User Manual Foseal PUMP-1 Portable Air Compressor Pump, 12V DC Digital Tire Inflator 150 PSI Auto Shut-off Easy to Use Tire Pump

Documents for Foseal PUMP-1

The following documents are available:
User Manual Photos
PUMP-1 photo
Contact support: [email protected]
Any question, please email us. We will send our response
within 24 business hours
1.Possible cause - Fuse blown in the 12 Volt adapter.
Solution - Replace the fuse in the adapter
2.Possible cause - The pressure setting may be
lower than the current pressure
Solution - Adjust pressure setting pointer to a higher
setting
Air Compressor does not start
/9.18 FT
1.DO NOT use the air compressor device continuously
for more than 10 minutes. Allow the unite to cool before
using it again.
2.DO NOT use with 110V - If you want to use the air
compressor at home, please buy an AC to DC
power adapter 110V to 12V.
3.Keep the air compressor out of reach of children
and store in a dry place
4.This item inflates a midsize car tire in 3-5 minutes
5.Display Units: PSI, KPA, BAR,KG/CM.
6.DO NOT leave the air compressor unattended.
Start your
vehicle engine
Insert 12V DC plug
into cigarette lighter
socket
Press R to switch the
unit of pressure
and + or - to set the
preferered value
Plug inflatable nozzle on
tire air valve, press the lock
bar down once you hear
leakage sound
Press ON/OFF button
to start the air compressor
after the digits flashes
3 times
The air compressor
will automatically shut
off at the pre-set pressure
Start your
vehicle engine
Insert 12V DC plug
into cigarette lighter
socket
Plug inflatable
nozzle on tire air
valve, press the
lock bar down once
you hear leakage
sound
It will indicate the
current pressure on
the digital display
Loading ...
Summary of Contents for Foseal PUMP-1:
