New Comfort
Commercial Air Purifier
Model SS-700
Air Odor Purification Unit
User Guide
“Knock out
odors at their source”
Please read all of the information provided in this user’s guide before
operating your new air unit.
1
Congratulations on your purchase of your New Comfort SS-700
Commercial Ozone Generator and odor eliminator! The SS-
700 is made from durable Stainless Steel construction and
designed to last for many years. With a powerful 3000
mg/hour of output it is designed to remove even the worst of
odors. Features Include:
• Stainless Steel construction makes it designed to last many
years and resists any corrosion.
• Powerful Large Industrial 3 Ceramic Plate design produces
an amazing 3000 mg/hour of Ozone output, which can
eliminate most powerful odors. The user may reduce the
Ozone output for smaller spaces by removing a plate.
• 1 Hour Timer allows for treating a room and simply walking
away. After 1 hours the unit turns of automatically and the
area is treated. For more serious odors the unit has a
continuous “Hold” feature where the unit can be manually ran
until the user turns it off.
• Powerful UV which treats and cleans all the air as it passes
through the unit.
• 3 Year Factory Warranty
Examples of Odors it can help control can be: Smoke Damage,
Pet Odors, Pesticides, Cleaning Fume Odors, Cigarette Smoke,
Mold & Mildew, Virus's, Paint Odors, Cooking Odors, Water
Damage, Decaying material and much more.
Only operate in unoccupied room as high concentrations of
Ozone may cause lung irritation.
NEVER PLUG UNIT INTO A POWER STRIP. ALWAYS
PLUG UNIT DIRECTLY INTO A WALL OUTLET
2
CAUTION
RISK OF ELECTRICAL
SHOCK DO NOT OPEN
ATTENTION
This “lightning bolt” indicates un-insulated material
within your unit may cause an electrical shock. For the
safety of everyone, do not remove product covering.
This “exclamation point” calls attention to a feature for
which you should read the enclosed literature carefully to
prevent operating and maintenance problems.
3
FOR YOUR RECORDS
Please record the model and serial number below, for easy refer-
ence, in case of loss or theft. These numbers are located on the back
panel of your air purification unit. Space is also provided for other
relevant information.
Model Number__________________________________
Serial Number____________________________________
Date of Purchase__________________________________
Purchased From___________________________________
Read ALL instructions carefully before using this
product.
Operating the SS-700 Commercial Cleaner
(Front View)
Timer Control
Knob
Indicator Light
UV light
Turn clockwise to set the timer for timed
operation up to one hour. Turn
counter-clockwise to ‘Hold’ position for
continuous use.
Illuminates when unit is in operation.
UV light can kill bacteria, mold, germ, etc. 5
Watt 5000 hour rated bulb.
5
(Back View)
Plate Receiver
Slots
Fuse Holder
Power Cord
Insertion of ceramic plates.
Houses removable fuse. (Spare fuse
included, 1 amp, 1.25 inch)
110 Volt grounded cord (unless otherwise
specified). DO NOT bypass ground.
6
The New Comfort SS-700 Commercial Purifier is designed to
remove odors and sanitize the air in unoccupied spaces by using
Ozone and UV light. The unit has a timer that will enable it to run
unattended. The timer will run the unit for up to an hour and then
shut the Industrial Cleaner off. You should allow 45 minutes to 1
hour before returning to the treated area.
To operate the Industrial Cleaner:
Close off the desired area to be treated.
Remove all occupants and pets.
Position the unit as close as possible to the odor source.
In such environments as motels that have individual heating and
cooling systems, turn the fan on and set on re-circulate.
Set timer to desired time and leave the room.
Allow 45 minutes to 1 hour before re-entering the treated space.
Return to space & ventilation area.
Note: For more severe odor problems, turn dial to the left onto
indefinite “Hold”. This will allow for much longer sanitization. Upon
return be sure to turn off immediately and open outside windows and
doors and return when sanitization smell is gone.
Warning: Excessive ozone concentrations may cause mucous
membrane or respiratory irritation and can be harmful.
The amount of time necessary to eliminate pollutants depends on the
type of pollutant causing the odors. The effect of ozone may vary
according to atmospheric and/or environmental conditions such as
altitude, humidity, air movement, design/floor plan, and the severity
7
of the odor problem.
Altitude: The higher altitudes should require less ozone.
Humidity: High humidity should require more ozone.
In order to treat a specified area, the air in that area does not need to
pass through the unit as with air filtration devices. Instead, the unit
generates ozone internally which circulates throughout the room to
attack odor at their source.
It will control odors from sources such as:
Cigarette Smoke
Cooking Odors
Water Damage
Mold & Mildew
Decaying Matter
Cleaning Fumes
Smoke Damage
Pet Odors
New Construction
Paint Fumes
Carpet Odors
Pesticides
The Industrial Cleaner is ideal for such application as:
Automobiles
Airplanes
Carpet Cleaning
Boats
Office Buildings
Property Management
Basements
Food Markets
Motel/Hotel Resorts
Limousines
Food Service
Recreational Vehicles
Warning：Excess ozone concentrations can cause mucous membrane
and respiratory irritation, turn off the dial and ventilate the area after
sanitizing. To reduce the risk of electrical shock, do not remove
cover.
Warning：Eye damage may result from directly viewing the light
produced from the UV lamp used in this product. Always unplug unit
before servicing.
Read Carefully ： This commercial air cleaner is for use in
unoccupied space only. Close all doors and windows in the space to
be treated. Make certain all occupants and pets have been removed.
Turn dial clockwise to select time desired or turn counterclockwise
for indefinite time. Make sure Timer dial is OFF when return to
space. Open the windows and doors until sanitizing smell is gone.
Read Carefully：For best results carefully clean Ozone plates every
30 days.
8
When the purifier no longer produces enough ozone to be effective,
the ozone plates should be cleaned. A good rule of thumb is every 30
days. Some environments can cause ozone output to be reduced in
shorter time but other environments may take longer.
To clean the ozone plate: first turn the unit off and unplug from
outlet. Next remove the plates from back of unit. Pull plates firmly to
remove from slot. With plate firmly supported in the hand or on a flat
surface, wash with warm soapy water or a grease cutting detergent
and scrub with a brush. A spray liquid detergent with chlorine may
be used if necessary. Be careful not to drop the plate. Clean the metal
screen and the ceramic tile. Rinse plate in hot water and dry
completely before reinstalling. Reinstall plate, making sure it is flush
with the back of the unit.
WARNING – Failure to properly clean (every 6 months) inspect, maintain, and/or
replace defective ozone plates may result in a fire hazard.
The Commercial Purifier incorporates a timer for your convenience
and safety. The timer can be set for up to a total of 60 minutes. When
you turn the dial to the right or clock-wise you are activating the
timer.
9
If you suspect a problem with your unit check the following:
1)
Unit is plugged in properly and turned on. This includes
making sure the cord if firmly shoved in all the way where it
connects to the unit.
• Wall outlet is active.
• Ceramic plates are clean and dry.
• Plate alignment is correct, making sure plates are flush with
back of unit.
• Fuse is installed properly and in good condition (to replace
fuse, rotate fuse holder counterclockwise to unscrew, remove
old fuse, replace with spare). Fuse is 1 amp (1.25 inch).
NOTE - It’s important that the Lightning Air be properly grounded to
avoid potential shock.
If the fan is still not operating or no buzzing sound is detected when
operating, please contact your authorized New Comfort Service
Center.
If UV light does not work, please contact your New Comfort
Authorized dealer for service repairs or to purchase replacement
bulb. Do not disassemble unit.
Caution: No attempt should be made to remove the top panel of
the unit, as there are no user serviceable parts. Opening the unit
without consent may void the warranty.
The commercial air purifier comes with a 3 Year Limited Warranty
for Residential use and a 1 Year Limited Warranty for Commercial
Use. For warranty or service on this unit please contact the
retailer you bought the unit from.
