1 in. Bristle Brush
Dual voltage for
worldwide usage
Cool Tip
1½ in. Curling
Brush Attachment
e Br
ush
tage
for
e us
age
Cool
Tip
1½ i
n. Curli
ng
Brus
h At
tach
ment
1 in
. Br
Professional
Power Cord
3-Position
Switch
High/Low/Off
VOLUME
SERIES
BY
Hot Air 1½ in. Curling Brush
& 1 in. Bristle Brush
Model CD160PPCS
IMPORTANT SAFETY
INSTRUCTIONS
When using electrical appliances, especially
when children are present, basic safety
precautions should always be followed,
including the following:
READ ALL INSTRUCTIONS
BEFORE USING
KEEP AWAY FROM WATER
DANGER –
Any appliance is electrically
live even when the switch is off.
To reduce the risk of death or injury by
electric shock:
1. Always unplug appliance immediately
after using.
2. Do not use while bathing or in a shower.
3. Do not place or store appliance where it can
fall or be pulled into a tub or sink.
4. Do not place in, or drop into, water or other
liquids.
5. If an appliance falls into water, unplug it
immediately. Do not reach into the water.
WARNING –
To reduce the risk of
burns, electrocution, fi re, or injury to persons:
1. This appliance should never be left
unattended when plugged in. Do not pull,
twist, or wrap line cord around appliance.
2. This appliance should not be used by, on, or near
children or individuals with certain disabilities.
3. Use this appliance only for its intended use
as described in this manual. Do not use
attachments not recommended by the
manufacturer.
4. Never operate this appliance if it has a
damaged cord or plug, if it is not working
properly, if it has been dropped or damaged
or dropped into water. Return the appliance
to an authorized service center for examina-
tion and repair.
5. Keep the cord away from heated surfaces.
6. Never block the air openings of the appliance or
place it on a soft surface, such as a bed or couch,
where the air openings may be blocked. Keep the
air openings free of lint, hair, and the like.
7. Never use while sleeping.
8. Never drop or insert any object into any
opening or hose.
9. Do not use outdoors or operate where
aerosol (spray) products are being used or
where oxygen is being administered.
10. Do not use an extension cord with
this appliance.
11. Do not direct hot air toward eyes or other
heat-sensitive areas.
12. Attachments may be hot during use. Allow
them to cool before handling.
13. Do not place appliance on any surface while
it is operating.
14. While using the appliance, keep your hair
away from the air inlets.
15. Do not operate with a voltage converter.
16. Be sure dual voltage selector is in the
correct voltage position before operating.
Before plugging in, read the information about
dual voltage contained in this booklet.
17. This appliance was set at the factory to
operate at 125 volts. Refer to information in this
booklet for conversion to 240/250 volt operation.
SAVE THESE
INSTRUCTIONS
OPERATING
INSTRUCTIONS
This appliance is intended for household use.
Use on Alternating Current (60 hertz) only. This
appliance is designed to operate at 110 to 125
volts AC or 220 to 250 volts AC.
FOR DUAL VOLTAGE HOT BRUSH
For use in the U.S.A., the voltage selector
switch should be placed in the 125 position. For
use in several countries overseas, the voltage
selector may need to be placed in the 250
position. Confi rm the voltage available at each
overseas location before using the appliance.
For connection to a 240 volt supply, use an
attachment plug adapter of the proper
confi guration for the power receptacle.
For 110–125 Volt Operation
Flick the dual voltage switch to the 125
position. In this position, the appliance operates
in all available heat and speed settings.
For 220–250 Volt Operation
First put the HI–LO switch on OFF. Flick the
dual voltage switch to the 250 position. At
220–250V while set at LO, the appliance
operates only at LO heat and speed settings. Do
not attempt to operate the HI-LO switch or
change to 125 when operating on 220–250.
The switches must be set and remain in the LO
and 250 positions. A plug adapter may be
necessary in certain countries.
ADDITIONAL INFORMATION
This appliance has a polarized plug (one blade
is wider than the other). As a safety feature, this
plug will fi t into a polarized outlet only one way.
If the plug does not fi t fully into the outlet,
reverse the plug. If it still does not fi t, contact a
qualifi ed electrician. Do not attempt to defeat
this safety feature.
CHECK ALCI SAFETY FEATURE EVERY TIME
YOU USE APPLIANCE.
This appliance is equipped with an Appliance
Leakage Circuit Interrupter (ALCI), a safety
feature that renders it inoperable under some
abnormal conditions, such as immersion in water.
To make sure the ALCI is functioning properly,
perform the following test. The purpose of this
test is to allow you to make sure the water
sensing system (ALCI) is working.
1. Plug in the appliance and press test button on
plug (see appropriate diagram at right).
2. The appliance will stop working. There will be
an audible click and reset button will pop out.
3. To reset ALCI with a reset button, unit should
be unplugged. Then push in reset button and
reinsert plug into outlet.
Reset
Test
Reset
Test
4. If ALCI is not functioning properly, return
appliance to nearest service center.
5. It is important that if immersion occurs, this
unit be brought to a service center. Do not try to
reset.
6. Be sure to repeat test every time you use the
unit, to confi rm ALCI is operational.
Should the appliance go off and the reset button
pop up during use, this could indicate a
malfunction in the unit. Remove plug from outlet
and allow the hot air brush to cool. Reinsert
plug into outlet.
HOW TO STYLE WITH YOUR
HOT AIR BRUSH
To create, lift, or set
medium, soft curls use the
1-inch brush on partially dry
hair. Beginning at the crown
area, take a small section of
hair and place the 1-inch
brush near the root area.
Slide the hot air brush
toward the ends, then wind hair back toward the
root area. Hold for approximately 10 seconds,
then gently unwind hair from the brush without
using tension. Continue throughout your hair until
you get the style you want.
To create volume, wave or
body, use the 1½-inch brush
on partially dry hair. The Hot
Air Brush can create lift and
large, soft curls.
Beginning at the crown
area, take a section of hair
and place the 1½-inch hot
air brush near the root area. Slide the hot air
brush toward the ends, then wind toward the
root area. Hold for approximately 10 seconds,
then gently unwind the hair without tension.
Continue throughout the hair until all the hair
has been curled.
USER
MAINTENANCE
Your appliance is virtually maintenance free. For
proper performance, the appliance must be
kept clean. Blocked or clogged air intake vents
will cause the appliance to overheat. When
cleaning is needed, unplug the cord and clean
dust and lint from air intake openings with a
small brush. The outer surface of the appliance
should be wiped clean with a cloth only. If
abnormal conditions occur, unplug the
appliance, allow it to cool and return it for repair
to an authorized service representative only. No
repairs should be attempted by the consumer.
DUAL VOLTAGE
Be sure dual voltage selector is in the correct
voltage position before operating. This
appliance was set at the factory to operate at
125 volts. Before plugging in, read the
information about dual voltage contained in the
Operating Instructions section of this booklet.
GET TO KNOW YOUR STYLER
This message about…
G
ROUND
F
AULT
C
IRCUIT
I
NTERRUPTERS
…can save a life!
IF YOU MUST USE YOUR HAIR DRYER IN THE
BATHROOM, INSTALL A GFCI* NOW!
Your local electrician can help you decide which
type is best for you – a portable unit that plugs
into the electrical outlet or a permanent unit
installed by your electrician. The National
Electrical Code now requires GFCIs in the
bathrooms, garages, and outdoor outlets of all
new homes.
WHY DO YOU NEED A GFCI? Electricity and
water don’t mix. If your hair dryer falls in water
while it’s plugged in, the electric shock can kill
you...even if the switch is
off. A regular fuse or circuit
breaker won’t protect you
under these circumstances.
A GFCI offers you far
greater protection.
A GFCI can save your life! Compared to that,
the price is small! Don’t wait...install one now!
*A GFCI is a sensitive device that reacts
immediately to a small electric current leak by
stopping the electricity fl ow.
CAUTION
–
NEVER allow the power
supply cord to be pulled or twisted. Never wrap
the cord around the appliance. Damage will
occur at the high fl ex point of entry into the
appliance, causing it to rupture and short circuit.
Inspect the cord frequently for damage. STOP
USE IMMEDIATELY if damage is visible or if unit
stops or operates intermittently.
STORAGE
When not in use, your appliance should be dis-
connected, allowed to cool and stored in a safe,
dry location out of reach of children. Do not wrap
the line cord around the appliance. Allow the cord
to hang or lie loose and straight at the point of
entry into the appliance.
WARNING:
IF YOU THINK
THE POWER IS OFF
WHEN THE SWITCH
IS OFF,
YOU’RE WRONG.
KEEP AWAY FROM WATER
Everyone knows that electricity and water are
a dangerous combination. But did you know
that an electric appliance is still electrically
live even if the switch is off?
If the plug is in, the power is on. So when
you are not using your appliances, keep them
unplugged.
ALWAYS UNPLUG
SMALL APPLIANCES
LIMITED ONE YEAR WARRANTY
Conair will repair or replace (at our option) your
unit free of charge for 12 months from the date
of purchase if the appliance is defective in
workmanship or materials.
To obtain service under this warranty, return the
defective product to the service center listed on
back, together with your purchase receipt and
$7.50 for postage and handling. California
residents need only provide proof of purchase and
should call 1-800-3-CONAIR for shipping
instructions. In the absence of a purchase receipt,
the warranty period shall be 12 months from the
date of manufacture.
ANY IMPLIED WARRANTIES, INCLUDING BUT
NOT LIMITED TO THE IMPLIED WARRANTY OF
MERCHANTABILITY AND FITNESS FOR A
PARTICULAR PURPOSE, SHALL BE LIMITED IN
DURATION TO THE 12-MONTH DURATION OF
THIS WRITTEN, LIMITED WARRANTY.
Some states do not allow limitations on how long
an implied warranty lasts, so the above
limitations may not apply to you.
IN NO EVENT SHALL CONAIR BE LIABLE FOR
ANY SPECIAL, INCIDENTAL, OR CONSEQUEN-
TIAL DAMAGES FOR THE BREACH OF THIS OR
ANY OTHER WARRANTY, EXPRESS OR
IMPLIED, WHATSOEVER.
This warranty gives you specifi c legal rights, and
you may also have other rights, which vary from
state to state.
Please register this product at:
www.conair.com/registration
For info on any Conair product,
call: 1-800-3-CONAIR or visit us
on the web at: www.conair.com
SERVICE CENTER
Conair Corporation
Service Department
7475 N. Glen Harbor Blvd
Glendale, AZ 85307
©2013 Conair Corporation
13PA138643
IB-11979
Loading ...
Loading ...
Loading ...
