranty.
Don’t Ride Until You Read This:
1. Avoid water - The scooter is not waterproof. The electronics may be damaged due
to water and water damage is not covered by our warranty. Riding in wet conditions
is also very dangerous and may result in injury.
2. Abuse - We do not cover physical damage due to negligent care and extreme
riding.
3. Whenever you ride the GOTRAX scooter, you risk severe injury or even death
from loss of control, collisions, and falls. Use caution and ride at your own risk.
4. Do not modify the product from the manufacturer’s original design.
5. Keep hands and all body parts away from moving parts while operating the
scooter.
6. Before riding - be sure to check the scooter over and make sure the scooter is
operating correctly before each use.
7. Before riding - be sure to check that the braking system is functioning properly;
also be sure to check that all safety labels are in place and you understand the safety
warnings.
8. Before riding - be sure that any and all axle guards, chain guards, or other covers
or guards supplied by the manufacturer are in place and in serviceable condition.
9. Before riding - be sure to check that the tires are in good condition, inated
properly, and have sufcient tread remaining.
10. Never exceed the 220 lb (100 kg) maximum load rating.
11. The electric scooter should never be used by children under the age of 16.
12. Maximum Speed - Your electric scooter goes the maximum speed of 18 mph.
Warning Message
Remove all packaging material, then inspect each item for any
accidental damage that may have occurred during shipping.
You should nd each of these items in your box:
1. Electric Scooter
2. 4 Screws
3. 3mm Allen Wrench
4. Approved Power Adapter / Charging Unit
5. Tire pump extender
Unpack
5
1
3
4
2
Get To Know Your Scooter
Accelerator (right thumb throttle)
Display
Switch Button
Folding Mechanism
Side Reector
Kick Stand
Tiller
Headlight
Handbrake (with bell)
Specications
Top Speed:
Distance per Charge:
Weight Range Up To:
Battery Type:
Battery Charger
Charge Time:
Power Requirements:
18 mph
18 miles
220lbs
36V 7.8Ah
DC 42V 2.0A
4-5 hours
AC 100-240V
~
50/60HZ 2.0A
The electric scooter comes partially assembled.
Assemble Your Scooter
Straighten the tiller and lift the tiller upright (as
shown in the gure).
Press the folding lever as the gure shows to lock
the tiller.
Insert the exposed cable into tiller and then
insert the console into the tiller. Use the tool and
screws to lock the console into place (as shown
in the gure).
1
3
2
Before using the scooter, you must fully charge the battery.
Charge Your Scooter
1. Open the rubber charging port cover.
2. Insert the charging plug into the port.
3. The charger box will have a green light when fully charged and a red light when
charging.
4. When you are done charging be sure to cover the charging port to keep it clear of
dust and debris.
5. Charging Time: 4.5 hours
Charging Requirement: Make sure to charge your scooter in conditions that do not
exceed 104 degrees Fahrenheit or below 32 degrees Fahrenheit.
Long press power button to power on and off.
Hold “+” button for 3 seconds to power the headlight and tail light power on and off.
To unlock the display lock the password is 000. Use the “ + “ button to input 0 and
press the power button to set. Repeat the process to enter in the full code 000. Once all three
zero’s have been selected, press the power button twice to deactivate the lock.
To set your own code, press the “ + “ button and the power button together for 10
seconds. Then use the “ + “ button to input the rst number of your code and press the power
button to set. Repeat the process to set your own individual three number code. Once your
three number code is selected, press the power button twice to deactivate the lock.
Press the throttle for 8 seconds to activate Cruise Control while moving. Press the
handbrake to cancel the cruise control feature.
Hold the “ - “ button while walking next to the scooter to activate push assist mode. Once
the push assist mode has been activated the scooter will move at 1.8 mph to make it easier to
walk next to the scooter.
The console on the scooter displays speed in MPH, Distance, Battery life, and the Headlights.
To lock the tiller lock, adjust the password wheel to show “0000”. Pull the lock pin and
insert it into the lock hole. Scramble the password wheel to lock.
To unlock the tiller lock, adjust the password wheel to show “0000”. Press the button and
pull out the lock pin from the lock hole and insert the lock pin cord back into the tiller.
To set your own code, Adjust the password wheel to show “0000” and then push the set
button to the “set” position. Adjust the password wheel to the four digit code of your choice
and then push the set button back to the left.
Scooter Console Functions
1. You will want to start riding your scooter with one foot on the platform and one foot
on the ground. Use your foot on the ground to push off and at the same time, press
the throttle button to begin movement.
2. Press the brake handbrake to slow down or stop.
3. The scooters perform best when on a smooth surface e.g. carparks, smooth roads,
footpaths, & bike lanes.
4. Always clean your scooter (wheels, platform, etc.), it’s a machine and it needs to be
maintained.
5. Do not press the throttle while walking with the scooter beside you.
6. Be aware of the terrain you are riding on, watch out for curbs and obstacles!
Riding Tips
Before folding the scooter, make sure that the scooter is powered off. .
Folding: Ensure the electric scooter is powered off, press the lock buckle as the gure
shows and pull down the lever. Fold the tiller down towards the rear fender and lock
the tiller hook to the fender hook buckle.
Unfolding: Unconnect the tiller hook from the fender hook. Once unhooked pull the
tiller upwards and lock the locking device on the bottom of the tiller by pulling the
clamp towards the tiller. Make sure to test the tiller before riding to make sure it is
locked into place.
Putting Your Scooter
Away/Folding
1 2
If you regularly clean and maintain your electric scooter, it will extend
its life.
Cleaning and storage: If the scooter is dirty, wipe it clean with a soft damp cloth.
Disc Brake Adjustments: If the brake is too tight, use a 4mm Allen wrench to
loosen the screws counterclockwise. Push the brake wire to shorten and lock the screw
in place. If the brake is too loose, loosen the screws and pull the brake wire to extend
the wire and lock the screws.
Tiller Adjustments: If the tiller wiggles while riding, please check the folding
mechanism. Use an Allen wrench to tighten the screws as the gure shows.
Tires: If you notice that the tire pressure is low, please ll to the recommended PSI on
the side of the tire. Recommended PSI: 50
DO NOT use alcohol, gasoline, kerosene, or other corrosive chemical solvents
to clean the scooter. It can severely damage the appearance and structure of the
scooter. Please do not use a pressure washer as it may also cause damage to the
electronics.
Storage: When you’re not using your scooter store in a dry and cool location. Avoid
storing your scooter outdoors because sun exposure can damage it’s appearance
and may cause wear on the life of the battery and tires.
Maintenance & Repair
Only use the approved GOTRAX power adapter to charge your scooter, others may
cause risk of re & equipment may be damaged.
Improper disposal of used batteries may seriously pollute the environment. Please
comply with local disposal regulations.
Make sure to store your scooter and power adapter in conditions that do not exceed
122 degrees Fahrenheit or below -4 degrees.
Warning - Risk of Fire - No User Serviceable Parts, The prolonged exposure to UV
Rays, Rain and the Elements may damage the enclosed materials, store indoors when
not in use.
Battery Information
We frequently update our user manuals at gotrax.com, and reserve the right to
update and change manuals online.
Please contact our customer service team if you are experiencing
problems or need more detailed information. They can be reached at
gotrax.com
Troubleshooting
For warranty information, please visit us at www.gotrax.com.
Warranty
WWW.GOTRAX.COM
#RideGOTRAX
GOLABS, INC
GOTRAX.com
2201 Luna Rd.
Carrollton, TX 75006
